Invacare RBL250 Instrucciones de montaje

NOTE: Check all parts for shipping damage before

using. In case of damage, DO NOT use. Contact the

Dealer/Carrier for further instructions.

SAFETY SUMMARY

The following recommendations are made for the

safe installation of the Mounting Kit on the Reli-

ant Bath Lift (RBL250).

GENERAL WARNING

DO NOT assemble or use this kit without

first reading and understanding this in-

struction sheet. If you are unable to un-

derstand the Warnings, Cautions or Instruc-

tions in this Instruction Sheet and in the

Owner's Operating and Maintenance

Manual (Part No. 1081003) provided with

the Bath Lift. contact a healthcare pro-

fessional, dealer or technical personnel

before attempting to install this kit, other-

wise, injury or damage may occur.

REPLACING THE BATH LIFT

MOUNTS

Removing the Bath Lift Seat (FIGURES 1-7)

NOTE: Refer to the GENERAL WARNINGS in the

SAFTY SUMMARY of this Instruction Sheet.

1. Raise the Bath Lift seat by pressing the UP (é) but-

ton on the pendant (FIGURE 1).

NOTE: The lift will automatically stop at the top and

bottom limits if UP/DOWN buttons are not released.

2. Remove the battery pack by grasping the handgrip

on battery pack and pulling upwards (FIGURE 2).

FIGURE 2 - REMOVING THE BATTERY PACK

DESCRIPTION QTY

Suction Cups 2

End Plugs 4

Locking Clips 2

Rubber Pads 2

Instruction Sheet 1

This kit contains the following:

FIGURE 3 - RELEASING THE SEAT

WARNING

To prevent pinching injury between seat

back and motor shroud when removing/

installing the seat, DO NOT grasp seat any-

where other than at the recess at the top

(FIGURE 3), the opening at the bottom of

the seat or the lip where the battery pack

was. CAUTION

DO NOT remove the seat until the bath Lift

is raised to the upper limit. Otherwise dam-

age may occur.

3. To release the seat, press and hold the spring loaded

chair release button (FIGURE 3).

Spring Loaded

Chair Release

Button

Recess

Seat

4. While holding the spring loaded chair release but-

ton with one hand, grasp the seat bottom firmly with

your other hand.

5. Lift the seat up until the slide block comes free of the

grooves on the Bath Lift frame to remove the seat

from the frame (FIGURE 4).

FIGURE 1 - RAISING THE BATH LIFT

Pendant

INSTALLATION WARNINGS

When installing or removing the Battery

pack ALWAYS hold the battery pack firmly,

otherwise injury or damage may result.

To prevent frame from tipping when raising

or lowering the seat, either suction the frame

to the floor or place one foot on the frame

base when removing/installing the seat.

PULL UP TO

REMOVE

Battery Pack Frame

Handgrip

Motor Shroud Battery Pack

Reliant Bath Lift (RBL250) Mounting Kit

Assembly, Installation and O erating Instructions

Kit No. 1085143

Groove

FIGURE 4 - REMOVING THE SEAT

LIFT THE SEAT

Frame

Slide Block

6. Install the battery pack by grasping the handgrip

and sliding the battery pack onto the charger con-

nector on the frame (FIGURE 5).

NOTE: The battery pack should fit snugly and not

wobble.

7. Lower the Bath Lift by pressing the DOWN (ê)

button on the pendant (FIGURE 6).

FIGURE 6 - LOWERING THE BATH LIFT

Down

Pendant

NOTE: The lift will automatically stop at the top and

bottom limits if UP/DOWN buttons are not released.

REMOVING THE BATH LIFT FROM

THE BATHTUB (FIGURE 8)

WARNING

Use proper lifting techniques to avoid in-

jury. Keep back straight and bend knees

when lifting components of the Bath Lift.

CAUTION

ALWAYS release suction cups from bathtub

bottom BEFORE removing frame to prevent

damage to the frame or bathtub.

REPLACING SUCTION CUPS

(FIGURES 9-12)

1. Lean Bath Lift backwards so that the back of the frame

is resting on the floor.

8. Remove the battery pack by grasping the handgrip

on battery pack and pulling upwards (FIGURE 7).

WARNING

Always point the screwdriver away from

your body. Otherwise injury may occur.

2. Place screwdriver behind the lip of the EXISTING end

plug (FIGURE 9).

3. Use a hammer to gently tap the back of the screw-

driver until the EXISTING end plug comes free.

