Invion GPS-4V2 Manual de usuario
GPS NAVIGATION SYSTEM
GPS-4V2
INSTRUCTION MANUAL
2
Congratulations on choosing your new Invion product. We have
every expectation that you will be completely satised with your new
purchase.
To always guarantee optimal function and performance of your product, we
would ask the following:
Before using the product for the rst time, carefully read the operating
instructions and adhere to the safety precautions!
All activities at and with this product may only be carried out as described
in these operating instructions.
Please be sure to include the operating instructions in case you pass
along this product to someone else.
Packaging:
This product is delivered in protective packaging to prevent transportation
damage. Packaging materials are raw materials and can therefore be
recycled. Please recycle these materials.
•
•
•
3
Content
I. Brief introduction of Hardware..................................................5
II. Navigation Manual.....................................................................7
1. Introduction......................................................................................7
Features.............................................................................................7
Guided Tour .......................................................................................7
Technical Support ..............................................................................7
2. Getting Started.................................................................................8
End User License Agreement ............................................................8
Driver Warning ...................................................................................8
Initial Conguration Wizard................................................................8
Menus ................................................................................................9
Main Map .........................................................................................14
GPS Not Found ...............................................................................15
Map Views .......................................................................................15
Point on the Map..............................................................................16
Screen Buttons ................................................................................16
Cycling Through Screens.................................................................17
3. Search for a Location ....................................................................17
Enter Address ..................................................................................17
Recent Locations .............................................................................22
My Favorites ....................................................................................23
POI (Points of Interest) ....................................................................26
Route Manager ................................................................................29
Map Manager...................................................................................34
Extras...............................................................................................36
4. Settings...........................................................................................39
Prompts ...........................................................................................39
Time Zone Settings..........................................................................40
Language Settings...........................................................................40
GPS Settings ...................................................................................40
Demo Button....................................................................................41
4
5. Installation......................................................................................42
PC Requirements ............................................................................42
Installing the Console ......................................................................42
Console Toolbar...............................................................................42
Map Screen Interface ......................................................................43
Installing a Map................................................................................44
Load Map.........................................................................................44
Remove Map ...................................................................................44
Import Favorite Location ..................................................................44
Export Favorite Location..................................................................46
III. MP3/Movie Player ...............................................................................48
IV. Specications ....................................................................................50
V. Legal .....................................................................................................51
1. Notices, Disclaimers, and Terms of Use .....................................51
2. Copyright Notice............................................................................52
3. Safety advice..................................................................................53
4. Caution ...........................................................................................54
5. FCC compliance.............................................................................55
VI. Claims & Warranties ..........................................................................56
5
I. Brief introduction of Hardware
TOUCH SCREEN
BULIT-IN GPS ANTENNA
EXTERNAL ANTENNA
SOCKET
SD CARD SLOT *
RESET
USB *
CHARGE INDICATOR
1.
2.
3.
4.
5.
6.
7.
POWER / DEVICE TOP MENU
Long press to turn the unit on and
turn off / Short press when the
device is on to switch to the Top
menu.
HEADPHONE JACK
DC IN
TOUCH PEN
8.
9.
10.
11.
ABOUT THE TOUCH SCREEN
Before the unit starts up completely, do not touch the touch screen.
Otherwise, the touch screen may fail to function.
The navigation device is mainly operated by touching the buttons on the
touch screen.
If nothing happen when you touch the buttons on the touch screen, move
your hand or the touch pen from the screen and touch the button again.
Do not touch any button which is grayed out.
Clean the touch screen with a soft cloth.
•
•
•
•
•
23
4
5
9
11
10
8
1
7
6
Standard Package
Before getting started with your GPS, check to see that your Invion
package includes the following items. If you are missing any parts, please
contact your Invion dealer immediately.
● GPS Unit ● SD Card
● Owner’s Manual ● Card Reader (optional)
● DVD-ROM (optional) ● Accessories (see Specications, page 50)
6
SIRF III Chipset
operates behind athermic windshield
CONNECTION
Connect to Car Power
Connect the mini plug of the car adapter to the DC IN jack on the side
of the GPS device.
Connect the other plug of the car adapter into the car cigarette socket.
* SD CARD SLOT: Insert a SD/MMC card containing the navigation
software, songs or videos to load them on the GPS
device.
* For loading MP3 and Movies to the SD card, we recommend using a
separate SD card reader / writer.
* USB: For installation use only.
1.
2.
90°
7
II. Navigation manual
1. Introduction
Welcome to the world of mobile navigation! With Invion, you can steer into
a new era of mobile navigation. Simple operation, clear maps in 2D or 3D
mode as well as numerous innovative features and functions have made
Invion the essential guide for every traveler – whether in the car, on foot or
by bike.
