INSTALLATION MANUAL
KYS2000a
Sauna Series
30 Day Technical Support:
Call 01908 317512 and request technical support for aiding your
installaon.
Replacements Parts: Inside of your warranty period visit:
hps://www.insigniashowers.com, click support and make a
warranty claim.
Spares/Replacements Parts: Outside of your warranty period visit
hps://www.insigniashowers.com/replacement-parts.html
ATTENTION INSTALLERS:
These instrucons must be
le with the customer CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!
www.insigniashowers.com Last Modied: 31/01/2022
02
Contents
Thank you for your purchase 3
Electrical & Tool requirements 4
Box contents 5
Sauna Side Panel and Back Panel Install 6
Floor Placement 7
Bench Install 8
Bench Electrics Connecon 9
Bench Seat Install 10
Central Glass Paron Install 11
Fixed Glass Panel Install (Sauna) 12
Roof Install 13
Central Upright Connecon 14
Door Install (Sauna) 15
Door Handle Install (Sauna) 16
Roof Cover Install 17
Sauna Control Panel Instrucons 18
Sauna Room Safety Guide 19
WEEE Compliance Statement 20
www.insigniashowers.com Last Modied: 31/01/2022
03
Thank you for your recent purchase of an Insignia Sauna. Please read this booklet with
great care to ensure you get the best out of your build and have a Sauna that will last
for many years to come! Like everything, in order to obtain a rst class product that
will serve you well for many years, the eort and correctness put into the assembly
will reect in the quality of your nish.
www.insigniashowers.com Last Modied: 31/01/2022
04
• Scissors
• Knife
• Spirit Level
• Tape Measure
• Philips Screwdriver
• Electric Drill
• Safety Gloves
• Safety Glasses
Tools Required
Voltage Rang 220-240AC
Frequency Rang 50Hz
Power Rang 1597 Was
Total Amperage 6.67 Amps
Always consult a qualied Electrician before connecon as to suitability
Always Obtain Relevant Cercaon (minor Works Part P etc)
This Sauna / Shower must comply with current UK bathroom regulaons
Your electrical contractor will understand ALL legal requirements of connecon before undertaking any work or
installaon.
UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF
Note for electrician:
1) Connect within current laws and IP direcves.
2) (Preferred) Wire into isolated fused feed connecng directly to the house consumer/service box.
Always use protecon against electrical surge. Your shower should be treated the same as a home computer. A
surge protector should eradicate the possibility of burn out.
Subject to connecon type, electrical work needs to be signed o by a fully qualied operave by law. Failure to
adhere to this will not only void your electrical warranty for your sauna, but could void your house insurance.
Electrical Requirements Model KSY2000
www.insigniashowers.com Last Modied: 31/01/2022
05
What’s in the Boxes?
Contents Quanty
Roof
Floor
Middle Paron Glass Panel
Wooden Side Panel
Wooden Back Panel
Accessories
Door Handle
Door Hinge
Sauna Door
Central Upright Connector
Magnec Seal
Rear Door Seal
1
1
1
1
1
1
1
4
1
1
4
2
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
VERY IMPORTANT
Have you got everything? If not please contact the Insignia directly on 01908 317 512.
Remember NEVER book your tradesman unl everything has arrived, been checked and is
present. No replacement/missing parts can be obtained free of charge during or aer the
build. Any claims can only be within the mescale permied (48 hours aer delivery) and
always BEFORE build.
Contents Quanty
Bench Top
Bench Side
Bench Front
1
1
1
[ ]
[ ]
[ ]
www.insigniashowers.com Last Modied: 31/01/2022
06
Step 1 — Installing the back and side panel (Sauna)
The panel connecon brackets are shown (above). Li
panels and locate the interlocking connecon brackets
and push the panel down to secure into posion. Locate
both panels onto the wooden side of the base.
www.insigniashowers.com Last Modied: 31/01/2022
07
Step 2 — Placing the oor into posion
Locate the oor and place into posion by
pushing it up to the side and back panel ghtly.
www.insigniashowers.com Last Modied: 31/01/2022
08
Step 3 — Installing the bench
Locate the bench front and place between the two
wooden struts on the side panel to secure it into posion.
Locate the bench side and place between the wooden
struts on the back panel to secure into posion.
On the inner side of the bench,
locate the 50mm screws and
secure the bench pieces to the
oor, panels and each other.
6 x 50mm Screws
www.insigniashowers.com Last Modied: 31/01/2022
09
Step 4 — Connecng the heater electrics
Locate the wires and connect together
before nishing the bench install.
www.insigniashowers.com Last Modied: 31/01/2022
10
Step 5 — Installing the bench topper
Locate the bench seat and slide into posion. The
underside of the bench top will have a grooved
recess which ts over the bench uprights.
2 x 60mm Screws
