Johnson 40-6584 Manual de usuario

Electronic Self-Leveling Dual Grade

Horizontal Rotary La er

Model No. 40-6584

Instruction Manual

Congratulat ons on your cho ce of th s Electron c Self-Level ng Dual

Grade Hor zontal Rotary Laser. We suggest you read th s nstruct on

manual thoroughly before us ng the nstrument. Save th s nstruct on

manual for future use.

This is a Class IIIa laser tool and is manufactured to comply with C R 21,

parts 1040.10 and 1040.11 as well as international safety rule IEC 285.

6274H-2_Manuals 9/26/12 11:32 AM Page 1

Table of Contents

1. Kit Contents

2. eatures and unctions

3. Safety Instructions

4. Location/Content

of Warning Labels

5. Location of Parts/Components

6. Operating Instructions

7. Using the Product

8. Self-Check & ine Calibration

9. Technical Specifications

10. Application Demonstrations

11. Care and Handling

12. Product Warranty

13. Warranty Registration

14. Accessories

1. Kit Contents

Description Model No. 40-6584 Qty.

Electronic Self-Leveling Dual Grade Horizontal Rotary Laser

Li-ion Rechargeable Battery Pack 1

Battery Adapter 1

Remote Control with 2 AA Batteries 1

Detector with 9V Battery and Clamp 1

Alkaline Battery Compartment (batteries not included) 1

Sighting Scope 1

Slope Plate 1

ine Adjusting Plate 1

Instruction Manual with Warranty Card 1

Hard-Shell Carrying Case 1

2. Features and Functions

• Large ±8° electronic auto-level range. When beyond the leveling

range, the laser beam will flash, rotation of the beam will stop, and

an audible alarm will activate.

• Electronic beam shield to turn the laser beam off in one to three

quadrants, when multiple lasers are being used.

• Programmable dual slope operation function allows user to

perform slope at different inclinations in both x and y axis.

• Height of Instrument/Tilt alarm function ensures product accuracy.

• Dust and rain resistant.

• Operates with remote control.

• LCD display with backlight illumination.

• Adjustable rotation speeds of 600 and 1100 rpms.

6274H-2_Manuals 9/26/12 11:32 AM Page 2

3. Safety Instructions

Please read and understand all of the following instructions, prior

to using this tool. ailure to do so, may void the warranty.

DANGER!

Class IIIa Laser Product

Max. Power Output: ≤5mW

Wavelength: 625-645nm

THIS TOOL EMITS LASER RADIATION.

DO NOT STARE INTO BEAM.

AVOID DIRECT EYE EX OSURE.

ATTENTION IMPORTANT

• Read all instructions prior to operating this laser tool. Do not remove any labels from tool.

• Do not stare directly at the laser beam.

• Do not project the laser beam directly into the eyes of others.

• Do not set up laser tool at eye level or operate the tool near a reflective surface as

the laser beam could be projected into your eyes or into the eyes of others.

• Do not place the laser tool in a manner that may cause someone to unintentionally

look into the laser beam. Serious eye injury may result.

• Do not operate the tool in explosive environments, i.e. in the presence of gases or

flammable liquids.

• Keep the laser tool out of the reach of children and other untrained persons.

• Do not attempt to view the laser beam through optical tools such as telescopes as

serious eye injury may result.

• Always turn the laser tool off when not in use or left unattended for a period of time.

• Remove the batteries when storing the tool for an extended time (more than 3 months)

to avoid damage to the tool should the batteries deteriorate.

• Do not attempt to repair or disassemble the laser tool. If unqualified persons attempt

to repair this tool, warranty will be void.

• Use only original Johnson®parts and accessories purchased from your Johnson®

authorized dealer. Use of non-Johnson®parts and accessories will void warranty.

6274H-2_Manuals 9/26/12 11:32 AM Page 3

4. Location/Content of Warning Labels

6274H-2_Manuals 9/26/12 11:32 AM Page 4

5. Location of art/Components

Laser

Output

Window

LCD

Display

Handle

Charging Port

Connection to

the Laser

Screw

5/8” - 11

Screw

Thread

Slope Plate

ine Adjustment Knobs 5/8” - 11 Screw Thread

Lock Knob Fine Adjusting Plate

Battery

Cover Screw

Battery

Cover

Keypad

Sighting Scope

5/8” - 11

Screw

Thread

6274H-2_Manuals 9/26/12 11:32 AM Page 5

6. Operating Instructions

IM ORTANT: It is the responsibility of the user to verify the

calibration of the instrument before each use.

