User

Clock Radio with Voice Command

NS-CLVR01

User Guide

NS-CLVR01_10-0138_MAN_ENG_V2.fm Page 1 Tuesday, February 2, 2010 3:04 PM

www.insigniaproducts.com 3

Insignia NS-CLVR01

Clock Radio with Voice Command

Contents

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Setting up your clock radio . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Using your clock radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Using voice commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Using manual buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

90-day limited warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Introduction

Congratulations on your purchase of a high-quality Insignia product.

Your NS-CLVR01 represents the state of the art in clock radio design

and is designed for reliable and trouble-free performance.

Safety information

The lightning flash with arrowhead symbol

within an equilateral triangle is intended to

alert you to the presence of uninsulated

dangerous voltage within your clock radio’s

enclosure that may be of sufficient

magnitude to constitute a risk of electric

shock.

CAUTION:

TO REDUCE THE RISK OF

ELECTRIC

SHOCK, DO NOT REMOVE

COVER

(OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING

QUALIFIED SERVICE PERSONNEL.

NS-CLVR01_10-0138_MAN_ENG_V2.fm Page 3 Tuesday, February 2, 2010 3:04 PM

Insignia NS-CLVR01 Clock Radio with Voice Command

www.insigniaproducts.com

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with a dry cloth.

7) Do not block any ventilation openings. Install in accordance with

the manufacture's instructions.

8) Do not install near any heat source, such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that

produce heat.

9) Do not defeat the safety feature of the polarized or grounding-type

plug. A polarized plug has two blades and a third grounding prong.

The wide blade or the third prong are provided for your safety. If the

provided plug does not fit into your outlet. Consult an electrician for

replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched,

particularly at plugs, convenience receptacles, and the point where

they exit the clock radio.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by

the manufacturer, or sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus combination to avoid

injury from tip-over.

13) Unplug this clock radio during lightning storms or when unused

for long periods of time.

14) Refer all servicing to qualified service personal. Servicing is

required when the clock radio has been damaged in any way, such as

the power cord or plug is damaged, liquid has been spilled or objects

have fallen into the clock radio, the clock radio has been exposed to

rain or moisture, does not operate normally, or has been dropped.

15) Do not expose your clock radio to dripping or splashing liquids,

and no objects filled with liquids should be placed on it.

16) Excessive sound pressure from earphones and headphones can

cause hearing loss.

The exclamation point within an equilateral

triangle is intended to alert you to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying your clock radio.

NS-CLVR01_10-0138_MAN_ENG_V2.fm Page 4 Tuesday, February 2, 2010 3:04 PM

Insignia NS-CLVR01 Clock Radio with Voice Command

www.insigniaproducts.com

17) The AC adapter is used as the disconnect device and it shall

remain readily operable during use. In order to disconnect the clock

radio, the AC adapter should be removed from the AC power outlet

completely.

18) The batteries (battery pack and batteries installed) should not be

exposed to excessive heat, such as sunshine, fire, or similar heat

sources.

Features

Package contents

Your clock radio includes the following items:

• Clock radio

• AC power adapter

• User Guide

• Quick Setup Guide

• AAA alkaline batteries (3)

Front view

NoteRead Rating Labels on the bottom of the system for power

input and other safety information.

NoteVoice commands are recognized in English only.

# Feature Description

1 LCD display Provides information about the clock radio functions.

NS-CLVR01_10-0138_MAN_ENG_V2.fm Page 5 Tuesday, February 2, 2010 3:04 PM

Insignia NS-CLVR01 Clock Radio with Voice Command

www.insigniaproducts.com

Top view

# Feature Description

1 Speakers and

microphone Produces the sound (speakers) and receives voice

commands (microphone).

2 Volume + button Press to increase the volume of the clock radio.

3 Volume – button Press to decrease the volume of the clock radio.

4 RECORD button Press to record the preset station names.

5 SNOOZE/SLEEP/

VOICE COMMAND

BUTTON

Press to start the voice commands, or press and hold to

set the sleep timer. When the alarm is sounding, press to

temporarily turn off the alarm (snooze).

6 /SOURCE button Press and hold to turn the clock radio on or off. When the

radio is on, repeatedly press to cycle through AM, FM,

and Aux in.

7 Tune – button Press to tune or scan the radio to a lower frequency.

8 Tune + button Press to tune or scan the radio to a higher frequency.

9 PRESET button Press repeatedly to recall preset stations.

NS-CLVR01_10-0138_MAN_ENG_V2.fm Page 6 Tuesday, February 2, 2010 3:04 PM

Insignia NS-CLVR01 Clock Radio with Voice Command

www.insigniaproducts.com

Back view

Setting up your clock radio

Installing the backup batteries

The clock radio uses a backup battery system to maintain clock and

alarm settings in the event of a power failure. If the backup batteries

have been installed and a power failure occurs or the AC cord is

accidentally disconnected, the display will not remain lit, but the

current time and alarm time settings (the alarm will not sound) will be

temporarily maintained. Otherwise, you must reset the time and alarm

settings.

