Kichler Lighting Renew Select Manual de usuario

Product images may vary slightly from actual product.

52" RENEW SELECT

INSTRUCTION MANUAL

UL Model #330161

READ AND SAVE THESE INSTRUCTIONS REV 02-APR-2021

Net Weight: 8.30 kgs (18.30 lbs)

Gross weight: 9.70 kgs (21.38 lbs)

52" Renew Select | 3

SAFETY RULES

CARE AND USE INSTRUCTIONS

TOOLS AND MATERIALS REQUIRED

PACKAGE CONTENTS

MOUNTING OPTIONS

HANGING THE FAN

INSTALLATION OF SAFETY SUPPORT

ELECTRICAL CONNECTIONS

FINISHING THE MOTOR INSTALLATION

ATTACHING THE FAN BLADES

INSTALLING THE LIGHT KIT

ATTACHING THE GLASS SHADE

OPERATING INSTRUCTIONS

TROUBLESHOOTING

CEILING AND WALL FAN WARRANTY

FCC INFORMATION

TABLE OF CONTENTS

Read all instructions BEFORE assembly and USE of product

KEEP INSTRUCTIONS FOR FUTURE USE

| KICHLER.COM

SAFETY RULES

1. CAUTION -RISK OF SHOCK-

Disconnect Power at the main circuit breaker panel

or main fusebox before starting and during the

installation.

2. WARNING: This fixture is intended for installation in

accordance with the National Electrical Code (NEC)

and all local code specifications. If you are not familiar

with code requirements, installation by a certified

electrician is recommended.

3. WARNING: To reduce the risk of fire or electric shock,

do not use this fan with any solid-state speed control

device.

4. WARNING: To reduce the risk of fire, electric shock,

or personal Injury mount to an outlet box marked

“Acceptable For Fan Support of up to 22.7 kg (50

lbs)”. For outlet box mounting, use mounting screws

provided with the outlet box.

5. WARNING: To reduce the risk of fire, electric shock

or personal injury, mount fan to outlet box marked

“acceptable for fan support”.

6. The outlet box and support structure must be securely

mounted and capable of reliably supporting a minimum

of 50 pounds. Use only cULus Listed outlet boxes

marked “FOR FAN SUPPORT”.

7. The fan must be mounted with a minimum of 2.1 m

(7 feet) clearance from the trailing edge of the blades

to the floor.

8. WARNING: Do not operate reversing switch while fan

blades are in motion. Fan must be turned o and blades

stopped before reversing blade direction.

9. Avoid placing objects in the path of the blades.

10. To avoid personal injury or damage to the fan and other

items, be cautious when working around or cleaning

the fan.

11. WARNING: Make sure the power is disconnected

before cleaning the fan.

12. Do not use water or detergents when cleaning the fan

or fan blades. A dry dust cloth or lightly dampened

cloth will be suitable for most cleaning.

13. After marking electrical connections, spliced

conductors should be turned upward and pushed

carefully up into outlet box. The wires should be

spread apart with the grounded conductor and the

equipment-grounding conductor on one side of the

outlet box and the ungrounded conductor on the other

side of the outlet box.

14. Electrical diagrams are reference only. Light Kits that

are not packed with the fan must be cULus Listed

and marked suitable for use with the model fan you

are installing. Switches must be cULus General Use

Switches. Refer to the Instructions packaged with the

light kits and switches for proper assembly.

15. WARNING: To reduce the risk of personal injury, do not

bend the blade brackets (also reered to as flanges)

during assembly or after installation. Do not insert

objects in the path of blades.

16. All set screws must be checked, and retightened where

necessary, before installation.

52" Renew Select | 5

CARE AND USE INSTRUCTIONS

1. Read and understand these Care and Use Instructions

and all installation instructions provided with this

fixture, both front and back, before proceeding with

assembly, installation, care and use of this fixture.

2. If you have doubts about how to install a lighting

fixture or if the fixture fails to operate correctly, please

contact a local qualified licensed electrical contractor.

3. All parts must be used as indicated in the assembly/

installation instructions. Do not substitute the

parts provided with any other parts (use authorized

replacement parts only) or use any parts which are

worn out or broken. If replacement parts are needed,

write to

Authorized Replacement Parts Distribution Department,

P.O. Box 318010, Cleveland, Ohio 44131-8010.

Failure to obey this instruction could invalidate the ETL/

UL or CSA certification for this fixture.

4. Be sure to use light bulbs with wattage no greater than

specified on this fixture. Be certain the electric current

is turned o before changing light bulbs.

5. If a green insulated wire or bare copper or silver wire is

included with this fixture be certain never to attach this

wire to the “hot” current carrying supply wire.

