Intel®IXDP465 Development

Platform

Quick Start Guide

May 2005

May 2005 Intel®IXDP465 Development Platform AN

2 Order Number: 305825, Revision: 002

Legal Notice

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. EXCEPT AS PROVIDED IN INTEL'S TERMS

AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS

OR IMPLIED WARRANTY RELATING TO SALE AND/OR USE OF INTEL PRODUCTS, INCLUDING LIABILITY OR WARRANTIES RELATING TO

FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT, OR OTHER

INTELLECTUAL PROPERTY RIGHT.

Intel Corporation may have patents or pending patent applications, trademarks, copyrights, or other intellectual property rights that relate to the

presented subject matter. The furnishing of documents and other materials and information does not provide any license, express or implied, by

estoppel or otherwise, to any such patents, trademarks, copyrights, or other intellectual property rights.

Intel products are not intended for use in medical, life saving, life sustaining, critical control or safety systems, or in nuclear facility applications.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved” or “undefined.” Intel reserves these for

future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel literature may be obtained by calling

1-800-548-4725 or by visiting Intel's website at http://www.intel.com.

BunnyPeople, CablePort, Celeron, Chips, Dialogic, DM3, EtherExpress, ETOX, FlashFile, i386, i486, i960, iCOMP, InstantIP, Intel, Intel Centrino, Intel

Centrino logo, Intel logo, Intel386, Intel486, Intel740, IntelDX2, IntelDX4, IntelSX2, Intel Inside, Intel Inside logo, Intel NetBurst, Intel NetMerge, Intel

NetStructure, Intel SingleDriver, Intel SpeedStep, Intel StrataFlash, Intel Xeon, Intel XScale, IPLink, Itanium, MCS, MMX, MMX logo, Optimizer logo,

OverDrive, Paragon, PDCharm, Pentium, Pentium II Xeon, Pentium III Xeon, Performance at Your Command, RemoteExpress, SmartDie,

Solutions960, Sound Mark, StorageExpress, The Computer Inside, The Journey Inside, TokenExpress, VTune, and Xircom are trademarks or

registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

*Other names and brands may be claimed as the property of others.

Intel®IXDP465 Development Platform—Contents

AN Intel®IXDP465 Development Platform May 2005

Order Number: 305825, Revision: 002 3

Contents

1.0 Purpose ..........................................................................................................................................5

2.0 Applicable Documents and Revisions ........................................................................................5

3.0 Known Issues ................................................................................................................................6

4.0 Inspection.......................................................................................................................................6

5.0 Intel®IXDP465 Development Platform Overview........................................................................7

5.1 Emulation with the Intel®IXDP465 Development Platform...................................................8

6.0 Default Switch Settings.................................................................................................................9

7.0 Default Jumper Settings .............................................................................................................12

7.1 Intel®IXDP465 Baseboard Jumpers ..................................................................................12

7.2 Intel®IXP465 Network Processor/DDR Module Jumpers ..................................................15

7.3 Intel®IXPETM465 Ethernet PHY Mezzanine Card Jumpers..............................................17

8.0 LCD Display and LED Indicators................................................................................................18

9.0 Preparing the Platform for Initial Use........................................................................................21

10.0 Starting the Platform...................................................................................................................21

11.0 Operating the Platform................................................................................................................22

12.0 Technical Support .......................................................................................................................22

Figures

1 Photo of IXDP465 Development Platform Setup for Quick Start Operation .................................8

2 Intel®IXDP465 Development Platform Switch Locations...........................................................11

3 Intel®IXDP465 Baseboard Jumper Locations............................................................................14

4 Intel®IXP465 Network Processor/DDR Module Jumper Locations............................................16

5 Intel®IXPETM465 Ethernet PHY Mezzanine Card Jumper Locations.......................................18

6 Intel®IXDP465 Development Platform LED Locations ..............................................................20

7 LCD Display for Wind River* VxWorks* Bootloader ...................................................................22

Tables

1 Reference Documents..................................................................................................................5

2 Fuse Bit Settings for Network Processor Emulation.....................................................................9

