Intellinet 524957 Manual de usuario
4-PORT
BROADBAND
ROUTER
USER
MANUAL
MODEL 524957
INT-524957-UM-1210-02
2
INTRODUCTION
INTRODUCTION
Thank you for purchasing the INTELLINET NETWORK SOLUTIONS™
4-Port Broadband Router, Model 524957.
Combining a router, rewall and four-port Fast Ethernet switch, this
handy device lets you experience fast speeds as you surf the Web,
download music or photos, and play online games. A DHCP server
that automatically assigns IP addresses to users on the LAN — plus
UPnP that supports gaming — makes this the perfect router for the
home network.
Keeping intruders out of your network can be a challenge, but this
feature-rich router is designed to make that task easier. It includes a
true rewall that secures your network against hackers. With Network
Address Translation (NAT) to shield your networked devices from
intruders plus content control using URL and MAC ltering, you can
rest assured that you have taken the necessary precautions to protect
the data on your network.
The easy-to-follow instructions in this user manual help make setup
and operation quick and simple, so you’ll also soon be enjoying the
benets of these additional features:
• Integrated 10/100 Mbps LAN switch with Auto MDI/MDI-X support
• Supports virtual server and DMZ (demilitarized zone)
• Supports DDNS (dynamic DNS)
• Supports VPN pass-through (PPTP, L2TP)
• QoS (Quality of Service) bandwidth management
• VPN Pass Through (PPTP, IPSec, L2TP)
• DHCP server supports static lease management
• Supports remote management
• Supports static routing
• Firmware updates via Web-based user interface
• Three-Year Warranty
Package Contents
• 4-Port Broadband Router
• User manual on CD, plus quick installation guide
• RJ45 Ethernet cable: 1.0 m (3 ft.)
• Power adapter
3
TABLE OF CONTENTS
TABLE OF CONTENTS
1 Hardware Installation.................................................................... 4
1.1 Rear Panel Ports & Jacks..................................................... 4
1.2 Front Panel LEDs ................................................................. 5
2 Network Settings.......................................................................... 5
2.1 IP Address Setup ................................................................. 5
2.2 Conrming the Connection................................................. 14
2.3 Logging In to the Web Browser .......................................... 16
3 Router Setup .............................................................................. 18
3.1 Quick Setup........................................................................ 18
3.2 Admin ................................................................................. 23
3.3 WAN .................................................................................. 27
3.4 LAN .................................................................................. 33
3.5 NAT .................................................................................. 35
3.6 Firewall ............................................................................... 40
3.7 Routing............................................................................... 43
3.8 QoS .................................................................................. 45
3.9 Miscellaneous..................................................................... 47
3.10 High Level .......................................................................... 49
3 .11 S t a t u s ................................................................................. 49
4 Troubleshooting.......................................................................... 51
5 Specications............................................................................. 52
4
HARDWARE INSTALLATION
1 HARDWARE INSTALLATION
Using the included RJ45 Ethernet cable (and more, as needed), make
your 4-Port Broadband Router network connections by following the
steps below and referring to the Port and LED descriptions (presented
from left to right).
1. Turn off all devices to be incorporated into the network, including
any PCs, switches/hubs, the modem and the router.
2. Connect the LAN or Ethernet network port of the cable/DSL modem
to the router’s WAN port.
3. Connect PCs (and any switch/hub used to expand the network) to
the router’s LAN ports.
4. Turn on the cable/DSL modem.
5. Use the included power adapter to connect the router to an AC
outlet.
6. Turn on the PC you’ll be using to congure the router.
1.1 Rear Panel Ports & Jacks
WAN — This 10/100Mbps port connects the cable/DSL modem.
PC1-4 — These four LAN ports connect networked devices, such as
PCs, print servers and remote hard drives. If you connect a LAN
port to a switch or hub, check that both the device’s Power LED
and the router’s corresponding PC/LAN LED (see below) light to
conrm the connection.
Reset — Push this recessed button to clear all established router
conguration settings and reset to the factory default settings. See
Section 3: Restore Defaults.
PWR — This jack is for the included external 9 V DC, 500 mA power
adapter.
PWR
PC2 PC3 PC4 Reset
WAN PC1
5
NETWORK SETTINGS
1.2 Front Panel LEDs
PWR — This lights when the router is turned on.
4-1 — These correspond to the four LAN ports on the router’s rear
panel. Lighted indicates a successful connection; blinking means
data is being transmitted or received through that port.
WAN — Lighted indicates a successful Internet connection; blinking
indicates data is being transmitted or received through that port.
2 NETWORK SETTINGS
To congure the router using a Web browser-based conguration utility,
at least one properly congured computer needs to be connected to
the router via the Ethernet. This 4-Port Broadband Router is congured
with the default IP address of 192.168.2.1 and subnet mask of
255.255.255.0, and its DHCP server is enabled by default.
2.1 IP Address Setup
2.1.1 Windows 98SE / Me
1. On your PC’s desktop, click “Start” and go to the Control Panel.
2. Double-click the “Network” icon to display the Network dialog box.
3. Click the Conguration tab and ensure that you have the
appropriate network card installed.
4. Select “TCP/IP.” NOTE: If “TCP/IP” is listed more than once, select
At this point, you can proceed to Section 2.3: Logging In to the Web
Browser. If you encounter problems from there, return here and follow
the steps in Sections 2.1: IP Address Setup and 2.2: Conrming the
Connection.
6
NETWORK SETTINGS
the item that has an arrow (→) pointing to the network card installed
on your computer. Do not choose the TCP/IP listing that has the
words “Dial Up Adapter” beside it.
5. Click “Properties” to display the TCP/IP Properties dialog box.
6. Ensure “Obtain IP Address Automatically” is selected/checked.
7. In the WINS Conguration dialog box, ensure that “Disable WINS
Resolution” is checked.
8. In the Gateway dialog box, remove all entries from the “Installed
gateways” section by selecting them and clicking “Remove.”
9. In the DNS Conguration dialog box, remove all entries from the
DNS Server Search Order box by selecting them and clicking
“Remove.” Remove all entries from the Domain Sufx Search Order
box by selecting them and clicking “Remove.” Click “Disable DNS.”
10. Click “OK” to return to the Network Conguration dialog box.
11. Click “OK.” If prompted to restart, click “Yes.”
2.1.2 Windows 2000
1. On your PC’s desktop, click “Start” and “Settings,” then go to the
Control Panel.
2. Double-click the “Network and Dial-up Connections” icon.
Network and
Dial-up
Connections
7
NETWORK SETTINGS
3. Right-click on the “Local Area Connections” icon to display the
pop-up menu, then click “Properties.”
4. Highlight “Internet Protocol (TCP/P)” and click “Properties.”
8
NETWORK SETTINGS
5. Select “Obtain an IP address automatically” and “Obtain DNS server
address automatically”; click “OK” to return to the previous screen.
6. When the Local Area Connection Properties screen displays again,
click “OK.”
9
NETWORK SETTINGS
2.1.3 Windows XP
1. On your PC’s desktop, click “Start” and go to the Control Panel.
2. Select “Network and Internet Connections.”
3. Click “Network Connections.”
10
NETWORK SETTINGS
4. Right-click on the “Local Area Connections” icon to display the
pop-up menu, then click “Properties.”
5. On the subsequent Local Area Connection Properties screen, select
“Internet Protocol (TCP/IP)” and click “Properties.”
