Intel Atom E3900 SoC Series Manual de usuario

Document Number: 334828-002US

Intel Atom® Processor E3900 SoC

Family/ Intel® Celeron® Processor

N3350/ Intel® Pentium® Processor

N4200/ Intel® Celeron® Processor J3355

& J3455 for Yocto Project*

Getting Started Guide

October 2018

Intel Atom® Processor E3900 SoC Family/Intel® Celeron® Processor N3350/Intel® Pentium® Processor N4200/

Intel® Celeron® Processor J3355 & J3455

Getting Started Guide October 2018

Page 2 Document Number: 334828-002US

You may not use or facilitate the use of this document in connection with any infringement or other legal analysis concerning Intel products

described herein. You agree to grant Intel a non-exclusive, royalty-free license to any patent claim thereafter drafted which includes subject

matter disclosed herein.

No license (express or implied, by estoppel or otherwise) to any intellectual property rights is granted by this document.

All information provided here is subject to change without notice. Contact your Intel representative to obtain the latest Intel product

specifications and roadmaps.

The products described may contain design defects or errors known as errata which may cause the product to deviate from published

specifications. Current characterized errata are available on request.

Copies of documents which have an order number and are referenced in this document may be obtained by calling 1-800-548-4725 or by

visiting: http://www.intel.com/design/literature.htm

Intel Atom, Intel® Hyper-Threading Technology, and the Intel logo are trademarks of Intel Corporation in the U.S. and/or other countries.

*Other names and brands may be claimed as the property of others.

Intel Atom® Processor E3900 SoC Family/Intel® Celeron®

Processor N3350/Intel® Pentium® Processor N4200/ Intel® Celeron® Processor J3355 & J3455

October 2018 Getting Started Guide

Document Number: 334828-002US Page 3

Contents

1.0 Introduction............................................................................................................................................5

1.1 Terminology ......................................................................................................................................................5

1.2 Reference Documents ................................................................................................................................5

1.3 Known Issues...................................................................................................................................................6

2.0 Setting up the Build System..........................................................................................................7

2.1 Pre-requisites ...................................................................................................................................................7

2.2 Preparing the Build Environment in Build System .................................................................7

Intel Atom® Processor E3900 SoC Family/Intel® Celeron® Processor N3350/Intel® Pentium® Processor N4200/

Intel® Celeron® Processor J3355 & J3455

Getting Started Guide October 2018

Page 4 Document Number: 334828-002US

Revision History

Date Revision Description

October 2018 002 Updated product marketing name.

Added reference documents for MR4 Release.

Added known issues.

February 2017 001 Initial release.

Introduction

Intel Atom® Processor E3900 SoC Family/Intel® Celeron®

Processor N3350/Intel® Pentium® Processor N4200/ Intel® Celeron® Processor J3355 & J3455

October 2018 Getting Started Guide

Document Number: 334828-002US Page 5

1.0 Introduction

This Guide contains general information and guidelines to prepare the build

environments in the build system. This Getting Started Guide targets users who need to

build, customize, and configure their build environment specifically for Yocto* Board

Support Systems (BSPs).

1.1 Terminology

Table 1. Terminology

Term Description

BSP Board Support Package

OS Operating System

RAM Random Access Memory

SoC System-on-a-Chip

1.2 Reference Documents

Table 2. Reference Documents

Document Document

No./Location

Intel Atom® Processor E3900 SoC Family/Intel® Celeron® Processor

N3350/Intel® Pentium® Processor N4200/ Intel® Celeron® Processor J3355 &

J3455 Board Support Package for Yocto Project* - MR3.1 – Release Notes

333732

Intel Atom® Processor E3900 SoC Family/Intel® Celeron® Processor

N3350/Intel® Pentium® Processor N4200/ Intel® Celeron® Processor J3355 &

J3455 Board Support Package for Yocto Project* - MR4 – Release Notes

595926

Introduction

Intel Atom® Processor E3900 SoC Family/Intel® Celeron® Processor N3350/Intel® Pentium® Processor N4200/

Intel® Celeron® Processor J3355 & J3455

Getting Started Guide October 2018

Page 6 Document Number: 334828-002US

1.3 Known Issues

Table 3. Known Issues

Reference No. Issue Workaround

1504693541 Desktop manager crashes and

restarts during image build.

If Yocto Project* 2.3 or later is used, access build system

and build image using SSH instead of directly using the

GUI on the build system.

This issue is tracked on Bugzilla*.

Setting up the Build System

Intel Atom® Processor E3900 SoC Family/Intel® Celeron®

Processor N3350/Intel® Pentium® Processor N4200/ Intel® Celeron® Processor J3355 & J3455

October 2018 Getting Started Guide

Document Number: 334828-002US Page 7

2.0 Setting up the Build System

This chapter contains the list of pre-requisites and the steps to configure the build

environment to build the Yocto Project*-based image for Apollo Lake. Once the build

system is properly set up and configured, it can be used to build the image that will

eventually be used to boot up the Apollo Lake-based platform. Refer to the BSP

Release Noteson how to get the Apollo Lake BSP and build the image.

