Intel 6 SERIES Manual de usuario

Document Number: 325208

2nd Generation Intel®Core™

Processor Family with

Intel®6 Series Chipset

Development Kit

User Guide

March 2011

About This Document

2nd Generation Intel®Core™ Processor with Intel®6 Series Chipset Development Kit

User Guide March 2011

2 Document Number: 325208-001

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED,

BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS

PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER

AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING

LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY

PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.

UNLESS OTHERWISE AGREED IN WRITING BY INTEL, THE INTEL PRODUCTS ARE NOT DESIGNED NOR INTENDED FOR ANY

APPLICATION IN WHICH THE FAILURE OF THE INTEL PRODUCT COULD CREATE A SITUATION WHERE PERSONAL INJURY OR

DEATH MAY OCCUR.

Intel may make changes to specifications and product descriptions at any time, without notice.

Intel Corporation may have patents or pending patent applications, trademarks, copyrights, or other intellectual property rights

that relate to the presented subject matter. The furnishing of documents and other materials and information does not provide any

license, express or implied, by estoppel or otherwise, to any such patents, trademarks, copyrights, or other intellectual property

rights.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved” or “undefined.” Intel

reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future

changes to them.

Intel processor numbers are not a measure of performance. Processor numbers differentiate features within each processor family,

not across different processor families. See http://www.intel.com/products/processor_number for details.

The 2nd Generation Intel®Core™ Processor with Intel®6 Series Chipset may contain design defects or errors known as errata which

may cause the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an order number and are referenced in this document, or other Intel literature may be obtained

by calling 1-800-548-4725 or by visiting Intel's website at http://www.intel.com.

BunnyPeople, Celeron, Celeron Inside, Centrino, Centrino Inside, Core Inside, i960, Intel, the Intel logo, Intel AppUp, Intel Atom,

Intel Atom Inside, Intel Core, Intel Inside, the Intel Inside logo, Intel NetBurst, Intel NetMerge, Intel NetStructure, Intel

SingleDriver, Intel SpeedStep, Intel Sponsors of Tomorrow., the Intel Sponsors of Tomorrow. logo, Intel StrataFlash, Intel vPro,

Intel XScale, InTru, the InTru logo, the InTru Inside logo, InTru soundmark, Itanium, Itanium Inside, MCS, MMX, Moblin, Pentium,

Pentium Inside, skoool, the skoool logo, Sound Mark, The Creators Project, The Journey Inside, vPro Inside, VTune, Xeon, and

Xeon Inside are trademarks of Intel Corporation in the U.S. and/or other countries.

*Other names and brands may be claimed as the property of others.

About This Document

2nd Generation Intel®Core™ Processor with Intel®6 Series Chipset Development Kit

March 2011 User Guide

Document Number: 325208-001 3

Contents

1About This Document ................................................................................................... 7

1.1 Content Overview...................................................................................................7

1.2 Text Conventions....................................................................................................7

1.3 Glossary of Terms and Acronyms .............................................................................9

1.4 Related Documents and Information.......................................................................14

1.5 Development Kit Technical Support ........................................................................15

1.5.1 Online Support..........................................................................................15

1.5.2 Additional Technical Support.......................................................................15

2Getting Started........................................................................................................... 16

2.1 Development Kit Contents.....................................................................................16

2.2 Additional Required Hardware Not Included In This Kit .............................................16

2.3 Additional Required Software Not Included in this Kit................................................17

2.4 Workspace Preparation..........................................................................................18

2.5 System Setup ......................................................................................................18

2.6System Power-Up.................................................................................................19

2.7 System Power-Down.............................................................................................19

2.8 System BIOS .......................................................................................................19

2.8.1 Configuring the BIOS.................................................................................20

2.8.2 Programming BIOS Using a Bootable USB Device..........................................20

3Development Kit Features.......................................................................................... 22

3.1 Processor Support ................................................................................................24

3.1.1 Clock Requirements...................................................................................25

3.1.2 Processor Voltage Regulator .......................................................................25

3.1.2.1 SVID Supported in Intel®MVP-7 Voltage Regulator .......................25

3.1.3 Power Management and Key Signals............................................................25

3.1.4 Memory Support .......................................................................................26

3.1.5 Graphics Support ......................................................................................27

3.1.5.1 Internal Graphics Support...........................................................27

3.1.5.2 External Graphics Support ..........................................................28

3.1.5.3 Direct Media Interface (DMI)-2 Interface......................................28

3.1.6 Intel®Flexible Display Interface (Intel®FDI)................................................28

3.1.7 Processor Thermals ...................................................................................29

3.1.8 Processor Active Cooling ............................................................................29

3.2PCH Support ........................................................................................................29

