Intel NUC 8 Business Manual del propietario

Intel® NUC 8 Compute Element

Product Specification

Revision 1.2

Regulatory Model: CM8CB

March 2021

Intel® NUC 8 CM8CCB4R, CM8PCB4R, CM8I3CB4N, CM8I5CB8N, CM8V5CB8N, CM8I7CB8N or CM8V7CB8N may contain design defects or errors

known as errata that may cause the product to deviate from published specifications. Current characterized errata, if any, are documented in this

product specification

Downloaded from Arrow.com.

Revision History

Revision

Revision History

Date

1.0

First release

October 2019

1.1

BIOS version number updated, processor stepping/spec updated, connector pin

out changed.

July 2020

1.2

Product name changed. Added note that SATA is not supported on CM8PCB4R

March 2021

Disclaimer

This product specification applies only to the standard Intel®NUC 8 Element with BIOS identifier

CBWHL357.86A or CBWHLMIV.86A.

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE, EXPRESS OR

IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT.

EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO

LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR

USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE,

MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.

UNLESS OTHERWISE AGREED IN WRITING BY INTEL, THE INTEL PRODUCTS ARE NOT DESIGNED NOR INTENDED FOR

ANY APPLICATION IN WHICH THE FAILURE OF THE INTEL PRODUCT COULD CREATE A SITUATION WHERE PERSONAL

INJURY OR DEATH MAY OCCUR.

All Intel® NUC 8 Compute Elements are evaluated as Information Technology Equipment (I.T.E.) for use in personal

computers (PC) for installation in homes, offices, schools, computer rooms, and similar locations. The suitability of this

product for other PC or embedded non-PC applications or other environments, such as medical, industrial, alarm systems,

test equipment, etc. may not be supported without further evaluation by Intel.

Intel Corporation may have patents or pending patent applications, trademarks, copyrights, or other intellectual property

rights that relate to the presented subject matter. The furnishing of documents and other materials and information does

not provide any license, express or implied, by estoppel or otherwise, to any such patents, trademarks, copyrights, or

other intellectual property rights.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved” or

“undefined.” Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or

incompatibilities arising from future changes to them.

Intel processor numbers are not a measure of performance. Processor numbers differentiate features within each

processor family, not across different processor families: Go to:

Learn About Intel®Processor Numbers

Intel® NUC 8 Compute Elements may contain design defects or errors known as errata, which may cause the product to

deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your product

order.

Intel, the Intel logo and Intel Core are trademarks of Intel Corporation in the U.S. and/or other countries.

* Other names and brands may be claimed as the property of others.

Downloaded from Arrow.com.Downloaded from Arrow.com.

iii

Preface

This Product Specification specifies the layout, components, connectors, power, and

environmental features for the Intel® NUC 8 CM8CCB4R, CM8PCB4R, CM8I3CB4N, CM8I5CB8N,

CM8V5CB8N, CM8I7CB8N or CM8V7CB8N.

NOTE

In this document, the use of “Intel® NUC 8 Compute Element” will refer to the CM8CCB4R,

CM8PCB4R, CM8I3CB4N, CM8I5CB8N, CM8V5CB8N, CM8I7CB8N and CB8V7CB8N versions.

Intended Audience

This document is intended to provide technical information about Intel® NUC 8 CM8CCB4R,

CM8PCB4R, CM8I3CB4N, CM8I5CB8N, CM8V5CB8N, CM8I7CB8N or CB8V7CB8N and its

components to the vendors, system integrators, and other engineers and technicians who need

this level of information. It is specifically not intended for general audiences.

What This Document Contains

Chapter

Description

A description of the CM8CCB4R, CM8PCB4R, CM8I3CB4N, CM8I5CB8N, CM8V5CB8N,

CM8I7CB8N or CM8V7CB8N features

A technical description of the CM8CCB4R, CM8PCB4R, CM8I3CB4N, CM8I5CB8N,

CM8V5CB8N CM8I7CB8N or CM8V7CB8N

Typographical Conventions

This section contains information about the conventions used in this specification. Not all of

these symbols and abbreviations appear in all specifications of this type.

Notes, Cautions, and Warnings

NOTE

Notes call attention to important information.

CAUTION

Cautions are included to help you avoid damaging hardware or losing data.