2.1 Pre-requisites

Prepare a build system (computer) with the recommended minimum hardware

requirement:

•Intel® Core™ i7 processor (4 cores with Intel® Hyper-Threading Technology)

•Minimum of 4 GB Random Access Memory (RAM)

•Minimum of 250 GB disk space

•High-speed network connectivity

•Linux* OS for Yocto Project* BSP: Ubuntu* v14.04 LTS

2.2 Preparing the Build Environment in Build System

The following procedure is used to prepare the build environment in the build system.

1. Set user as sudoer, so the user can perform super-user tasks:

a. Change to supervisor:

$ sudo su

b. modify /etc/sudoers by adding the highlighted value:

$ gedit /etc/sudoers

root ALL=(ALL:ALL) ALL

<username> ALL=(ALL:ALL) ALL

Note: <username> is the name that is used to log in to the build system.

c. Use the following to change back to normal user:

$ su - <username>

Note: Step 1 is usually performed by the network administrator.

Setting up the Build System

Intel Atom® Processor E3900 SoC Family/Intel® Celeron® Processor N3350/Intel® Pentium® Processor N4200/

Intel® Celeron® Processor J3355 & J3455

Getting Started Guide October 2018

Page 8 Document Number: 334828-002US

2. Perform this step only if the build system is behind a corporate network with a

proxy server.

a. Add the following lines in the /etc/environment:

$ sudo gedit /etc/environment

export SOCKS_SERVER=socks://<proxy server IP or DNS>:<socks

port number>

export HTTP_PROXY=http://<proxy server IP or DNS>:<http

port number>

export HTTPS_PROXY=https://<proxy server IP or DNS>:<https

port number>

export FTP_PROXY=http://<proxy server IP or DNS>:<ftp port

number>

b. Edit the .bashrc file and append to the proxy settings using the following:

$gedit ~/.bashrc

# Insert the below lines in ~/.bashrc

export SOCKS_SERVER=socks://<proxy server IP or DNS>:<socks

port number>

export HTTP_PROXY=http://<proxy server IP or DNS>:<http

port number>

export HTTPS_PROXY=https://<proxy server IP or DNS>:<https

port number>

export FTP_PROXY=http://<proxy server IP or DNS>:<ftp port

number>

export export HTTP_DIRECT=localhost,127.0.0.0/8,<your

network subnets>

export SOCKS_DIRECT=$HTTP_DIRECT

export NO_PROXY=$HTTP_DIRECT

export ALL_PROXY=$HTTP_DIRECT

export socks_server=$SOCKS_SERVER

export http_proxy=$HTTP_PROXY

export https_proxy=$HTTPS_PROXY

export ftp_proxy=$FTP_PROXY

export http_direct=$HTTP_DIRECT

export socks_direct=$SOCKS_DIRECT

export no_proxy=$NO_PROXY

Setting up the Build System

Intel Atom® Processor E3900 SoC Family/Intel® Celeron®

Processor N3350/Intel® Pentium® Processor N4200/ Intel® Celeron® Processor J3355 & J3455

October 2018 Getting Started Guide

Document Number: 334828-002US Page 9

c. Reload the bash environment using the following:

$source ~/.bashrc

d. Set up the proxy for apt-get by editing apt.conf using the following:

$ sudo gedit /etc/apt/apt.conf

Acquire::http::proxy "http://<proxy server IP or DNS>:<http

port>/";

Acquire::https::proxy "https://<proxy server IP or

DNS>:<https port>/";

Acquire::ftp::proxy "ftp://<proxy server IP or DNS>:<ftp

port>/";

Acquire::socks::proxy "socks://<proxy server IP or

DNS>:<socks proxy>/";

Setting up the Build System

Intel Atom® Processor E3900 SoC Family/Intel® Celeron® Processor N3350/Intel® Pentium® Processor N4200/

Intel® Celeron® Processor J3355 & J3455

Getting Started Guide October 2018

Page 10 Document Number: 334828-002US

3. Use the following commands to install the necessary tools:

$ sudo apt-get install gawk wget git-core diffstat unzip \

texinfo gcc-multilib build-essential chrpath socat

$ sudo apt-get install libsdl1.2-dev xterm

$ sudo apt-get install make xsltproc docbook-utils fop

dblatex xmlto

$ sudo apt-get install autoconf automake libtool

libglib2.0-dev

$ sudo apt-get install xutils-dev nfs-common

4. Create and add the following configuration under

/home/<username>/.gitconfig by using the following:

[user]

email = <your.name>@<your_domain>.com

name = <Your Name>

[sendemail]

smtpserver = <Your organization’s SMTP server address>

signedoffcc = false

suppresscc = all

chainreplyto = false

assume8bitEncoding = utf-8

from = <Your Name> <your.name@your_domain.com>

confirm = always

[color "grep"]

match = red

[color]

diff = auto

ui = auto

interactive = auto

grep = always

[alias]

co = checkout

br = branch

ci = commit

st = status

ol = log -- oneline

[core]

editor = gedit OR vi

#uncomment the gitproxy variable below if you require a

gitproxy

#gitproxy = /home/<username>/bin/gitproxy
