Insignia NS-CLOPP1 Manual de usuario

User Guide

Digital Clock Radio with FM

NS-CLOPP1

Before using your new product, please read these instructions to prevent any damage.

Insignia NS-CLOPP1 Digital Clock Radio with FM

www.insigniaproducts.com

Insignia NS-CLOPP1

Digital Clock Radio with FM

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Top buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Setting up your radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing backup batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Connecting the AC/DC power adapter . . . . . . . . . . . . . . . . . . . . . . .8

Using your radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Setting the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Setting the alarm sound. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Setting the alarm time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Using the snooze feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Turning off the alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Adjusting the LCD brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Playing your radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Programming a radio station preset . . . . . . . . . . . . . . . . . . . . . . . .12

Tuning to a preset radio station . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Connecting an audio device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

90-day limited warranty - Insignia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Introduction

Congratulations on your purchase of a high-quality Insignia product. Your

NS-CLOPP1 represents the state of the art in digital clock radio design and

is designed for reliable and trouble-free performance.

Insignia NS-CLOPP1 Digital Clock Radio with FM

www.insigniaproducts.com

Important safety instructions

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with the

manufacturer's instructions.

Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including amplifiers) that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type plug.

A polarized plug has two blades with one wider than the other. A

grounding type plug has two blades and a third grounding prong. The

wide blade or the third prong are provided for your safety. If the provided

plug does not fit into your outlet, consult an electrician for replacement of

the obsolete outlet.

Protect the power cord from being walked on or pinched particularly at

plugs, convenience receptacles, and the point where they exit from the

apparatus.

Only use attachments/accessories specified by the manufacturer.

Unplug this apparatus during lightning storms or when unused for long

periods of time.

Refer all servicing to qualified service personnel. Servicing is required

when the apparatus has been damaged in any way, such as power-supply

cord or plug is damaged, liquid has been spilled or objects have fallen into

the apparatus, the apparatus has been exposed to rain or moisture, does

not operate normally, or has been dropped.

To reduce the risk of fire or electric shock, do not expose this device to

rain, moisture, dripping, or splashing, and no objects filled with liquids,

such as vases, shall be placed on it.

The wall plug is the disconnecting device. The plug must remain readily

operable.

Batteries should not be exposed to excessive heat such as sunshine, fire, or

the like.

Caution

Danger of explosion if battery is incorrectly replaced. Replace

only with the same or equivalent type.

Insignia NS-CLOPP1 Digital Clock Radio with FM

www.insigniaproducts.com

Features

Top buttons

# Item Description

1 Preset button Press to program a radio station preset or to tune to a preset radio

station. See “Programming a radio station preset” on page 12 or

“Tuning to a preset radio station” on page 12.

2 Sleep button Press to set the time or the sleep timer. For more information, see

“Setting the time” on page 8 or “Setting the sleep timer” on page 10.

3 (previous/fast reverse) button Press and hold for one second to go to the next lower radio station.

Quickly press and release to manually tune to a lower radio frequency.

4 (Alarm 1) button Press to set Alarm 1. See “Setting the alarm sound” on page 9 and

“Setting the alarm time” on page 9.

5 (next/fast forward) button Press and hold for one second to go to the next higher radio station.

Quickly press and release to manually tune to a higher radio

frequency.

6 (Alarm 2) button Press to set Alarm 2. See “Setting the alarm sound” on page 9 and

“Setting the alarm time” on page 9.

7 button When the alarm turns on, press to turn off the alarm for 10 minutes.

See “Using the snooze feature” on page 10.

Press to adjust the LCD brightness. See “Adjusting the LCD brightness”

on page 11.

8 Source (source/standby) button When your radio is turned off (in standby mode), press to turn it on.

See “Playing your radio” on page 11.

When your radio is turned on, press and hold for more than two

seconds to turn your radio off (put in standby mode).

When your radio is turned on, quickly press and release to switch

between playing the radio and playing a connected audio device. See

“Connecting an audio device” on page 12.

SNOOZE / DIMMER

Preset

Sleep

Source

910

SNOOZE / DIMMER

Insignia NS-CLOPP1 Digital Clock Radio with FM

www.insigniaproducts.com

Back

9 (volume down) button Press to decrease the volume.

10 (volume up) button Press to increase the volume.

# Item Description

1 DC IN jack Connect the AC/DC power adapter to this the jack. See

“Connecting the AC/DC power adapter” on page 8.

2 AUX jack Connect an audio device to this jack to play the audio from the

device through the radio speakers. See “Connecting an audio

device” on page 12.

# Item Description

5V 0.7A AUX

Insignia NS-CLOPP1 Digital Clock Radio with FM

www.insigniaproducts.com

LCD

# Icon Description

1 Preset When you are programming a radio station preset, “Preset” and the preset number (P-01

through P-10) appear in the center of the LCD. See “Programming a radio station preset”

on page 12.

