Innovative 8521 Manual de usuario

800.524.2744 InnovativeWorkspaces.com

Model 8521

Installation Instructions

© 2019 Innovative Office Products, LLC P514443 REV B

CAUTION

Mechanism can rise quickly with no equipment in place.

User equipment must be properly installed, prior to height

adjustment. Failure to do so may result in personal injury

and/or property damage.

PAGE 1 OF 8

800.524.2744 InnovativeWorkspaces.com

Model 8521

Parts List

A Monitor Tilter 1x

414291

B M6 x 12mm Screw 1x

713217

C 10-32 x 3/8" PhPHS (4-pack) 1x

702281

D 75/100 mm VESA Adapter 1x

105587

E M4 x 12 mm PhPHS (4-pack) 1x

702096

F 7/32" Allen Wrench 1x

7 0 112 7

PAGE 2 OF 8

800.524.2744 InnovativeWorkspaces.com

1

2x

1/8 "

i

Please refer to your original

product instructions for additional

adjustments that may be needed

after this assembly is complete.

All product instructions are

available for download at:

InnovativeWorkspaces.com

INSTRUCTIONS

PAGE 3 OF 8

800.524.2744 InnovativeWorkspaces.com

2

PAGE 4 OF 8

800.524.2744 InnovativeWorkspaces.com

3

3mm

PAGE 5 OF 8

800.524.2744 InnovativeWorkspaces.com

4 5

A

B

BC

C

D

PAGE 6 OF 8

800.524.2744 InnovativeWorkspaces.com

6

E

E

PAGE 7 OF 8

800.524.2744 InnovativeWorkspaces.com

7

7/32 "

8

F

PAGE 8 OF 8
