Keysight Technologies UXA N9040B Manual de usuario

Keysight X-Series

Signal Analyzer

This manual provides documentation for the following X-Series

Analyzers running the Microsoft Windows 10 operating system:

UXA Signal Analyzer N9040B

PXA Signal Analyzer N9030B

MXA Signal Analyzer N9020B

EXA Signal Analyzer N9010B

CXA Signal Analyzer N9000B

Getting Started and

Troubleshooting

Guide

Notices

2018

No part of this manual may be

reproduced in any form or by any

means (including electronic storage

and retrieval or translation into a

foreign language) without prior

agreement and written consent from

Keysight Technologies, Inc. as

governed by United States and

international copyright laws.

Trademark Acknowledgements

Manual Part Number

N9040-90049

Publication Date

March 2018

Edition 1

Published in USA

Keysight Technologies Inc.

1400 Fountaingrove Parkway

Santa Rosa, CA 95403

Warranty

THE MATERIAL CONTAINED IN THIS

DOCUMENT IS PROVIDED “AS IS,”

AND IS SUBJECT TO BEING

CHANGED, WITHOUT NOTICE, IN

FUTURE EDITIONS. FURTHER, TO

THE MAXIMUM EXTENT PERMITTED

BY APPLICABLE LAW, KEYSIGHT

DISCLAIMS ALL WARRANTIES,

EITHER EXPRESS OR IMPLIED WITH

REGARD TO THIS MANUAL AND

ANY INFORMATION CONTAINED

HEREIN, INCLUDING BUT NOT

LIMITED TO THE IMPLIED

WARRANTIES OF

MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE.

KEYSIGHT SHALL NOT BE LIABLE

FOR ERRORS OR FOR INCIDENTAL

OR CONSEQUENTIAL DAMAGES IN

CONNECTION WITH THE

FURNISHING, USE, OR

PERFORMANCE OF THIS

DOCUMENT OR ANY INFORMATION

CONTAINED HEREIN. SHOULD

KEYSIGHT AND THE USER HAVE A

SEPARATE WRITTEN AGREEMENT

WITH WARRANTY TERMS

COVERING THE MATERIAL IN THIS

DOCUMENT THAT CONFLICT WITH

THESE TERMS, THE WARRANTY

TERMS IN THE SEPARATE

AGREEMENT WILL CONTROL.

Technology Licenses

The hardware and/or software

described in this document are

furnished under a license and may be

used or copied only in accordance

with the terms of such license.

U.S. Government Rights

The Software is “commercial

computer software,” as defined

by Federal Acquisition Regulation

(“FAR”) 2.101. Pursuant to FAR

12.212 and 27.405-3 and

Department of Defense FAR

Supplement (“DFARS”) 227.7202,

the U.S. government acquires

commercial computer software

under the same terms by which

the software is customarily

provided to the public.

Accordingly, Keysight provides

the Software to U.S. government

customers under its standard

commercial license, which is

embodied in its End User License

Agreement (EULA), a copy of

which can be found at

http://www.keysight.com/find/sweula

The license set forth in the EULA

represents the exclusive authority

by which the U.S. government

may use, modify, distribute, or

disclose the Software. The EULA

and the license set forth therein,

does not require or permit,

among other things, that

Keysight: (1) Furnish technical

information related to

commercial computer software

or commercial computer

software documentation that is

not customarily provided to the

public; or (2) Relinquish to, or

otherwise provide, the

government rights in excess of

these rights customarily provided

to the public to use, modify,

reproduce, release, perform,

display, or disclose commercial

computer software or

commercial computer software

documentation. No additional

government requirements

beyond those set forth in the

EULA shall apply, except to the

extent that those terms, rights, or

licenses are explicitly required

from all providers of commercial

computer software pursuant to

the FAR and the DFARS and are

set forth specifically in writing

elsewhere in the EULA. Keysight

shall be under no obligation to

update, revise or otherwise

modify the Software. With

respect to any technical data as

defined by FAR 2.101, pursuant

to FAR 12.211 and 27.404.2 and

DFARS 227.7102, the U.S.

government acquires no greater

than Limited Rights as defined in

FAR 27.401 or DFAR 227.7103-5

(c), as applicable in any technical

data.

