Twibi Giga
8. Technical specications
Hardware
2 internal antennas of 3 dBi
1 WAN/LAN gigabit port
1 LAN gigabit port
Chipset Realtek®RTL8197FS+RTL8812BR+RTL8363
16 MB ash Memory
RAM memory 128 MB
Wireless parameters
Standards
IEEE 802.11ac/a/n 5 GHz
IEEE 802.11b/g/n 2.4 GHz
IEEE 802.11v/r (roaming)
Radio mode MU-MiMo
Beamforming
Frequency of operation 2.4 GHz
5 GHz
Bandwidth 2.4 GHz: 20, 40 MHz
5 GHz: 40, 80 MHz
Transmission rate 2.4 GHz: up to 300 Mbps
5 GHz: up to 867 Mbps
Channels of operation 2.4 GHz: 1-11 (Brazil)
5 GHz: 40
Maximum power
(E.I.R.P.)
2.4 GHz: 315 mW (25 dBm)
5 GHz: 315 mW (25 dBm)
Receiver sensitivity
at 2.4 GHz
802.11b 1 Mbps: -97 dBm
802.11n 20 MHz MCS7: -71 dBm
802.11n 40 MHz MCS7: -70 dBm
Receiver sensitivity
at 5 GHz
802.11a 6 Mbps: -92 dBm
802.11ac 80 MHz MCS9: -61 dBm
Security WPA2-PSK
Power supply
Input 100–240 V to 50/60 Hz
Output 12 V/1,5 A
Maximum power
consumption 18 W
Attention: this equipment is not entitled to protection from harmful
interference and shall not cause interference in duly authorized
systems.
Warranty term
It is expressly stated that this contractual warranty is given subject to
the following conditions:
Name of customer:
Signature of the customer:
Invoice no.:
Date of purchase:
Model: Serial no.:
Reseller:
1. All parts and components of the product are under warranty against possi-
ble manufacturing defects, which may present, for a period of 5 (ve) years
comprising 03 (three) months of legal warranty and 57 (fty seven) months
of contractual warranty –, counted from the date of purchase of the product
by the Consumer, as stated in the invoice of purchase of the product, which is
part of this Term throughout the national territory. This contractual warranty
includes the free exchange of parts and components that have a manufactu-
ring defect, including the expenses with the labor used in this repair. If there
is no manufacturing defect, but aw(s) from improper use, the Consumer will
bear these expenses.
2. The product installation must be done in accordance with the Product Ma-
nual and/or Installation Guide. If your product needs to be installed and
congured by a qualied technician, look for a suitable and specialized
professional, and the costs of these services are not included in the value
of the product.
3. If you notice a defect, you should immediately contact the nearest Au-
thorized Service listed by the manufacturer – only they are authorized to
examine and remedy the defect during the warranty period provided he-
rein. If this is not adhered to, this warranty will lose its validity, as it will be
characterized as the violation of the product.
4. In the event that the Customer requests home care, the Customer should
refer to the nearest Authorized Service for the technical visit fee. If the need
for withdrawal of the product is found, the expenses arising, such as trans-
portation and safety to and from the product, are under the responsibility
of the Consumer.
5. The warranty will totally lose its validity in the event of any of the following:
a) if the defect is not of manufacture, but caused by the Consumer or by
third parties alien to the manufacturer; b) if the damage to the product
comes from accidents, claims, agents of nature (lightning, oods, lands-
lides, etc.. ), humidity, mains voltage (overvoltage caused by accidents or
excessive mains uctuations), installation/use in disagreement with the
user manual or due to natural wear of parts, pieces and components; c) if
the product has been inuenced by chemical, electromagnetic, electrical or
animal (insects, etc.); d) if the product’s serial number has been tampered
with or erased; e) if the device has been violated.
6. This warranty does not cover loss of data, so it is recommended, if the
product is concerned, that the Consumer make a regular backup copy of
the data contained in the product.
7. Intelbras is not responsible for the installation of this product and also
for any attempts of fraud and/or sabotage on its products. Keep software
and application updates, if any, up to date, as well as network protections
necessary to protect against hackers. The equipment is under warranty
against aws within its normal conditions of use, and it is important to be
aware that, since it is an electronic equipment, it is not free from frauds and
scams that may interfere with its correct functioning.
8. After its useful life, the product must be delivered to an authorized techni-
cal assistance from Intelbras or directly to the environmentally appropriate
nal destination, avoiding environmental impacts and health. If you prefer,
the battery, as well as other unused Intelbras electronics, can be disposed
of at any Green Eletron collection point (electronic waste manager to which
we are associated). In case of doubt about the reverse logistics process,
please contact us by phone (48) 2106-0006 or 0800 704 2767 (Monday to
Friday from 8 am to 8 pm and on Saturdays from 8 am to 6 pm) or through
e -mail suporte@intelbras.com.br.
As these are the conditions of this Term of Additional Guarantee,
Intelbras S/A reserves the right to change the general, technical and
aesthetic characteristics of its products without prior notice.
The manufacturing process of this product is not covered by ISO
14001 requirements.
All images in this manual are illustrative.
App Store is a service mark of Apple Inc. GOOGLE is a registered trademark
of Google Inc. Realtek is a trademark of Realtek Semiconductor Corp.