3 Intel®IXDP465 Development Platform Switch Descriptions and Default Settings.....................10

4 Intel®IXDP465 Baseboard Jumper Descriptions and Default Settings......................................12

5 Intel®IXP465 Network Processor/DDR Module Jumper Descriptions and Default Settings......15

6 Intel®IXPETM465 Ethernet PHY Mezzanine Card Jumper Descriptions and Default Settings.17

7 Intel®IXDP465 Development Platform LED Descriptions and Default Settings.........................19

8 UART Communications Configuration........................................................................................21

Intel®IXDP465 Development Platform—Contents

May 2005 Intel®IXDP465 Development Platform AN

4 Order Number: 305825, Revision: 002

Revision History

Date Revision Description

May 2005 002

Text updates for this release include:

• Added paragraph about using zoom feature to read PDF

in Section 1.0. (SCR 4282)

• Added references to Intel®IXDP465 Development

Platform Specification Update.

• Added detail to procedure in Section 4.0.

• Added Section 5.1, “Emulation with the Intel®IXDP465

Development Platform” on page 8.

• Clarified default settings for J127 and J128 in Table 4.

(SCR 4280)

• Added info about updating flash memory to Section 11.0.

(SCR 4281)

• Updated Figures 1-6, replacing line art with board photos.

April 2005 001 Initial release of this document.

Quick Start Guide—Intel®IXDP465 Development Platform

AN Intel®IXDP465 Development Platform May 2005

Order Number: 305825, Revision: 002 5

1.0 Purpose

This document, the Intel®IXDP465 Development Platform Quick Start Guide, contains

instructions for unpacking, inspecting, setting up, and starting the Intel®IXDP465 Development

Platform.

Before the IXDP465 development platform is powered up for the first time, it is very important to

first become familiar with the platform. Therefore, Section 5.0 through Section 8.0 provide the

required information for powering up the platform for first time use. These sections provide the

following information:

•Photo of the IXDP465 development platform setup for Quick Start operation, showing the

location of factory-installed mezzanine modules and location of key interfaces to assist with

connection of console, Ethernet, and power cables.

•Factory default settings of all switches and jumpers, allowing the user to ensure they were not

accidentally changed during transport, or repositioned by a previous platform user.

•Location and definitions of the LCD display and all the platform LEDs, so that they can be

visually monitored for proper power-up and booting.

Instructions for preparing and starting the IXDP465 development platform begin in Section 9.0.

Note: It is highly recommended that a printout of this entire Quick Start Guide is obtained prior to

preparing and powering up the platform for the first time. All tables in this Quick Start Guide

include checkboxes so that items in the printout can be checked off to insure that all platform

switches, jumpers, and LEDs operate in their default state, which will ensure a successful first-time

bootup of the platform.

Use the Zoom feature in Adobe* Reader* to optimize viewing of the figure details contained in this

document, for example, the switch and jumper locations on the IXDP465 development platform.

Note: If any deviations from the factory default settings of this Quick Start Guide are planned, or for

more detailed information about this platform, including design definition of all boards, mezzanine

cards, platform components, optional modules, optional switch and jumper settings, and overall

development capabilities, please see the Intel®IXDP465 Development Platform User’s Guide.

2.0 Applicable Documents and Revisions

The documents referenced below may be obtained online unless noted otherwise.

Table 1. Reference Documents (Sheet 1 of 2)

Title Document

Number Location

Intel®IXDP465 Development Platform User’s Guide 306462 Documentation Web Page†

Intel®IXDP465 Development Platform Specification Update 306509 Intel Representative

Intel®IXDP465 Development Platform Documentation Kit N/A Documentation Web Page†

† This document is available at:

http://www.intel.com/design/network/products/npfamily/docs/ixp4xx.htm

†† This document is available at: http://www.intel.com/design/network/products/npfamily/ixp425swr1.htm

Intel®IXDP465 Development Platform—Quick Start Guide

May 2005 Intel®IXDP465 Development Platform AN

6 Order Number: 305825, Revision: 002

3.0 Known Issues

Known issues are described in the following documents:

•Silicon errata: Intel®IXP4XX Product Line of Network Processors Specification Update

•Software errata: Intel®IXP400 Software - Software Specification Update

•Platform errata: Intel®IXDP465 Development Platform Specification Update

4.0 Inspection

Before the contents of the box are unpacked, ensure that all precautions are observed prior to

removing Electrostatic Sensitive Device (ESD) assemblies from their protective packaging.