6. Be sure the fixture is supported by a chain only (if

fixture hangs by chain) and not by wire.

7. The hand-crafted beauty of this fixture is the

result of tasteful design, experienced engineering,

careful craftsmanship and a dedication to customer

satisfaction. You will be assured years of service and

enjoyment if you read and observe the following list of

product care suggestions:

• Be certain electric current is turned o before

cleaning.

• Clean metal components with a soft cloth,

moistened with a mild liquid soap solution. Wipe

clean and bu with a soft dry cloth. Under no

circumstances should any metal polish be used,

as its abrasive nature could damage the protective

finish placed on the metal parts.

• Wood components may be polished with a fine

furniture polish, taking care to avoid getting the

polish on the metal surfaces.

• Never wash glass shades in an automatic

dishwasher. To wash glass shades, line a sink with a

towel and fill with warm water and a mild liquid soap.

Wash glass with a soft cloth, rinse and wipe dry.

| KICHLER.COM

TOOLS REQUIRED

PACKAGE CONTENTS

• Philips screw driver

• Blade screw driver

• 11mm wrench

• Step ladder

• Wire cutters

Unpack your fan and check the contents. You should have the following items:

A. Fan blades (5)

B. Ceiling mounting bracket

C. Canopy decoration ring

D. Canopy

E. Canopy cover

F. Ball/downrod assembly

G. Coupler cover

H. Fan motor assembly

I. Light kit

J. Blade brackets with pre-installed

mounting screws (5)

K. Glass shade

L. Package hardware:

1) Safety cable hardware:

screw (1)

2) Gasket

3) Pull chains and fobs (1)

4) Balancing Kit

5) Blade attachment hardware:

screws (15), washers (15)

6) Plastic wire connectors (3)

52" Renew Select | 7

Outlet box

Provide strong

support

Recessed

outlet box Ceiling

mounting plate

Outlet box

ANGLED CEILING

MAXIMUM 22°

ANGLE

MOUNTING OPTIONS

If there is not an existing UL (cUL for Canadian Installation) listed

mounting box, then read the following instructions. Disconnect the

power by removing fuses or turning o circuit breakers.

Secure the outlet box directly to the building structure. Use

appropriate fasteners and building materials. The outlet box and its

support must be able to fully support the full weight of the fan (up

to 50 lbs). Do not use plastic outlet boxes.

Figures 1, 2, and 3 are examples of dierent ways to mount the

outlet box.

NOTE: If you are installing the ceiling fan on a sloped (vaulted)

ceiling, you may need a longer downrod to maintain proper

clearance between the tip of the blade and the ceiling. A minimum

clearance of 12” is suggested for optimal operation.

NOTE: Depending on the location you have selected for

installation, you may need to purchase and install a “Joist Hanger”

for the support of the outlet box. Make sure the joist hanger you

purchase has been designed for use with ceiling fans. (Fig. 4)

Fig. 2

Fig. 1

Fig. 3

Fig. 4

| KICHLER.COM

HANGING THE FAN

REMEMBER to turn o the power before you begin.

To properly install your ceiling fan, follow the steps below.

NOTE: This ceiling fan is supplied with two types of hanging

assemblies; the standard ceiling installation using the downrod with

ball and socket mounting and the “close-to-ceiling” installation. The

“close-to-ceiling” installation is recommended in rooms with less

than 8-feet ceilings or in areas where additional space is desired from

the floor to the fan blades.

cULus Listed

outlet box

Ceiling

mounting

bracket

Mounting screws

(supplied with electrical box

)

Washer

120V wires

Fig. 5

52" Renew Select | 9

HANGING THE MOTOR ASSEMBLY

Standard Ceiling Installation

Step 1. Pass the 120-volt supply wires through the center hole in the

ceiling hanger bracket as shown in Fig. 5.

Step 2. Secure the hanger bracket to the ceiling outlet box with the

screws and washers provided with your outlet box.

Step 3. Remove the hitch pin, lock pin and set screws from the top of the

motor assembly.

Step 4. Route wires exiting from the top of the fan motor through the

coupler cover, canopy cover, canopy, decoration ring and then through

the ball/downrod. (Fig. 6)

Step 5. Align the holes at the bottom of the downrod with the holes

in the collar on top of the motor housing (Fig. 6). Carefully insert the

hitch pin through the holes in the collar and downrod. Be careful not

to jam the pin against the wiring inside the downrod. Insert the locking

pin through the hole near the end of the hitch pin until it snaps into its

locked position.

