Jacuzzi MITO 6 Manual de usuario

Mito™6

SALON™ SPA

MODEL NUMBER:

DZ95 – (RH pump and

blower)

EXTERIOR DIMENSIONS:

72" long x 42" wide x

21½" high

INTERIOR DIMENSIONS

(AT BOTTOM):

43¾" long x 27" wide x

23" wide

# OF JETS/TYPE OF JETS:

4 TheraPro™ Jets

2 AccuPro™ Foot Jets

OPERATING GALLONS:

73 gallons

Mito™6 |SALON™ SPA BATH

Mito—in Italian, “myth.” Our Mito™—a combination of

fabled luxury. Think of the Mito™ as a fantastic experience.

Legendary hydrotherapy in a roomy, bow-tie shaped

bathing well.

WHIRLPOOL BATH FEATURES:

• Combinedwhirlpool&PureAir®for maximum massage

• 360ºBalancedAirow™system

• 600wattheatedairblower

• ThermalLumbarComfort(TLC)™

• Timedpurgecycle

• 4fullyadjustableTheraPro™jets

• 2directionallyadjustableAccuPro™jets

• Airowadjustability

• Sculptedarmrestandbackrest

• PrO3

™ Ozone Sanitation System standard

Detail: The Mito

Salon™ Spa’s sculpted interior features gracious

curves, a deep bathing well, and integral armrests.

Mito™6

SALON™ SPA BATH

Technical Speciﬁcations

DIMENSIONS

72” L†x 42” W x 21-1/2” H

(1829 mm) L x (1067 mm) W x (546 mm) H

(†Add 1/4” to this dimension when roughing-in for 3-wall niche.)

DRAIN/OVERFLOW

A: 17-1/2” (445 mm) B: 11-7/8” (302 mm)

CUTOUT

70” (1778 mm) x 40” (1016 mm)

TOTAL WEIGHT

1197 lb (543 kg) / 57 lb/ft2(278 kg/m2)

OPERATING GALLONAGE

73 U.S. Gal. (288 Liters)

PRODUCT WEIGHT

155 lb (70 kg)

SKIRT MOUNTING

Not Available

ELECTRICAL SPECIFICATIONS

Requires a dedicated GFCI protected separate circuit.

Blower: 120VAC, 20AMP, 60 Hz.

Motor/Pump and Optional RapidHeat™: 240VAC, 20AMP, 60 Hz.

HEATER (OPTIONAL)

Requires a dedicated GFCI protected separate circuit.

RapidHeat™: P/N S750000

INSTALLATION NOTES

Refer to installation instructions included with ﬁxture before

beginning installation. Please conﬁrm product availability and

speciﬁcations before commencing with any installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT

TO CHANGE WITHOUT NOTICE.

#FR72000 01/08

DZ95 Mito© 6 Salon™ Spa, Right Hand

• Center Drain Location

• Accessories / Hardware:

Trip-Lever Drain Kit #X559

Rotary Drain Kit, 26” Cable #8730

HTC Jet Trim Kit: #D095

2 X BMH Jet Trim Kit: #J869

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(849) – Oil Rubbed Bronze

36"

42"

72"

11-7/8"

10" x 4"

Motor

12" H x 24" L

Service Access

Opt. Service

Access

5-3/8"

Blower

Optional Heater

END VIEW

SIDE VIEW

72" 2"

(51 mm)

(Optional Heater)

42"

21-1/2"

(Blower)

(Motor)

(Optional

Heater)

DRAIN/OVERFLOW

Product Shown: Mito©6 Salon™ Spa Right Hand

Shown Model: DZ95

* Measurements inside unit represent cutout in

ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.