Unpack the contents of the box. After all the components are unpacked, verify that all the items

listed in the packing list are present. The packing list is included in the STOP Readme First

document shipped with the kit. If any item is missing, refer to Section 12.0, “Technical Support”

for instructions.

After verifying all items are present:

•Inspect each item for any visible damage.

•Inspect the cable connectors to ensure that none of the pins are bent or damaged.

•Inspect the overall platform assembly to ensure that all mezzanine cards (modules) are

properly seated. This can be done by first ensuring that all four 5/8 inch standoffs and nuts on

each corner of the mezzanine cards are not loose. If they appear loose either due to shipping or

previous handling, then they need to be re-seated per the following procedure:

a. Remove all four nuts, by hand-turning them in a counter-clockwise direction as viewed

from the top of the assembly.

b. Ensure that all four 5/8 inch standoffs are tight, by hand-turning each of them in a

clockwise direction while the mezzanine card is still plugged in.

Intel®IXP4XX Product Line of Network Processors

Specification Update 306428 Intel Representative

Intel®IXP45X and Intel®IXP46X Product Line of Network

Processors Datasheet 306261 Documentation Web Page†

Intel®IXP45X and Intel®IXP46X Product Line of Network

Processors Developer’s Manual 306262 Documentation Web Page†

Intel®IXP400 Software Release - Software Release Notes N/A Software Web Page††

Intel®IXP400 Software - Software Specification Update 273795 Documentation Web Page†

Intel®IXP400 Software Programmer’s Guide 252539 Documentation Web Page†

Table 1. Reference Documents (Sheet 2 of 2)

Title Document

Number Location

† This document is available at:

http://www.intel.com/design/network/products/npfamily/docs/ixp4xx.htm

†† This document is available at: http://www.intel.com/design/network/products/npfamily/ixp425swr1.htm

Quick Start Guide—Intel®IXDP465 Development Platform

AN Intel®IXDP465 Development Platform May 2005

Order Number: 305825, Revision: 002 7

c. Re-seat the mezzanine card into the connector by applying finger pressure from one hand

to the top-side of the mezzanine card directly over the connector while applying finger

pressure from your other hand to the bottom-side of the base platform directly under the

connector.

Caution: Make sure that your fingers on both hands do not press against installed

components on the assembly.

d. Verify that the mezzanine card is properly re-seated, by visually confirming there are no

gaps between the connectors and no gaps between the four standoffs and the mezzanine

card.

e. Replace all four nuts, by hand-turning and tightening them in a clockwise direction.

If any item is damaged or missing, refer to Section 12.0, “Technical Support” for instructions.

Note: A set of extra jumpers is included with the kit. These jumpers are not required for default operation

of the platform as described in this manual. The extra jumpers are provided for any deviations from

the factory default settings which may be required to support optional platform configurations.

5.0 Intel®IXDP465 Development Platform Overview

The IXDP465 development platform is used for development with the Intel®IXP46X Product Line

of Network Processors, and consists of:

•one Intel®IXDP465 development platform baseboard

•one Intel®IXP465 Network Processor/DDR module (defaulted to 533 MHz operation)

•one Intel®IXPETM465 MII Ethernet PHY mezzanine card

Both the Intel®IXP465 Network Processor/DDR Module and the Intel®IXPETM465 MII

Ethernet PHY Mezzanine card plug into the baseboard. These three separate card assemblies are

shipped pre-assembled by the factory and should appear per the photo as shown in Figure 1 on

page 8. The IXDP465 development platform also ships with a Intel®PRO/100+ Adapter

(packaged separately).

Figure 1 represents the top side view of IXDP465 development platform setup and shows all key

interfaces and components. This figure should be compared against the platform that was contained

in the box, so that familiarity is gained of all key platform components. The platform should also

be viewed from the back side, to observe all provisions for optional mezzanine cards, but if more

data is required, please see the Intel®IXDP465 Development Platform User’s Guide.

