Infineon XMC4000 series Manual de usuario

Microcontroller

Hexagon Application Kit

For XMC4000 Family

Board User‘s Manual

Revision 1.0, 2013-02-20

CPU_45B-V1

CPU Board XMC4500 SDRAM

Edition 2013-02-20

Published by

Infineon Technologies AG

81726 Munich, Germany

Legal Disclaimer

The information given in this document shall in no event be regarded as a guarantee of conditions or

characteristics. With respect to any examples or hints given herein, any typical values stated herein and/or any

information regarding the application of the device, Infineon Technologies hereby disclaims any and all

warranties and liabilities of any kind, including without limitation, warranties of non-infringement of intellectual

property rights of any third party.

Information

For further information on technology, delivery terms and conditions and prices, please contact the nearest

Infineon Technologies Office (www.infineon.com).

Warnings

Due to technical requirements, components may contain dangerous substances. For information on the types in

question, please contact the nearest Infineon Technologies Office.

Infineon Technologies components may be used in life-support devices or systems only with the express written

approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the

failure of that life-support device or system or to affect the safety or effectiveness of that device or system. Life

support devices or systems are intended to be implanted in the human body or to support and/or maintain and

sustain and/or protect human life. If they fail, it is reasonable to assume that the health of the user or other

persons may be endangered.

CPU_45B-V1

CPU Board XMC4500 SDRAM

Template: IFX_Template_2011-02-24.dot

Revision History

Page or Item

Subjects (major changes since previous revision)

Revision 1.0

2013-02-20

Trademarks of Infineon Technologies AG

AURIX™, C166™, CanPAK™, CIPOS™, CIPURSE™, EconoPACK™, CoolMOS™, CoolSET™,

CORECONTROL™, CROSSAVE™, DAVE™, EasyPIM™, EconoBRIDGE™, EconoDUAL™, EconoPIM™,

EiceDRIVER™, eupec™, FCOS™, HITFET™, HybridPACK™, I²RF™, ISOFACE™, IsoPACK™, MIPAQ™,

ModSTACK™, my-d™, NovalithIC™, OptiMOS™, ORIGA™, PRIMARION™, PrimePACK™, PrimeSTACK™,

PRO-SIL™, PROFET™, RASIC™, ReverSave™, SatRIC™, SIEGET™, SINDRION™, SIPMOS™,

SmartLEWIS™, SOLID FLASH™, TEMPFET™, thinQ!™, TRENCHSTOP™, TriCore™.

Other Trademarks

Advance Design System™ (ADS) of Agilent Technologies, AMBA™, ARM™, MULTI-ICE™, KEIL™,

PRIMECELL™, REALVIEW™, THUMB™, µVision™ of ARM Limited, UK. AUTOSAR™ is licensed by

AUTOSAR development partnership. Bluetooth™ of Bluetooth SIG Inc. CAT-iq™ of DECT Forum.

COLOSSUS™, FirstGPS™ of Trimble Navigation Ltd. EMV™ of EMVCo, LLC (Visa Holdings Inc.). EPCOS™

of Epcos AG. FLEXGO™ of Microsoft Corporation. FlexRay™ is licensed by FlexRay Consortium.

HYPERTERMINAL™ of Hilgraeve Incorporated. IEC™ of Commission Electrotechnique Internationale. IrDA™

of Infrared Data Association Corporation. ISO™ of INTERNATIONAL ORGANIZATION FOR

STANDARDIZATION. MATLAB™ of MathWorks, Inc. MAXIM™ of Maxim Integrated Products, Inc.

MICROTEC™, NUCLEUS™ of Mentor Graphics Corporation. Mifare™ of NXP. MIPI™ of MIPI Alliance, Inc.

MIPS™ of MIPS Technologies, Inc., USA. muRata™ of MURATA MANUFACTURING CO., MICROWAVE

OFFICE™ (MWO) of Applied Wave Research Inc., OmniVision™ of OmniVision Technologies, Inc.

Openwave™ Openwave Systems Inc. RED HAT™ Red Hat, Inc. RFMD™ RF Micro Devices, Inc. SIRIUS™ of

Sirius Satellite Radio Inc. SOLARIS™ of Sun Microsystems, Inc. SPANSION™ of Spansion LLC Ltd.

