Itec C31TRIPLE4KDOCKPDPRO Manual de usuario

I-TEC USB-C TRIPLE DISPLAY

DOCKING STATION

WITH POWER DELIVERY 100W

P/N: C31TRIPLE4KDOCKPDPRO

User guide • Gebrauchsanweisung • Mode d’emploi

Manual de instrucciones • Manuale • Uživatelská příručka

Instrukcje obsługi • Užívateľská príručka

• Vartotojo vadovas • Handleiding

Quick Start

ENGLISH

EN Please read the entire instruction manual carefully. Detailed

manual is available on our website www.i-tec.cz/en/ in the tab

„Manuals, drivers“. In case of any issues, please contact our technical

support at: [email protected]

DE Bitte lesen Sie das gesamte Handbuch sorgfältig durch. Die

ausführliche Gebrauchsanweisung ist auch auf unserer Webseite

www.i-tec.cz/de/ unter „Benutzerhandbücher, Treiber“ bei diesem

Produkt zu finden.

Wenn Sie Probleme haben, kontaktieren Sie bitte

unser Support-Team unter: [email protected]

FR Veuillez lire attentivement le manuel dans son intégralité. Un

manuel détaillé est disponible sur notre site www.i-tec.cz/fr/ sous

l'onglet "Manuels, pilotes". Si vous avez des problèmes, veuillez

contacter notre équipe support à support@itecproduct.com

ES Por favor, lea atentamente todo el manual. El manual detallado

está disponible en nuestro sitio web, www.i-tec.cz/es/ bajo la

pestaña "Manuales y controladores" de este producto. Si tiene algún

problema, póngase en contacto con nuestro equipo de soporte en

[email protected]

IT Leggere attentamente tutto il Libretto d’uso. Il Libretto d’uso è a

disposizione anche sulla scheda “Manuali e strumenti” del nostro

sito web: www.i-tec.cz/it/. In caso di problemi rivolgersi al supporto

tecnico: support@itecproduct.com

CZ Prosíme o pečlivé přečtení celého manuálu. Podrobný manuál je

k dispozici na našem webu www.i-tec.cz v záložce „Manuály,

ovladače“ u tohoto produktu. V případě problémů se můžete

obrátit na naši technickou podporu: support@itecproduct.com

PL Upewnij się, że uważnie przeczytałeś instrukcji obsługi.

Szczegółowy podręcznik

jest dostępny na naszej stronie

internetowej www.i-tec.cz/pl/ w zakładce "Instrukcje, sterowniki".

W razie jakichkolwiek problemów, skontaktuj się z naszym

serwisem pod adresem: support@itecproduct.com

C31TRIPLE4KDOCKPDPRO

ENGLISH

SK Prosíme o dôkladné prečítanie celého manuálu. Podrobný manuál

je k dis pozícii tiež na našom webe www.i-tec.cz v záložke „Manuály,

ovladače“ pri tomto produkte. V prípade problémov sa môžete obrátiť

na našu technickú podporu: support@itecproduct.com

LT Prašome įdėmiai perskaityti visą vadovą. Išsamų vadovą galite

rasti

mūsų svetainėje www.i-tec.cz/en/ šio produkto skyrelyje

„Manuals,

drivers“. Iškilus problemoms galite susisiekti su mūsų

technine pagalba: [email protected]

NL Wij vragen u vriendelijk om de volledige handleiding zorgvuldig

door te lezen. Een gedetailleerde handleiding van dit product is

beschikbaar op onze website www.i-tec.cz/nl/ onder het tabblad

"Handleidingen en drivers". Mochten er zich problemen voordoen

kunt u contact opnemen met ons supportcenter via

[email protected].

