KitchenAid KSB5000 Manual de usuario
KSB5000 KSB5010 KSB5011
KSB5015 KSB5060
W10810093A_EN_v06.indd 1 7/27/15 2:14 PM
BLENDER INSTRUCTIONS
W10810093A_EN_v06.indd 2 7/27/15 2:14 PM
3
English
BLENDER INSTRUCTIONS
BLENDER SAFETY
Important safeguards.......................................................................................... 4
Electrical requirements ...................................................................................... 6
Motor horsepower............................................................................................. 6
PARTS AND FEATURES
Parts and accessories.......................................................................................... 7
ASSEMBLING THE BLENDER
Preparing the Blender for use ............................................................................ 8
OPERATING THE BLENDER
Using the Blender............................................................................................... 8
Blender function guide...................................................................................... 11
TIPS FOR GREAT RESULTS
Quick tips ......................................................................................................... 12
CARE AND CLEANING
Cleaning the Blender ........................................................................................ 13
TROUBLESHOOTING
Understanding the Blender ash codes............................................................ 14
Blender does not operate when a setting is selected....................................... 15
Blender stops while blending ........................................................................... 15
TABLE OF CONTENTS
W10810093A_EN_v06.indd 3 7/27/15 2:14 PM
4
BLENDER SAFETYBLENDER SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety
precautions should always be followed, including
the following:
1. Read all instructions. Misuse of appliance may
result in personal injury.
2. To protect against risk of electrical shock, do not
put Blender in water or other liquid.
3. This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
4. Unplug from outlet when not in use, before putting
on or taking off parts, and before cleaning.
5. Avoid contact with moving parts.
W10810093A_EN_v06.indd 4 7/27/15 2:14 PM
5
English
BLENDER SAFETYBLENDER SAFETY
6. Do not operate the Blender with a damaged cord or
plug or after appliance malfunctions, or is dropped
or damaged in any manner. Return appliance to the
nearest Authorised Service Center for examination,
repair or electrical or mechanical adjustment.
7. Do not use outdoors.
8. Do not let cord hang over edge of table or counter.
9. Keep hands and utensils out of container while
blending to reduce the risk of severe injury to persons
or damage to the Blender. A scraper may be used but
must be used only when the Blender is not running.
10. Blades are sharp. Care should be taken when
handling the sharp cutting blades, emptying the
pitcher and during cleaning.The use of attachments,
including canning jars, not recommended by
KitchenAid may cause a risk of injury to persons.
11. The use of attachments not recommended by
KitchenAid may cause a risk of injury to persons.
12. Flashing light indicates ready to operate — avoid
any contact with blades or moveable parts.
13. Be careful if hot liquid is poured into the blender as
it can be ejected out of the appliance due to sudden
steaming.
14. This appliance is intended to be used in household
and similar applications such as:
- staff kitchen areas in shops, offices or other
working environments;
- farm houses.
- by clients in hotels, motels and other residential
type environments.
- bed and breakfast type environments.
SAVE THESE INSTRUCTIONS
W10810093A_EN_v06.indd 5 7/27/15 2:14 PM
6
PARTS AND FEATURESBLENDER SAFETY
Motor horsepower for the Blender motor was measured using a dynamometer, a machine
that laboratories routinely use to measure the mechanical power of motors. Our 1,8 peak
horsepower (HP) motor reference reects the horsepower output of the motor itself and
not the Blender’s horsepower output in the Blender pitcher. As with any blender, the power
output in the pitcher is not the same as the horsepower of the motor itself. This motor
delivers 1,4 peak HP in the pitcher enabling your Blender to deliver robust power for all
your recipes.
NOTE: As with many products containing magnets, it is recommended that those with
implantable pacemakers/debrillators should use care with the Blender and keep their
device 30 cm away from the Blender.
Motor horsepower
Electrical requirements
Voltage: 120 Volts A.C. only
Wattage: 1300 watts
Frequency: 60 Hz
NOTE: If the plug does not fit in the outlet,
contact a qualified electrician. Do not modify
the plug in any way. Do not use an adapter.