# Feature Description

1 DC in jack Connect the AC power adapter here.

2 AUX in jack Connect a cable from an external audio source to this jack

to hear the sound through your clock radio.

3 FM antenna (wire) Uncoil and extend this wire antenna to improve FM radio

reception.

4 Dimmer button Press to adjust the backlight of the LCD.

5 Time set button Press and hold to enter the time set mode.

6 Hour button Press to set the hour.

7 Minute button Press to set the minutes.

8 Alarm 1 button Press and hold to select Alarm 1 and change the setting.

9 Alarm 2 button Press and hold to select Alarm 2 and change the setting.

10 VC ON/OFF button Press turn the voice command function on or off.

NS-CLVR01_10-0138_MAN_ENG_V2.fm Page 7 Tuesday, February 2, 2010 3:04 PM

Insignia NS-CLVR01 Clock Radio with Voice Command

www.insigniaproducts.com

A battery indicator icon will appear on the display if the batteries

are low.

Make sure the AC cord is connected. Otherwise all settings may be

lost during battery replacement.

To install the backup batteries:

1Open the battery compartment cover located on the bottom of

your clock radio.

2Insert three “AAA” batteries, checking that the polarity (+ and -

ends of the batteries) matches the drawing inside the battery

compartment. We recommend the use of alkaline batteries for

longer life.

3Close the battery compartment cover.

Warnings

• Do not recharge, short, disassemble, or heat the

batteries, or dispose of in a fire.

• Dispose of battery in the proper manner, according to

federal, state, and local regulations.

• Remove the batteries when the charge is depleted.

• Battery chemicals can cause a rash. If the batteries leak,

clean the battery compartment with a cloth. If chemicals

touch your skin, wash immediately.

• Do not mix different types of batteries.

• Do not try to recharge non-rechargable batteries.

NS-CLVR01_10-0138_MAN_ENG_V2.fm Page 8 Tuesday, February 2, 2010 3:04 PM

Insignia NS-CLVR01 Clock Radio with Voice Command

www.insigniaproducts.com

Making connections

Connecting the AC power adapter

Make sure that the AC power outlet matches the AC adapter’s power

specifications (110 V ~ 60 Hz) prior to plugging in the adapter.

To connect the AC adapter:

1Plug the small DC power connector into the DC IN 9V jack on the

back of your clock radio.

2Plug the AC adapter into an AC power outlet.

Connecting an external sound source

You can listen to an external sound source, such as a CD, MD, or

non-docking iPod®, on your clock radio.

To listen to an external sound source:

1Make sure that your clock radio is turned off.

2Connect the external sound source to the AUX IN jack on the back

of your clock radio using a stereo 3.5mm plug cord (not supplied).

3Press and hold the /SOURCE button for two seconds to turn on

your clock radio.

4Press the /SOURCE button repeatedly until “AUX” appears on

the display.

5Start playback on the external sound source, then adjust the

volume to a comfortable level. Control playback on the external

audio device.

Setting the clock

You can also set the clock using voice commands. See “Using voice

commands” on page 10.

To set the clock:

1Press and hold the TIME SET button on the back of your clock

radio. The time blinks on the LCD.

2Press MIN (minute) to set the minutes and HOUR to set the hours.

Make sure that you set AM/PM correctly.

3Press TIME SET again. The clock is set.

Note• Remove both the DC plug and the AC-IN plug to

disconnect the AC power adapter when not in use.

• Use only the supplied AC power adapter to power your

clock radio. (DC 9V, 1A )

NS-CLVR01_10-0138_MAN_ENG_V2.fm Page 9 Tuesday, February 2, 2010 3:04 PM

Insignia NS-CLVR01 Clock Radio with Voice Command

www.insigniaproducts.com

Using your clock radio

Turning your clock radio on and off

To turn your clock radio on and off:

1Press and hold /SOURCE for two seconds. Your clock radio

turns on.

2Press DIMMER on the back of your clock radio to set the display

backlight of the LCD to a comfortable level.

3Press and hold /SOURCE again to switch your clock radio to

standby mode.

Using voice commands

To use voice commands:

1To activate the voice interactive commands, make sure that the

voice control button on the back of the clock radio is set to on (the

“VC” indicator appears on the LCD display).

2Say “Voice Command” to the clock radio or press the SNOOZE/

SLEEP/VOICE COMMAND button. The clock will respond “What

can I do for you?.”

NoteVoice commands are recognized in English only.

Tips• Keep the background fairly quiet.

• Speak clearly and in a normal tone.

• Give correct commands (refer to command list below).

• Do not give commands when the clock radio is speaking.

• Speak near the microphone located on the top of the

clock radio.

NoteWhen the clock radio is waiting for your commands, always

respond within three seconds. If no response is received

from you within this time, the clock will reply “Sorry, I did not

recognize your command.” The clock radio will revert to

standby mode if it asks this more than two times. You will

hear “Sorry, I am having trouble understanding you. Please

try again later” before it quits.