Quick Start

ENGLISH

C31TRIPLE4KDOCKPDPRO

ENGLISH

ENGLISH................................................... 06–10

DEUTSCH.................................................. 11–15

FRANÇAIS.................................................16–20

ESPAÑOL...................................................21–25

ITALIANO...................................................26–30

ČESKY........................................................ 31–35

POLSKI...................................................... 36–40

SLOVENSKY.............................................. 41–45

LIETUVOS................................................. 46–50

NEDERLANDS........................................... 51–55

WEEE......................................................... 56–57

Declaration of Conformity........................ 58–59

FCC...................................................................50

Quick Start

ENGLISH

6 7 8 9

3 4 5

DESCRIPTION

Front panel:

1. USB-C 3.2 Gen.2 port

2. USB 3.2 Gen.2 port

Right Panel:

3. Audio combo jack

4. Support for Kensington lock

5. DisplayPort (with DP++ support)

Back panel:

6. DisplayPort (with DP++ support)

7. HDMI port

8. Ethernet GLAN RJ-45 Port

9. USB-C PD port.

Left panel:

10. 2x USB 2.0 port

11. 2x USB 3.2 port Gen.1

Top Panel:

12. LED-backlit button

to turn the docking

station on and off.

C31TRIPLE4KDOCKPDPRO

ENGLISH

SPECIFICATIONS

• 1x integrated USB-C cable for connection to the device (100 cm)

• Docking station technology: USB-C (MST)

• Power Delivery: up to 100 W

• Internal power consumption: 5-10W (more info here)

• Video Ports: 2x DisplayPort (supporting DP++), 1x HDMI

Resolution:

• Host device with DisplayPort 1.2 support:

• 1 monitor - 1x HDMI or DP up to 4K/30Hz

• 1 monitor - 1x HDMI or DP up to 1080p/120Hz

• 2 monitors - 1x DP + 1x HDMI up to 2x 1080p/60Hz*.

• 2 monitors - 2x DP up to 2x 1080p/60Hz*

• 3 monitors - 1x HDMI + 1x DP + 1x DP up to 1x 1080p/60Hz + up to 2x 720p/60Hz*

• Host device with DisplayPort 1.4 support:

• 1 monitor - 1x HDMI  up to 4K/60Hz

• 1 monitor - 1x DP  up to 4K/60Hz

• 2 monitors - 1x DP + 1x HDMI  up to 2x 1440p/60Hz*

• 2 monitors - 1x DP + 1x HDMI  up to 2x 4K/30Hz*

• 2 monitors - 2x DP  up to 2x 4K/30Hz*

• 3 monitors - 1x HDMI + 1x DP + 1x DP up to 3x 1080p/60Hz*

• DisplayPort 1.4 host device with DSC support:

• 1 monitor - 1x HDMI  up to 4K/60Hz

• 1 monitor - 1x DP  up to 5K/60Hz

• 1 monitor - 1x HDMI  up to 1440p/144Hz or 1080p/240Hz

• 1 monitor - 1x DP  up to 4K/144Hz or 1440p/240Hz or 1080p/360Hz

• 2 monitors - 1x DP + 1x HDMI  up to 2x 4K/60Hz*

• 2 monitors - 1x DP + 1x HDMI or DP  up to 2x 1440p/144Hz*

• 3 monitors - 1x HDMI + 1x DP + 1x DP  up to 3x 4K/30Hz*

• 1x USB-C 3.2 Gen.2 port (10 Gbps)

• 1x USB-C 3.2 port Gen.2 (10 Gbps) + PD (Power delivery)

• 3x USB-A 3.2 port Gen. 1 port (5 Gbps)

• 2x USB 2.0 port

• 1x Ethernet GLAN RJ-45 port

• 1x 3.5 mm Combo Audio port

• LED indication

• ON/OFF switch to turn the docking station on and off

• MAC address cloning: yes (using i-tec Docker Pro software)

• VOL: S1, S2, S3

• Support for Kensington lock

• OS: Windows 11, Windows 10, macOS*, iPadOS**, Android**, Chrome OS and Linux

with the latest updates

•Product dimensions: 113 x 113 x 31.2 mm

•Product weight: 340 g

•Package dimensions: 250 x 242 x 50 mm

Quick Start

ENGLISH

Specication notes:

* The macOS operating system doesn’t support Multi Stream Transport (MST), which

means that when connected to macOS, the same image will be projected on all con-

nected monitors.

