Janitza UMG 509-PRO Manual de instrucciones

Doc. no. 2.059.011.2.o 06/2021

Power Quality Analyser

UMG 509-PRO

User manual and technical data

Part no. 33.03.217

Janitza electronics GmbH

Vor dem Polstück 6

D-35633 Lahnau

Support tel. +49 6441 9642-22

email: [email protected]

www.janitza.com

UMG 509-PRO www.janitza.de

1. Contents

1. General 1

1. 1 Disclaimer 1

1. 2 Copyright notice 1

1. 3 Technical changes 1

1. 4 Declaration of conformity 1

1. 5 Comments on the manual 1

1. 6 Meaning of symbols 1

2. Safety 3

2. 1 Safety information 3

2. 2 Safety measures 4

2. 3 Qualiﬁed staff 4

3. Proper use 5

3. 1 Inspection on receipt 5

3. 2 Scope of delivery 6

3. 3 Available accessories 6

4. Product description 7

4. 1 Measuring process 7

4. 2 Usage concept 7

4. 3 GridVis® network analysis software 7

4. 4 Features 8

4. 5 Product overview 9

5. Installation 11

5. 1 Installation location 11

5. 2 Installation position 11

5. 3 Mounting 11

6. Network systems 13

6. 1 Three-phase 3-conductor systems 14

6. 2 Three-phase 4-conductor systems 14

6. 3 Rated voltages 15

6. 3. 1 Three-phase 4-conductor network with

earthed neutral conductor 15

6. 3. 2 Three-phase 3-conductor network, non-earthed 15

www.janitza.de UMG 509-PRO

7. Installation 17

7. 1 Connection to a PC 17

7. 2 Ground wire connection 18

7. 3 Disconnectors 18

7. 4 Supply voltage 18

7. 5 Measured voltage 19

7. 5. 1 Overvoltage 19

7. 5. 2 Frequency 19

7. 6 Current measurement 20

7. 6. 2 Current direction 21

7. 6. 3 Total current measurement 21

7. 6. 1 Ammeter 21

7. 7 Connection variants 22

7. 7. 1 Voltage measurement 22

7. 7. 2 Current measurement 23

7. 7. 3 Supporting measurement, input V4 24

7. 8 Residual current monitoring 25

7. 8. 1 Failure monitoring 25

7. 8. 2 Example: Residual current transformer insulation 26

7. 9 Temperature measurement 27

7. 9. 1 Example: Temperature sensor insulation 27

8. Interfaces 29

8. 1 Shielding 29

8. 2 RS485 interface 30

8. 2. 1 Termination resistors 30

8. 3 Proﬁbus interface 31

8. 3. 1 Connecting the bus lines 31

8. 4 Bus structure 32

8. 5 Ethernet interface 33

9. Digital inputs and outputs 35

9. 1 Digital inputs 35

9. 1. 1 S0 pulse input 36

9. 2 Digital outputs 37

10. Operation 39

10. 1 Button allocation 39

10. 2 “Home" measured value indication 39

10. 3 Measured value indication 40

10. 3. 1 Main values 40

10. 3. 2 By-values 40

10. 4 Selecting a measured value indication 41

10. 5 View additional information 42

10. 6 Deleting values 42

10. 7 Transients list 43

10. 8 Event list 44

UMG 509-PRO www.janitza.de

III

11. Conﬁguration 45

11. 1 Languages 45

11. 2 Communication 45

11. 2. 1 Ethernet(TCP/IP) 45

11. 2. 2 Field bus 46

11. 3 Measurement 47

11. 3. 1 Measuring transducer 47

11. 3. 2 Transients 51

11. 3. 3 Events 53

11. 3. 4 Mains frequency 54

11. 4. 2 Temperature 55

11. 4 System 55

11. 4. 1 Password 56

11. 4. 3 Reset 56

11. 5 Display 58

11. 6 Colours 59

11. 7 Extensions 59

11. 8 PTP conﬁguration 61

11. 8. 1 Important Modbus parameters for the PTP

conﬁguration of the device 61

11. 8. 2 PTP parameter _MODE_NTP 61

11. 8. 3 Example: PTP timing according to IEEE 1588-2008 and

clock types 62

12. Commissioning 63

12. 1 Connecting the supply voltage 63

12. 2 Connecting the measured voltage 63

12. 3 Frequency measurement 64

12. 4 Phase sequence 64

12. 5 Applying the measured current 65

12. 5. 1 Phasor diagram examples 66

12. 6 Applying the residual current 66

12. 7 Failure monitoring (RCM) 67

12. 7. 1 Alarm status 67

12. 8 Measurement range exceeded 68

12. 9 Checking the power measurement 68

12. 10 Checking the communication 68

12. 11 Communication in the bus system 69

12. 11. 1 RS485 69

12. 11. 2 Proﬁbus 70

12. 11. 3 Recording conﬁguration 75

12. 12 Digital inputs/outputs 77

12. 12. 1 Digital inputs 77

12. 12. 2 Pulse output 77

www.janitza.de UMG 509-PRO

13. Device homepage 81

13. 1 Measured values 82

13. 1. 1 Short overview 82

13. 1. 2 Detailed measured values 83

13. 1. 3 Diagrams 84

13. 1. 4 RCM - residual current monitoring 84

13. 1. 5 Events 85

13. 1. 6 Transients 85

