Key Digital KD-4KWHCEX Manual de usuario

521 East 3rd Street Mt. Vernon, NY 10553 • www.keydigital.com

Rev 1.0 –Oct, 2023

4KWHCEX

HDMI 4K 60Hz 100ft / 30m

Wireless Extender System with IR

521 East 3rd Street Mt. Vernon, NY 10553 • www.keydigital.com

Rev 1.0 –Oct, 2023

Table of Contents

About KD-4KWHCEX 3

Application Diagrams 4

Quick Connection Guide 5

Connections, Buttons, and LEDs 6

Specifications 9

Product Warnings & Safety Instructions 9

Operation Manual

Please visit www.keydigital.com for the latest product documentation,

firmware, control drivers and software downloads. Product features and

specifications are subject to change without notice

Always follow the instructions provided in this Operation Manual.

521 East 3rd Street Mt. Vernon, NY 10553 • www.keydigital.com

Rev 1.0 –Oct, 2023

About KD-4KWHCEX

KD-4KWHCEX is a wireless HDMI extender kit with support for resolutions up to 4K. The innovative

technology behind KD-4KWHCEX reliably extends HDMI signals with the latest standards - up to

3840x2160 resolution, HDR, 4:4:4 chroma, and deep color –for an effortless solution ideal for

temporary and permanent installation in presentation spaces, outdoor AV setups, and all

environments where running a new wire is not possible.

KD-4KWHCEX features an HDMI pass-through port for connecting a local monitor or sending audio

into an AV receiver. Additionally, the included IR sensor and emitter allow for control of the connected

HDMI source devices such as cable boxes or streamers.

Key Features

•Wireless Extension: Great for temporary setups or installations where new wiring is not possible.

•4K Resolution Support: Up to 3840x2160 24/25/30/60hz at 4:4:4 (signals up to 18Gbps bandwidth) and

backward compatible.

•Signal Distance: 100ft / 30m extension with optimal quality. Up to 164ft / 50m capable in ideal

environments.

•5G WiFi Technology: Transmits through walls and ceilings with minimal range loss and maximum

resistance to wireless interference.

•IR Control Extension: Sensor at Rx unit collects IR signals from device remote to control source

equipment at Tx unit with IR emitter.

•HDMI Pass-Through: Ideal for local monitor or connection into AV receivers

•Surround and 2ch Audio Support: Pass-through port supports up to Dolby®, DTS™(formats up to

5.1/6.1). 2ch audio maximum support via wireless extension to Rx unit.

•Point-to-Point: Pairing of up 4 extender sets using 4 unique channels possible within the same job site.

•Complete Kit: Includes transmitter, receiver, power supplies, IR sensor, IR emitter, antennae, mounting

brackets and screws.

Additional Features

•HDR10 (High Dynamic Range): More life-like images through a greater range of luminance

•Deep Color Support: Up to UHD/4K 30Hz 4:4:4/12 bits or 60Hz 4:4:4/8 bit

•Visually Lossless Compression: 18G enabling technology allows wireless extension of HDMI signals with

latest resolution and features

•HDCP 2.2: Compliancy up to HDCP 2.x and backward compliant

•HDCP Authentication: HDCP sources are authenticated by the HDCP key on transmit unit, for one-to-one

topology

•AV Signal Regeneration: Re-clocking of TMDS (AV signal) channel data at Transmit unit for brand-new AV

signal

521 East 3rd Street Mt. Vernon, NY 10553 • www.keydigital.com

Rev 1.0 –Oct, 2023

Accessories Included

•Qty 2) 5V/2A, 24W DC Power Supply. Model

KD-PS5V2A

•Qty 4) Antenna

•Qty 1) IR Sensor

•Qty 1) IR Emitter

•Qty 4) Mounting L-Bracket

•Qty 10) Mounting Screw

•Qty 2) Grounding Screw

Application Diagrams

521 East 3rd Street Mt. Vernon, NY 10553 • www.keydigital.com

Rev 1.0 –Oct, 2023

Quick Connection Guide

BeginwiththeTxand Rxunits and allinput/output devicesturned offwithpowercables removed

1. Connect your HDMI source to the input port of the Tx unit.

2. Connect your HDMI display to the output port of the Rx unit.

3. (Optional) Connect your local monitor / AV Receiver to the HDMI pass-through port of the Tx unit.

