IPazzPort KP-810 Manual de usuario

wireless Mini Keyboard-[2.4GHz]

User’s Manual

Ver:2.1

Safety Precautions

Safety Matters

To avo id injury,death of per sonnel or damag e to ghe equ ipme nt th e ope rator mus t

refer to the exp lanations in this Use r’s Manual.

Bat tery:Thereis a lithium- ion rechargea bl e bat tery in this dev ice.Don ’t wat er th is dev ice,

or put it in a humi d env ironmen t for a long time or the dev ice will be damag ed

Attention to traffic safety

(CAR PC): Do not use the deivce while driving.When you want to use it,please

park your car

Turn off this device on planes

This Electronic wireless product can disturb the communications system of

planes.

Please turn it off before boarding.

In Vicinity of dangerous goods to be shut down

In gas station and close to fuel and chemical agents and other hazardous

materials areas,please turn the device off

Turn off this devoce in hospital

Please turn the device off in areas with “no wireless device”indication

wireless devices may interfere with implanted cardiac pacemakers,hearing aids and

other

Medcal implant devices

Interference

All wireless devices may be subject to interference, thus affecting the

performance of this product.

Accissories

Only use factory specified parts.Please use supplied travel charging cable.The

use of other charging devices ma y be dangerous.

Do not point the laser be am on human or animal eyes direc tly to avo id dama ge to the eye

Overview

This is a wond erful com bo,2.4G Hz Wireless mini QWERTY keyb oard,T ouch Pad and

presenter com bo,w it h USB int erface recei ver.

This produc t consist s not only of norm al wir eless keyb oard keys,but also of mult imedia

control keys and PC gam ing control keys.It has built -in program mable smart touch pad-the

world' s first Touch pad which can be used in horizontal and verti cal direct ions. It has pow er

indicat or,RFsignal indicat or,CA PLOCK

light, low -volt age indicat or and keyp ad backlight to faci litat e the use in dark environm ents. In

additi on,i t also has a built -in pointer

Introduction

Product view

RF communication indicator

Charging Indicator

Battery capacity indicator

Caps indicator

Power Swi tch

USB Charging Port C

FGHJKL

VBNM

TYUIOP

34567890

#$%^&*(~

Alt

==//??

;

Enter

Ctrl+Alt+Del

F2 F3 F4 F5 F 6 F 7 F 8

Pr tSc

BACK

DelDel

Esc

Tab

Cap

Shift Z

Fn Ctrl

Fn+Ctrl=

"start" short cut

Pointer switch

Fn+Alt=

Touch Pad

90-degree flip

Left mouse

button

Direction keys

Fn+Up=Page Up

Fn+Down=page Down

Right mouse

button

Laser

Pointer

Touch Pad

USB mini Receiver

Multimedia Control Keys

F1 to F8 keys

Backspace key

Fn Alt

PAIR/CONNECT

Touchpad

The touchpad can be used in a

To switch between horizontal or

Horizontal or ver tical pos ition

vertical mode , hold the Fn key

RFRF

and hit the Alt key

Connecting the receiver.

Slide the receiver out from the side of keyboard, an d insert to the devices with a stadard

USB interface. Once connected, slide the power switch to the "ON" position located on

the left side of the unit to establish the connection.

Enabl e the backl ight

Once the key boa rd has establ ished a con nec tion to the receiver, the bac klight key s wil l

aut omat ically turn on for 3 secon ds. The bac klight wil l turn off after 3 secon ds to preserve

bat tery life. To manual ly tur n the bac klight on, simply press the key specified abo ve in the

diagr am..

Aut o sl ee p and wake feature .

The keyboard also features an au to sleep and aut o wake mod e. If there is a long per iod of

inactivity, the keyboard wil l automa tically go inot sleep mode. During the sleep mode,

the user ca n wake the uni t up by pre ssing any key. The 2.4GHz receiver and key board's

RF indicator wi ll continue to flash and wil l not power down.

Switch off the keyb oard aft er use.

After finis h usi ng the keyboard, push the switch to the off posit ion. This tur ns off the

pow er, of the keyboard. The USB recei ver should be plugged out from the PC and then ins ert

back in the keyboard so it is being kept saf ely.

Charging the ba ttery.

The device with built-in li thium-ion ba ttery,please use only ap proved da ta lines and

chargers

Note: fully charge the unit befor e op erating for th e first time. This de vi ce can be used

when charging , bu t wi ll extend the ch arging time;

Whe n ba ttery is lo w, the lo w voltage li ght will flash to warn th e us er. The unit will

automatically turn off if th e battery has been de pl eted.

Laser point er

Using the la ser pointer only re qu ires that the ke yboard will be tu rned on. Press the laser

Switch as long as yo u wan t to use the laser pointer.

Appendix:

Technical pa ram eters

Specificat ion

Measureme nt s(L x W x H): 151mm x 59mm x 12 .5mm

Weight(grams ): 100g/0.22pound

Ope ration al rang e: up to 10 met ers/30 feet

Transmit power: +4db Ma x

Ope ration voltage: 3.3V

Ope ration current: <80mA

Cha rging current: <300mA

Sleep current: <1mA

Computer system requirement

Windows 2000

Windows XP

Windows Vista, Windows CE, Windows 7

Linux(Debian-3.1, Redhat-9.0,Ubuntu-8.10 Fedora-7.0 tested)

Maintenance

Do not attempt to disassemb le the device or re place rechargeable ba ttery. Doing so

will void the warranty.

The battery will discharge if stored for a long period of time wi thout usage.

Use the specified charger. Disconnect the device after the battery has been fully

charged. Ov ercharging the battery will shorten the life of the battery.

Do not expose the deice in the ex treme heat or cold. Extreme temp erature will cause

the life span of the battery to shorten.

Use only a damp cloth with mi ld soap to cl ean the de vice. Solvents and ot her

cleaning agents may cause da ma ge to the de vice.

Troubleshooting

Below are some basic troubleshooting scenarios for the de vice. Please contact support

from the place of purchase if you are unable to resolve any issues with de vice

Problem

Unit does not

respond

1. Low battery power

2. Unit is not turned

1. Charge the device for at

least 15minutes

2. Check if te switch

selected to the "ON"

position

Keyboard cannot

establish a

connection to the

receiver

1. The receiver may

not be inserted

correctly

2.Possible wireless

interference with

another device

1. Disconnect and reconnect

the receiver to the USB

port

2. Change the channel of the

device by pressing and

holding the Fn+F1 key for

10 seconds and let the unit

reconnect.

The mouse pointer

moves erratically

and/or

unresponsive

1. Device may not be

within optimal

range of the

receiver

2. Dust or oil on the

touchpad

1. Bring the unit closer to the

receiver.

2. Clean the touchpad with a

damp cloth.

Possible issue Solution

The unit does not

charge

1. Defective battery

2. Check connection

1. Contact your local dealer

for replacement

2. Verify if the device is

securely connected to the

charger.