13. 2 Power quality 86

13. 3 Apps 87

13. 3. 1 Push Service 87

13. 4 Information 88

13. 4. 1 Device information 88

13. 4. 2 Display 88

13. 4. 3 Downloads 88

14. Service and maintenance 89

14. 1 Repair and calibration 89

14. 2 Front ﬁlm 89

14. 3 Disposal 89

14. 4 Service 89

14. 5 Device calibration 89

14. 6 Calibration intervals 89

14. 7 Firmware update 89

14. 8 Battery 90

15. Procedure in the event of faults 91

16. Technical data 93

16. 1 Supply voltage 93

16. 2 Voltage and current measurement 94

16. 3 Residual current monitoring 95

16. 4 Temperature measurement input 96

16. 5 Digital inputs and outputs 97

16. 6 Interfaces 98

16. 7 Function parameters 99

16. 8 Dimension diagrams 100

17. Menu guide overview 101

17. 1 Conﬁguration menu overview 101

17. 2 Overview of measured value indications 102

18. Connection example 105

UMG 509-PRO www.janitza.de

1. 1 Disclaimer

Observing the information products

for the devices is the prerequisite for safe

operation and in order to obtain the speciﬁed

performance and product features. Janitza

electronics GmbH accepts no liability

for injuries to personnel, property damage

or ﬁnancial losses arising due to a failure

to comply with the information products.

Ensure that your information products are

accessible and legible.

1. 2 Copyright notice

Duplication, editing, dissemination and other

utilisation, also in part, is prohibited.

All trademarks and the resulting rights

are the property of their respective owners.

1. 3 Technical changes

• Please ensure that your device complies

with the installation manual.

• Please read and understand

the documents enclosed with the product

ﬁrst.

• Keep the documents enclosed with

the product available throughout the entire

service life of the product and pass them

on to subsequent users if applicable.

• Inform yourself of any new device versions

and the associated updates to the

documentation enclosed with the product

at www.janitza.de.

1. 4 Declaration of conformity

For information on the laws, standards and

directives that Janitza electronics GmbH has

applied for the device, see the declaration

of conformity on our website

(www.janitza.de).

1. 5 Comments on the manual

We welcome your comments. If anything

in this manual seems unclear, please let

us know by sending us an e-mail to:

[email protected]

1. 6 Meaning of symbols

This manual uses the following pictograms:

1. General

Ground wire connection.

Inductive.

The current lags behind the voltage.

Capacitive.

The voltage lags behind the current.

www.janitza.de UMG 509-PRO

UMG 509-PRO www.janitza.de

Please read this user manual and all other

publications that must be consulted to work

with this product. This applies particularly

to installation, operation and maintenance.

Observe all safety instructions and warnings.

Failure to comply with the instructions can

result in personal injuries and/or damage

to the product.

Any unauthorised changes or use

of this device, which go beyond

the mechanical, electrical or otherwise stated

operating limitations, can result in bodily

injury and/or damage to the product.

Any such unauthorised change constitutes

"misuse" and/or "negligence" according

to the warranty for the product and thus

excludes the warranty for covering possible

damage resulting from this.

The user manual:

• must be read before using the device.

• must be kept throughout the entire service

life of the product and be readily available

for reference.

Follow additional legal and safety regulations

required for the respective application when

using the device.

2. 1 Safety information

Symbols used:

ccThis symbol is used as an addition

to the safety instructions and warns

of an electrical hazard.

CCThis symbol with the word note

describes:

• Procedures that do not pose

any risk of injures.

• Important information,

procedures or handling steps.

Safety information is highlighted by a warning

triangle and is indicated as follows depending

on the degree of danger:

DANGER!

Indicates an imminent danger

that causes severe or fatal

injuries.

WARNING!