4. (Optional) Connect IR emitter to the IR Out port of the Tx unit and mount over the IR receptor of the

device you wish to control.

5. (Optional) Connect IR Sensor to the IR In port of the Rx unit and mount in a location within clear line-of-

sight and within 16ft / 5m from the source’s IR remote control

6. BEFORE connecting power supply to power outlet, connect the power supply to the Tx and Rx units.

AFTER all connections are made, plug-in power supply to power outlet. Allow

7. Allow approximately 15 seconds for the Tx and Rx unit to pair. When pairing, the Wireless LED will

blink, and will illuminate solid to indicate successful pairing.

8. Power on source and display. Successful HDMI signal extension is indicated by a solid Link LED

9. (Optional) For sites with more than one KD-4KWHCED set installed, pairing will be required.

a. Plugin power to the 1st Tx + Rx set. For ease of pairing, place them next to each other.

b. Press & hold the Pairing Button simultaneously on the Tx + Rx units until the Wireless LED

begins to blink. Release the pairing button.

c. Allow up to 1 minute for the units to pair, as indicated by a solid Wireless LED on the Tx and Rx.

d. Continue with the 2nd 3rd, and 4th Tx + Rx sets following pairing above pairing steps one-by-one.

There can be a maximum of 4 KD-4KWHCEX sets installed per installation site.

521 East 3rd Street Mt. Vernon, NY 10553 • www.keydigital.com

Rev 1.0 –Oct, 2023

Connections, Buttons, and LEDs

HDMI Input, Pass-through, and Output

HDMI Input: Using a short HDMI cable, connect your source device.

HDMI Pass-through: Using a short HDMI cable, connect to a surround receiver or local monitor.

HDMI Output: Using a short HDMI cable, connect your display device.

•Support up to UHD/4K @ 50/60 fps [4:4:4], HDR10, 18Gbps signals. See Supported standard 4K Video

Formats table

•Compliant with HDCP 2.2 and previous

•HDMI Input port provides EDID

handshake with 3840x2160 60hz at 4:4:4

and 2ch audio format to the connected

HDMI source. EDID profile is not

adjustable.

•Important: HDMI Input & Pass-thru

support surround audio formats including

Dolby ®, DTS™(formats up to 5.1 / 6.1).

However, the wireless extension supports

2ch PCM maximum audio.

•For DVI-D / DVI-I sources or monitors,

use appropriate adapters. For Display

Port, use active converters.

521 East 3rd Street Mt. Vernon, NY 10553 • www.keydigital.com

Rev 1.0 –Oct, 2023

Antenna Connections

Connect the included (4) antennae to ensure reliable

wireless extension and optimal distance performance.

•Wireless extension range for 4K and lower resolutions:

o100ft / 30m extension with optimal quality.

oUp to 164ft / 50m capable in ideal environments with minimal

walls, ceilings, and wireless interference.

•Supports 2ch PCM audio maximum wireless audio signal extension.

•Antennae must be connected for functionality.

IR In, IR Out

IR control extension is one-directional, and the ports are specific. Third-party IR emitters or sensors are not

supported.

oThe RX unit’s IR In supports connection with the included IR sensor only (hard-wired / serial IR

input signals are not supported). The incoming IR signal is output on the Tx unit’s IR Out port.

▪The IR Sensor receives signals from a 90° angle at up to 16 ft. away. It accepts a

maximum IR burst frequency of 60kHz.

oThe TX unit’s IR Out port outputs IR signal with the included IR emitter.