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Other Common Notation

Used after a signal name to identify an active-low signal (such as USBP0#)

Gigabyte (1,073,741,824 bytes)

GB/s

Gigabytes per second

Gb/s

Gigabits per second

Kilobyte (1024 bytes)

Kilobit (1024 bits)

kb/s

1000 bits per second

Megabyte (1,048,576 bytes)

MB/s

Megabytes per second

Megabit (1,048,576 bits)

Mb/s

Megabits per second

TDP

Thermal Design Power

Xxh

An address or data value ending with a lowercase h indicates a hexadecimal value.

x.x V

Volts. Voltages are DC unless otherwise specified.

This symbol is used to indicate third-party brands and names that are the property of their respective

owners.

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Intel® NUC 8 Compute Element Identification Information

AA Revision

Product Code

Original BIOS Revision

Notes

K53739-203

BKCM8CCB4R

CBWHL357.0058

1,2

K53742-203

BKCM8PCB4R

CBWHL357.0058

1,3

K53744-203

BKCM8I3CB4N

CBWHL357.0058

1,4

K53746-203

BKCM8I5CB8N

CBWHL357.0058

1,5

K53774-203

BKCM8V5CB8N

CBWHLMIV.0058

1,6

K53740-203

BKCM8I7CB8N

CBWHL357.0058

1,7

K53738-203

BKCM8V7CB8N

CBWHLMIV.0058

1,8

Notes:

1. The AA number is found on the Mylar cover.

2. The Intel® Celeron® 4305U processor is used on this AA revision consisting of the following component:

Device

Stepping

Spec Code

Intel® Celeron® 4305U

SRFA5

3. The Intel® Pentium® Gold 5405U processor is used on this AA revision consisting of the following component:

Device

Stepping

Spec Code

Intel® Pentium® Gold 5405U

SRFG1

4. The Intel® Core™ i3-8145U processor is used on this AA revision consisting of the following component:

Device

Stepping

Spec Code

Intel® Core™ i3-8145U

SRFFZ

5. The Intel® Core™ i5-8265U processor is used on this AA revision consisting of the following component:

Device

Stepping

Spec Code

Intel Core™ i5-8265U

SRFFX

6. The Intel® Core™ i5-8365U processor is used on this AA revision consisting of the following component:

Device

Stepping

Spec Code

Intel® Core™ i5-8365U

SRF9Z

7. The Intel® Core™ i5-8365U processor is used on this AA revision consisting of the following component:

Device

Stepping

Spec Code

Intel® Core™ i7-8565U

SRFFW

8. The Intel® Core™ i5-8365U processor is used on this AA revision consisting of the following component:

Device

Stepping

Spec Code

Intel® Core™ i7-8665U

SRF9W

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Specification Changes or Clarifications

The table below indicates the Specification Changes or Specification Clarifications that apply to

the Intel® NUC 8 CM8CCB4R, CM8PCB4R, CM8I3CB4N, CM8I5CB8N, CM8V5CB8N, CM8I7CB8N or

CM8V7CB8N.

Specification Changes or Clarifications

Date

Type of Change

Description of Changes or Clarifications

July 2020

BIOS Version,

connector

Clarified actual BIOS versions for current shipping products, changed pin

numbers 214, 216, 220 and 222 to reserved

March 2021

Feature Support

SATA is not supported on CM8PCB4R

Errata

Current characterized errata, if any, will be documented in Section 4 of this Product Specification.

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

vii

Contents

Revision History...............................................................................................................ii

Disclaimer .................................................................................................................................................................. ii

Preface ..............................................................................................................................iii

Intended Audience................................................................................................................................................ iii

What This Document Contains........................................................................................................................ iii

Typographical Conventions .............................................................................................................................. iii

Intel® NUC 8 Compute Element Identification Information.................................................................. v

Specification Changes or Clarifications........................................................................................................vi

Errata........................................................................................................................................................................... vi

Contents ..........................................................................................................................vii

2Product Description ..................................................................................................9

2.1 Overview .........................................................................................................................................................9

2.2 Version Summary........................................................................................................................................9

2.3 Feature Summary.....................................................................................................................................10

3Technical Reference............................................................................................... 12

3.1 Block Diagram............................................................................................................................................ 12

3.2 Compute Element Exterior...................................................................................................................13

