IRobot Roomba 4110 Manual de usuario

Model 4100

Table of Contents

Roomba Anatomy........................................................................................

Charging Roomba........................................................................................

Cleaning with Roomba..............................................................................

Roomba Features ........................................................................................

Roomba Maintenance................................................................................

Virtual Walls ....................................................................................................

Frequently Asked Questions..................................................................

Contact iRobot Corporation ................................................................

page 2-3

page 4

page 5

page 6-7

page 8-9

page 10

page 11

page 12

Roomba AnatomyRoomba Anatomy

Advanced Power

System Battery

7 Hour

Charging Brick

Filters

1 Virtual Wall®

Brush Guard Release Tabs

Vacuum Inlet

Flexible Brush

Main Brush

Edge-Cleaning Side

Brush

Cliff Sensor Openings

Contact points for

drive-on-charger.

Brush Bearings

(yellow)

Remove and clean the

brushes and bearings regularly to ensure

optimal cleaning performance. See pg.8

Dirt Detect Sensors

Before cleaning with Roomba, clear the

floor of loose objects. If you don't

vacuum over it, don't use Roomba over

it (e.g., rug tassels, power and blind

cords).

Roomba will clean based on the

cleaning mode you select. Roomba has

two cleaning modes:

Clean mode - Roomba automatically

calculates the room size and adjusts its

cleaning time appropriately. Roomba

may clean for up to 60 minutes.

Spot mode - Roomba will spiral approx-

imately 3 feet in diameter and then spi-

ral back to where it started, intensly

cleaning a localized area.

Cleaning with RoombaCharging Roomba

Place APS battery into Roomba Robotic Floorvac.

Press down on both ends.

Plug the charger directly into Roomba.

For best battery performance, always

keep Roomba plugged in.

Roomba will run for up to 120 minutes on hard

floors. Run times may vary based on floor surface.

You can use a Virtual Wall to block

off areas you don't want Roomba to enter.

(See page 10)

Charge for 7 hours.

Power light will turn solid green to indicate a

full charge.

Unplug the charger and press clean.

Cleaning Pattern

You need to charge Roomba

before cleaning for the first time.

Roomba Features

If Roomba's mission is abandoned,

always make sure the brushes and

bearings are clean.

Dirt Detect Mode

Roomba features the ability to clean more intensly in dirty areas.When Roomba finds a

particularly dirty area you will see the blue Dirt Detect light come on and Roomba will

change its cleaning pattern.

Roomba uses two sensors to recognize the dirtiest areas.To ensure optimal performance,

you may want to periodically wipe the sensors with a dry cloth. Roomba will sense heavy

debris like pepper, sand, and rice. Roomba will not sense pet hair or dust, but will pick

them up.

Roomba Stops for 3 reasons

Sensor Sensor

Mission Status:

At the end of a cleaning mission, Roomba will tell you if it has successfully completed

its mission.

Roomba Maintenance

Inspect the vacuum inlet and clean

debris as needed.

2Remove and clean the brush-

es every 5 uses.

Inspect & clean sensors.

(when you clean brushes)

Periodically clean the

sensors with cotton swabs or

compressed air.

Empty the bin over trash barrel after each use.

Empty the filter compartment after each use.

Keep

Dispose

There are a few things you can do to keep Roomba running at peak performance.

Periodically change

Roomba’s filter.

Cliff Sensors

Roomba Accessories

Virtual Walls create a keyhole shaped area that Roomba will not

enter. Virtual Walls are great for keeping Roomba in or out of

rooms, or away from cords and other spots you don't want

Roomba to clean.

Virtual Walls will automatically shut off after approximately

130 minutes.

You can set Virtual Walls to block areas up to 13 feet wide.

Remember, at 13 feet, the far end of the beam will be very

wide.

Virtual Wall

Frequently Asked Questions

What can I do if Roomba's battery does not seem to be charging?

If Roomba's battery is not charging, you should first make sure it is properly seated in Roomba.

When you insert the battery, you should hear two clicks. Then confirm that the green light on the

charging “brick” is a solid green and that the power indicator light is pulsing. If this does not work,

call customer service at 877-855-8593.

What should I do if Roomba repeatedly starts and stops, or just spins in place?

If Roomba is repeatedly starting and stopping, or just spinning in place, you may have a blocked cliff

sensor.Try cleaning the cliff sensors, located under the bumper, with a Q-tip or compressed air.You

also should remove and clean Roomba's brushes and brush bearings.

What can I do if Roomba is cleaning longer than I'd like in a particular room?

Roomba automatically calculates room size and run time based on a number of factors. Roomba

will clean for longer in rooms with more debris and furniture. Roomba also spends a little bit

longer cleaning rugs than hard floors. In an empty 8x10 room with hard floors, Roomba will clean

for approximately 20 minutes. Removing obstacles from a room will decrease the amount of time

Roomba needs to spend in a room.

Roomba Last Thoughts

The Roomba Robotic Floorvac is easy to use,

but under the hood it’s a complex robot.We’re

Roboticists, your retailers are not. If you have

questions or comments, we’re anxious to help,

please visit us at

www.irobot.com

call 877-855-8593

iRobot, Roomba, Roomba Discovery,Virtual Wall are trademarks of iRobot Corporation.

US Pat Nos 6,594,844; 6,690,134 and 6,809,490. Additional Patents Pending

Burlington, MA 01803 Version: 4100-V2
