Juniper SRX5600 Manual de usuario

SRX 5600 Services Gateway

Getting Started Guide

August 2008

Part Number: 530-023490-01

Revision 02

This document describes how to install the SRX 5600 services gateway.

Contents About This Guide .............................................................................................3

Step 1: Prepare the Site ...................................................................................4

Rack-Mounting Requirements ...................................................................4

Required Tools ..........................................................................................5

Step 2: Install the Mounting Hardware ............................................................6

Install the Mounting Hardware in a Four-Post Rack or Cabinet or an

Open-Frame Rack ..............................................................................6

Step 3: Install the Device .................................................................................8

Install the Device Using a Lift ....................................................................8

Install the Device Without a Mechanical Lift ...........................................10

Remove Components .......................................................................11

Lift the Chassis into the Rack ............................................................11

Reinstall Components ......................................................................12

Step 4: Connect External Devices and IOC Cables .........................................12

Connect to a Network for Out-of-Band Management ...............................13

Connect a Management Console .............................................................13

Connect the IOC Cables ..........................................................................13

Step 5: Connect Ground and Power Cables ...................................................14

Connect the Grounding Cable .................................................................14

Connect Power to an AC-Powered Services Gateway ..............................15

Connect Power to a DC-Powered Services Gateway ................................16

Step 6: Perform Initial Software Configuration ..............................................18

Safety Warnings ............................................................................................22

■1

Compliance Statements for NEBS ..................................................................24

Compliance Statements for EMC Requirements ............................................24

Canada ...................................................................................................24

European Union ......................................................................................24

JUNOS Software Documentation for J-series Services Routers and SRX-series

Services Gateways ..................................................................................24

Requesting Technical Support .......................................................................26

Revision History ............................................................................................27

2■

SRX 5600 Services Gateway Getting Started Guide

About This Guide

This guide contains information you need to install and configure the SRX 5600

services gateway quickly. For complete installation instructions, see the SRX 5600

Services Gateway Hardware Guide at http://www.juniper.net/techpubs/.

WARNING: This guide contains a summary of safety warnings in “Safety

Warnings”on page 22. For a complete list of warnings for this device, including

translations, see the SRX 5600 Services Gateway Hardware Guide at

http://www.juniper.net/techpubs/.

The SRX 5600 services gateway is a high-performance, highly-scalable, carrier-class

security device with multi-processor architecture. The services gateway has a capacity

of up to 60 gigabits per second (Gbps), full duplex. The device is eight rack units (RU)

tall. Five devices can be stacked in a single floor-to-ceiling rack, for increased port

density per unit of floor space. The device provides eight slots that can be populated

with up to six Services Processing Cards (SPCs) and I/O cards(IOCs) and two Switch

Control Boards (SCBs) in nonredundant fabric configurations.

By installing different combinations of IOCs and SPCs, you can tailor both the number

of Gigabit ports and the maximum security processing capacity to suit your network.

Table 1 on page 3 describes the minimum system configuration for the SRX 5600.

Table 1: Minimum System Configuraton

MinimumComponent

1SPC

1IOC

1SCB

1Routing Engine

Fully populated, the device provides up to 200 Gigabit Ethernet or up to 20 10-Gigabit

Ethernet ports. Two types of IOC interface cards are available, each of which consists

of four Packet Forwarding Engines and enables a throughput of 10 Gbps. You can

install any combination of IOC types in the services gateway.

The SRX 5600 provides redundancy and resiliency. The hardware system is fully

redundant, including power supplies and SCBs.

The services gateway is shipped in a cardboard box strapped securely to a wooden

pallet. Plastic straps secure the top and bottom in place. The device chassis is bolted

to this pallet. Quick start installation instructions and a cardboard accessory box are

also included in the shipping container.

About This Guide ■3

About This Guide

Step 1: Prepare the Site

Figure 1: Rack Clearance and Chassis Dimensions

Rack-Mounting Requirements

■You can install the device in a four-post rack or cabinet or an open-frame rack.

■The rack rails must be spaced widely enough to accommodate the device chassis's

external dimensions: 14.0 in. (35.6 cm) high, 24.5 in. (62.2 cm) deep, and

17.45 in. (44.3 cm) wide. The outer edges of the mounting brackets extend the

width to 19 in. (48.3 cm).

■The rack must be strong enough to support the weight of the fully configured

device, up to 163.5 lb (74.2 kg). If you stack five fully configured devices in one

rack, it must be capable of supporting about 818 lb (371.0 kg).

■For service personnel to remove and install hardware components, there must

be adequate space at the front and back of the device. Allow at least

30 in. (76.2 cm) in front of the device and 24 in. (61 cm) behind the device.

