Inter-m PP-9113 Manual de usuario
SERVICE
MANUAL
P R E
AMPLIFIER
PP-9113
ELECTRICAL PARTS LIST
Ref No. Part No. Description Value
MAIN B'D (4005106000)
Q101-115 Q201 2008606104-T TR NPN KTC3198-Y-AT TO-92 KTC 3198Y
Q203
Q403 2008606105-T TR NPN KTA1266-Y-AT TO-92 KTA1266Y
Q202 Q401-402 2008606998-T KTD1302-AT 2SD 1302R
D501-4 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N4006*4
D401-402 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006
D505-507
D403 2058304107 DIODE SCH0TTKY SB-150 (SR105) SB-150
IC115 2118010332 IC NJM 5532DD JRC NJM 5532DD
IC101 IC103 2118010432 IC NJM2068DD JRC NJM 2068DD
IC105 IC107
IC111
IC102 IC104 2118010590 IC NJM4558D JRC NJM 4558D
IC106
IC108-110
IC112-114
IC401-402 2128610900 IC KA7815 COMMON 7815
FB101-114 2648609900 FERITE BEAD H5B H5B
R344-345 R606 3009100973 RES CF 56K 1/5W J N 10
R195 R211 R221 3009102973 RES CF 1K 1/5W J N 1K
R232 R243 R299
R301 R310 R402
R263-273 R281 3009103973 RES CF 10K 1/5W J N 10K
R317 R337-339
VR101
R196-197 R209 3009104973 RES CF 100K 1/5W J N 100K
R254-255 R262
R297 R302-303
R306-307
R311-312
R326-327 R602
R140 R155 R170 3009105973 RES CF 1M 1/5W J N 1M
R185 R202 R215
R220 R225 R231
R236 R242 R247
R324 R601
1 / 8
R253 3009109973 RES CF 1 1/5W J N 1
R191 3009121973 RES CF 120 1/5W J N 120
R109 R124 R194 3009123973 RES CF 12K 1/5W J N 12K
R212 R223 R233
R244 R319 R335
R105-106 3009124973 RES CF 120K 1/5W J N 120K
R121-122
R136-137
R141-142
R151-152
R156-157
R166-167
R171-172
R181-182
R186-187
R203-204 R219
R230 R241
R250-251 R348
R231A
R101-102 3009152973 RES CF 1.5K 1/5W J N 1.5K
R117-118
R132-133
R147-148
R162-163
R177-178 R200
R340 R343
R274-275 R304 3009153973 RES CF 15K 1/5W J N 15K
R308
R111-112 3009154973 RES CF 150K 1/5W J N 150K
R126-127
R404 3009182973 RES CF 1.8K 1/5W J N 1.8K
R603-604 3009183973 RES CF 18K 1/5W J N 18K
R314 3009202973 RES CF 2K 1/5W J N 2K
R295-296 R315 3009222973 RES CF 2.2K 1/5W J N 2.2K
R332
R214 R224 R235 3009223973 RES CF 22K 1/5W J N 22K
R245
R288 R305 R309 3009272973 RES CF 2.7K 1/5W J N 2.7K
ROO1
R328 3009273973 RES CF 27K 1/5W J N 27K
2 / 8
R256-257 R261 3009302973 RES CF 3K 1/5W J N 3K
R294 R403 3009330973 RES CF 33 1/5W J N 33
R405 R501 3009332973 RES CF 3.3K 1/5W J N 3.3K
R110 R114 R129 3009333973 RES CF 33K 1/5W J N 33K
R144 R159 R174
R189 R206 R217
R227 R238 R249
R289 R291-292
R330
R103-104 R113 3009334973 RES CF 330K 1/5W J N 330K
R119-120 R128
R134-135 R143
R149-150 R158
R164-165 R173
R179-180 R188
R192-193 R205
R216 R228 R237
R248 R329 R401
R125 3009394973 RES CF 390K 1/5W J N 390K
R279 R322 3009472973 RES CF 4.7K 1/5W J N 4.7K
R198 R201 R318 3009473973 RES CF 47K 1/5W J N 47K
R323
R293 3009474973 RES CF 470K 1/5W J N 230V 50Hz
R108 R116 R131 3009560973 RES CF 56 1/5W J N 56
R146 R161 R176
R208 R213 R222
R226 R234 R240
R246 R276 R290
R300 R320 R336
R258-259 R286 3009562973 RES CF 5.6K 1/5W J N 5.6K
R107 R123 3009563973 RES CF 56K 1/5W J N 56K