Features
Invion provides the following features for easy navigation:
Route calculation within seconds
High quality 2D/3D maps with display of street names
QuickNav button for travel to a predetermined address
Address input via a full-size keyboard optimized for nger input
Storing of any location one click away
Cross border navigation without switching maps
Address retrieval from History, Favorites, or Points of Interest (POI)
Planning and optimizing of multi-stop trips
Car navigation with fastest or shortest route
Pedestrian navigation in parks and town centers
Fast installation, no activation
Short tutorial for an easy start
Day and night views and turn-by-turn information
Guided Tour
When you rst start the navigation system, a message box appears
prompting you to open the Guided Tour program. The Guided Tour is an
excellent way of becoming familiar with the different navigation features
available. You can also start the Guided Tour any time, by tapping the
Tutorial button from the Extras menu.
Technical Support
If you have other questions about the software, please contact your
supplier.
•
•
•
•
•
•
•
•
•
•
•
•
•
8
2. Getting Started
End User License Agreement
When you start the device for the rst time, the End User License Agreement
screen appears. Please review the license information and tap the Agree
button. The End User License Agreement screen appears for each map
change where the user has not agreed to the license information.
Driver Warning
When you start, the Driver Warning Message screen appears.
Figure 1- Driver Warning Agreement
Please take a moment to review the information provided before tapping the
Agree button. Select the “Do not display this warning again” checkbox to
skip this message when starting.
Initial Conguration Wizard
This wizard lets you easily congure the system settings before using the
device by providing a step-by-step setup process to select an option for:
Language Settings – Lets you set text and voice language preferences.
GPS Settings – Lets you set GPS congurations.
Units of Measure – Lets you specify the system measurement units.
Prompts – Lets you specify the general navigation prompts that you want
to appear and how direction notications are displayed (for example, Text
or Symbol).
QuickNav Settings – Lets you specify an address or point of interest that
the device navigates to when you tap the QuickNav button on the Main
Map screen.
Tap the Next button to move from screen to screen. Tap the Done button
on the QuickNav screen to save your conguration choices and exit the
wizard. The top menu appears.
•
•
•
•
•
•
9
Menus
Destinations - Provides the central navigation features, such as Addresses,
Recent Locations, My Favorites, and POI (Points of Interest).
Options – Provides 2D/3D and Day/Night map view options, and the
following submenus:
Route Manager – Displays features relating to route information,
avoiding roads, and setting up the QuckNav route.
Map Manager – Displays features relating to selecting maps and
specifying map settings.
Extras – Displays add-on features.
Settings – Provides setting options to congure the navigation system.
You can press the Menu button from the Main Map screen to display
the top menu, as shown below.
Destinations Menu
The Address button lets you navigate to an address, as described in Enter Address
(see “Enter Address” on page 17).
The Recent Locations button lets you navigate to a previously visited destination,
as described in Recent Locations (on page 22).
The My Favorites button lets you navigate to a favorite location, as described in My
Favorites (on page 23).
Figure 2 - Destinations Menu
The Points of Interest button lets you navigate to thousands of interesting places.
For more information, see POI (Points of Interest) (on page 26).
The Cancel Route button stops the current navigation.
•
•
•
10
The Map button lets you return to the Main Map screen.
The Next button lets you move between the Destinations and
Options menus.
Options Menu
The Day/Night Mode toggle button lets you display
the map view for either day or night driving. For a display
of day and night maps, see Map Views (on page 15).
The 2D/3D Mode toggle button lets you display the map
view in 2-dimensional or 3-dimensional views for either
day or night driving. For a display of 2D and 3D maps,
see Map Views (on page 15).
Figure 3 - Options Menu
The Route Manager button displays a menu that lets you select from the following
route buttons: Show Route, Turn-by-Turn, Route Playback, Avoid Road, and
QuickNav. For more information, see Route Manager (on page 29).
The Map Manager button displays a menu that lets you select from the following
map buttons: Select Map, Pedestrian Mode, Free Map Browsing, Units of Measure,
and Map Settings. For more information, see Map Manager (on page 34).
The Extras button displays a menu that lets you select additional features. For more
information, see Extras (on page 36).
Tabla de contenidos
Otros manuales de GPS de Invion
Invion
Invion GPS-3V906-IUS Manual de usuario
Invion
Invion GPS-5V1 Manual de usuario
Invion
Invion GPS-4V106-IUS Instrucciones de montaje
Invion
Invion GPS-3V106-IUS Manual de usuario
Invion
Invion GPS-4V606-IUS Manual de usuario
Invion
Invion GPS-4V206-IUS Instrucciones de montaje
Invion
Invion GPS-4V506-IUS Manual de usuario
Invion
Invion GPS-7V106-IUS Instrucciones de montaje
Invion
Invion GPS-5V106-IUS Instrucciones de montaje
Invion
Invion GPS-3V106-IUS Instrucciones de montaje
