KitchenAid 9KSBC2F1 Manual de usuario

9KSBC2F1

Cord cleat

(not shown)

PARTS AND FEATURES

PARTS AND ACCESSORIES

Ingredient

cap with

measuring

cup

Flex Edge

tamper

Lid

Talon™

blade

Base

On/off

switch

(not shown)

Start/Stop toggle switch

Pulse toggle switch

Control

dial

Open handle

for easy

stackability

Removable blender

jar pad

Blender jar

Status indicator light

Power cord

socket and

removable

power cord

(not shown)

Motor horsepower for the blender motor was measured using a dynamometer, a machine

that laboratories routinely use to measure the mechanical power of motors. Our 3.5 peak

horsepower (HP) motor reference reﬂects the horsepower output of the motor itself and

not the Blender’s horsepower output in the blender jar. As with any blender, the power

output in the blender jar is not the same as the horsepower of the motor itself. This

motor delivers 2.45 peak HP in the blender jar, enabling your Blender to deliver robust

power for all your recipes.

ENGLISH

COMMERCIAL BLENDER SAFETY | 3

COMMERCIAL BLENDER SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety

precautions should always be followed, including the

following:

1. Read all instructions. Misuse of appliance may

result in personal injury.

2. To protect against risk of electrical shock, do not

put Blender in water or other liquid.

3. This appliance can be used by children aged

from 8 years and above and persons with reduced

physical, sensory, or mental capabilities or lack of

experience and knowledge if they have been given

supervision or instruction concerning use of the

appliance in a safe way and understand hazards

involved. Cleaning and user maintenance shall not

be made by children without supervision.

4. This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning use of the appliance by

a person responsible for their safety.

4 | COMMERCIAL BLENDER SAFETY

COMMERCIAL BLENDER SAFETY

5. Children should be supervised to ensure that they do

not play with the appliance.

6. This appliance shall not be used by children under

8 years. Keep the appliance and its cord out of reach

of children.

7. Never leave the Blender unattended while it is in

operation.

8. Avoid contacting moving parts. Keep hands, hair,

clothing, as well as spatulas and other utensils away

from blade during operation to reduce the risk of injury

to persons and/or damage to the Blender.

9. Unplug from outlet when not in use, before putting

on or taking off parts, and before cleaning.

10. Do not operate any appliance with a damaged cord

or plug or after the appliance malfunctions or has

been damaged in any manner. Return appliance to

the nearest Authorised Service Centre for examination,

repair or adjustment. If the supply cord is damaged,

it must be replaced by a special cord or assembly

available from the manufacturer, its service agent, or

similarly qualied persons in order to avoid a hazard.

11. Do not let cord hang over edge of table or counter.

12. The blades are sharp. Care should be taken when

handling the sharp cutting blades, emptying the jar,

and during cleaning.

13. Keep hands and utensils out of jar while blending to

reduce the risk of severe injury to persons or damage

to the Blender. A scraper may be used, but must be

used only when the Blender is not running.

14. Do not use the Blender outdoors.

15. Be careful if hot liquid is poured into the Blender as

it can be ejected out of the appliance due to sudden

steaming.

16. Always operate Blender with lid in place.

17. The use of attachments not recommended or sold by

KitchenAid may cause re, electric shock, or injury.

ENGLISH

COMMERCIAL BLENDER SAFETY | 5

COMMERCIAL BLENDER SAFETY

SAVE THESE INSTRUCTIONS

ELECTRICAL REQUIREMENTS

Electrical Shock Hazard

Plug into an earthed outlet.

Do not remove earth prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these

instructions can result in

death, fire, or electrical shock.

Voltage: 100 V

Frequency: 50-60 Hz

Power (Wattage): 1236 Watts

NOTE: If the plug does not fit in the

outlet, contact a qualified electrician. Do

not modify the plug in any way. Do not

use an adapter.

Do not use an extension cord. If the power

supply cord is too short, have a qualiﬁed

electrician or service technician install an

outlet near the appliance.

18. When blending hot liquids or ingredients, ingredient-

measuring cap should remain in place over the lid

opening. Always start on lowest speed and slowly

ramp to desired speed when blending hot liquids or

ingredients.

19. This appliance is intended to be used in commercial

and similar applications such as:

- staff kitchen areas in shops, ofces or other

working environments;

- farmhouses;

- by clients in hotels, motels and other residential

type environments;

- bed and breakfast type environments.

6 | USING THE COMMERCIAL BLENDER

USING THE COMMERCIAL BLENDER

The Blender has a preset recipe program: Coulis Cycle. It also features Variable Speeds

and Pulse functions that allow you to customize your blending for any recipe you make.