R277-278
R283-284
R333-334
R341-342
R199 3009564973 RES CF 560K 1/5W J N 560K
R280 R313 3009681973 RES CF 680 1/5W J N 680
R138-139 3009683973 RES CF 68K 1/5W J N 68K
R153-154
R168-169
3 / 8
R183-184
R210 3009753973 RES CF 75K 1/5W J N 75K
R346-347 3009820973 RES CF 82 1/5W J N 82
R115 R130 R145 3009821973 RES CF 820 1/5W J N 820
R160 R175 R190
R207 R218 R229
R239 R252 R298
R285 R316 R406 3009822973 RES CF 8.2K 1/5W J N 8.2K
R408
R260 R321 3009823973 RES CF 82K 1/5W J N 82K
R501A 3039100575-T RES MO 10 2W JR 10 2W
R409 3039560575-T RES MO 56 2W J RADIAL 56 2W
C403 C501 3408247161 CAP RSA 470UF 35V SNAP 13 P 470/35
C161 C168 C175 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50
C182 C189-190
C193 C198 C203
C206 C208
C210-211 C213
C221 C230
C108 C116 C124 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25
C132 C140 C148
C159 C166 C174
C180 C188 C223
CR145
C105 C113 C121 3409210971-T CAP AF RSG 1UF 50V 5 P 1/50
C129 C137 C145
C150 C156 C163
C170 C178 C184
C220
C106 C114 C122 3409222071-T CAP AF RSG 22UF 50V 5 P 22/50
C130 C138 C146
C157 C173 C186
C195-197 C212
C225 3409222141-T CAP AF RSG 220UF 25V J 8 P 220/25
C149 C264 C401 3409222171-T CAP AF RSG 220UF 50V SG 10 P 220/50
C224 C227 C229 3409233971-T CAP AF RSG 3.3UF 50V 5 P 3.3/50
C101-104 C107 3409247041-T CAP AF RSG 47UF 25V 5 P 47/25
C109-112
C117-120
C125-128
4 / 8
C133-136
C141-144 C155
C164 C169 C171
C176 C181 C185
C191-192 C194
C202 C205 C207
C209 C219 C226
C228 C404
C106A 3409247071-T CAP AF RSG 47UF 50V 6 P 47/50
C201 C502 3409247871-T CAP AF RSG 0.47UF 50V 5 P 0.47/50
C115 C123 C131 3409247971-T CAP AF RSG 4.7UF 50V 5 P 4.7/50
C139 C147 C151
C158 C162 C165
C167 C172 C177
C179 C183 C187
C199-200
C214-215 C222
C601-602
CR101-102 3509102231-A CAP CE YB 1000PF 50V K AXIAL 1000P
CR106-107
CR111-112
CR116-117
CR121-122
CR126-127
CR131
CR136-138
CR142
CR144 3509221231-A CAP CE B 220PF 50V K AXIAL 220P
CR148 3509471231-A CAP CE B 470PF 50V K AXIAL 470P
CR149 3509561231-A CAP CE B 560PF 50V K AXIAL 560P
CR113-115 3529050311-A CAP CE SL 5P 50V M AXIAL 5P
CR118-120
CR123-125
CR128-130
CR139-141
CR103-105 3529120311-A CAP CE SL 12PF 50V J AXIAL 12P
CR109-110
CR118A
CR143 3529330311-A CAP CE SL 33PF 50V J AXIAL 33P
CR132-135 3529470311-A CAP CE SL 47PF 50V J AXIAL 47P
5 / 8
CR151-152 3529560311-A CAP CE SL 56PF 50V J AXIAL 56P
CR146-147 3529680311-A CAP CE SL 68PF 50V J AXIAL 68P
CR150
C153 3609102120-T CAP MA 0.001UF 100V 0.001(M)
C217 3609333120-T CAP MA 0.033UF 100V J 0.033/100(M)
C154 3609392120-T CAP MA 0.0039UF 100V J 0.0039/100(M)
C216 3609473120-T CAP MA 0.047UF 100V 0.047/100(M)
CON416 4355942510 CON ASS'Y 2P ASS'Y 2P
CON101-106 4355928613 CONNECTOR ASS'Y 5P ASS'Y 5P
CON107-112 4355928615 CONNECTOR ASS'Y 5P ASS'Y 5P
CON113 4355928712 CONNECTOR ASS'Y 6P ASS'Y 6P
CON114 4355928812 CONNECTOR ASS'Y 5P ASS'Y 5P
XLR106 4408194610 JACK XLR XLR 3P(M)
CON116 4428595002 LW5267/LWB0640/2.5MM-02P WAFER 2P