** iPadOS, Android do not support multi-screen video transfer technology, nor the extend-

ed screen option. This means that when connected to an external monitor, only the

mirrored screen will be displayed. (Not valid for androids with DEX and Easy Projection

extension)

The docking station can be used without a power adapter connected. In this case, the

video outputs, LAN (RJ-45), audio/mic and both USB 2.0 ports will always be functional.

However, the USB 3.2 ports and the USB-C data port may not work when connecting devic-

es with higher power requirements (e.g. SSDs, especially NVMe drives). In this case, the

docking station may shut down We recommend using the docking station with the power

adapter connected to ensure that all ports are used and that maximum data transfer

speeds are achieved.

Note: If connected to an Android device, the dock will only work with the power adapter

connected. The adapter is not included.

SYSTEM REQUIREMENTS

Hardware requirements:

• Devices with a free USB-C, USB4 or Thunderbolt™ 3/4 port

Requirements for the Power Delivery function:

• Devices with a free USB-C, USB4 or Thunderbolt™ 3/4 port with Power Delivery support

Video output requirements:

• Devices with a free USB-C or USB4 port that supports DisplayPort Alternate Mode or

Thunderbolt™ 3/4 port

Operating system:

•Windows 10 / 11, macOS*, iPadOS**, Android**, Chrome OS and Linux with the latest

updates

* macOS does not support Multi Stream Transport (MST). Connecting two monitors to a

macOS station will cause both monitors to display the same image.

** iPadOS, Android systems do not support multi-screen image transfer technology or the

expanded screen option. This means that only the mirrored screen will be displayed

when connected to an external monitor. (Not valid for Android devices with DEX and

Easy Projection extensions).

C31TRIPLE4KDOCKPDPRO

ENGLISH

INSTALLING DRIVERS

Windows:

Only if a problem is detected with the LAN adapter, e.g. :

In case of outages, slow network and in case of poor or no LAN detection.

You can download LAN drivers here in the Manuals, Drivers section:

https://i-tec.pro/produkt/c31triple4kdockpdpro/

MacOS:

No need to install drivers.

SAFETY INSTRUCTIONS FOR USING THE DOCKING STATION

• Do not expose to extreme temperatures and humidity.

• Use the device on at pads to avoid slipping and falling on the ground. Keep the

controls and manual for later use.

• Avoid straining the USB-C port or cable.

• Restart the product periodically using the ON/OFF button or by unplugging it from

the mains.

• Do not plug USB-C PD adapters into USB-C ports that are not marked as ports to

connect USB-C PD power adapter.

• It is recommended that you switch off the docking station at the end of the day.

In cooperation with the service department:

• Check functionality after falling into water or on the ground.

• Verify functionality when the cover is cracked.

• Complain about the device not working according to the manual.

FREQUENTLY ASKED QUESTIONS

Available on our website www-i-tec.pro under “FAQ” for this product

Quick Start

ENGLISH

GLOSSARY OF TERMS

Interface / port / connector / input / slot - the place where two devices are physically

connected.

Controller - a semiconductor component (called a chipset) in a notebook/tablet that en-

sures the operation of one of the ports.

Thunderbolt™ - is a fast hardware interface that allows you to connect devices (periph-

erals) to your computer via an expansion bus. Thunderbolt combines PCI-Express and

DisplayPort into a serial data interface. It allows daisy chaining of up to 6 additional

Thunderbolt™ devices, with Thunderbolt™ 3/4 transfer rates of up to 40Gbit/s.