USB Service Port

Used for firmware updates only. Consult with Key Digital Technical Support

(tech@keydigital.com) before upgrading firmware.

Power Connection

•5V/2A, 10W DC power supply

•Power must be connected at the Tx and Rx unit

521 East 3rd Street Mt. Vernon, NY 10553 • www.keydigital.com

Rev 1.0 –Oct, 2023

Pairing Button

For installation sites with a single KD-4KWHCEX set, the Tx and Rx are pre-paired and

ready to install without any additional pariing.

For installation sites with multiple KD-4KWHCEX sets:

•Each set must be paired one-by-one:

oPlugin power to the 1st Tx + Rx set. For ease of pairing, place them next to each other.

oPress & hold the Pairing Button simultaneously on the Tx + Rx units until the Wireless LED

begins to blink. Release the pairing button.

oAllow up to 1 minute for the units to pair, as indicated by a solid Wireless LED on the Tx and Rx.

oContinue with the 2nd 3rd, and 4th Tx + Rx sets following pairing above pairing steps one-by-one.

There can be a maximum of 4 KD-4KWHCEX sets installed per installation site.

oAfter successful pairing, units may be moved and installed at their desired locations.

•Supported Wireless Frequencies

oWireless pairing and channel selection is auto-

adaptive.

oUnits scan the frequency range for the open bands,

avoiding frequencies which may be used by other

KD-4KWHCEX sets or nearby 5G WiFi networks.

LED Indicators

•Power (Blue)

oSolid illumination during power on state, as provided by healthy connection with power supply

•Wireless (Orange)

oSteady blink during pairing and when unit’s partner is not powered.

oSolid illumination from successful paring with Tx / Rx partner.

•Link (Orange)

oTx Unit HDMI Input: Solid illumination from active signal from connected HDMI source.

oRx Unit: Solid illumination from active incoming signal from the paired TX unit.

521 East 3rd Street Mt. Vernon, NY 10553 • www.keydigital.com

Rev 1.0 –Oct, 2023

Specifications

Technical

•Supported TMDS Bandwidth: 18Gbps

•Supported Resolutions:

3840x2160@24/30/50/60Hz, 2560x1600,

2560x1440, 1920x1200, 1080P@50/60Hz,

720P@50/60Hz,

•Deep Color Support: Up to 12 bits per color

•DDC Communication: EDID and HDCP Bi-

directional buffering from Display to Source

•Signal Extension Distance: ≤50m / 164ft

•Signal latency: ≤100ms

•DDC Signal (Data): 5 Volts p-p (TTL)

•TMDS HDMI Video/Audio Signal: 0.7 - 1.2

Volts p-p

•HDCP Support: HDCP 1.4, HCP 2.2

•Supported WiFi Frequencies: 5.18, 5.20,

5.22, 5.24 GHz with SSID Pairing supported

•HDMI Connector: Type A, 19 Pin Female

•IR In & Out Connectors (Each): 3.5mm

•Power Supply: (2) 5V/2A, 10W DC Power

Supply. 100-240VAC, 50-60Hz. Model KD-

PS12V2ASC.

•Power Consumption: Tx: ≤6W, Rx: ≤4W

General

•Regulation: CE, RoHS, WEEE, EAC

•Enclosure: Black Metal

•Tx & Rx Unit Dimensions (ea) (LxWxH):

4.53” x 4.92” x 0.81” (115 x 125 x 20.6mm)

•Product Weight (ea): Tx: 0.78lbs (353g), RX:

0.76lbs (346g)

•Package Dimensions (LxWxH): 6.04” x

14.06” x 3.35” (153.5 x 357 x 85mm)

•Package Weight: 2.65 lbs (1.2 KG)

•Operating Temperature: -4~140°F / -

20~60°C

Product Warnings & Safety Instructions

Important Product Warnings:

1. Connect all cables before providing power to the unit.

2. Test for proper operation before securing unit behind walls or in hard to access spaces.

3. If installing the unit into wall or mounting bracket into sheet-rock, provide proper screw support with bolts

or sheet-rock anchors.

