JBL SIMPLY CINEMA SCS110 Manual de usuario

SCS110

simple

set-up guide

thank youfor choosing JBL. For over 50 years, JBL

has been involved in every aspect of musical and film recording

and reproduction, from live performances to monitoring the

recordings you play in your home, car, or office.

We’re confident that the JBL system you have chosen

will provide every note of enjoyment that you expected –

and that when you think about purchasing additional audio

equipment for your home, car, or office, you will once again

choose JBL.

Please take a moment to complete the enclosed profile card.

It enables us to keep you posted on our latest advancements,

and helps us to better understand our customers and build

products that meet your needs and expectations.

JBL Consumer Products

SCS110 (Simply Cinema) OM 11/20/00 4:24 PM Page 1

read first! Before you begin

Two satellite speakers

(with removable shelf stands). One subwoofer. One sat10 center speaker.

One pair of sat10 surround

speakers with removable

wall-mounting brackets.

included

features

• 2-way satellite speakers

with 3/4" titanium composite

dome high-frequency drivers.

• Triple chamber band-pass

subwoofer.

• Adjustable satellites with

shelf stands included.

• Adjustable, removable wall-

mounting brackets (for use

with surround speakers).

• Video-shielded satellites.

• Recessed wire channels on

satellites and surrounds.

• Diffraction-limiting foam

satellite baffles.

SCS110 (Simply Cinema) OM 11/20/00 4:24 PM Page 2

On shelves. On the wall. Optional bracket.

Part No. SFX10BKT, or

SFX10BKTWHT (white).

Mounting Options

On optional stands.

Part No. FS10/20.

FS10/20WHT (white).

On optional stands.

Surrounds

On shelves. Wall-mounted. Brackets and

hardware included.

Subwoofer

Surround Speakers

5– 6 ft.

Satellites

one.Speaker Placement

Satellites

0-2 ft.

SCS110 (Simply Cinema) OM 11/20/00 4:25 PM Page 3

+ –+ +

– ++ –

– –

+ +

– –

Receiver

Subwoofer

Left

Surround

Right

Surround

Left Front 

sat10

Right Front

sat10

Front Center Rear

L R L R

Left Right

Output to Satellite

Input from Amplifier

Left Right

+ –

Center 

Speaker

–

two.Speaker Connections

For satellites, thread speaker

wire through the hole in the

bottom of the speaker, then

feed it through the recessed

wire channel.

Separate and strip the ends of

the speaker wire as shown.

Speakers and electronics ter-

minals have corresponding (+)

and (–) terminals. It is impor-

tant to connect both speakers

identically: (+) on the speaker

to (+) on the amplifier and (–)

on the speaker to (–) on the

amplifier. Wiring “out of

phase” results in thin sound,

weak bass and a poor stereo

image.

Connection Tips

SCS110 (Simply Cinema) OM 11/20/00 4:25 PM Page 4

Troubleshooting

three.Testing

Finally. Take a “test drive” with some favorite music or movies.

1. With the receiver/amplifier

still turned off, confirm that

its volume control is turned

all the way down. Next,

center the balance control. If

the receiver/amplifier has an

A/B speaker switch, set it to

correspond to the speaker

terminals connected to the

SCS110 system.

2. Now, turn on your receiver/

amplifier and select a music

source such as a CD player,

cassette deck or FM tuner.

3. Turn up the volume control

slowly until you hear sound

from the speakers.

4. Rotate the balance control

all the way to the left. Sound

should come only from the

left speaker. If the sound

comes from the right speaker

with the balance control to

the left, the speaker wires

have been reversed during

hook-up. Turn the receiver/

amplifier “off” and switch

both sets of speaker wires.

Dolby Pro Logic*-equipped

devices (AV Receivers,

Surround Sound processors

or decoders, TVs or other

sources) include a “test tone”

you can use to balance the

volume of all the speakers in

a surround sound system.

Refer to the instructions

accompanying your compo-

nent for selecting the test

tone mode and using it to

balance speaker levels in your

home theater.

If there is no sound from

any of the speakers, check

the following:

• Receiver/amplifier is on and

a source is playing.