3.2.1 Introduction to the Intel®6 Series Chipset...................................................29

3.2.2 Key Power Management Signals..................................................................29

3.2.3 PCIe* Support ..........................................................................................30

3.2.4 On-Board LAN...........................................................................................32

3.2.5 Soft Audio and Modem...............................................................................33

3.2.5.1 Realtek* Audio Card Support ......................................................33

3.2.6 SATA Storage ...........................................................................................34

3.2.7 Displays ...................................................................................................34

3.2.7.1 DP/HDMI Support ......................................................................36

3.2.7.2 DMC Support.............................................................................37

About This Document

2nd Generation Intel®Core™ Processor with Intel®6 Series Chipset Development Kit

User Guide March 2011

4 Document Number: 325208-001

3.2.7.3 Switchable Graphics...................................................................37

3.2.8 USB Connectors ........................................................................................38

3.2.8.1 USB2.0.....................................................................................38

3.2.9 LPC Super I/O (SIO)/LPC Slot.....................................................................40

3.2.10 Serial Port, IrDA........................................................................................40

3.2.11 System Management Controller (SMC)/Keyboard Controller (KBC)..................40

3.2.12 SPI ..........................................................................................................41

3.2.12.1 Multi-BIOS Support....................................................................41

3.2.12.2 Clocks ......................................................................................42

3.2.12.3 CPU_ITP Clock and XDP Clock .....................................................43

3.2.13 Real Time Clock ........................................................................................44

3.3 Debug Interfaces..................................................................................................45

3.3.1 Processor and PCH Debug ..........................................................................45

3.4Chassis................................................................................................................45

3.5 Power Supply Solutions, Usage, and Recommendations ............................................45

3.5.1 Power Supply Solutions..............................................................................45

3.5.2 Power Supply Usage and Recommendation ..................................................46

3.6 Power Management ..............................................................................................47

3.6.1 Power Management States.........................................................................47

4Development Board Summary.................................................................................... 48

4.1 Features..............................................................................................................48

4.2 Connectors ..........................................................................................................51

4.2.1 Back Panel Connectors...............................................................................51

4.3 Configuration Settings...........................................................................................52

4.3.1 Configuration Jumpers/Switches .................................................................52

4.4 Power On and Reset Button ...................................................................................53

4.5LEDs ...................................................................................................................54

5Quick Start ................................................................................................................. 56

5.1 Required Peripherals.............................................................................................56

5.2 Instructions to Flash BIOS to SPI ...........................................................................56

5.3 H8 Programming ..................................................................................................56

5.4 Key Jumpers........................................................................................................57

Figures

Figure 1. Development Board Block Diagram ........................................................22

Figure 2. Side View of Stacked SODIMM Slots.......................................................27

Figure 3. PCIe* Port Mapping – Schematic Snapshot .............................................31

Figure 4. On-Board LAN Block Diagram ................................................................33

Figure 5. Back Panel Connectors..........................................................................35

Figure 6. Display Ports On-Board.........................................................................36

Figure 7 Mini PCIe Connector Soldered In Place of DMC .........................................37

Figure 8. Switchable Graphics with eDP from PCH .................................................38

Figure 9. Clock (Integrated Mode) Block Diagram..................................................43

Figure 10. Block Diagram of GDXC and XDP Clock on the Development Board..........43

Figure 11. Layout Snapshot for Reworks for GDXC and XDP Clock Options On-Board 44

Figure 12. Development Board Components – Top View.........................................48

Figure 13. Development Board Components - Bottom View ....................................50

Figure 14. Back Panel Connectors........................................................................51

Figure 15. Jumpers for Programming SPI and H8 ..................................................58

About This Document

2nd Generation Intel®Core™ Processor with Intel®6 Series Chipset Development Kit

March 2011 User Guide

Document Number: 325208-001 5

Tables

Table 1. Text Conventions ....................................................................................7

Table 2. Terms ....................................................................................................9

Table 3. Acronyms .............................................................................................11

Table 4. Related Documents and Information........................................................15

Table 5. Development Board Feature Description ..................................................22

Table 6. CFG[6] and [5] Straps Combined and Used for PEG Interface Configuration.28

Table 7. Other PEG Interface Straps ....................................................................28

Table 8. PCIe* Ports...........................................................................................30

Table 9. Reworks for Different Port Mappings........................................................32

Table 10. Selection of I/O Voltage for the Intel®High Definition Audio.....................33

Table 11. SATA Ports..........................................................................................34

Table 12. USB Port Mapping................................................................................39

Table 13. USB2.0 Ports.......................................................................................40

Table 14. Jumper Settings for SPI Programming....................................................41

Table 15. Multi-BIOS Implementation ..................................................................42

Table 16. Development Board Power Management States ......................................47

Table 17. Development Board Components List - Top View.....................................49