Figure 1 should also be referenced while preparing the platform for initial use per Section 9.0, to

use as a visual aid to validating proper setup of the IXDP465 development platform for Quick Start

operation.

Intel®IXDP465 Development Platform—Quick Start Guide

May 2005 Intel®IXDP465 Development Platform AN

8 Order Number: 305825, Revision: 002

5.1 Emulation with the Intel®IXDP465 Development Platform

The Intel®IXDP465 Development Platform can be used for development of products using the

Intel®IXP45X and Intel®IXP46X Product Line of Network Processors. Although the IXDP465

development platform is shipped with a fully-featured Intel®IXP465 Network Processor operating

at 533 MHz, the platform can also be used to develop products that require either an Intel®IXP460

Network Processor or an Intel®IXP455 Network Processor. These processors support subsets of

the IXP465 processor’s features, therefore software can be used to disable certain features on the

IXP465 to emulate the IXP460 and IXP455 processors.

Figure 1. Photo of IXDP465 Development Platform Setup for Quick Start Operation

B4991-02

11 13 1412 15

KEY:

1. EthernetPort 0

2. EthernetPHYMezzanine Card in MII-0 NPE B slot

3. EthernetSMII6-pack

4. MII-1 NPE C location(no mezzanine cardinstalled)

5. USB 2.0 HostController

6. USB 1.1 Device Controller

7. Flash Memory

8. DDRIMemory

9. UART1 Cable to PC for WindRiver* VxWorks*

10. UART0 Cable to PC for RedHat* RedBoot*

11. Intel® IXP465Network Processor/DDR Module

12. Intel® IXP465 Network Processor

13. PCI Option Interface

14. EthernetNIC Card plugged into PCIslot0

15. EthernetCable fromNIC to PC

16. Power Switch

17. 4-slot HostPCI backplane

18. Power Supply

19. Voltage Regulators

20. Power Supply Cable Connector

21. LCD Display

Quick Start Guide—Intel®IXDP465 Development Platform

AN Intel®IXDP465 Development Platform May 2005

Order Number: 305825, Revision: 002 9

Emulation is accomplished by accessing the EXP_UNIT_FUSE_RESET register via software and

writing a 1 to the fuse bit number that corresponds to the feature to be disabled. For a full

description of this register, see the Intel®IXP45X and Intel®IXP46X Product Line of Network

Processors Developer’s Manual.

Table 2 shows the default fuse bit settings for the fully-featured IXP465 network processor. Other

rows in the table show the fuse bit settings which can disable a feature to emulate IXP460 or

IXP455 network processor operation.

6.0 Default Switch Settings

This section describes the factory default settings of all platform switches, to ensure they were not

accidentally changed during transport, or repositioned by a previous user of the platform.

The IXDP465 development platform has all switches located on the top-side of the entire assembly.

Figure 2 on page 11 identifies the exact location of all switches, clustered into two different areas,

one for GPIO LED Switches and one for Expansion Bus Address Strap Switches.

•The GPIO LED Switches (SW1, SW2) allow the choice of connecting any of the 16 GPIO

signals to a LED, which can be useful for development purposes. Each GPIO has a green LED

indicator attached to it, which when illuminated, indicates a “low” state. A switch is placed on

each LED to allow the LED to be disconnected from the GPIO and reduce loading. See

Figure 2 on page 11 for the DIP Switch locations. Although the factory default setting for

these switches is “LED Illuminated,” these 16 switches can be set to other settings if desired.

•The Expansion Bus Address Strap switches (SW3, SW4, SW5) allows the choice of either

floating, or a 1 K pull-down resistor on each of the 24 expansion bus address lines. If set to

floating, then a weak internal pull-up resistor in the IXP465 network processor controls the

strap value. For operation as defined in this guide, ensure that all switches are set as shown in

Figure 2.

All platform switches are summarized in Table 3, which provides a high-level description of each

switch and their factory default settings, all of which must be checked prior to powering up the

platform for the first time.

