Operations Manual

TABLE OF CONTENTS

Sequence of Operations for Start-Up Programming 4

States of the Lock 4

Factory Mode 4

Access Mode 4

Pushbutton Programming Mode 5

Default Values of the E-Plex™5000 Programmable Parameters 5

Configuring the Lock 6

General Procedure for Pushbutton Programming 6

Reset Procedures 7

Procedure 1 - Program the Access Code Length 7

Procedure 2 - Modify the Master User Access Code 8

Procedure 3 - Set the Date / Time 8-9

Procedure 4 - Program the Lock ID and Unlock Time 9

Procedure 5 -Program the Duration of the 10

Passage Mode Period

Procedure 6 - Program the Lock for Tamper 10-11

Time Parameters

Procedure 7 -Programming the Lock for Keypad 11-12

Buzzer Volume

Users - General Information 12

User Levels 13

User Codes 14

User Access Codes (PINs) - Examples 14

Procedure 1 - Add / Modify a User Access Code 15

Procedure 2 -Add / Modify a Manager Access Code 16

Procedure 3 -Add / Modify Service User Access Code 16-17

Procedure 4 - Delete User Access Codes 17

Procedure 5 - Delete Manager Access Codes 18

Procedure 6 -Delete Service User Access Codes 18

Procedure 7 - Delete All Access Codes Except Master, 19

Manager, and M-Unit

Procedure 8 -Activate User Access Codes 19

Procedure 9 -Activate Manager Access Code 20

Procedure 10 - Activate Service User Access Code 20

Procedure 11 - Activate All User Access Codes 21

Procedure 12 - Activate / De-activate Passage Mode 21

Procedure 13 - De-activate User Access Codes 22

Procedure 14 - De-activate Manager Access Codes 22

Procedure 15 - De-activate Service User Access Code 23

Procedure 16 - De-activate all Access Codes except 23

Master, Manager, and M-Unit

Procedure 17 - Activate / De-activate Lockout Mode 24

Procedure 18 - Perform Manual Diagnostics 24-25

Battery Life and Replacement 25

Summary of Pushbutton Programming Commands 26-28

Visual Feedback Message Definitions 29

TABLE OF CONTENTS (continued)

Apublication of Kaba Access Control

2941 Indiana Avenue

Winston-Salem, NC 27105

No part of this book may be reproduced or

transmitted in any form or by any means,

electronic or mechanical, including photocopying,

recording, or by any information storage and

retrieval system, without prior written permission

from the Publisher.

The information contained in this publication

is accurate to the best of Kaba Access

Control’s knowledge.

Specifications are subject to change

without notice.

States of the Lock

Factory Mode

The factory mode is one of three primary states of the E-Plex 5000. The

main characteristics of this state are:

• The E-Plex 5000 opens only when the 8-digit master

combination (1-2-3-4-5-6-7-8) is keyed in.

• The visual indication for ‘access granted’ is green LED

flashing once. A high-pitched tone is also generated while

the green LED is on.

• The Master User must change the combination to be able

to exit the factory mode, and switch to the access mode.

Access Mode

This mode refers to a lock that is operational for user access, and not in

factory or Programming Mode.

Pushbutton Programming Mode

The E-Plex 5000 enters the Pushbutton Programming Mode when the

user enters the master combination or one of the manager combinations,

preceded and followed by the character ‘#’ (ex: #12345678#). Once

the E-Plex 5000 is in the Pushbutton Programming Mode, the Master/

Manager can enter one or more command sequences. Each command

sequence ends with a ‘#’ character that acts like an < enter > character.

At the very end of all sequences of programming commands, enter one

more # to remove the lock from the Pushbutton Programming Mode to

return to normal access mode.

Sequence of Operations

for Start-Up Programming

What is the recommended sequence of operations?

With the E-Plex 5000 in the factory mode.

•Program the Access Code Length (default length is four digits).

