Joy-it Bread Power Manual de usuario

Ausgabe 04.01.2017 Copyright by Joy-IT 1

3

Bread Power

3

Ausgabe 04.01.2017 Copyright by Joy-IT 2

3Bread Power

Index

1. Technical specicaon

2. Installaon

3. Usage

4. Security informaons

Ausgabe 04.01.2017 Copyright by Joy-IT 3

Dear customer,

thank you for purchasing our product.

Please nd our instrucons below.

1. Technical specicaon

Model Bread Power

Arcle number SBC-POW-BB

Maximum current 700mA

Input 1 Hohlstecker 5.5 / 2.1mm, DC IN 6-12V

Input 2 USB 5V

Input 3 Micro USB 5V

Output 3.3V, 5V, Masse, USB (s.o)

Measurements (BxHxT) Ca. 70x15x30mm

Box contents PCB

EAN 4250236814728

The Bread Power—extension-board can extend your breadboard with a power supply by simply aaching

it.

Aached to a breadboard, it can include a power supply between 6V and 12B, or an USB-connecon.

While using another power-supply, the USB-Port can also be used as output.

The output-voltage to the breadboard can be set to 0V, 3,3V and 5V.

Ausgabe 04.01.2017 Copyright by Joy-IT 4

2. Installaon

Connect the Bread Power—extension board, as seen below, to your breadboard.

The extension board is ready to use.

3. Usage

Ausgabe 04.01.2017 Copyright by Joy-IT 5

4. Security informaons

Please note our security informaons:

The set is for usage in dry rooms only.

It must not get wet or moist.

This is no toy and small parts can be swallowed and lead to death.

We can not ensure a perfect funcon by using third-party supplies.

This especially counts for foreign power-adapters.

The device can be damaged by higher voltage and could cause re or lead to damage by an electric shock.