When you are tuning to a radio station preset, “Preset” and the preset number (P-01

through P-10) appear in the center of the LCD. See “Tuning to a preset radio station” on

page 12.

2 Volume After you select the alarm sound, this icon indicates that you can change the volume of the

alarm. See “Setting the alarm sound” on page 9.

When you are playing the radio, the “Volume” icon lights and the current volume level

(1 through 15) appears in the center of the LCD.

3 Current time Displays the current time.

4 Sleep Lights when the sleep timer is active. See “Setting the sleep timer” on page 10.

5 Alarm 1 Lights when Alarm 1 has been set. See “Setting the alarm time” on page 9.

6 AUX Lights when a connected audio device is selected as the audio source. See “Connecting an

audio device” on page 12.

7 FM Lights when the radio is selected as the audio source.

8 AM/PM “AM” lights after midnight and before noon. “PM” lights after noon and before midnight.

9 Snooze Lights when your radio is in snooze mode. See “Using the snooze feature” on page 10.

10 Battery Lights when no backup batteries are installed or when the backup battery charge is low.

11 Alarm 2 Lights when Alarm 2 has been set. See “Setting the alarm time” on page 9.

Volume Preset AUX FM

MHz

SLEEP SNOOZE

Buzzer

1Radio

Buzzer

2Radio

12:08

Insignia NS-CLOPP1 Digital Clock Radio with FM

www.insigniaproducts.com

Package contents

• Digital clock radio with FM

•AC/DCpoweradapter

•QuickSetupGuide

•User Guide

Setting up your radio

Installing backup batteries

The backup batteries provide power to backup the time setting when you

unplug the AC/DC power adapter.

To install batteries:

1Push the latch to release the battery compartment cover on the

bottom of your radio, then lift the cover off the battery compartment.

2Insert two AAA batteries (not included) into the battery compartment.

Make sure that the + and – symbols on the batteries align with the +

and – symbols inside the compartment.

Cautions

• Use only the size and type of batteries specified.

• Do not mix old and new batteries.

• Make sure that you follow the correct polarity as

indicated in the battery compartment.

• Do not try to recharge batteries not intended to be

recharged. They can overheat and rupture. (Follow the

battery manufacturer’s directions.)

• Do not throw batteries into a fire. Dispose of used

batteries as hazardous waste.

Note

If you unplug the AC/DC power adapter and the backup batteries

are dead or not installed, the time setting is lost.

AAA

Insignia NS-CLOPP1 Digital Clock Radio with FM

www.insigniaproducts.com

3Insert the tab on the battery compartment cover into the slot on the

battery compartment, then press the cover down until it clicks into

place.

Connecting the AC/DC power adapter

To connect the AC/DC power adapter:

1Plug the small connector on the power adapter into the DC IN jack on

the back of your radio.

2Plug the other connector on the power adapter into a power outlet.

Using your radio

Setting the time

To set the time:

1Press Sleep for about two seconds until the hour digits blink on

the LCD.

2Press or to increase the hour or press or to decrease the

hour.

3Press Sleep again. The minutes digits blink on the LCD.

4Press or to increase the minutes or press or to decrease

the minutes.

5Press Sleep again or wait 10 seconds to save the time setting and

exit time setting mode.

Note

If you unplug the AC/DC power adapter and the backup batteries

are dead or not installed, the time setting is lost.

Notes

“AM” or “PM” appears on the LCD to the right of the time. When

you set the time, make sure that the “AM” or “PM” displays

correctly.

Insignia NS-CLOPP1 Digital Clock Radio with FM

www.insigniaproducts.com

Setting the alarm sound

Your radio has two alarms and can play the buzzer or the radio for the

alarm sound. You can use the same alarm sound for both alarms or set one

alarm to use the buzzer and the other alarm to use the radio.

To set the alarm sound:

1Press (Alarm 1) or (Alarm 2). The or icon blinks on

the LCD.

2To use the radio as the alarm sound, press (Alarm 1) or (Alarm 2)

once. The or icon blinks on the LCD and the alarm sound

is set to the radio. Wait three seconds to save the setting and exit alarm

sound setting mode. When the alarm turns on, the last tuned radio

station plays.

To use the buzzer as the alarm sound, press (Alarm 1) or

(Alarm 2) twice. The or icon blinks on the LCD and

the alarm sound is set to the buzzer. Wait three seconds to save the

setting and exit alarm sound setting mode.

3To completely turn off the alarm, press (Alarm 1) or (Alarm 2)

repeatedly until the or icon disappears from the LCD.

Setting the alarm time

Your radio has two alarms that you can set for different times.

To set the alarm time:

1Press and hold (Alarm 1) or (Alarm 2) for about two seconds

until the hour digits blink on the LCD.

2Press or to increase the hour or press or to decrease the

hour.