The access code field length can only be changed when the

lock is not activated (when still in the factory mode).

• Change factory Master to your own Master Code (always

eight digits) to place lock in access mode.

Put lock in Pushbutton Programming Mode.

• Set the Date / Time.

• Program the Lock ID and Unlock time.

•

Program the Lock for the Duration of Passage Mode (if desired).

• Program the Lock for Tamper Time Settings.

• Program the Lock for Buzzer Volume.

• Add Access Codes as desired.

Default values of the E-Plex™5000 programmable

parameters

Parameters Factory Default Values

Date (MM/DD/YY) 01/01/00

Time (HH:MM) 00:00

Lock state Unprogrammed

Lock ID 0000

Passage mode open time limit 9 hours

Passage mode Disabled

Lockout mode Disabled

Unlock time 2 seconds

Buzzer volume control Low

Tamper shutdown time 30 seconds

Tamper attempt count 4 attempts

Access code length 4 digits

Master combination 12345678 (8 digits)

Access code None

Code status Activated

M-Unit user’s combination None

M-Unit user’s status Disabled

Configuring the Lock

General Procedure for Pushbutton Programming

1. The pages that follow provide step-by-step instructions for

programming the E-Plex 5000 lock.

2. The general procedure for all programming functions is as follows:

a. Put the lock in Programming Mode by pressing # Master

Code #

b. Use the Summary of Commands Table in the appendix section

of this guide to enter the three digit command sequence

(Command Type + Function Code), followed by #.

c. Enter the appropriate numbers as required.

d. Press # to end Programming Mode.

e. Once the lock is in programming mode, multiple command

sequences can be entered without having to repeat the

#mastercode#. However, if there is no activity for 15

seconds at the keypad, the lock will automatically exit

from programming mode.

For example

• If the Master or Manager enters his code of 00004992, the

door will open.

•If he enters #00004992#, the lock will enter into the

Programming Mode and wait for the next part of the command.

•If he enters the # sign twice at the end of the code, for

example #00004992##, the lock will go out of Programming

Mode and return to its normal mode.

Note: The # pound sign acts like the Enter key on a keyboard in your

communications with the lock. The # tells the lock that one part of the

entry is finished. The # serves another purpose - to distinguish a

programming type command from a simple Access Code to open the

door. AMaster or Manager User can use the same number to open the

door or to put the lock in Programming Mode, the only difference being

that he uses the # sign in front to signal that he is about to enter a

programming command. For increased security, it is recommended that

the master user code not be used for everyday access. This can be

accomplished by creating an access user code for the master user.

Reset Procedures

There are three different “Reset” levels available in the E-Plex 5000.

Code 099# will reset the lock to the factory default settings except

for the access code length (Master, Manager Access User codes

and Time / Date are retained if already programmed)

Code 299# will delete all access and service user codes (Master,

Manager and M-Unit * users are retained)

Hard Reset will return the lock to factory mode including deleting all

codes, putting the lock back to factory default values (4 digit access

code length) and making the master code 1-2-3-4-5-6-7-8. A hard

reset is performed as follows.

Insert key, turn and hold in open position.

Within 5 seconds, press # and then release latch

While red / green light flashes, press 1-2-3-4-5-6-7-8-# on keypad

The lock will reset. Agreen light with corresponding high pitch tone

indicates reset is complete.

Lock is now reset to the factory mode and the Master Code is now

1-2-3-4-5-6-7-8.

*M-Unit is only applicable when using optional E-Plex software.

Procedure 1 - Program the Access Code Length

Setting the length of Access Codes must be the first lock programmable

function you perform, because all your other access codes must have

the same length. If a user enters a code of a different length, the lock

will not accept it. Longer length Access Codes permit a greater number

of code possibilities, and thus higher security. The master code must

always be 8 digits

Required User Level: Master

1. To configure the E-Plex 5000 programmable pushbutton lock,

it must first be placed in Programming Mode.

