Buck and Boost Voltage Converter
BuckBoost Voltage Converter
Published: 24.01.2019 Copyright by Joy-IT 3
Dear customer,
thank you very much for choosing our product. In the following we have listed what you have to consider
during the setup.
The freely customizable voltage converter module is equipped with a "Step UP" and a "Step DOWN"
funcon. The voltage can be set individually and is shown on the integrated segment display.
1. DEVICE OVERVIEW
Input Voltage 5 - 25V
Output Voltage 0.5 - 25V
Max. Current Input: 2A
Output: 2A
Display Mode 3 digits Segment display
Display Color Blue
Dimensions 47 x 41 x 16mm
Weight 23g
BuckBoost Voltage Converter
Published: 24.01.2019 Copyright by Joy-IT 4
Connect the cables of your power source to the input (Input + / Input -) of the voltage converter.
Next, connect the cables (Output +/Output -) of the device to be supplied. The voltage transformer is now
ready for use.
2. USAGE AND FUNCTIONS
BuckBoost Voltage Converter
Published: 24.01.2019 Copyright by Joy-IT 5
The desired voltage can be set with the adjusng screw. The display shows the current output voltage.
With the S1 buon you can change through a total of three display modes. The factory seng
automacally shows the input mode aer the device has been started. Here the input voltage is shown on
the display. The LED, which is located directly below the buon, lights up permanently.
By pressing the buon you switch to the output mode. Here the output voltage is displayed and the LED
turns o. Pressing the buon again acvates the alternave mode. The input and output modes are
changed every three seconds.
You can also press and hold the S1 buon for three seconds to save the current mode. This mode will be
loaded automacally each me the unit is started.
BuckBoost Voltage Converter
Published: 24.01.2019 Copyright by Joy-IT 6
The voltage output can also be switched on or o with the ON/OFF key.
BuckBoost Voltage Converter
Published: 24.01.2019 Copyright by Joy-IT 7
Our informaon and take-back obligaons according to the Electrical and Electronic
Equipment Act (ElektroG)
Symbol on electrical and electronic equipment:
This crossed-out dustbin means that electrical and electronic appliances do not belong in the household
waste. You must return the old appliances to a collecon point.
Before handing over waste baeries and accumulators that are not enclosed by waste equipment must
be separated from it.
Return opons:
As an end user, you can return your old device (which essenally fulls the same funcon as the new
device purchased from us) free of charge for disposal when you purchase a new device.
Small appliances with no external dimensions greater than 25 cm can be disposed of in normal household
quanes independently of the purchase of a new appliance.
Possibility of return at our company locaon during opening hours:
Simac GmbH, Pascalstr. 8, D-47506 Neukirchen-Vluyn, Germany
Possibility of return in your area:
We will send you a parcel stamp with which you can return the device to us free of charge. Please contact
us by e-mail at Service@joy-it.net or by telephone.
Informaon on packaging:
If you do not have suitable packaging material or do not wish to use your own, please contact us and we
will send you suitable packaging.
3. ADDITIONAL INFORMATIONS
BuckBoost Voltage Converter
Published: 24.01.2019 Copyright by Joy-IT 8
We are also there for you aer the purchase. If you sll have quesons le or encounter any problems,
we are also available by e-mail, telephone and cket support system.
E-Mail: service@joy-it.net
Ticket-System: hp://support.joy-it.net
Phone: +49 (0)2845 98469 – 66 (9:30 - 17:00 o‘clock)
For further informaon please visit our website:
www.joy-it.net
4. SUPPORT