3.3 Connector.................................................................................................................................................... 14

3.3.1 Connector Pin-Out................................................................................................................15

3.4 Antenna Connection ...............................................................................................................................19

3.5 BIOS Security Switch...............................................................................................................................19

3.6 Power.............................................................................................................................................................21

3.7 Mechanical ..................................................................................................................................................21

3.8 Thermal ........................................................................................................................................................23

3.9 Environmental ...........................................................................................................................................24

4Characterized Errata............................................................................................... 25

Figures

Figure 1. Block Diagram........................................................................................................................................... 12

Figure 2. Integrated Heat Shield Side................................................................................................................ 13

Figure 3. Mylar Side................................................................................................................................................... 13

Figure 4. Connector with Pinout –Mylar Side................................................................................................14

Figure 5. Connector with Pinout –IHS Side ....................................................................................................14

Figure 6. Location of the Antenna Connectors..............................................................................................19

Figure 7. Location of the BIOS Security Switch.............................................................................................20

Figure 8. Mylar Side................................................................................................................................................... 21

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

viii

Figure 9. Integrated Heat Shield Side................................................................................................................ 22

Figure 10. Front (Showing Connector).............................................................................................................. 22

Figure 11. Back............................................................................................................................................................22

Figure 12. Left..............................................................................................................................................................22

Figure 13. Right...........................................................................................................................................................23

Tables

Table 1. Version Summary........................................................................................................................................9

Table 2. Feature Summary..................................................................................................................................... 10

Table 3. LOTES Connector Options ...................................................................................................................14

Table 4. Connector Segment One with Pin Numbers and Signals........................................................15

Table 5. Connector Segment Two with Pin Numbers and Signals........................................................ 16

Table 6. Connector Segment Three with Pin Numbers and Signals ....................................................17

Table 7. Connector Segment Four with Pin Numbers and Signal ......................................................... 18

Table 8. BIOS Security Switch Settings............................................................................................................. 20

Table 9. Environmental Specifications .............................................................................................................24

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Intel® NUC 8 Compute Element Product Specification

2Product Description

2.1 Overview

The Intel® NUC 8 Compute Element are System-on-Module architecture optimized for integrated

designs. The NUC 8 Compute Element consists of the processor, memory, wireless, Bluetooth*,

integrated heat shield and depending on the model may include storage and discrete TPM. See

Table 1 for a summary.

The Intel® NUC 8 Compute Element requires a compatible carrier board in order to operate.

For information on compatible devices for use with the Intel® NUC 8 Compute Element see

http://www.intel.com/NUCElements.

2.2 Version Summary

There are eight different versions of this model of Intel® NUC 8 Compute Element available which

are summarized in Table 1. Unless otherwise noted in this document, not all features are

available on all versions.

Table 1. Version Summary

Version

Intel® vPro™

Discrete TPM

Memory

Storage

Processor

CM8CCB4R

4 GB

64 GB

Intel® Celeron® 4305U

CM8PCB4R

4 GB

64 GB

Intel® Pentium® Gold 5405U

CM8I3CB4N

4 GB

None

Intel® Core™ i3-8145U

CM8I5CB8N

8 GB

None

Intel® Core™ i5-8265U

CM8V5CB8N

Yes

8 GB

None

Intel® Core™ i5-8365U

CM8I7CB8N

8 GB

None

Intel® Core™ i7-8565U

CM8V7CB8N

Yes

8 GB

None

Intel® Core™ i7-8665U

NOTE

Intel® NUC 8 Compute Elements listed in Table 1 have been certified for use as a component in

Information Technology Equipment in certain countries. The system integrator is responsible for

testing and acquiring any additional country-specific regulatory approvals, including all system-

wide certifications.

NOTE

For information on how to design a carrier board and/or an enclosure for the Intel® NUC 8

Compute Element a design guide is available on MyIntel.

Intel® NUC 8 Compute Element Product Specification

2.3 Feature Summary

Table 2 summarizes the major features of the Intel® NUC 8 Compute Elements.

