JBL ES80 Manual de usuario

Key Specifications

Finishes: Cherry, Beech and Black

19mm (3/4") Polyester-film ring-radiator ultrahigh-frequency driver

with waveguide

19mm (3/4") Titanium-laminate-dome high-frequency transducer mounted in

Elliptical Oblate SpheroidalTM (EOS) waveguide

Dual 170mm (6") PolyPlasTM-cone low-frequency transducer

Straight-Line Signal PathTM (SSP) crossover network preserves clarity, detail and

dynamics of the original content

MDF enclosure with low-diffraction IsopowerTM baffle and internal bracing

Dual gold-plated 5-way speaker terminals, bi-wirable

Rear-firing FreeflowTM flared, tuned port

Magnetically shield

Removable feet (Standard rubber feet supply)

Highlights

4-Way Dual 6" (170mm)

Floorstanding Loudspeaker

Ultra-High Frequency (UHF)

tweeter expands frequency

response up to 40kHz – capable

of accurately reproducing high-

definition audio

Elegant Cabinet design with its

slender profile and combination

of wood-like vinyl with textured

high-quality charcoal vinyl

High-definition audio with professional credentials

The JBL® ES Series offers a variety of bookshelf, wall-mount and floorstanding loudspeakers, and bring-down-the-house pow-

ered subwoofers. With innovative technologies derived directly from JBL Professional equipment, the JBL ES Series delivers

powerful, accurate audio performance and brings the legendary JBL sound from concert stages, recording studios and movie

theatres to living rooms, dens, bedrooms and patios. And with three finishes to choose from – black, beech and cherry – they’re

designed to look good anywhere, with a style that equals their substance.

JBL ES Series Speaker Systems

ES80

Harman Consumer Group, Inc.

2, route de Tours, 72500 Château du Loir, France • 250 Crossways Park Drive, Woodbury, NY 11797, USA • 8500 Balboa Boulevard, Northridge, CA 91329, USA

www.jbl.com

in the United States and/or other countries. Elliptical Oblate Spheroidal (EOS), PolyPlas, Straight-Line Signal Path, FreeFlow and IsoPower are trademarks

of Harman International Industries, Incorporated.

Features, specifications and appearance are subject to change without notice.

Specifications

Frequency response (–3dB): 45Hz – 40kHz

Max. recommended amplifier power*: 200W

Power handling (continuous/peak): 100W/400W

Sensitivity (2.83V/1m): 90dB

Nominal impedance: 8 Ohms

Crossover frequencies: 700Hz, 3600Hz – 24dB/octave; 12000Hz – 18dB/octave

Low-frequency transducer: Dual 170mm (6") PolyPlas, shielded

Midrange transducer: 100mm (4") PolyPlas, shielded

High-frequency transducer: 19mm (3/4") Titanium-laminate dome, shielded; EOS waveguide

Ultrahigh-frequency transducer: 19mm (3/4") Polyester-film, ring-radiator, shielded; EOS waveguide

Dimensions with grille (H x W x D): 1084mm x 223mm x 330mm (42-11/16" x 8-3/4" x 13")

Weight per speaker: 21kg (46.3 lb)

* The maximum recommended amplifier power rating will ensure proper system headroom to allow for occasional peaks.

We do not recommend sustained operation at these maximum power levels.

JBL ES Series Speaker Systems

ES80