Safety Notices

A CAUTION notice denotes a hazard. It

calls attention to an operating

procedure, practice, or the like that,

if not correctly performed or adhered

to, could result in damage to the

product or loss of important data. Do

not proceed beyond a CAUTION

notice until the indicated conditions

are fully understood and met.

A WARNING notice denotes a hazard.

It calls attention to an operating

procedure, practice, or the like that,

if not correctly performed or adhered

to, could result in personal injury or

death. Do not proceed beyond a

WARNING notice until the indicated

conditions are fully understood and

met.

In This Guide…

This guide contains the following information:

1 Quick-Start

This chapter explains how to initialize the signal analyzer and view a signal.

2 Front and Rear Panel Features

Refer to this chapter for information on front- and rear-panel key functionality, and display annotations.

3 Instrument Operating System

This chapter describes the Microsoft Windows 10 configuration and the settings used with the Keysight

instrument software.

4 Using Windows Tools

The information in this chapter provides some guidelines for using the Microsoft Windows 10 feature capabilities

with the signal analyzer.

5 Troubleshooting

This chapter details some basic steps that may solve any problems you are experiencing with either the signal

analyzer or Microsoft Windows 10.

Where to Find the Latest Information

Documentation is updated periodically. For the latest information about these products, including

instrument software upgrades, application information, and product information, browse to one of the

following URLs, according to the name of your product:

http://www.keysight.com/find/N9040B

http://www.keysight.com/find/N9030B

http://www.keysight.com/find/N9020B

http://www.keysight.com/find/N9010B

http://www.keysight.com/find/N9000B

To receive the latest updates by email, subscribe to Keysight Email Updates at the following URL:

http://www.keysight.com/find/MyKeysight

Information on preventing analyzer damage can be found at:

http://www.keysight.com/find/PreventingInstrumentRepair

Is your product software up-to-date?

Periodically, Keysight releases software updates to fix known defects and incorporate product

enhancements. To search for software updates for your product, go to the Keysight Technical Support

website at:

http://www.keysight.com/find/sa_software

Contents

1 Quick Start

Initial Inspection 10

Verify the Contents 10

Shipping Problems? 10

Instrument Location and Rack Mounting Requirements 11

Locating the analyzer 11

Cooling and rack mounting 11

Turning on the Analyzer the First Time 12

Initializing the analyzer 12

Anti-Virus Software and Firewalls 16

Instrument Information 17

Power requirements 17

Protecting Against Overpowering 18

Instrument Maintenance 18

Protecting against electrostatic discharge 20

2 Front and Rear Panel Features

Front-Panel Features 22

Display Features 25

Invalid Data Indicator 25

Screen Tabs 26

Meas Bar 27

Measurement Display 28

Menu Panel 29

Bottom Bar 31

Rear-Panel Features 32

Front and Rear Panel Symbols 36

3 Instrument Operating System

Contents

Microsoft Windows 38

Installed Software 38

Signal analyzer software 38

Vector signal analyzer software 38

Customer installation of software 39

3rd Party Software verified by Keysight 39

Installation of other 3rd Party Software 39

User Accounts 40

Administrator account 40

Instrument accounts 40

KeysightOnly user account 40

Service user accounts 40

Customer creation of accounts 40

Keysight X-Series Analyzer Licensing Options 42

Fixed Licenses 42

Transportable Licenses 42

Network Licenses 43

USB Portable Licenses 43

Configuring Network and USB Licenses 44

Licensing New Measurement Application Software -

After Initial Purchase 45

Installation procedure over USB for Fixed licenses 45

Windows Configuration 47

Settings that can be changed 47

Settings that must not be changed 48

Autoplay/Autorun 49

Configuring Printers 50

Configuring LAN 51

Hostname 51

IP Address & Gateway 51

Connecting to a Network Shared Folder 51

Windows Security 53

Contents

Windows Firewall 53

Automatic Updates 53

Virus Protection 54

Spyware Protection 54

System Maintenance 55

Backup 55

System Restore 55

Disk Defragmenting 55

USB Connections 56

Disk Drive Partitioning and Use 57

Backing-up the factory calibration data 57

Disk Drive Recovery Process 59

Updating the software (required after a recovery) 61

4 Using Windows Tools

Navigating Windows Without a Mouse 64

Remote Desktop: Using the X-Series Signal Analyzers Remotely 65

Overview of Remote Desktop operation 65

Setting up Remote Desktop operation 66

How to locate the computer name of the instrument 67

Running a Remote Desktop session 68

Embedded Web Server: Using the X-Series Signal Analyzers Remotely 73

Browsers that support the X-Series Signal Analyzer Embedded Web Server

(these versions or later) 73

Accessing the instrument through the Internet 73

Controlling the Instrument 75

Enabling SCPI Control of the instrument 76

Selecting the Get Image tab 76

Selecting the Transfer Data tab 77

Selecting the Save/Recall tab 77

Selecting the Docs/Links tab 78

Windows Shortcuts and Miscellaneous Tasks 79

Contents

Windows shortcuts (key combinations) 79

Windows taskbar auto-hide feature 80

5 Troubleshooting

Check the Basics 82

Problems with Microsoft Windows 10 84

Returning an Analyzer for Service 85

Calling Keysight Technologies 85

Locations for Keysight Technologies 86

Read the Warranty 86

Service Options 87

Packaging the Instrument 88

Keysight X-Series Signal Analyzers

N9040B, N9030B, N9020B, N9010B, N9000B

Getting Started and Troubleshooting Guide

1 Quick Start

This section explains how to initialize the Signal Analyzer and view a signal.

The following topics can be found in this section:

“Initial Inspection” on page 10

“Instrument Location and Rack Mounting Requirements” on page 11

“Turning on the Analyzer the First Time” on page 12

“Anti-Virus Software and Firewalls” on page 16

“Instrument Information” on page 17

10 X-Series Signal Analyzers Getting Started and Troubleshooting Guide

Quick Start

Initial Inspection

Inspect the shipping container and the cushioning material for signs of stress.

Retain the shipping materials for future use, as you may wish to ship the

analyzer to another location or to Keysight Technologies for service.

Verify the Contents

Verify the shipping container contents using the box contents list.

Shipping Problems?

If the shipping materials are damaged or the contents of the container are

incomplete:

— Contact the nearest Keysight Technologies office.

— Keep the shipping materials for the carrier’s inspection.

— If you must return an analyzer to Keysight Technologies, use the original (or

comparable) shipping materials. See “Returning an Analyzer for Service”

on page 85.

Otros manuales para UXA N9040B

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Instrumento de medición de Keysight Technologies

Keysight Technologies

Keysight Technologies FieldFox N9927-90002 Manual de usuario

Keysight Technologies

Keysight Technologies M9393A Instrucciones de funcionamiento

Keysight Technologies

Keysight Technologies E5868A Instrucciones de montaje

Keysight Technologies

Keysight Technologies FieldFox N9923A Manual de usuario

Keysight Technologies

Keysight Technologies 8970B Manual de usuario

Keysight Technologies

Keysight Technologies UXA N9040B Manual de usuario

Keysight Technologies

Keysight Technologies M9203A Guía rápida

Keysight Technologies

Keysight Technologies M980xA PXIe Manual de usuario

Keysight Technologies

Keysight Technologies N5247B Manual de usuario

Keysight Technologies

Keysight Technologies BT2152A Manual de servicio

Keysight Technologies

Keysight Technologies ENA Series Guía de inicio rápido

Keysight Technologies

Keysight Technologies E4980A Manual de usuario

Keysight Technologies

Keysight Technologies M9300A Guía del usuario

Keysight Technologies

Keysight Technologies PD1000A Manual de usuario

Keysight Technologies

Keysight Technologies M9391A PXIe Manual de usuario

Keysight Technologies

Keysight Technologies N4960A Manual de usuario

Keysight Technologies

Keysight Technologies N99xxA Series Manual de usuario

Keysight Technologies

Keysight Technologies N5241BU-677 Manual de usuario

Keysight Technologies

Keysight Technologies N5221/2A Series Manual de usuario

Keysight Technologies

Keysight Technologies W3301A Manual de usuario

Keysight Technologies

Keysight Technologies FieldFox N9913A Manual de usuario

Keysight Technologies

Keysight Technologies E5260 Series Instrucciones de funcionamiento

Keysight Technologies

Keysight Technologies N9030B Manual de instalación y operación

Keysight Technologies

Keysight Technologies FieldFox N9913A Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