FIGURE 5 - INSTALLING THE BATTERY PACK

PUSH DOWN

TO INSTALL

Battery Pack Frame

Handgrip

FIGURE 7 - REMOVING THE BATTERY PACK

PULL UP TO

REMOVE

Battery Pack Frame

handgrip

1. Tilt the frame forward towards the drain or gently pull up

on the suction cup loops to release the suction cups.

2. Remove frame from bathtub (FIGURE 8).

FIGURE 8 - REMOVING THE BATH LIFT FROM

THE BATHTUB

TILT FRAME

FORWARDS

Frame

Bathtub

Suction Cup

Rubber Pad

Suction Cup Loop

Base Frame

NOTE: Suction Cup

removed for clarity.

Screwdriver

FIGURE 9 - REMOVING THE EXISTING END

PLUG

End Plug

4. Twisting EXISTING suction cup from side, pull the the

suction cup off of the bath lift base frame (FIGURE 10).

8. Repeat STEPS 2-7 on second suction cup.

9. Tilt the Bath Lift foward so that it is resting in the

upright position.

10. Perform one (1) of the following:

A. Replace Rubber Pads, refer to REPLACING

THE RUBER PADS in this instruction sheet.

B. Reinstall the Bath Lift into the bath tub, refer to

INSTALLING THE BATHLIFT INTO THE

BATH TUB in this instruction sheet.

REPLACING THE RUBBER PADS

(FIGURES 12-14)

1. Tilt Bath Lift foward so that it rests on the front por-

tion of the frame and top edge of the top cover.

5. Leave EXISTING locking clip on the bath lift base frame

(it is glued in place).

6. Install the NEW suction cup by reversing STEP 4.

7. Place NEW end plug into the bath lift base frame and

using a hammer gently tap the end plug securely into

position (FIGURE 12).

EXISTING Suction Cup

EXISTING Locking Clip

Bath Lift

Base Frame

FIGURE 11 - INSTALLING END PLUG

New End

Plug

Locking Clip

Suction Cup

Base Frame

FIGURE 10 - REMOVING THE EXISTING

SUCTION CUP

WARNING

Always point the screwdriver away from

your body. Otherwise injury may occur.

4. Twisting EXISTING Rubber Pad from side,pullthe the

suction cup off of the bath lift base frame (FIGURE 13).

5. Install the NEW rubber pad by reversing STEP 4.

6. Place NEW end plug into the bath lift base frame and

use a hammer to gently tap the end plug securely into

position (FIGURE 14).

7. Repeat STEPS 2-6 on second rubber pad.

8. Tilt the Bath Lift back to the upright position.

9. Reinstall the Bath Lift into the bath tub, refer to

INSTALLING THE BATHLIFT INTO THE BATH TUB

in this instruction sheet.

2. Place screwdriver behind the lip of the EXISTING end

plug (FIGURE 12).

3. Use a hammer to gently tap the back of the screw-

driver until the EXISTING end plug comes free.

FIGURE 14 - INSTALLING END PLUG

NEW RubberPad

Bath Lift Base Frame

NEW End Plug

EXISTING End Plug

Bath Lift

Base Frame

NOTE: Rubber Pad

removed for clarity.

Screwdriver

FIGURE 12 - REMOVING THE EXISTING

END PLUG

FIGURE 13 - REMOVING THE EXISTING

RUBBER PAD

EXISTING Rubber Pad

Bath Lift Base Frame

INSTALLING THE BATH LIFT INTO

THE BATHTUB (FIGURE 15)

NOTE: Refer to the GENERAL WARNINGS in the

SAFTY SUMMARY of this Instruction Sheet.

1. Clean tub and wipe suction cups with a damp cloth.

2. Place the bath lift base frame in the bathtub (FIG-

URE 15).

3. Position the rear pads of the frame just in front of the

curve at the bottom of the back of the bath.

WARNING

Lifting column MUST be in lowest position

BEFORE installing frame to prevent tipping.

The frame should be placed into an EMPTY

bathtub.

1. Raise the bath lift all the way up by pressing the

UP (é) button on the pendant (FIGURE 16).

NOTE: The lift will automatically stop at the top and

bottom limits if UP/DOWN buttons are not released.

Reinstall Seat onto Bath Lift Frame

(FIGURES 16-18)

NOTE: If necessary, reinstall the battery pack on the frame.

Back of

the

Bathtub

Frame

Suction Cup

Rubber Pad

Front of the Bathtub

(fixture end)

FIGURE 15 - INSTALLING THE BATH LIFT INTO

THE BATH TUB

FIGURE 16 - RAISING THE BATH LIFT

Pendant

2. Remove the battery pack by grasping the handgrip

on battery pack and pull upwards (FIGURE 17).