Step 6. Tighten two set screws on top of the fan motor firmly. (Fig. 6)

Step 7. Place downrod ball into the hanger bracket socket. (Fig 7)

Fig. 6

Registration slotCheck tab

Locking pin

Set screws

Hitch pin

Ceiling canopy

Decoration ring

Coupler cover

Downrod

Cross pinHanger ball

Fig. 7

| KICHLER.COM

Fig. 7

HANGING THE MOTOR ASSEMBLY

Close-to-Ceiling Installation

Step 1. Pass the 120-volt supply wires through the center hole in the

ceiling hanger bracket as shown in Fig. 5.

Step 2. Secure the hanger bracket to the ceiling outlet box with the

screws and washers provided with your outlet box.

Step 3. Remove three of the six screws and lock washers (every

other one) from the collar of top motor (Fig. 8)

Step 4. Place the ceiling canopy with decoration ring and the

gasket over the collar at the top of the motor. Align the mounting

holes with the holes in the motor and fasten using the screws and

lock washers provided. (Fig. 8)

Step 5. Tighten the mounting screws securely.

WARNING: Failure to completely tighten the three screws in step 5

could result in fan loosening and possibly falling.

Step 6. Hang the fan on the hook of the hanger bracket. Be certain

that the canopy is fully locked into hook as shown in Fig. 9. This will

allow you to make the electrical connections.

Ceiling mountin

bracket

Canopy

Hook

Fig. 8

Fig. 9

Screws and Lock

washers(3 of 6 places)

Canopy

Gasket

Collar

Decoration ring

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Admirador de Kichler Lighting

Kichler Lighting

Kichler Lighting Verdi Manual de usuario

Kichler Lighting

Kichler Lighting FRYST Manual de usuario

Kichler Lighting

Kichler Lighting Vinea 52 Manual de usuario

Kichler Lighting

Kichler Lighting Select Sutter Place Manual de usuario

Kichler Lighting

Kichler Lighting 35153 Manual

Kichler Lighting

Kichler Lighting Lehr Decor 80" Manual de usuario

Kichler Lighting

Kichler Lighting KLF-SOLA-34-WHT-BN Manual de usuario

Kichler Lighting

Kichler Lighting Decor Kimberley Manual de usuario

Kichler Lighting

Kichler Lighting Bentzen Manual de usuario

Kichler Lighting

Kichler Lighting Kevlar 310150WCP Manual de usuario

Kichler Lighting

Kichler Lighting Vassar 330002OZ Manual de usuario

Kichler Lighting

Kichler Lighting Olympia Manual de usuario

Kichler Lighting

Kichler Lighting 35152 Manual de usuario

Kichler Lighting

Kichler Lighting XETY LED Manual de usuario

Kichler Lighting

Kichler Lighting Select Canfield 300107 Manual de usuario

Kichler Lighting

Kichler Lighting 52" Chiara LED Manual de usuario

Kichler Lighting

Kichler Lighting 52" RENEW ENERGY STAR Manual de usuario

Kichler Lighting

Kichler Lighting 42 STRATMOOR Manual de usuario

Kichler Lighting

Kichler Lighting 35155 Manual de usuario

Kichler Lighting

Kichler Lighting 52" RENEW DESIGNER Manual de usuario

Kichler Lighting

Kichler Lighting Sterling Manor Patio Manual de usuario

Kichler Lighting

Kichler Lighting Jade 300030 Manual de usuario

Kichler Lighting

Kichler Lighting Lucian II 330241 Manual de usuario

Kichler Lighting

Kichler Lighting Arkwright Manual de usuario

Manuales populares de Admirador de otras marcas

ELTA FANS

ELTA FANS H03VV-F Manual de usuario

Hunter

Hunter 20714 Manual de instrucciones

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manual de usuario

Hunter

Hunter Caraway Manual de instrucciones

Panasonic

Panasonic FV-15NLFS1 Manual de usuario

Kompernass

Kompernass KH 1150 Manual de usuario

VES

VES FALA100/12V/TR Manual de usuario

Vertiv

Vertiv Liebert DCD Manual de usuario

Westinghouse

Westinghouse GFP Series Manual de usuario

Venmar

Venmar KUBIX HRV PLUS Series Manual de usuario

Maico

Maico ECR 31 Manual de usuario

Sonnenkonig

Sonnenkonig Dinky Manual de usuario

S&P

S&P ECOWATT HXBR Manual de usuario

Wider

Wider IMP03369BH Manual de usuario

Panasonic

Panasonic F-60DHN Manual de usuario

Hinkley

Hinkley HIGHLAND Manual de usuario

Broan

Broan 766BN Manual de usuario

Premium

Premium PFS16022 Instrucciones de montaje