Alkaline Battery Installation:

Put 3 “D” alkaline batteries (not included)

into the battery pack according to the polarity

direction, then insert the battery pack into the

laser. (Note: Batteries facing up.)

Rechargeable Battery ack Installation:

Install the rechargeable battery pack into

the laser.

Charging the Rechargeable Battery ack:

Charge the rechargeable battery pack by inserting the charger into

the charging port. The LED on the charger is red during the charging

process; the LED on the charger will turn green when the battery is

fully charged.

Charging LED

Charger

Charge the rechargeable battery pack

outside the laser

Charge the rechargeable battery pack with

battery pack inside the laser

6274H-2_Manuals 9/26/12 11:32 AM Page 6

Note:

(1) Charge the rechargeable battery when the battery power is low

(battery symbol on the LCD is flashing). This will extend the

battery life.

(2) If the laser is not going to be used for a long period of time,

charge the rechargeable battery every 2-3 months.

(3) The instrument can operate while the batteries are recharging.

Use of the Slope late and Fine Adjusting late:

If the laser is operating with less than +12% grade in

the Y-axis, the slope plate is not required.

If the laser is operating between +12% and +25% in

the Y-axis, the slope plate is required.

or exact positioning of the X or Y-axis, screw the ine Adjusting Plate

on the tripod and then screw the laser to the ine Adjusting Plate.

Use the sighting scope to rotate the laser to the exact position

required. Use the ine Adjustment Knobs for fine movement. Use the

Lock Knob when positioned in the correct position.

Slope Plate

ine Adjusting

Plate

6274H-2_Manuals 9/26/12 11:32 AM Page 7

7. Using the roduct

Keypad Controls

LCD Display

Rotating Speed Button On/Off Button

Grade Axis and

Position Button

Grade Value Buttons

Manual Mode Button

Remote Channel Button

Vibrate/VWS Button

Tilt Button

Beam Shield Buttons

Rotating Speed

X-Axis Grade Value

Y-Axis Grade Value

Battery Capacity

Beam Shield

Remote Channel

Remote On/Off

Manual Mode

Vibrate/VWS Mode

Tilt Mode

Level Button /

LCD Backlight Button

6274H-2_Manuals 9/26/12 11:32 AM Page 8

ower On/Off Button:

Press this button to power on/off the laser.

The laser is in self-leveling status when powered on.

Default rotate speed is 600 RPM

Default beam shield is off in all four quadrants;

Default grade for X-axis and Y-axis is 0.

The remote channel will display CH1.

If there is a matched remote control with the power on, the

remote status will display if there is not a matched remote, it

will display .

When powered on, the laser will automatically check the battery

capacity.

When powering on the laser it will enter into the self-leveling mode.

The TILT display will blink for thirty seconds after the lasers starts

to rotate. During these thirty seconds, if the laser is moved it will

stop rotating and re-level itself. After thirty seconds, the laser

will enter into the TILT mode and the LCD will show a solid

TILT display. (See TILT button)

Grade axis and Grade Value Button:

With the laser on, press the Grade Axis and Position button and hold

in for two seconds. The laser will beep once and the laser will enter

the X-axis grade setting mode. The X-axis symbol “X” and axis

direction symbol (+) will flash. A short press of the button will move

the position to the next symbol. Pressing the grade value buttons

will change the values. When the X-axis setting is

6274H-2_Manuals 9/26/12 11:32 AM Page 9

completed, press the grade axis button for two seconds to enter into the

Y-axis grade setting mode. The Y-axis symbol “Y” and axis direction

symbol (+) will flash. The setting method is the same as the X-axis.

After the Y-axis grade setting is completed, press this key for two

seconds to confirm the grade setting. The laser will beep once

and will quit the grade setting mode and start to work under the

confirmed grade.

Note: If there is no buttons pressed for eight seconds in the

grade setting mode, the laser ill confirm the current grade

setting data automatically. The laser ill beep once and leave

the grade setting mode.

Rotating Speed Button:

Press this button to select the rotating speed from 600 RPM

to 1100 RPM.

Beam Shield Buttons:

When turning on the laser, the beam shield will be off in all four

quadrants. All four quadrants on the LCD will be displayed. Pushing

one of the buttons will turn the beam off in that quadrant and that

quadrant will not be displayed on the LCD.

Note: One, two or three quadrants can be turned off simultaneously.

6274H-2_Manuals 9/26/12 11:32 AM Page 10