To clean the Blender: Quick pulses of power and high speeds work to clean the blender

jar with just 2 cups of water and a drop of dish soap.

BLENDER FUNCTION GUIDE

SETTING DESCRIPTION BLENDING TIME

(IN MIN:SEC)

Blends ﬂuid gels into a smooth mixture. A series of pulses

and speeds run before the unit gradually ramps up to full

power before it ﬁnishes with a slow speed to allow air to

escape from the ﬂuid. For best results, cut or crumble gel

into 1/2'' cubes before blending. Limit gel to 500-1000

grams. Do not exceed 1000 grams in the jar. You may need

to use the tamper for thicker ﬂuid gels.

< 3 minutes

VARIABLE

SPEEDS

When the Start/Stop switch is pressed, the Blender will

run continuously until the Start/Stop switch is pressed

again, or after 6 minutes have elapse.

N/A

:30 When the :30 time is selected, the Blender will gradually

ramp up to full power and run for 30 seconds total. :30

:45 When the :45 time is selected, the Blender will gradually

ramp up to full power and run for 45 seconds total. :45

:60 When the :60 time is selected, the Blender will gradually

ramp up to full power and run for 60 seconds total. :60

Alternatively, use Pulse during manual operation to

manually operate the Blender at either High or Low

speeds.

N/A

ENGLISH

USING THE COMMERCIAL BLENDER | 7

USING THE COMMERCIAL BLENDER

Before ﬁrst use

Before using your Blender for the ﬁrst

time, wipe the blender base with a warm

damp cloth, then wipe clean with a damp

cloth. Dry with a soft cloth. Wash the

blender jar, lid, and ingredient cup in warm,

sudsy water (see the “Care and cleaning”

section). Rinse parts and wipe dry.

Before using the Blender, be sure the

countertop beneath the Blender and

surrounding areas are dry and clean.

Be sure the power switch on the back

of the blender base is in the Off (O)

position and the cord is also fully

plugged into the back of the Blender.

Then, plug the Blender into

an earthed.

The main power switch is on the

back of the blender base. Flip the

POWER switch to the On (I) position.

The status indicator light above the

Start toggle button will begin to

flash, indicating that the Blender is in

Standby mode. The Blender is now

ready to operate.

Electrical Shock Hazard

Plug into an earthed outlet.

Do not remove earth prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these

instructions can result in

death, fire, or electrical shock.

PREPARING THE COMMERCIAL BLENDER FOR USE

NOTE: The cord cleat is not to be used

as a handle; the cord cleat is designed to

wrap the power cord around it for

storage only.

8 | USING THE COMMERCIAL BLENDER

USING THE COMMERCIAL BLENDER

Turn the control dial to your desired

speed, time, or program. See the

“Blender function guide” for more

information.

Flip the Start/Stop toggle switch up

or down to begin operation of the

Blender. The status indicator light will

now be solid.

ASSEMBLING AND RUNNING THE COMMERCIAL BLENDER

NOTE: To avoid spills, do not fill blender

jar past the top-most measurement mark,

especially when blending liquids.

Put the items to blend into the

blender jar. Add liquids first, then

soft foods, then leafy greens, and

ice or frozen items last.

Make sure that the lid is fully secured

on the blender jar; next, place the

blender jar on the base, making sure

that it is fully aligned on the jar pad.

NOTE: If you select a preprogrammed

cycle, you will need to ﬂip the Start/Stop

toggle to begin operation.

ENGLISH

USING THE COMMERCIAL BLENDER | 9

Use the Flex Edge tamper accessory

as needed for optimal blending

performance. Remove the ingredient-

measuring cap only, and leave the

lid in place. Stir or press contents

down towards the blade. When you

are finished, replace the ingredient-

measuring cap in the blender jar lid

before resuming blending.

If desired, use the Pulse function for

a momentary boost of speed while

blending on the variable speed

settings.

Press and hold the Pulse toggle

switch up for a faster pulse, or down

for a slower pulse.

After blending, flip the Start/Stop

toggle switch up or down. Allow the

Blender to come to a complete stop

before removing the lid and pouring

your blended ingredients.

If the Blender remains in standby

mode for 28 minutes with no

activity, the Blender will enter sleep

mode. To get out of sleep mode,

press the Start/Stop switch once

to bring into standby mode. Then,

press Start/Stop once more to start

the Blender.

USING THE COMMERCIAL BLENDER

NOTE: The Pulse function may also

be used on its own as a separate

blending function while the Blender

is in standby mode.