■The rack or cabinet must have an adequate supply of cooling air.

■Ensure that the cabinet allows the chassis hot exhaust air to exit the cabinet

without recirculating into the device.

4■Step 1: Prepare the Site

SRX 5600 Services Gateway Getting Started Guide

■The device must be installed into a rack that is secured to the building structure.

■The device should be mounted at the bottom of the rack if it is the only unit in

the rack.

■When mounting the device in a partially filled rack, load the rack from the bottom

to the top with the heaviest component at the bottom of the rack.

Required Tools

To unpack the services gateway and prepare for installation, you need the following

tools:

■A mechanical lift—recommended

■Phillips (+) screwdrivers, numbers 1 and 2

■2.5 mm flat-blade (–) screwdriver

■3/8-in. nut driver

■1/2-in. or 13-mm open-end or socket wrench to remove bracket bolts from the

shipping pallet

■Electrostatic discharge (ESD) wrist strap

■Antistatic mat

Step 1: Prepare the Site ■5

Step 1: Prepare the Site

Step 2: Install the Mounting Hardware

To install the mounting hardware in a four-post rack or cabinet or an open-frame

rack:

■Install the Mounting Hardware in a Four-Post Rack or Cabinet or an Open-Frame

Rack on page 6

Install the Mounting Hardware in a Four-Post Rack or Cabinet or an Open-Frame Rack

To install the mounting shelf on the front rails of a four-post rack or cabinet, or the

rails of an open-frame rack:

1. If needed, install cage nuts in the holes specified in Table 2 on page 6.

2. On the back of each rack rail, partially insert a mounting screw into the lowest

hole specified in Table 2 on page 6.

3. Install the mounting shelf on the back of the rack rails. Rest the bottom slot of

each flange on a mounting screw.

4. Partially insert screws into the open holes in each flange of the mounting shelf

(see Figure 2 on page 7 or Figure 3 on page 8).

5. Tighten all the screws completely.

Table 2: Mounting Hole Locations

Mounting ShelfDistance Above “U”DivisionHole

1.14 U2.00 in. (5.1 cm)4

0.86 U1.51 in. (3.8 cm)3

0.50 U0.88 in. (2.2 cm)2

0.14 U0.25 in. (0.6 cm)1

6■Step 2: Install the Mounting Hardware

SRX 5600 Services Gateway Getting Started Guide

Figure 2: Mounting Hardware for a Four-Post Rack or Cabinet

Step 2: Install the Mounting Hardware ■7

Step 2: Install the Mounting Hardware

Figure 3: Mounting Hardware for an Open-Frame Rack

Step 3: Install the Device

Because of the device's size and weight, we recommend you install the device using

a mechanical lift. The procedure for installing the device depends on whether you

use a mechanical lift:

■Install the Device Using a Lift on page 8

■Install the Device Without a Mechanical Lift on page 10

Install the Device Using a Lift

1. Ensure the rack is in its permanent location and is secured to the building. Ensure

that the installation site allows adequate clearance for both airflow and

maintenance. For details, see the SRX 5600 Services Gateway Hardware Guide.

2. Load the device onto the lift, making sure it rests securely on the lift platform

(see Figure 4 on page 9).

8■Step 3: Install the Device

SRX 5600 Services Gateway Getting Started Guide

Figure 4: Load the Device onto the Lift

3. Using the lift, position the device in front of the rack or cabinet, centering it in

front of the mounting shelf.

4. Lift the chassis approximately 0.75 in. above the surface of the mounting shelf

and position it as close as possible to the shelf.

5. Carefully slide the device onto the mounting shelf so that the bottom of the

chassis and the mounting shelf overlap by approximately two inches.

6. Slide the chassis onto the mounting shelf until the mounting brackets contact

the rack rails. The shelf ensures that the holes in the mounting brackets and the

front-mounting flanges of the chassis align with the holes in the rack rails.

7. Move the lift away from the rack.

8. Install a mounting screw into each of the open mounting holes aligned with the

rack, starting from the bottom.

9. Visually inspect the alignment of the device. If the device is installed properly in

the rack, all the mounting screws on one side of the rack should be aligned with

the mounting screws on the opposite side and the device should be level.

Step 3: Install the Device ■9

Step 3: Install the Device

Install the Device Without a Mechanical Lift

To install the device without a mechanical lift:

■Remove Components on page 11

■Lift the Chassis into the Rack on page 11

■Reinstall Components on page 12

Figure 5: Components to Remove from the Front of the Device

Figure 6: Components to Remove from the Rear of the Device

10 ■Step 3: Install the Device

SRX 5600 Services Gateway Getting Started Guide