• Review proper operation of

your receiver/amplifier.

If there is no sound coming

from one speaker, check the

following:

• Check the “Balance” control

on your receiver/amplifier.

• Check all wires and con-

nections between receiver/

amplifier and speakers.

• Make sure all wires are con-

nected. Make sure none of the

speaker wires are frayed, cut,

or punctured.

If the system plays at low

volumes but shuts off as

volume is increased, check

the following:

• Check all wires and con-

nections between receiver/

amplifier and speakers.

• Make sure all wires are con-

nected. Make sure none of the

speaker wires are frayed, cut,

or punctured.

• If more than one pair of

main speakers is being used,

check the minimum impedance

requirements of your receiver/

amplifier.

If there is low bass output,

check the following:

• Make sure the polarity

(+ and –) of the left and

right “Speaker Inputs” are

connected properly.

If there is no sound from

the surround speakers, check

the following:

• Check all wires and con-

nections between receiver/

amplifier and speakers.

• Make sure all wires are con-

nected. Make sure none of the

speaker wires are frayed, cut,

or punctured.

• Review proper operation of

your receiver/amplifier and its

surround sound features.

SCS110 (Simply Cinema) OM 11/20/00 4:25 PM Page 5

JBL Consumer Products

80 Crossways Park West, Woodbury, NY 11797

8500 Balboa Boulevard, Northridge, CA 91329

1-800-336-4JBL (4525) (USA only)

*Trademark of Dolby Laboratories.

Printed in USA 8/96 Part No. SCS110OM

Specifications

SCS110 System

Power Handling

10 – 120 watts

Frequency Response

40Hz – 20kHz (±3dB)

Accessories such as the

optional stands and brackets

are available through your JBL

dealer. For a dealer in the USA

call 1-800-336-4JBL.

Refinements may be made on

occasion to existing products

without notice, but will always

meet or exceed original speci-

fications unless otherwise

stated.

Notice to Purchaser: JBL

assumes no responsibility or

liability for injuries or property

damage – direct, indirect, or

consequential – resulting from

the improper installation of

these loudspeakers.

sat10

Power Handling

10 – 80 watts

Frequency Response

150Hz – 20kHz (±3dB)

Impedance

8 ohms nominal

Sensitivity

88dB @ 1 watt/1 meter

Crossover Frequency

3.5kHz (midrange to tweeter)

Tweeter

One 3/4" titanium composite

dome, video-shielded

Midrange

One 3-1/2" neodymium

driver, video-shielded

Dimensions (HxWxD)

6-1/2 x 3-3/4 x 4-1/4 inches

165 x 95 x 108mm

Weight

1.5 lbs/.7 kg

bass10

Power Handling

10 – 120 watts

Frequency Response

40Hz – 150Hz (±3dB)

Impedance

8 ohms nominal

Sensitivity

88dB @ 1 watt/1 meter

Crossover Frequency

150Hz (subwoofer to satellite)

Bass

Two 5-1/4" woofers

Triple chamber band-pass

subwoofer

Dimensions (HxWxD)

14-3/4 x 8-1/2 x 19 inches

375 x 216 x 465mm

Weight

28 lbs/12.7 kg

sat10 Surround

Speakers

Recommended Power

10 – 70 watts

Impedance

8 ohms nominal

Sensitivity

90dB @ 1 watt/1 meter

Frequency Response

100Hz – 15kHz (±3dB)

Dimensions (HxWxD)

6-1/2 x 3-3/4 x 4-1/4 inches

165 x 95 x 108mm

Weight

1.5 lbs/.7 kg

Declaration of Conformity

We, JBL Europe A/S

Kongevejen 194B

DK-3460 Birkerød

DENMARK

declare in own responsibility, that the products described

in this owner’s manual are in compliance with technical

standards:

EN 50 081-1/1992

EN 50 082-1/3.1995

Steen Michaelsen

JBL Europe A/S

Birkerød. DENMARK. 7/96

A Harman International Company

SCS110 (Simply Cinema) OM 11/20/00 4:25 PM Page 6