Do not use an extension cord. If the power
supply cord is too short, have a qualified
electrician or serviceman install an outlet
near the appliance.
W10810093A_EN_v06.indd 6 7/27/15 2:14 PM
7
English
PARTS AND FEATURESBLENDER SAFETY
Parts and accessories
BPA Free
pitcher with lid
Function
selection dial*
Die-cast
metal base
Pitcher release
lever
Stainless
steel blades
Removable
ingredient cap
with measuring markings
Removable funnel
* See the “Blender function guide” section.
Magnetic drive
(not shown)
W10810093A_EN_v06.indd 7 7/27/15 2:14 PM
8
ASSEMBLING THE BLENDER
Before rst use
Before using your Blender for the first
time, wipe Blender base with a warm
damp cloth, then wipe clean with a damp
cloth. Dry with a soft cloth. Wash pitcher,
lid, and ingredient cup in warm, sudsy
water (see “Care and cleaning” section).
Rinse parts and wipe dry.
Before using the Blender, plug into
a grounded outlet.
OPERATING THE BLENDER
Using the Blender
Before use
Before operating the Blender, make sure
the pitcher is properly locked into the
Blender base.
The Blender will not run if the pitcher and
lid are not fully in place. If you pull the
Blender out of the base before the Blender
stops running, the blade brake will kick in to
stop the blades, and the Blender will stop
after a few seconds.
The Blender has four pre-set recipe programs:
Icy Drinks/Frozen Smoothies, Milkshakes,
Soups/Sauces, and Juice/Green Smoothies.
It also features Variable Speed and Pulse
selections that allow you to customize your
blending for any recipe you make. See
“Blender function guide” for more detailed
information.
Preparing the Blender for use
OPERATING THE BLENDER
W10810093A_EN_v06.indd 8 7/27/15 2:14 PM
9
English
ASSEMBLING THE BLENDER
OPERATING THE BLENDER
OPERATING THE BLENDER
2Put ingredients in the pitcher. Add
liquids first, then soft foods, then ice or
frozen fruit last. Do not fill the pitcher
beyond the max fill line (1.75L [60 oz.])
- especially when using primarily liquids.
Put the lid on the pitcher spout first,
then push down on the side of the lid
near the handle, ensuring that the lid is
on straight. The Blender will not work
without the lid in place.
3Align the top of the pitcher to slide
under the top of the base, and slide
pitcher forward into the housing. Ensure
that the pitcher goes in straight and is
secured in place.
1Remove the pitcher from the Blender
base in order to fill it with ingredients.
Pull the pitcher release lever to help
remove the pitcher. Grab the handle
firmly, and pull the pitcher straight
towards you to remove.
4Ensure that the pitcher is fully in place
by making sure that the tab on the
pitcher release handle sits between the
two triangular notches on the base of
the pitcher. You will hear a click when
the pitcher is fully in place.
NOTE: There should be 1,27 cm of
platform evenly visible around the pitcher
when it’s fully locked in place.
W10810093A_EN_v06.indd 9 7/27/15 2:14 PM
10
OPERATING THE BLENDER
6Press the START/PAUSE button.
5Turn the selection knob to your desired
pre-set program or variable speed
selection (see the “Blender function
guide” for more information).
7You may use the removable ingredient
cap and removable funnel to add
more ingredients to the pitcher while
blending, if needed. The cap includes
convenient measuring indicators
for precise measurement of added
ingredients.
10 Pull the release lever to help remove
the pitcher after you have finished
blending. Grab the handle firmly, and
pull the pitcher straight towards you
to remove.
8To use the Pulse feature, turn the dial
to PULSE, then PRESS AND HOLD
the START/PAUSE button for the
desired length of time.
9The Blender will automatically stop
when programs are complete. The
Blender will chime to signal the cycle is
complete, or Press the START/PAUSE
button to stop the Blender manually.
OPERATING THE BLENDER
W10810093A_EN_v06.indd 10 7/27/15 2:14 PM