3Press (Alarm 1) or (Alarm 2) again. The minutes digits blink on

the LCD.

Note

Button presses must be within three seconds of each other. If

you do not press a button within three seconds, your radio exits

alarm setting mode.

Notes

• “AM” or “PM” appears on the LCD to the right of the time.

When you set the time, make sure that the “AM” or “PM”

displays correctly.

• Button presses must be within 10 seconds of each other.

If you do not press a button within 10 seconds, your radio

exits alarm setting mode.

1212

1Radio 2Radio

Buzzer

Insignia NS-CLOPP1 Digital Clock Radio with FM

www.insigniaproducts.com

4Press or to increase the minutes or press or to decrease

the minutes.

5Press (Alarm 1) or (Alarm 2) again. The Volume icon appears on

the LCD and the volume digits blink.

6Press or to increase the alarm volume or press or to

decrease the alarm volume. The alarm volume range is from 1 to 15

with 15 being the loudest setting. The default setting is 10.

7Press (Alarm 1) or (Alarm 2) again to save the time setting and

exit alarm setting mode.

Turning off the alarm

To turn off the alarm:

• Press any button except .

Using the snooze feature

To use the snooze feature:

• When the alarm sounds, press . The alarm turns off for 10

minutes and SNOOZE appears on the LCD.

Setting the sleep timer

You can specify the amount of time your radio waits before it turns off

automatically.

To set the sleep timer:

• Press Sleep repeatedly to select the amount of time you want

your radio to wait before it turns off automatically. You can select 15,

30, 45, 60, or 90 minutes. The time you select and the SLEEP icon

appear on the LCD.

• To turn off the sleep timer, press Sleep repeatedly until 00

appears and the SLEEP icon disappears.

Note

You can press a total of six times. If you press it a

seventh time, the alarm turns off.

SNOOZE / DIMMER

Otros manuales para NS-CLOPP1

Tabla de contenidos

Otros manuales de Radio reloj de Insignia

Insignia

Insignia NS-CLBT01 Manual de instalación y operación

Insignia

Insignia Insignia Narrator NS-CLHD01 Manual de usuario

Insignia

Insignia NS-CLOPP2 Manual de usuario

Insignia

Insignia NS-CL02 Manual de usuario

Insignia

Insignia NS-CLBT02 Manual de usuario

Insignia

Insignia NS-PRCL01 Manual de usuario

Insignia

Insignia NS-PRCL01 Manual de usuario

Insignia

Insignia NS-CLBT01-W Manual de usuario

Insignia

Insignia Insignia Narrator NS-CLHD01 Guía de inicio rápido

Insignia

Insignia Insignia Narrator NS-CLHD01 Manual de instalación y operación

Insignia

Insignia NS-C2112 Manual de usuario

Insignia

Insignia NS-CLIP02 Manual de usuario

Insignia

Insignia NS-C2114 Manual de usuario

Insignia

Insignia Insignia Narrator NS-CLHD01 Manual de usuario

Insignia

Insignia NS-CLWL01 Manual de usuario

Insignia

Insignia NS-PRCL01 Manual de usuario

Insignia

Insignia NS-CLIP02 Manual de lista de piezas

Insignia

Insignia NS-CL3B01 Manual de instalación y operación

Insignia

Insignia NS-CLVR01 Manual de usuario

Insignia

Insignia NS-CLWL01 Manual de usuario

Insignia

Insignia NS-CL3B01 Manual de lista de piezas

Insignia

Insignia NS-CLBT01-W Guía de inicio rápido

Insignia

Insignia NS-CLWL01 Manual de usuario

Insignia

Insignia NS-CLW01 Guía de inicio rápido

Manuales populares de Radio reloj de otras marcas

Denver

Denver CRQ-105 Manual de usuario

Audiovox

Audiovox CE90 Manual de usuario

Sony

Sony Dream Machine ICF-C763L Manual de usuario

Sanyo

Sanyo DMP-P6 Manual de usuario

RCA

RCA RPC100 Manual de usuario

Yamaha

Yamaha ISX-80 Manual de usuario

Pyle

Pyle PLMR20W Manual de usuario

Blaupunkt

Blaupunkt CR7BK Manual de usuario

Philips

Philips AJ3180 Manual de usuario

HoMedics

HoMedics SS-5500-2EU Manual de usuario

RCA

RCA RC66i Manual de usuario

Versaudio

Versaudio Vers Manual de usuario

SOUNDMASTER

SOUNDMASTER UR8100 Manual de usuario

Audiovox

Audiovox CE90 Manual de usuario

Jensen Audio

Jensen Audio JCR-222 - AM/FM Projection Alarm Clock Radio Manual de usuario

Roberts

Roberts ChronoDAB Manual de usuario

AEG

AEG MRC 4132 BT Manual de usuario

Tokai

Tokai TC-155 Manual de usuario