Table 2. Fuse Bit Settings for Network Processor Emulation

Features of Intel®IXP45X and Intel®IXP46X Product Line of Network Processors

Processor

ECC/1588

PCI

NPE-C (crypto)

NPE-B (no crypto)

NPE-A (WAN)

Ethernet C (crypto)

Ethernet B (no crypto)

UTOPIA

HSS/HDLC

Hash/AES/DES

UDC (USB Device)

RCOMP_disable

Core speed

RSA

Ethernet B [1-3]

Ethernet A

USB Host

UCP (phy_limit[1])

UCP (phy_limit[0])

Intel®IXP465 (533 MHz) 00000000000000000000

Intel®IXP460 (533 MHz) 00001001110000111000

Intel®IXP455 (533 MHz) 10000000000000010000

Fuse Bit Number†232221201918171613109876543210

† Available to software via EXP_UNIT_FUSE_RESET register.

Intel®IXDP465 Development Platform—Quick Start Guide

May 2005 Intel®IXDP465 Development Platform AN

10 Order Number: 305825, Revision: 002

Table 3. Intel®IXDP465 Development Platform Switch Descriptions and Default Settings

Board Location

(See Figure 2) Ref ID Switch Description Default Settings Quick

Start

Check?

GPIO LED Switches SW1 Select individual LED illumination

settings of all odd GPIO signals All odd GPIO illuminated.

Switch in ON position. F

GPIO LED Switches SW2 Select individual LED illumination

settings of all even GPIO signals All even GPIO illuminated.

Switch in ON position. F

Expansion Bus

Address Strap

Switches SW3 Select floating or pull down straps

for EX_ADDR[8:1] signals All EX_ADDR floating.

Switch in OFF position. F

Expansion Bus

Address Strap

Switches SW4 Select floating or pull down straps

for EX_ADDR[16:9] signals All EX_ADDR floating.

Switch in OFF position. F

Expansion Bus

Address Strap

Switches SW5 Select floating or pull down straps

for EX_ADDR[24:17] signals All EX_ADDR floating.

Switch in OFF position. F

Tabla de contenidos

Otros manuales de Hardware de computadora de Intel

Intel

Intel BX80570E8200 - Core 2 Duo 2.66 GHz Processor Guía

Intel

Intel Core i7-860 Instrucciones de funcionamiento y seguridad

Intel

Intel 2ND GENERATION CORE PROCESSOR FAMILY DESKTOP - VOLUME 2... Manual de usuario

Intel

Intel SROMBSASMR Manual de instalación

Intel

Intel G22856-001 Manual de instalación

Intel

Intel 8086 Manual de usuario

Intel

Intel Xeon 5500 Series Manual técnico

Intel

Intel 2ND GENERATION INTEL CORE PROCESSOR FAMILY MOBILE - SPECIFICATION UPDATE... Manual de usuario

Intel

Intel 80386 Manual de usuario

Intel

Intel SRCMR - RAID Controller Manual de usuario

Intel

Intel 925 - Pentium D 925 3.0GHz 800MHz 4MB-Cache Socket 775... Manual de usuario

Intel

Intel 2ND GENERATION CORE PROCESSOR FAMILY DESKTOP - VOLUME 1... Manual de usuario

Intel

Intel Xeon E5-2400 Guía

Intel

Intel NUC11PAQi7 Manual de usuario

Intel

Intel Xeon LV Manual de usuario

Intel

Intel Xeon Processor E5-1600 Manual de usuario

Intel

Intel RMS2MH080 Manual de instalación

Intel

Intel SRCSASPH16I - RAID Controller Instrucciones de instalación

Intel

Intel DUAL-CORE - UPDATE REV 010 Manual de usuario

Intel

Intel SBEFCM4 Manual de usuario

Intel

Intel WPC2011NA - Pro/wireless 2011 Pccard Wireless... Manual de instalación y operación

Intel

Intel Atom C2000 Manual de usuario

Intel

Intel X3350 - Xeon 2.66 Ghz 12M L2 Cache 1333MHz FSB LGA775 Quad-Core... Guía

Intel

Intel RS2WC080 Manual de instalación

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario

Advantech

Advantech ASMB-935 Series Manual de usuario

Jupiter

Jupiter RAM PACK Manual de usuario