Table 18. Development Board Components List - Bottom View ...............................50

Table 19. Back Panel Connectors.........................................................................51

Table 20. Configuration Jumper/Switches .............................................................52

Table 21. Power On and Reset Button ..................................................................54

Table 22. Other Development Board Switches.......................................................54

Table 23. Development Board LEDs .....................................................................54

Table 24. H8 Programming Jumpers ....................................................................57

Table 25. Key Jumpers.......................................................................................58

About This Document

2nd Generation Intel®Core™ Processor with Intel®6 Series Chipset Development Kit

User Guide March 2011

6 Document Number: 325208-001

Revision History

Document

Number Revision

Number Description Revision Date

325208 001 Initial release. March 2011

About This Document

2nd Generation Intel®Core™ Processor with Intel®6 Series Chipset Development Kit

March 2011 User Guide

Document Number: 325208-001 7

1About This Document

This guide describes the use of the 2nd Generation Intel®Core™ Processor Family with

Intel®6 Series Chipset Development Kit. The document has been written for OEMs,

system evaluators, and embedded system developers, and assumes basic familiarity

in the fundamental concepts involved with installing and configuring hardware for a

personal computer system. The document defines all jumpers, headers, LED functions,

their locations on the development kit, and other subsystem features and POST codes.

For the latest information about the 2nd Generation Intel®Core™ Processor Family

with Intel®6 Series Chipset development board design collateral, please visit the

Intel®Embedded Design Center.

1.1 Content Overview

This manual is arranged into the following sections:

•About This Document contains a description of conventions used in this document.

The last few sections explain how to obtain literature and contact customer

support.

•Getting Started describes the contents of the development kit and explains the

basics steps necessary to get the board running. This section also includes

information on how to update the BIOS.

•Development Kit Features describes details on the hardware features of the

development board. It explains the Power Management and Testability features.

•Development Board Summary provides a list of major board components and

connectors. It gives a description of jumper settings and functions. The section

also explains the use of the programming headers.

•Add-In Cards contains information on add-in cards available from Intel that can be

used with the development board.

1.2 Text Conventions

The notations listed in Table 1 may be used throughout this document.

Table 1. Text Conventions

Notation Definition

# The pound symbol (#) appended to a signal name indicates that the signal

is active low (e.g., PRSNT1#).

Variables Variables are shown in italics. Variables must be replaced with correct

values.

Instructions Instruction mnemonics are shown in uppercase. When you are

programming, instructions are not case-sensitive. You may use either

About This Document

2nd Generation Intel®Core™ Processor with Intel®6 Series Chipset Development Kit

User Guide March 2011

8 Document Number: 325208-001

Notation Definition

uppercase or lowercase.

Numbers

Hexadecimal numbers are represented by a string of hexadecimal digits

followed by the character H. A zero prefix is added to numbers that begin

with A through F. (For example, FF is shown as 0FFH.) Decimal and binary

numbers are represented by their customary notations (i.e., 255 is a

decimal number and 1111 is a binary number; in some cases, the letter B

is added for clarity).

Units of Measure

Gbyte

Kbyte

KΩ

Mbyte

MHz

µA

µF

µs

µW

The following abbreviations are used to represent units of measure:

amps, amperes

gigabytes

gigabits

giga transfers

kilobytes

kilo-ohms

milliamps, mill amperes

megabytes

megahertz

milliseconds

Mega Transfers

milliwatts

nanoseconds

picofarads

watts

volts

microamps, microamperes

microfarads

microseconds

microwatts

Signal Names

Signal names are shown in uppercase. When several signals share a

common name, an individual signal is represented by the signal name

followed by a number, while the group is represented by the signal name

followed by a variable (n). For example, the lower chip-select signals are

named CS0#, CS1#, CS2#, and so on; they are collectively called CSn#.

A pound symbol (#) appended to a signal name identifies an active-low

signal. Port pins are represented by the port abbreviation, a period, and

the pin number (e.g., P1.0).

About This Document

2nd Generation Intel®Core™ Processor with Intel®6 Series Chipset Development Kit

March 2011 User Guide

Document Number: 325208-001 9

1.3 Glossary of Terms and Acronyms

Table 2 defines conventions and terminology used throughout this document.

Table 2. Terms

Term Definition

Aggressor A network that transmits a coupled signal to another network.

Anti-etch Any plane-split, void or cutout in a VCC or GND plane.

Bus Agent A component or group of components that, when combined, represent a

single load on the AGTL+ bus.

Crosstalk

The reception on a victim network of a signal imposed by aggressor

network(s) through inductive and capacitive coupling between the

networks.

Backward Crosstalk - Coupling that creates a signal in a victim network

that travels in the opposite direction as the aggressor’s signal.

