Johnson 40-6601 Manual de usuario

Self-Leveling Cross-Line Laser

Model Nos. 40-6601, 40-6603, 40-6605

Instruction Manual

Congratulations on your choice of this Self-Leveling Cross-Line Laser. We

suggest you read this instruction manual thoroughly before using the

instrument and save this instruction manual for future use.

This is a Class laser tool and is manufactured to comply with CRF 21,

parts 1040.10 and 1040.11 as well as international safety rule EC 285.

2891i-3English_Manuals 6/4/18 10:26 AM Page 1

Table of Contents

1. Kit Contents

2. Features and Functions

3. Safety nstructions

4. Location/Content

of Warning Labels

5. Location of Parts/Components

6. Operating nstructions

7. Checking Accuracy

8. Application Examples

9. Troubleshooting Guide

10. Technical Specifications

11. Product Warranty

12. Warranty Registration

1. Kit Contents

Description for Model 40-6603 Qty.

Self-Leveling Cross-Line Laser

“AA” Alkaline Batteries 2

Description for Model 40-6601 & 40-6605 Qty.

Self-Leveling Cross-Line Laser

Magnetic Bracket 1

Tinted Glasses 1

Magnetic Target 1

“AA” Alkaline Batteries 2

Hard-Shell Carrying Case 1

2891i-3English_Manuals 6/4/18 10:26 AM Page 2

2. Features and Functions

• Simultaneously projects two laser beams both horizontally (level)

and vertically (plumb)

• Tilt mode can be used to plot lines at any angle

• Magnetically dampened compensator system stabilizes the

pendulum quickly and accurately, and stays level even with

nearby jobsite vibration.

• Status light alerts you to when the tool is beyond its leveling

range

• Locking mechanism protects the pendulum during transportation

• 1/4″-20 tripod thread for use with most common tripods

2891i-3English_Manuals 6/4/18 10:26 AM Page 3

3. Safety Instructions

Please read and understand all of the following instructions, prior

to using this tool. Failure to do so, may void the warranty.

DANGER!

Class Laser Product

Max. Power Output: ≤1mW

Wavelength: 635nm (40-6603 & 40-6605)

THIS TOOL EMITS LASER RADIATION.

DO NOT STARE INTO BEAM.

AVOID DIRECT EYE EX OSURE.

DANGER!

Class Laser Product

Max. Power Output: ≤1mW

Wavelength: 520nm (40-6601)

THIS TOOL EMITS LASER RADIATION.

DO NOT STARE INTO BEAM.

AVOID DIRECT EYE EX OSURE.

CAUTION

Maximum Power < 1mW

Wavelength 520nm

Class II laser product

LASER RADIATION-DO NOT STARE

INTO THE BEAM OR VIEW DIRECTLY

WITH OPTICAL INSTRUMENTS

This device complies with 21 CFR chapter 1,

Subchapter J, CFR1040.10 and 1040.11

2891i-3English_Manuals 6/4/18 10:26 AM Page 4

ATTENTION IMPORTANT

• Read all instructions prior to operating this laser tool. Do not remove any labels from tool.

• Do not stare directly at the laser beam.

• Do not project the laser beam directly into the eyes of others.

• Do not set up laser tool at eye level or operate the tool near a reflective surface as

the laser beam could be projected into your eyes or into the eyes of others.

• Do not place the laser tool in a manner that may cause someone to unintentionally

look into the laser beam. Serious eye injury may result.

• Do not operate the tool in explosive environments, i.e. in the presence of gases or

flammable liquids.

• Keep the laser tool out of the reach of children and other untrained persons.

• Do not attempt to view the laser beam through optical tools such as telescopes as

serious eye injury may result.

• Always turn the laser tool off when not in use or left unattended for a period of time.

• Remove the batteries when storing the tool for an extended time (more than 3 months)

to avoid damage to the tool should the batteries deteriorate.

• Do not attempt to repair or disassemble the laser tool. f unqualified persons attempt

to repair this tool, warranty will be void.

• Use only original Johnson®parts and accessories purchased from your Johnson®

authorized dealer. Use of non-Johnson®parts and accessories will void warranty.