CON517 4428598303 CONNECTOR WAFER LW-0640-3P LW3P
DC_TER 4438094610 DC TERMINAL 2P DC 24V
RCA101 4438095210 JACK RCA 4P RCA 4P
JACK101-107 4438097310 JACK PHONE 4P PHONE JACK
XLR101-105 4438099410 JACK XLR XLR 3P(F)
RZ101 5528001040 RELAY RZ-24 RY24W DC24V 24W
R407 JUMP JUMP JUMP
C218 OPEN OPEN OPEN
4355934405 TERMINAL WIRE PP-9113
7505299340 HEAT SINK EQ-131
4355740707 CON ASS'Y 2P BLK 150MM
4355803613 CON ASS'Y 1P 187T PP-9113
4235007210 GND TERMONAL (POWER B 'D)
4355934408 TERMINAL WIRE
CON115~415 4355474210 CON ASS'Y 2P 220V 60Hz
240V 50Hz
120V 60Hz
4355942510 230V 50Hz
230~240V 50Hz
220V
FUSE 5508111737 FUSE 51S 20MM 500MA/250V U/C 220V 60Hz
120V 60Hz
240V 50Hz
5508411739 230V 50Hz
230~240V 50Hz
220V 50Hz
6 / 8
FUSE CLIP 4458999110 FUSE CLIP 5*20 5*20
VR B'D (4005106010)
VR612-613 3238082310 VR RV09A-40-20K-A14 ALPHA 10KA
VR614-615 3238082410 VR RV09A-40-20K-1315-0C ALPHA 100KB
VR601-611 3238094810 VR RS209121L2A013A (RSC87) 10KA
VR616 3238094810 VR RS209121L2A013A (RSC87) 10KA*2
CON601 CON603 4355928613 CONNECTOR ASS'Y 5P ASS'Y 5P
CON602 4355928613 CONNECTOR ASS'Y 5P ASS' Y 5P
CON604-606
CON607-612 4355928615 CONNECTOR ASS'Y 5P ASS' Y 5P
CON613 4355928712 CONNECTOR ASS'Y 6P ASS' Y 6P
CON614 4355928812 CONNECTOR ASS'Y 5P ASS'Y 5P
S/W B'D (4005106020)
C503 3549472407 CAP DE2E3KH472MA4B 0.0047/400
CON415 4355474210 CON ASS'Y 2P ASS' Y 2P
P501-502 4355803613 CON ASS'Y 1P 187T PP-9113 ASS' Y 1P
PWR_SW 4648099110 SW PUSH JPJ010-301DT-41 220V 60Hz
120V 60Hz
240V 50Hz
4648098410 SW PS-5-W7AV 230V 50Hz
230~240V 50Hz
4648097110 SW POWER KDCA06 220V 50Hz
LED B'D (4005106030)
D404 2300050101 LED LTL-307E-012A RED
CON416 4355942510 CON ASS'Y 2P 2P
ASS'Y
CONNECTOR 4408104910 TERMINAL GND(4M)GT-2190C TERMINAL
CONNECTOR 4355934707 SOCKET TERMINAL(150MM)EUROPE TERMINAL
POWER TRANS 2828082100 TRANS POWER PP-9113 POWER TRANS
AC INLET 4448996910 AC INLET BACI-05-E1A (BELTON) 220V 60Hz
120V 60Hz
240V 50Hz
4448997110 AC INLET NO.KE-10.2100.151 230V 50Hz
220V 50Hz
230~240V 50Hz
FUSE DRAWER 4448996911 FUSE DRAWER(31.8MM) 220V 60Hz
120V 60Hz
240V 50Hz
4448997120 FUSE DRAWER NO.4305.0001(20MM) 230V 50Hz
7 / 8
230~240V 50Hz
220V 50Hz
VOLTAGE 4448996914 VOLTAGE SELECTOR 220V ONLY 220V 60Hz
4448997112 VOLTAGE 4305.0048.17(115/230) 230V 50Hz
230~240V 50Hz
220V 50Hz
4448996916 VOLTAGE SELECTOR 120/240V 120V 60Hz
240V 50Hz
FUSE 5508221130 FUSE NB 31.8MM 200MA/250V KS 220V 60Hz
5508411134 FUSE 218T 20MM 200MA/250V UCSK 230V 50Hz
230~240V 50Hz
5508221133 FUSE NB 31.8MM 200MA/250V U/C 240V 50Hz
5508411139 FUSE NB 31.8MM 200MA/250V U/C 220V 50Hz
5508221333 FUSE NB 31.8MM 300MA/250V U/C 120V 60Hz
AC CORD 4308999310 AC CORD UL 3 (INLET) 120V 60Hz
4308997310 AC CORD DOME 3-CORES 220V 60Hz
4308988610 AC POWER CORD CCC 220V 50Hz
4308996710 AC CORD (WITHOUT PLUG) 230~240V 50Hz
4308999410 AC CORD V+VII6A-250VHOVV-F3G 230V 50Hz
4308998000 AC CORD POWER FOR SAA 240V 50Hz
8 / 8