Indicates a potentially

hazardous situation that can

cause severe injuries or death.

CAUTION!

Indicates a potentially

hazardous situation that can

cause minor injuries or damage

to property.

2. Safety

www.janitza.de UMG 509-PRO

2. 2 Safety measures

When operating electrical devices, certain

parts of these devices are invariably

subjected to hazardous voltage. Therefore,

severe bodily injuries or damage to property

can occur if they are not handled properly:

WARNING!

Risk of injury due

to electric voltage!

Severe bodily injuries or death can occur

due to dangerous voltages.

Therefore, note the following:

• Before connecting connections,

earth the device at the ground wire

connection if present.

• Hazardous voltages may be present

in all switching parts that are

connected to the power supply.

• Hazardous voltages may also

be present in the device even after

disconnecting the supply voltage.

• Provide single core conductors with

sleeves.

• Only connect screw-type terminals

with a matching number of pins

and of the same type.

• If the device is not operated according

to the documentation, protection

is no longer ensured and hazards

can be posed by the device.

• De-energise the system before

starting work.

2. 3 Qualiﬁed staff

This device must only be operated

and repaired by specialised personnel.

Specialised personnel are people who are

qualiﬁed to recognise risks and prevent

potential dangers that can be caused

by the operation or maintenance

of the device based on their respective

training and experience.

WARNING!

Risk of injury due to electric

voltage!

Janitza measurement devices or their

components can lead to injuries and even

death or to material damage!

• Do not use Janitza measurement devic-

es or components for critical switching,

control or protection applications where

the safety of persons and property de-

pends on this function.

• Do not carry out switching operations

with the Janitza measurement devices

or components without prior inspection

by your plant manager with specialist

knowledge! In particular, the safety of

persons, material assets and the ap-

plicable standards must be taken into

account!

UMG 509-PRO www.janitza.de

3. 1 Inspection on receipt

The prerequisites of faultless, safe operation

of this device are proper transport and proper

storage, set-up and installation, as well

as careful operation and maintenance.

Packing and unpacking must be carried

out with customary care without the use

of force and only using suitable tools.

Visually inspect the devices for ﬂawless

mechanical condition.

Please check the delivered items

for completeness before you start installing

the device.

If it can be assumed that risk-free operation

is no longer possible, the device must

be immediately put out of operation

and secured against being put back

into operation again. It can be assumed

that risk-free operation is no longer possible

if the device, for example:

• has visible damage.

• no longer works despite the mains power

supply being intact.

• has been exposed to prolonged

adverse conditions (e.g. storage outside

the permissible climate limits without

being adapted to the room climate,

condensation, etc.) or rough handling

during transportation (e.g. falling from

a height, even if there is no visible external

damage, etc.).

3. Proper use

CCNOTE!

All screw-type terminals included

in the scope of delivery are attached

to the device.

CCNOTE!

All supplied options and versions

are described on the delivery note.

Otros manuales para UMG 509-PRO

Tabla de contenidos

Otros manuales de Instrumento de medición de janitza

janitza

janitza 800-CT8-A Manual de usuario

janitza

janitza UMG 512-Pro Manual de instrucciones

janitza

janitza UMG 96-PA Manual de usuario

janitza

janitza UMG 96-S2 Manual de usuario

janitza

janitza UMG 804 Manual de usuario

janitza

janitza UMG 96-S2 Manual de instrucciones

janitza

janitza UMG 96 RM-EL Manual de instrucciones

janitza

janitza UMG 605US Manual de usuario

janitza

janitza UMG 806 Manual de instrucciones

janitza

janitza RCM 202-AB Manual de usuario

janitza

janitza UMG 806 Manual de instrucciones

janitza

janitza UMG 96-PA Manual de usuario

janitza

janitza optec UMG-96 Manual de usuario

janitza

janitza UMG 96 RM-EL Manual de usuario

janitza

janitza UMG 96 Manual de usuario

janitza

janitza UMG 96-PQ-L-LP Manual de usuario

janitza

janitza FBM Series Manual de usuario

janitza

janitza UMG 604 Manual de usuario

janitza

janitza UMG510 Manual de usuario

janitza

janitza UMG 96 RM-E Manual de usuario

janitza

janitza UMG507 Instrucciones de funcionamiento e instalación

janitza

janitza UMG 604 Manual de usuario

janitza

janitza UMG 96-S2 Manual de usuario

janitza

janitza UMG 103 Manual de servicio

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario

janitza UMG 509-PRO Manual de instrucciones

Manuales populares de Instrumento de medición de otras marcas