Forward Crosstalk - Coupling that creates a signal in a victim network that

travels in the same direction as the aggressor’s signal.

Even Mode Crosstalk - Coupling from a signal or multiple aggressors when

all the aggressors switch in the same direction that the victim is switching.

Odd Mode Crosstalk - Coupling from a signal or multiple aggressors when

all the aggressors switch to the direction opposite the victim’s switching.

Duck Bay 3 PCI Express* interposer card that provides Express-card support for the

development board

Flight Time

Flight time is a term in the timing equation that includes the signal

propagation delay, any effects the system has on the TCO (time from

clock-in to data-out) of the driver, plus any adjustments to the signal at

the receiver needed to ensure the setup time of the receiver. More

precisely, flight time is defined as:

The time difference between a signal at the input pin of a receiving agent

crossing the switching voltage (adjusted to meet the receiver

manufacturer’s conditions required for AC timing specifications; i.e.,

ringback, etc.) and the output pin of the driving agent crossing the

switching voltage when the driver is driving a test load used to specify the

driver’s AC timings.

Maximum and Minimum Flight Time - Flight time variations are caused by

many different parameters. The more obvious causes include variation of

the board dielectric constant, changes in load condition, crosstalk, power

noise, variation in termination resistance, and differences in I/O buffer

performance as a function of temperature, voltage, and manufacturing

process. Some less obvious causes include effects of Simultaneous

Switching Output (SSO) and packaging effects.

Maximum flight time is the largest acceptable flight time a network will

experience under all conditions.

Minimum flight time is the smallest acceptable flight time a network will

experience under all conditions.

Gen 2 PCI Express Generation 2

About This Document

2nd Generation Intel®Core™ Processor with Intel®6 Series Chipset Development Kit

User Guide March 2011

10 Document Number: 325208-001

Term Definition

Infrared Data

Assoc.

The Infrared Data Association (IrDA) has outlined a specification for serial

communication between two devices via a bidirectional infrared data port.

The CRB has such a port and it is located on the rear of the platform

between the two USB connectors.

Intel®MVP 7.0 The Intel®Mobile Voltage Positioning specification for the 2nd generation

Intel®Core™ Processor Family. It is a DC-DC converter module that

supplies the required voltage and current to a single processor.

Inter-Symbol

Interference

Inter-symbol interference is the effect of a previous signal (or transition)

on the interconnect delay. For example, when a signal is transmitted

down a line and the reflections due to the transition have not completely

dissipated, the following data transition launched onto the bus is affected.

ISI is dependent upon frequency, time delay of the line, and the reflection

coefficient at the driver and receiver. ISI may impact both timing and

signal integrity.

Mott Canyon IV This Add-in card enables Intel®High Definition Audio functionality.

Network The network is the trace of a Printed Circuit Board (PCB) that completes

an electrical connection between two or more components.

Overshoot The maximum voltage observed for a signal at the device pad, measured

with respect to VCC.

Pad The electrical contact point of a semiconductor die to the package

substrate. A pad is only observable in simulations.

Pin The contact point of a component package to the traces on a substrate,

such as the motherboard. Signal quality and timings may be measured at

the pin.

Power-Good

“Power-Good,” “PWRGOOD,” or “CPUPWRGOOD” (an active high signal)

indicates that all of the system power supplies and clocks are stable.

PWRGOOD should go active at a predetermined time after system

voltages are stable and should go inactive as soon as any of these

voltages fail their specifications.

Ringback The voltage to which a signal changes after reaching its maximum

absolute value. Ringback may be caused by reflections, driver oscillations,

or other transmission line phenomena.

RJ45 A type of registered jack.

System Bus The System Bus is the microprocessor bus of the processor.

Setup Window The time between the beginning of Setup to Clock (TSU_MIN) and the

arrival of a valid clock edge. This window may be different for each type of

bus agent in the system.

Simultaneous

Switching Output

Simultaneous Switching Output (SSO) effects are differences in electrical

timing parameters and degradation in signal quality caused by multiple

signal outputs simultaneously switching voltage levels in the opposite

direction from a single signal or in the same direction. These are called

odd mode and even mode switching, respectively. This simultaneous

switching of multiple outputs creates higher current swings that may

cause additional propagation delay (“push-out”) or a decrease in

propagation delay (“pull-in”). These SSO effects may impact the setup

and/or hold times and are not always taken into account by simulations.

System timing budgets should include margin for SSO effects.

Tabla de contenidos

Otros manuales de Hardware de computadora de Intel

Intel

Intel Braswell Series Manual de usuario

Intel

Intel 2ND GENERATION CORE PROCESSOR FAMILY DESKTOP - THERMAL MECHANICAL S AND DESIGN GUIDELINES... Manual de usuario

Intel