10 | CARE AND CLEANING

To clean the blender base and cord:

Unplug the Blender before cleaning.

Wipe the base and the cord with a

warm, damp cloth; wipe clean with a

damp cloth, and dry with a soft cloth.

Make sure to clean the blender jar,

lid, and ingredient cap after each

use. Remove any remaining contents

from the blender jar using a spatula

and pre-rinse it with hot water. Fill jar

with 700 mL of hot water and add 3-4

drops of liquid dish detergent. Place

the lid on the blender jar, and make

sure the blender jar is fully in place on

the blender base.

CARE AND CLEANING

CLEANING THE BLENDER AND ACCESSORIES

Clean the Blender thoroughly after every use.

NOTE: To avoid damaging the Blender, do not immerse the blender base

or cord in water. To avoid scratching the Blender, do not use abrasive cleansers

or scouring pads.

Rotate the control dial to 30 seconds.

Flip the Start/Stop toggle switch up

or down. When the timer finishes,

pour out the soapy water, and rinse

the blender jar with warm water.

The blender jar, lid, Flex Edge tamper,

and ingredient-measuring cap are

dishwasher-safe; the Flex Edge

tamper, lid, and ingredient-measuring

cap should be placed in the top rack

of the dishwasher. If preferred, all

parts may also be washed by hand

with a damp cloth and warm soapy

water, and then rinsed with warm

water and dried with a soft cloth.

Otros manuales para 9KSBC2F1

Tabla de contenidos

Otros manuales de Licuadora de KitchenAid

KitchenAid

KitchenAid KCB148SGR - Pro Line Commercial Bar Blender Manual de usuario

KitchenAid

KitchenAid 5KSB5080 Manual de usuario

KitchenAid

KitchenAid 5KHB2571 Manual de usuario

KitchenAid

KitchenAid KSB560 Manual de usuario

KitchenAid

KitchenAid KSB1575 Manual de usuario

KitchenAid

KitchenAid KSB580CR0 Manual de usuario

KitchenAid

KitchenAid KSB6060 Manual de usuario

KitchenAid

KitchenAid 5KSB1325 Manual de usuario

KitchenAid

KitchenAid 5KSB45BWH1 Guía rápida

KitchenAid

KitchenAid 5KSB560 Guía rápida

KitchenAid

KitchenAid 5KHBV53 Manual de usuario

KitchenAid

KitchenAid KSBC1B0CU Manual de usuario

KitchenAid

KitchenAid 5KSB6061 Manual de usuario

KitchenAid

KitchenAid 4KPCB348PPM1 Manual de usuario

KitchenAid

KitchenAid STAND MIXER Guía rápida

KitchenAid

KitchenAid KHB1235 Series Manual de usuario

KitchenAid

KitchenAid KSB1570 Manual de usuario

KitchenAid

KitchenAid 9KSBC2F1 Manual de usuario

KitchenAid

KitchenAid KSB6060FG Manual de usuario

KitchenAid

KitchenAid Artisan Power Plus 5KSB8270 Manual de usuario

KitchenAid

KitchenAid KHBC210 Manual de usuario

KitchenAid

KitchenAid 5KHB1231G Instrucciones de instalación

KitchenAid

KitchenAid KSBC1B0 Manual de usuario

KitchenAid

KitchenAid KSB540WH0 Manual de usuario

Manuales populares de Licuadora de otras marcas

ROTOR

ROTOR 1125.201 Manual de usuario

Braun

Braun Multiquick 5 Vario series Manual de usuario

ARENDO

ARENDO MIRA 305424 Manual de usuario

CHEF-BUILT

CHEF-BUILT CCB-3500 Manual de usuario

Viconte

Viconte VC-4406 Manual de usuario

Oster

Oster BLSTAB-CB0 Manual de usuario

HOFFEN

HOFFEN MC-3005 Manual de usuario

Black & Decker

Black & Decker BLC18750DM Manual de usuario

Sunbeam

Sunbeam 4182 Manual de usuario

Bialetti

Bialetti FMX35 Manual de usuario

Black & Decker

Black & Decker BL8000 Manual de usuario

Duronic

Duronic BL530 Manual de usuario

Exquisit

Exquisit MS 3002 wes Manual de usuario

Lumme

Lumme LU-KP1891A Manual de usuario

Binatone

Binatone HB-735 Manual de usuario

Moulinex

Moulinex LM936E10 Manual de usuario

Oster

Oster VERSA Manual de instalación y operación

Ninja

Ninja NN210Q Manual de usuario