2891i-3English_Manuals 6/4/18 10:26 AM Page 5

4. Location/Content of Warning Labels

40-6603

40-6605

CAUTION

Maximum Power < 1mW

Wavelength 520nm

Class II laser product

LASER RADIATION-DO NOT STARE

INTO THE BEAM OR VIEW DIRECTLY

WITH OPTICAL INSTRUMENTS

This device complies with 21 CFR chapter 1,

Subchapter J, CFR1040.10 and 1040.11

40-6601

2891i-3English_Manuals 6/4/18 10:26 AM Page 6

5. Location of arts/Components

Locking

Compensator/

Power Switch

Battery Cover

Release Tab

Tilt Mode

Button

Status Light

Laser Output

Window

1/4″-20 Tripod Thread

(underneath, not shown)

2891i-3English_Manuals 6/4/18 10:26 AM Page 7

6. Operating Instructions

IM ORTANT: t is the responsibility of the user to ensure proper

maintenance of the Self-Leveling Cross-Line Laser. Conduct

periodic test measurements to ensure the instrument is measuring

accurately and consistently. This is most important if the

instrument has been exposed to extreme temperatures or

moisture. Keep the Self-Leveling Cross-Line Laser optic lens clean

and inspect for damage.

Battery Installation

To install batteries in the Self-Leveling

Cross-Line Laser:

1. Remove the battery cover, which is located at

the back of the tool, by pressing the battery

cover release tabs found on the left and right

sides of the tool and pulling the cover straight

out from the tool housing.

2. nsert 2 “AA” batteries into the battery compartment according to

the polarity illustrated inside the battery compartment.

3. Replace the battery cover. Press in the release tabs as you insert

them into the tool housing.

Notes:

• Always check that the locking compensator/power switch is in the

locked position before removing and replacing batteries.

• Use only alkaline batteries.

• Remove the batteries when storing the instrument for an extended

time (more than 3 months) to avoid damage to the tool should the

batteries deteriorate.

2891i-3English_Manuals 6/4/18 10:26 AM Page 8

Using the roduct in Self-Leveling Mode

Slide the locking compensator up to the unlocked position to power

on the unit. The status light will illuminate, and the unit will emit

two laser beams.

Slide the locking compensator down to the unlocked position to

power off the unit.

Note: The Self-Leveling Cross-Line Laser must be within ±4° of level

for the self-leveling feature to function properly. f the instrument is

beyond its 4° self-leveling range, the laser will not self-level, the

laser will flash and the status light will turn red. Once the instrument

has been adjusted to within its 4° self-leveling range, the laser will

self-level, the status light will turn green and the laser light will stop

flashing and remain solid.

Using the roduct in Tilt (Manual Level) Mode

The Self-Leveling Cross-Line Laser can be used to project laser

beams at any angle desired, such as when projecting a line for stairs

or a railing. This mode produces the best results when the tool is

mounted on a tripod.

With the locking compensator down in the locked position, press the

tilt mode button to power on the unit. The status light will illuminate

in red to indicate that the tool is not self-leveling, and the unit will

emit two laser beams. The lasers will be perpendicular to each other,

but will not self level.

Press the tilt mode button to power off the unit.

2891i-3English_Manuals 6/4/18 10:26 AM Page 9

Tips from the ros

• ncreasing the Beams’ Visibility – When working in bright

conditions, such as when working near windows or outside walls,

the visibility of the laser beams can be maximized by following

these steps:

• Work towards the laser.

• Use a freestanding target (sold separately).

• Wear laser glasses (sold separately).

Note: Laser glasses enhance beam visibility but should never be

used to stare into the beam or be used as safety glasses. Eye

damage may result if these directions are not followed.

Care and Handling

• This Self-Leveling Cross-Line Laser is a precision tool that must be

handled with care.

• Avoid exposing unit to shock vibrations and extreme temperatures.

• Remove the batteries when storing the unit for an extended time

(more than 3 months) to avoid damage to the unit should the

batteries deteriorate.

• Avoid getting the unit wet.

• Keep the laser unit dry and clean, especially the laser output

window. Remove any moisture or dirt with a soft, dry cloth.

• Do not use harsh chemicals, strong detergents or cleaning

solvents to clean the unit.

2891i-3English_Manuals 6/4/18 10:26 AM Page 10