Important: This is the only programmable function that

can be done during the factory mode using the factory

master code. Except for changing from the factory code to a

new master code.

2. Enter the E-Plex 5000 factory Master (Programming) Code

(#12345678#). The lock responds with a flashing green light. If

1-2-3-4-5-6-7-8 does not seem to work, please follow the steps

to perform a hard reset by following the procedure in on page 7.

3. Enter the code 009 #LL #, where LL represents the length

(number of digits in a code). The range is from 04 to 08 digits.

You can leave the factory default Access Code length

(4 digits) if you wish.

4. Example of Complete Entry: 009#04#.

5. Key in another #to indicate the end of programming.

6. From now on, all the Access Codes you create must be the

length specified in this step.

Procedure 2 - Modify the Master User Access Code

Required User Level: Master

1. To change the factory code or current Master Code, follow the

next three steps:

2. Put lock into Pushbutton Programming Mode.

3. Use the command, 000, for Master, then the new Master

Code number.

4. You must use 8 digits between 00000000 and 99999999 as follows:

000#MMMMMMMM#, we’ll use 000#00004992# as an example.

5. Enter the Master Code again 00004992# for confirmation.

6. Example of Complete Entry: 000#00004992#00004992#.

7. Key in another #to indicate the end of programming.

8. After that, you will always use your own Master Code. Please

write the code down and keep in a safe place. The factory

code is no longer valid.

Procedure 3 - Set the Date / Time

You must enter the current date and time in each lock to enable accurate

programming and auditing. Always enter Standard Time; the software

package will make the adjustment for Daylight Savings Time. These

must be regularly updated according to your maintenance schedule.

Enter 001 for date settings and 002 for time settings. Date / time settings

are kept after a battery change unless you remove the batteries for more

than two minutes. In this case, the time is reset to 00:00:00 and the

date to 01/01/00.

Required User Level: Master

1. Put lock into pushbutton programming mode.

2. Enter the date as follows: 001#MMDDYY# (Month, Day, Year,

where MM = 01 to 12; DD = 01 to 31; YY = 00 to 99. For

example, Nov. 22, 2003 would be entered as 112203).

3. Enter the date again to confirm MMDDYY#.

Example of Complete Entry: 001#112203#112203#.

4. For the time, enter as follows: 002#HHMM#, where HH = 00 to

23 hours; MM = 00 to 59 minutes. Use military time - for example

eight-thirty in the morning would be 0830, while in the evening it

would be 2030).

5. Enter the code again HHMM#, for example 0830.

6. Example of Complete Entry: 002#0830#0830#.

7. Enter another #to indicate the end of programming.

8. The current date and time are now programmed into the lock.

Procedure 4 - Program the Lock ID and Unlock Time

Assign an ID number to each lock for configuration and auditing purposes.

This is an internal number (default 0000), so it does not have to be the

same as the door number. Unlock time is the length of time the door will

remain unlocked when a correct code is entered before automatically re-

locking itself.

Required User Level: Lock ID: Master, Unlock Time: Master, Manager

1. Put the lock into Pushbutton Programming Mode.

2. To set up the Lock ID, enter command 003#.

3. Enter NNNN (where NNNN is the lock ID - a number from 0000

to 9999). For example, 1234.

4. Example of Complete Entry: 003#1234#.

5. The lock ID is now in its memory.

6. Enter another #to indicate the end of programming, or remain in

programming mode to continue.

7. To establish Unlock Time, enter the following code: 004#TT#,

where TT is the time in seconds, (TT=02 to 20 seconds, for

example 10 seconds).

8. Example of Complete Entry: 004#10#.

9. Enter another #to indicate the end of programming.

10. You have now programmed the lock ID 1234 and, for example,

an Unlock Time of 10 seconds for the door.