USB-C / USB Type-C / USB4 / Thunderbolt™ 3/4 - is a symmetrical connector Allows

faster charging, power, dual-role (not only host, but also guest), support for alternative

modes - Alt Mode (DisplayPort, MHL, Thunderbolt 3, Power Delivery) and error notication

via Billboard device.

USB-C Power Delivery (USB-C PD) - optional feature of the USB-C connector. A connector

with this support can both charge and be charged, and supports loads from 10W to 240W

USB 3.2 / 3.1 / 3.0 / 2.0 - standard for USB interface / port for connecting various USB

devices. Various USB devices can be connected to the docking station or adapter using

USB Type-A interface. The USB Type B port is used to connect the docking station or

adapter to a laptop/tablet.

HDMI / Display Port - A standard for a digital graphics interface/port used to connect

monitors andother graphic display devices.

LAN (Local Area Network) - a local computer network, now the most common is the so-

called Ethernet, which at the docking station reaches a theoretical transfer rate of up to

2.5 Gbit/s .

Audio - a term for an audio input (microphone) or output device (headphones/speakers).

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Estación de acoplamiento de Itec

Itec

Itec TB3TRAVELDOCKPD Manual de usuario

Itec

Itec USB4DUAL4KDOCKPD Manual de usuario

Itec

Itec THUNDERBOLT TB4DUALDOCKPD Manual de usuario

Itec

Itec Advance Series Manual de usuario

Itec

Itec C31TRAVELDOCKPD Manual de usuario

Itec

Itec C31DUALDPDOCKPD65W Manual de usuario

Itec

Itec C31METAL4KDOCKPD Manual de usuario

Itec

Itec C31DUALDPDOCKPD Manual de usuario

Itec

Itec C31TRAVELEASYDOCKPD Manual de usuario

Itec

Itec U3HDMIDVIDOCKUK Manual de usuario

Itec

Itec C31TRIPLEDOCKPDPRO Manual de usuario

Itec

Itec C31DUALDOCKPDUK Manual de usuario

Itec

Itec Docking Station with Video Manual de usuario

Itec

Itec C31MINIDOCK4KPD Manual de usuario

Itec

Itec C31TRIPLE4KDOCKPD Manual de usuario

Itec

Itec C31NANODOCKPROPD Manual de usuario

Itec

Itec C31NANODOCKPROPD Manual de usuario

Itec

Itec C31DUALDPDOCKPD100W Manual de usuario

Itec

Itec C31TRIPLEDOCKPDIT Manual de usuario

Itec

Itec C31DUALDOCKPD Manual de usuario

Itec

Itec TB3HDMIDOCKPLUS Manual de usuario

Itec

Itec TB3HDMIDOCKPD Manual de usuario

Itec

Itec C31HDMIDPDOCKPD Manual de usuario

Itec

Itec U3DVIDOCKL Manual de usuario

Manuales populares de Estación de acoplamiento de otras marcas

Sony

Sony Dream Machine XDR-DS12iP Manual de usuario

Acer

Acer USB Type-C Dock II Manual de usuario

ATEN

ATEN UC-2000 Manual de usuario

Xcellon

Xcellon HDD-202 Manual de usuario

Dok

Dok CR09 Manual de usuario

Philips

Philips BTM630/12 Manual de usuario

IOGear

IOGear Travel Pro GUD3C09 Manual de usuario

RKI

RKI SDM-E2 Manual de usuario

iHome

iHome iP15 Manual de usuario

VITURE ONE

VITURE ONE MOBILE DOCK Manual de usuario

Lindy

Lindy 42984 Manual de usuario

CipherLab

CipherLab 8001 Manual de usuario

Pyle

Pyle PIPDSP2 Manual de usuario

Avol

Avol AS2350 Manual de usuario

Datalogic

Datalogic JoyaTouch Manual de usuario

Philips

Philips DC190/79 Manual de usuario

Targus

Targus DOCK315EUZ Manual de usuario

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Manual de usuario