Safety Instructions:

Please be sure to follow these instructions for safe operation of your unit.

1. Read and follow all instructions.

2. Heed all warnings.

3. Do not use this device near water.

4. Clean only with dry cloth.

521 East 3rd Street Mt. Vernon, NY 10553 • www.keydigital.com

Rev 1.0 –Oct, 2023

5. Install in accordance with the manufacturer’s instructions.

6. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

7. Only use attachments/accessories specified by the manufacturer.

8. Refer all servicing to qualified service personnel. Servicing is required when the device has been

damaged in any way including:

oDamage to the power supply or power plug

oExposure to rain or moisture

Power Supply Use:

You MUST use the Power Supply provided with your unit or you VOID the Key Digital® Warranty and

risk damage to your unit and associated equipment.

Tabla de contenidos

Otros manuales de Extensor de Key Digital

Key Digital

Key Digital FatCAT KD-CATHD Tx Manual de usuario

Key Digital

Key Digital KD-X400POHK Manual de usuario

Key Digital

Key Digital KD-CATHD300Lite Manual de usuario

Key Digital

Key Digital FATCAT Series Manual de usuario

Key Digital

Key Digital KD-X444LP Manual de usuario

Key Digital

Key Digital KD-X222 Manual de usuario

Key Digital

Key Digital KD-HDDA1x1Pro Manual de usuario

Key Digital

Key Digital KD-X422POA Manual de usuario

Key Digital

Key Digital KD-CAT5XCAT5 Manual de usuario

Key Digital

Key Digital KD-X444SP Manual de usuario

Key Digital

Key Digital KD-X222PO Manual de usuario

Key Digital

Key Digital KD-PS22UTx Manual de usuario

Key Digital

Key Digital KD-X422WP Manual de usuario

Key Digital

Key Digital Phantom KD-HDDA1X1 Manual de usuario

Key Digital

Key Digital PRO Connect PCBKDCATHD Tx Manual de usuario

Key Digital

Key Digital KD-EX18G Manual de usuario

Key Digital

Key Digital KD-FIX418 Manual de usuario

Key Digital

Key Digital FatCAT KD-CATHD250POH Manual de usuario

Key Digital

Key Digital Phantom KD-HD1X1ProK Manual de usuario

Key Digital

Key Digital KD-XUSB2 Manual de usuario

Key Digital

Key Digital KD-CAT5XHDMI Manual de usuario

Key Digital

Key Digital KD-X444LP Manual de usuario

Key Digital

Key Digital KD-X600ProK Manual de usuario

Key Digital

Key Digital Black Bull KD-CATDRV Tx Manual de usuario

Manuales populares de Extensor de otras marcas

SY HDBT-60T Manual de usuario

Appsys ProAudio

Appsys ProAudio ADX-16 Manual de usuario

Atlona

Atlona RS232 Manual de usuario

IDK

IDK OPF-TH1000-A Manual de usuario

Enable-IT

Enable-IT 824WP Manual de usuario

Worx

Worx Landroid RadioLink WA0864 Hoja de especificaciones

TP-Link

TP-Link TL-WA730RE Manual de usuario

Camplex

Camplex CMX-HDMI-SFPL Manual de usuario

SC&T

SC&T HE03-4K Manual de usuario

Marmitek

Marmitek MegaView70 Manual de usuario

Samsung

Samsung SCS-26UC4 Manual de usuario

Foxun

Foxun SX-GES24 Manual de usuario

MuxLab

MuxLab 500771 Manual de usuario

foxunhd

foxunhd SX-AEX01 Manual de usuario

TERK Technologies

TERK Technologies LFIRX2 Manual de usuario

Devolo

Devolo Audio Extender Manual

Edimax

Edimax EW-7438RPn V2 Manual de usuario

Shinybow USA

Shinybow USA SB-6335T5 Manual de usuario