Table 2. Feature Summary

Size

95 millimeters by 65 millimeters by 6 millimeters

Processor

•Soldered-down Intel® processor

oIntegrated graphics

oIntegrated memory controller

oIntegrated PCH

•The following processors are supported

oIntel® Celeron® 4305U

oIntel® Pentium® Gold 5405U

oIntel® Core™ i3-8145U

oIntel® Core™ i5-8265U

oIntel® Core™ i5-8365U

oIntel® Core™ i7-8565U

oIntel® Core™ i7-8665U

Memory

•Soldered-down dual-channel LPDDR3 memory

•4 GB total memory for CM8CCB4R, CM8PCB4R at 1866 MHz

•4GB total memory for CM8I3CB4N at 2133 MHz

•8 GB total memory for CM8I5CB8N, CM8V5CB8N, CM8I7CB8N and CM8V7CB8N at 2133 MHz

Graphics

Integrated graphics support with Intel®HD Graphics Technology

•Two Digital Display Interface (DDI) lanes are available from the Compute Element connector that

are configured as DisplayPort++ (HDMI can be supported on the carrier board)

•High-Bandwidth Digital Content Protection support for content protection

oHDCP 2.2 supported via DisplayPort*

oHDCP 1.4 supported via HDMI*

•Resolutions and refresh rates supported

oUp to 4K @ 60Hz via DisplayPort

oUp to 4K @ 30Hz via HDMI

Audio

Intel® High Definition (Intel®HD) Audio via the Digital Display Lanes using either DisplayPort or HDMI

Storage

64GB soldered down eMMC 5.1 HS400 for CM8PCB4R and CM8CCB4R

There is no onboard storage for CM8I3CB4N, CM8I5CB8N, CM8V5CB8N, CM8I7CB8N and

CM8V7CB8N

BIOS

•Intel®BIOS resident in the Serial Peripheral Interface (SPI) Flash device

•Support for Advanced Configuration and Power Interface (ACPI), Plug and Play, and System

Management BIOS (SMBIOS)

Wireless LAN

Soldered-down Intel® Dual Band Wireless-AC 9560

•802.11a/b/g/n, 802.11ac, Bluetooth* 5.0

•Antennas are not included

Interfaces

Supported via

the Edge

Connector

•4 USB 3.1 (Gen 21)

•3 USB 2.0

•1 PCIe x1 (Gen 3)

•1 PCIe x4 (Gen 3)

•1 PCIe x4 (Gen 3) or SATA III2(configurable)

•1 GbE PHY

1USB 3.1 (Gen 1) is supported on the CM8PCB4R

2SATA III is not supported on CM8PCB4R

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de computadora de Intel

Intel

Intel BX80623I32100 Manual de usuario

Intel

Intel RMS25PB080 Guía de configuración

Intel

Intel Pentium M Processor Guía

Intel

Intel DH61BE Guía de configuración

Intel

Intel WPC2011BWW - PRO/Wireless 2011B LAN PC Card Manual de usuario

Intel

Intel 80960SA Manual de usuario

Intel

Intel SRCS14L - RAID Controller Manual de usuario

Intel

Intel PXA270 Manual de usuario

Intel

Intel BX80562Q6600 - Core 2 Quad 2.4 GHz Processor Manual de usuario

Intel

Intel DP45SG - CARACTERISTIQUES TECHNIQUES Manual de usuario

Intel

Intel BX80571E5300 - Pentium 2.6 GHz Processor Manual de usuario

Intel

Intel MX4305UE Manual de usuario

Intel

Intel NUC 13 Pro Desk Edition Manual de usuario

Intel

Intel BX80613I7980 Manual de usuario

Intel

Intel ATOM PROCESSOR N 500 - UPDATE REVISION 001 Manual de usuario

Intel

Intel BX80569Q9550 - Core 2 Quad 2.83 GHz... Manual de usuario

Intel

Intel 2ND GENERATION CORE PROCESSOR FAMILY DESKTOP - VOLUME 2... Manual de usuario

Intel

Intel RMS25PB080 Manual de instalación

Intel

Intel 6 SERIES Manual de usuario

Intel

Intel SRCU42X Manual de instalación

Intel

Intel GDT6113RS Manual de usuario

Intel

Intel i960 Jx Manual de usuario

Intel

Intel SRCSASRB - RAID Controller Manual de instalación

Intel

Intel Xeon 5600 Series Manual técnico

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario

Advantech

Advantech ASMB-935 Series Manual de usuario

Jupiter

Jupiter RAM PACK Manual de usuario