FIGURE 17 - REMOVING THE BATTERY PACK

PULL UP TO

REMOVE

Battery

Pack

Frame

3. Lower the seat onto the frame, ensuring that the slide

block on the back of the chair slides down the two (2)

grooves on the frame (FIGURE 18).

NOTE: The seat MUST be lowered onto the frame until

the spring loaded chair release button locks in place and

an audible "click" is heard.

4. Position the Bath Lift in the bath tub, refer to POSI-

TIONING THE BATH LIFT FRAME IN BATH TUB in

this Instruction Sheet

Frame

FIGURE 18 - INSTALLING THE SEAT

Slide

Block Groove

Seat

LOWER

SEAT

2. Ensure the pads and suction cups are positioned

flat on the bottom of the bathtub.

NOTE: Pull up on suction cup loops to release suc-

tion cups from bathtub bottom.

3. Press firmly down onto the two (2) front suction cups

to attach the frame securely to the bottom of the bath.

1. Position the frame to align the line on the entry/exit

side flap with the inside edge of the bathtub as

shown in the FRONT VIEW of FIGURE 19.

Positioning the Bath Lift Frame in the

Bathtub (FIGURE 19)

WARNING

The frame must be positioned so that the

side flap of the seat on the entry/exit side

of the bathtub is fully supported by the

side of the bathtub. The inside edge of

the bathtub MUST be aligned with the line

on this side flap.

FIGURE 19 - POSITIONING THE BATH LIFT IN THE BATHTUB

Entry/Exit

Side Flap

Position of Line on Side Flap

Seat

Inside Edge

of Bathtub

PROPER POSITIONING OF

ENTRY/EXIT SIDE FLAP

Side Flap Hinge

NOTE: Suction Cups and

Ruber Pads must be flat on

bottom of bathtub

Suction Cup

Suction Cup Loop

Side Flaps

Seat

Frame

Bathtub

PRESS DOWN ON

SUCTION CUP

NOTES

PLEASE NOTE: THE WARRANTY BELOW HAS BEEN DRAFTED TO COMPLY WITH FEDERAL LAW

APPLICABLE TO PRODUCTS MANUFACTURED AFTER JULY 4, 1975.

This warranty is extended only to the original purchaser/user of our products.

This warranty gives you specific legal rights and you may also have other legal rights which

vary from state to state.

Invacare warrants the products manufactured to be free from defects in materials and

workmanship for a period of one (1) year from the date of purchase. If within such

warranty period any such product shall be proven to be defective, such product shall

be repaired or replaced, at Invacare’s option. This warranty does not include any

labor or shipping charges incurred in replacement part installation or repair of any such

product. Invacare’s sole obligation and your exclusive remedy under this warranty

shall be limited to such repair and/or replacement.

For warranty service, please contact the dealer from whom you purchased your Invac-

are product. In the event you do not receive satisfactory warranty service, please write

directly to Invacare at the address on the back page, provide dealer’s name, address,

date of purchase, and indicate nature of the defect.

Invacare Corporation will issue a serialized return authorization. The defective unit or parts

MUST be returned for warranty inspection using the serial number, when applicable as

identification within 30 days of return authorization date. Do not return products to our

factory without our prior consent. C.O.D. shipments will be refused; please prepay shipping

charges.

LIMITATIONS AND EXCLUSIONS: THE FOREGOING WARRANTY SHALL NOT APPLY TO SERIAL

NUMBERED PRODUCTS IF THE SERIAL NUMBER HAS BEEN REMOVED OR DEFACED, PRODUCTS

SUBJECTED TO NEGLIGENCE, ACCIDENT, IMPROPER OPERATION, MAINTENANCE OR STOR-

AGE, PRODUCTS MODIFIED WITHOUT INVACARE’S EXPRESS WRITTEN CONSENT (INCLUDING,

BUT NOT LIMITED TO, MODIFICATION THROUGH THE USE OF UNAUTHORIZED PARTS OR AT-

TACHMENTS; PRODUCTS DAMAGED BY REASON OF REPAIRS MADE TO ANY COMPONENT

WITHOUT THE SPECIFIC CONSENT OF INVACARE, OR TO A PRODUCT DAMAGED BY CIRCUM-

STANCES BEYOND INVACARE’S CONTROL, AND SUCH EVALUATION WILL BE SOLELY DETER-

MINED BY INVACARE. THE WARRANTY SHALL NOT APPLY TO PROBLEMS ARISING FROM NOR-

MAL WEAR OR FAILURE TO ADHERE TO THE INSTRUCTIONS IN THIS MANUAL.

THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS WARRANTIES.

IMPLIED WARRANTIES, IF ANY, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE, SHALL NOT EXTEND BEYOND THE DURATION OF THE

EXPRESSED WARRANTY PROVIDED HEREIN AND THE REMEDY FOR VIOLATIONS OF ANY IM-

PLIED WARRANTY SHALL BE LIMITED TO REPAIR OR REPLACEMENT OF THE DEFECTIVE PROD-

UCT PURSUANT TO THE TERMS CONTAINED HEREIN. INVACARE SHALL NOT BE LIABLE FOR ANY

CONSEQUENTIAL OR INCIDENTAL DAMAGES WHATSOEVER.

SOME STATES DO NOT ALLOW EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUEN-

TIAL DAMAGE, OR LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE

EXCLUSIONS AND LIMITATIONS MAY NOT APPLY TO YOU.

THIS WARRANTY SHALL BE EXTENDED TO COMPLY WITH STATE OR PROVINCIAL LAWS AND

REQUIREMENTS.

LIMITED WARRANTY

Invacare Cor oration www.invacare.com

USA

One Invacare Way Invacare is a registered trademark of Invacare Cor oration.

1999 Invacare Cor oration

44036-2125

800-333-6900 Form No. 98-328 Part No. 1085311 Rev A (1)-1/00

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Ayuda a la movilidad de Invacare

Invacare

Invacare Balnea Manual de usuario

Invacare

Invacare Cascata Manual de usuario

Invacare

Invacare Personal Back Manual de usuario

Invacare

Invacare ProntoTM R2TM Manual de instrucciones

Invacare

Invacare Aquatec 900 Manual de usuario

Invacare

Invacare Birdie Manual de usuario

Invacare

Invacare InTouch 1143199 Manual de operación

Invacare

Invacare 9805 Manual de usuario

Invacare

Invacare RHL450-1 Instrucciones de montaje

Invacare

Invacare Front Anti Tippers 1326 Manual de usuario

Invacare

Invacare Camlock Upgrade Kit 1052250 Manual de usuario

Invacare

Invacare BUZZ HMV Manual

Invacare

Invacare HMV Highly 300 Manual de operación

Invacare

Invacare Solara/Spree GT 1098319 Manual de usuario

Invacare

Invacare Dolomite Gloss 450 Manual de usuario

Invacare

Invacare Lynx L-3 Manual de usuario

Invacare

Invacare H140 Manual de usuario

Invacare

Invacare Fixed Released Rail/Cane Clamps Manual de usuario

Invacare

Invacare Dolomite Melody Series Manual de usuario

Invacare

Invacare Recline Manual de usuario

Invacare

Invacare Deluxe Three-Position IH6065 Manual de usuario

Invacare

Invacare TDX SP Manual de usuario

Invacare

Invacare WALKING TUTOR WT 200 Manual de usuario

Invacare

Invacare MB-54 Instrucciones de montaje

Manuales populares de Ayuda a la movilidad de otras marcas

Alber

Alber Scalamobil iQ Manual de usuario

Ferno

Ferno CCT-PX Manual de usuario

HEPRO

HEPRO Gripo Manual de usuario

Otto Bock

Otto Bock Pheon 3R62 Manual de usuario

NRS Healthcare

NRS Healthcare M11090 Manual de usuario

Medline

Medline MDS86835DSHEC Guía de instalación

Guldmann

Guldmann Twin Turner II Manual de usuario

Drive

Drive ROOMBA Manual de usuario

Gate

Gate Balder Manual de usuario

Decon wheel

Decon wheel TNS Notos Manual de usuario

ExoAtlet

ExoAtlet ExoAtlet-II Manual de usuario

Rhythm Healthcare

Rhythm Healthcare B3800F Manual de usuario

AMF-BRUNS

AMF-BRUNS PROTEKTOR Manual de usuario

Drive DeVilbiss Healthcare

Drive DeVilbiss Healthcare OTTER Manual de usuario

Rhythm Healthcare

Rhythm Healthcare C500U Manual de usuario

Lumex

Lumex RJ4200A Manual de usuario

Rebotec

Rebotec Jumbo Manual de usuario

Rehaforum MEDICAL

Rehaforum MEDICAL PR50548 Manual de usuario