Procedure 5 - Program the Duration of the Passage Mode

period

You might want to program locks for public areas, such as cafeterias, to

have free access (Passage Mode) during certain periods of the day, and

revert to required code access outside of these regular hours.

The length of time that the lock remains in Passage Mode is programmable.

The factory default length of time for Passage Mode is 9 hours - you may

leave the default.

Once the lock has been put into Passage Mode, it will automatically

relock after the designated duration.

Required User Level: Master, Manager

1. Put the lock into Pushbutton Programming Mode.

2. Enter command code 005#.

3. Then TT#, where TT= 01 to 24 hours.

4. ATT entry of 00 means there is no time limit - the door

remains unlocked.

5. Enter 005 #TT#; for example, 005#06# for six hours.

6. Example of Complete Entry: 005#06#.

7. Enter another #to indicate the end of programming.

8. In this example, the lock will remain unlocked for six hours,

starting from the time you put it in Passage Mode.

9. You have now configured the duration of the Passage Mode

period for that lock. This does NOT initiate Passage Mode.

10. The new length of time will take effect the next time you

put a lock into Passage Mode by following the correct

command sequence.

Tabla de contenidos

Otros manuales de Cerrar de Kaba

Kaba

Kaba Simplex 506 Series Manual de usuario

Kaba

Kaba Simplex 6200 Series Manual de usuario

Kaba

Kaba KEYLESS ENTRY LOCK Manual de usuario

Kaba

Kaba Simplex 7104 Series Manual de usuario

Kaba

Kaba E-Plex 50 Series Manual de usuario

Kaba

Kaba E-Plex 5200 Manual de usuario

Kaba

Kaba 5402 Series Manual de usuario

Kaba

Kaba PowerPlex 2000 Series Manual de usuario

Kaba

Kaba E-Flash EF680 Manual de usuario

Kaba

Kaba La Gard MECHANICAL Manual de usuario

Kaba

Kaba Combi B 30 Manual de usuario

Kaba

Kaba SILCA SW- VAG GROUP-L0 Manual de usuario

Kaba

Kaba LA GARD 1947 Manual de usuario

Kaba

Kaba E-Plex 5x63 Manual de usuario

Kaba

Kaba Simplex 8100 Series Manual de usuario

Kaba

Kaba LA GARD 1985 Manual de usuario

Kaba

Kaba 7004 Series Manual de usuario

Kaba

Kaba Simplex 1000 Series Manual de usuario

Kaba

Kaba Quantum Series Manual de usuario

Kaba

Kaba 1546-K5 Manual de usuario

Kaba

Kaba ilco 760 Instrucciones de montaje

Kaba

Kaba E-Plex 1500 Series Manual de usuario

Kaba

Kaba PowerLever PROX 9000 Manual de usuario

Kaba

Kaba Simplex Mechanical Pushbutton Locks Manual de usuario

Manuales populares de Cerrar de otras marcas

Magic

Magic 105 Manual de usuario

Gantner

Gantner GAT NET.Lock 7020 System Guía rápida

Wittkopp

Wittkopp Insys 7202 Manual de usuario

Dorma

Dorma Studio Classic Manual de usuario

Securam

Securam ECSL-601 Manual de usuario

Sudhaus

Sudhaus 3003 Manual de usuario

Safety 1st

Safety 1st 48517 Manual de usuario

Pado

Pado FDS-10 Manual de usuario

Esco

Esco systeQ Series Manual de usuario

COMPX

COMPX National D8951 Manual de usuario

secureo

secureo Key Box Manual de usuario

Stock Loks

Stock Loks C8713 Manual de usuario

COMPX

COMPX 1T-058 Manual del propietario

Auslock

Auslock T11 Manual de usuario

ELCOM

ELCOM 7205 Manual de usuario

Stealth SAFES

Stealth SAFES ShadowVault Manual de usuario

Knox

Knox KeySecure 5 Manual de usuario

Kwikset

Kwikset 48334/01 Manual de usuario
