Jensen CR271ML Instrucciones de funcionamiento
CR271ML
7” CAPACITIVE TOUCH SCREEN
MULTIMEDIA MECHLESS RECEIVER
AM-FM, Bluetooth
SiriusXM™ Ready
Front & Rear Camera Input
INSTALLATION &
OWNER’S MANUAL
W AT T S Front & Rear
Camera
CR271ML
2
INFORMATION
Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio, Inc. All
rights reserved.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG,
Inc.
microSD Logo is a registered trademark of SD-3C, LLC.
Siri and Apple are registered trademarks owned by Apple, Inc.
Google Assistant and Android are trademarks owned by Google LLC.
Other trademarks and trade names are those of their respective owners.
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Copyright and Trademark
3
CR271ML INFORMATION
Video / movie playback will not operate while the vehicle is moving. This is a
safety feature to prevent driver distraction. In-dash video / movie functions will
only operate when vehicle is in Park and the parking brake is engaged. It is illegal
in most jurisdictions for the driver to view video while the vehicle is in motion.
The SAFETY NOTICE is reminder to drive responsibly and safely while using your mobile
phone device, or any APP’s that are compatible with this unit.
It is highly recommended that your JENSEN CR271ML is installed by a professional installer
or an authorized dealer.
This product is only for use in vehicles with 12VDC negative ground only.
To prevent damage or injury:
• Make sure to ground the unit securely to the vehicle chassis ground.
• Do not remove the top or bottom covers of the unit.
• Do not install the unit in a spot exposed to direct sunlight or excessive heat or the
possibility of water splashing.
• Do not subject the unit to excessive shock.
• When replacing a fuse, only use a new one with the correct rating. Using a fuse with the
wrong rating may cause the unit to malfunction.
• To prevent short circuits when replacing a fuse, disconnect the wiring harness first.
• Use only the provided hardware and wire harness.
• If you experience problems during installation, consult your nearest JENSEN dealer.
• If the unit malfunctions, reset the unit as described. If the problem still persists, consult
your nearest JENSEN dealer or call tech assistance @ 1-888-921-4088.
• To clean the monitor, wipe only with a dry silicone cloth or soft cloth. Do not use a stiff
cloth, or solvents such as paint thinner and alcohol. They can scratch the surface of the
panel and/or remove the printing.
• When the temperature of the unit falls (as in winter), the liquid crystal inside the screen
will become darker than usual. Normal brightness will return after the unit is in use for a
while.
• When extending the ignition, battery or ground wiring, make sure to use automotive-grade
wiring with an a minimum AWG 16 or more to prevent voltage drops.
• Do not touch the liquid crystal fluid if the LCD is damaged or broken. The liquid crystal
fluid may be hazardous to your health or fatal. If the liquid crystal fluid from the LCD
contacts your body or clothing, wash it off with soap immediately.
Safety Notice
INSTALLATIONCR271ML
4
Please read and understand entire manual before installation.
Consult a qualified technician for detailed instructions or installation
assistance.
Before You Start
• Disconnect negative battery terminal.
• Avoid installing the unit where it would be subject to high
temperatures, such as from direct sunlight, or where it would be
subject to dust, dirt or excessive vibration.
Getting Started
• Unpack unit from its protective packaging.
• Connect vehicle wiring harness and antenna to this receivers
harness. See wiring instructions. Consult a qualified technician if
you are unsure.
• Certain vehicles may require an installation dash kit and/or wiring
harness adapter (sold separately).
• Reconnect battery negative terminal.
• Test for correct operation and secure back into dashboard.
• Snap trim ring into place if needed.
Preparation
Typical ISO-DIN Installation
Unit
Trim Ring
5
CR271ML INSTALLATION
Tips
EN
Nyne ADS15
USBCHARGE
5V1A
When replacing a fuse, make sure to use the correct type and amperage. Using
an incorrect fuse could cause damage. The unit uses (1) 10 amp ATC blade-type
fuse located on the back of the unit.
Front / Rear camera inputs
Up to two cameras (not included) can be used. We recommend JENSEN Part
# BUCAM200J for front camera and BUCAM300AJ or BUCAM400AJ for rear
camera.