NS-CLVR01_10-0138_MAN_ENG_V2.fm Page 10 Tuesday, February 2, 2010 3:04 PM

Insignia NS-CLVR01 Clock Radio with Voice Command

www.insigniaproducts.com

3Say any of the following commands for the function you want, then

follow the voice prompts carefully:

Command The Radio Responds What’s Next

Time The current time is - -: - - (AM/PM) The clock tells you the current time.

Set Time Please say the current time

including AM or PM. Say the time you want to set.

The time is now set to - -: - - (AM/

PM). If the clock radio failed to

understand the time stated, it will

give an example of how to say it

correctly.

I am sorry, please say current time,

for example six fifteen AM. If the clock still does not recognize

what you say after three tries, it will

respond again.

Sorry, I am having trouble

understanding you. Please try

again later.

Try again later.

Alarm Please say alarm one or alarm two Say “one” or “two.”

Alarm one (or two) is set to - - : - -

(AM/PM). The clock radio will also tell you if

the alarm is on or off, as well as the

existing alarm sound set.

The alarm is On. The alarm sound

is (Radio/Buzzer). Do you want to

turn it off?

You may either answer “Yes,” “No,”

or “Cancel.” If you say “Yes,” the

clock radio will confirm.

Alarm one is now turned off. If the instruction is “No” or “Cancel,”

the clock radio will quit the alarm

setting mode and your previous

setting will be kept as it is.

Set Alarm Please say alarm one or alarm two. Say “one” or “two.”

Please say the alarm time

including AM/PM. Say the alarm time you want.

Alarm one (or two) is set to - -:- -

(AM/PM). The clock radio will ask for

confirmation.

Please say confirm or reset. If you say “confirm,” the clock radio

will continue.

Please say buzzer alarm or radio

alarm. To wake to radio, say “radio alarm”

and the clock radio will confirm.

The alarm sound is radio. The alarm is set.

NoteIf you would like to change the alarm time after you have already stated the

time, when the clock radio asks “Please say confirm or reset,” you should say

“reset.” The clock radio will ask “Please say the alarm time including AM or

PM.” You can also say “Cancel” if you do not want to continue the alarm

setting.

NS-CLVR01_10-0138_MAN_ENG_V2.fm Page 11 Tuesday, February 2, 2010 3:04 PM

Otros manuales para NS-CLVR01

Tabla de contenidos

Otros manuales de Radio reloj de Insignia

Insignia

Insignia NS-CLBT01-W Manual de usuario

Insignia

Insignia NS-CLIP02 Manual de instalación y operación

Insignia

Insignia NS-CL3B01 Manual de usuario

Insignia

Insignia Insignia Narrator NS-CLHD01 Guía de inicio rápido

Insignia

Insignia NS-CLWL01 Manual de usuario

Insignia

Insignia NS-C2112 Manual de usuario

Insignia

Insignia NS-S4000 - 174; - Digital Clock Radio Manual de usuario

Insignia

Insignia NS-PRCL01 Manual de usuario

Insignia

Insignia Insignia Narrator NS-CLHD01 Manual de usuario

Insignia

Insignia NS-C2111 - Clock Radio Model Manual de usuario

Insignia

Insignia NS-C2116 Manual de usuario

Insignia

Insignia NS-CLOPP1 Manual de usuario

Insignia

Insignia NS-PRCL01 Manual de usuario

Insignia

Insignia NS-CLBT01 Manual de lista de piezas

Insignia

Insignia NS-CLVR01 Manual de usuario

Insignia

Insignia NS-CLW01 Manual de usuario

Insignia

Insignia NS-CLIP02 Manual de usuario

Insignia

Insignia NS-CLOPP1 Manual de usuario

Insignia

Insignia Insignia Narrator NS-CLHD01 Manual de lista de piezas

Insignia

Insignia NS-CL02 Manual de usuario

Insignia

Insignia NS-CLVR01 Manual de usuario

Insignia

Insignia NS-CL1111 Manual de usuario

Insignia

Insignia NS-CLVR01 Manual de usuario

Insignia

Insignia NS-CLOPP2 Manual de usuario

Manuales populares de Radio reloj de otras marcas

Denver

Denver CRQ-105 Manual de usuario

Audiovox

Audiovox CE90 Manual de usuario

Sony

Sony Dream Machine ICF-C763L Manual de usuario

Sanyo

Sanyo DMP-P6 Manual de usuario

RCA

RCA RPC100 Manual de usuario

Yamaha

Yamaha ISX-80 Manual de usuario

Pyle

Pyle PLMR20W Manual de usuario

Blaupunkt

Blaupunkt CR7BK Manual de usuario

Philips

Philips AJ3180 Manual de usuario

HoMedics

HoMedics SS-5500-2EU Manual de usuario

RCA

RCA RC66i Manual de usuario

Versaudio

Versaudio Vers Manual de usuario

SOUNDMASTER

SOUNDMASTER UR8100 Manual de usuario

Audiovox

Audiovox CE90 Manual de usuario

Jensen Audio

Jensen Audio JCR-222 - AM/FM Projection Alarm Clock Radio Manual de usuario

Roberts

Roberts ChronoDAB Manual de usuario

AEG

AEG MRC 4132 BT Manual de usuario

Tokai

Tokai TC-155 Manual de usuario