For more information on how to install the SiriusXM Connect Vehicle tuner,
consult the installation guide included with the tuner (SiriusXM connect tuner and
subscription sold separately).
Input / Output Wiring Diagram
SWC INPUT
GR
AY/RED
FR OUT FL OUT V OUT SUB OUT
RR OUT RL OUT F-CAM SUB OUT
R-IN L-IN V-IN R-CAM ANT
SXM IN
External MIC Input
OPERATIONCR271ML
6
Main Control Locations
1Microphone
2Mode / Voice Assistant
3Tune/Track Up
4Volume / Power / Mute
5Tune/Track Down
6microSD Card Slot
7Reset
8Auxiliary Input
9USB Slot
1 2 3 4
5
6
7
8
9
10
11
12
13
14
15
16
17
27
30
29
28
31
26
25
24
23
22
21
20
19
18
Mode
Power
Play / Pause
Mute
End call
Talk
Setup
Zone1
Zone2
Zoom
Select
Volume UP
Seek Up
Audio
Volume Down
* Key
1
2
3
4
5
6
7
8
9
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
10
11
12
13
14
15
Loudness
Number keys
Root
OSD (On Screen Display)
Local/Random
Seek Down / Prevous Trac
k
AS/PS/Repeat
Stereo
Stop
Enter / Direct Tune
Band
SiriusXM Skip Backward
SiriusXM Channel Up
SiriusXM Skip Forward
SiriusXM Channel Down
16
7
OPERATIONCR271ML
Remote Control Preparation
Notes:
• The remote control uses one 3 volt Lithium
CR2025 battery. Remove the battery if the
remote will not be used for a month or
longer.
• Remove and dispose of battery properly.
• Do not store battery with metallic objects
or materials.
Remove battery insulation tape .
To insert or replace the battery,
remove the battery holder.
Remove the battery from the
battery holder.
Install the new battery.
Make sure to keep the (+) side up.
Insert the battery holder .
OPERATIONCR271ML
8
On Screen Controls
123 4
Press up to two times to dim the screen. Press a
third time to put the unit in standby mode (screen
will go black). Press anywhere on the screen to
return to normal screen operation.
Press to activate the voice assistant feature.
Press to access and adjust audio settings.
Press to display and adjust system settings.
Screen Brightness 1
Voice Assistant 2
Audio 3
Settings 4
Source Menu Operation
6. Auxiliary Input
7. BT Music
8. BT Phone
9. microSD
10. USB
12
10
3
5
98 7 4
6
1. Radio
2. SiriusXM
3. Settings
4. Cameras
5. AV Input
9
OPERATIONCR271ML
Select any of the preset EQ settings (Flat, Classic, Rock, Pop, Jazz, Beat or User)
or use the touch screen to manually adjust EQ settings.
Select any of the preset Surround settings: Concert, Church, Passive, Wide, Live
or None.
Adjust balance (8L to 8R) and fader (8F to 8R), or use the touch screen to
manually adjust balance and fader settings.
Audio Settings
OPERATIONCR271ML
10
Settings Menu
From the Main Menu, press the gear icon to access the Setup menu and adjust
the following: General, Audio, Display and Bluetooth.
General:
• OSD Language - Select English.
• Wallpaper - Select from three different wallpaper options.
• Radio Area - Select Europe, USA, South America or Asia.
• Time Setting - Set the date (month, day, year) and time (hours, minutes,
AM/PM and 12-hour or 24-hour clock).
• Beep - Enable or disable the audible beep.
• Camera - Enable or disable the rear camera input.
• Version - Press to display version numbers.
• Restore Default - Press to restore unit to default factory settings.
Audio:
• Audio Settings - Press to access and adjust audio settings.
• Subwoofer- Press to adjust subwoofer frequency and volume.
• Loudness - Enable or disable the loudness feature.
Display:
• Aspect Ratio - Select desired region (America, Europe or Latin).
• Adjust - Press to adjust screen brightness, contrast, hue, saturation and
shaprness.
• Panel - Select from the following Backlight settings: Off, 10 seconds, 20
seconds or 30 seconds.
Bluetooth:
• Bluetooth - Turn Bluetooth signal on or off.
• Auto Answer - Turn auto answer feature on or off.