Symbian™ of Symbian Software Limited. TAIYO YUDEN™ of Taiyo Yuden Co. TEAKLITE™ of CEVA, Inc.

TEKTRONIX™ of Tektronix Inc. TOKO™ of TOKO KABUSHIKI KAISHA TA. UNIX™ of X/Open Company

Limited. VERILOG™, PALLADIUM™ of Cadence Design Systems, Inc. VLYNQ™ of Texas Instruments

Incorporated. VXWORKS™, WIND RIVER™ of WIND RIVER SYSTEMS, INC. ZETEX™ of Diodes Zetex

Limited.

Last Trademarks Update 2011-02-24

CPU_45B-V1

CPU Board XMC4500 SDRAM

Table of Contents

Board User's Manual 4 Revision 1.0, 2013-02-20

Table of Contents

Introduction............................................................................................................................................................7

1Overview .............................................................................................................................................7

1.1 Key Features........................................................................................................................................7

1.2 Block Diagram......................................................................................................................................8

2Hardware Description........................................................................................................................9

2.1 Power Supply.......................................................................................................................................9

2.2 Reset..................................................................................................................................................12

2.3 Clock Generation................................................................................................................................13

2.4 Boot Option ........................................................................................................................................13

2.5 Debug Interface..................................................................................................................................14

2.5.1 On-board USB Debugger...................................................................................................................15

2.5.2 Cortex Debug Connector (10-pin)......................................................................................................16

2.5.3 Cortex Debug+ETM Connector (20-pin)............................................................................................17

2.6 Serial Flash Memory..........................................................................................................................19

2.7 SDRAM ..............................................................................................................................................20

2.8 USB....................................................................................................................................................20

2.9 RTC....................................................................................................................................................22

2.10 User LEDs and User Button...............................................................................................................23

2.11 Potentiometer.....................................................................................................................................23

2.12 Satellite Connectors...........................................................................................................................24

2.12.1 COM Connector .................................................................................................................................25

2.12.2 HMI Connector...................................................................................................................................26

2.12.3 ACT Satellite Connector.....................................................................................................................27

3Production Data................................................................................................................................27

3.1 Schematics.........................................................................................................................................27

3.2 Component Placement and Geometry...............................................................................................32

3.3 Bill of Material (BOM).........................................................................................................................33

CPU_45B-V1

CPU Board XMC4500 SDRAM

List of Figures

Board User's Manual 5 Revision 1.0, 2013-02-20

List of Figures

Figure 1 CPU_45B-V1 Board Block Diagram.....................................................................................................8

Figure 2 CPU Board XMC4500 SDRAM (CPU_45B-V1)...................................................................................9

Figure 3 Powering option..................................................................................................................................10

Figure 4 Block Diagram Of Power Supply........................................................................................................10

Figure 5 Reset Circuit.......................................................................................................................................12

Figure 6 Reset LED and Reset Button.............................................................................................................12

Figure 7 Clock Generation Circuit ....................................................................................................................13

Figure 8 Boot Options Switch...........................................................................................................................13

Figure 9 Installation of Serial Port Driver..........................................................................................................15

Figure 10 On-Board USB Debugger ..................................................................................................................15

Figure 11 Cortex Debug Connector (10-pin)......................................................................................................16

Figure 12 Cortex Debug Connector (10-pin) Layout..........................................................................................17

Figure 13 Cortex Debug+ETM Connector (20-pin)............................................................................................17

Figure 14 Cortex Debug+ETM Connector (20-pin) Layout ................................................................................18

Figure 15 Quad SPI Flash Interface...................................................................................................................19

Figure 16 SDRAM Interface ...............................................................................................................................20

Figure 17 USB Connector ..................................................................................................................................20

Figure 18 USB power generation - Host/OTG mode .........................................................................................21

Figure 19 Battery Holder for Coin Cells..............................................................................................................22

Figure 20 XMC4500 Power Domains and Real Time Clock ..............................................................................22

Figure 21 User LEDs and User Buttons.............................................................................................................23

Figure 22 Satellite Connectors...........................................................................................................................24

Figure 23 Satellite Connector Type COM ..........................................................................................................25

Figure 24 Satellite Connector Type HMI ............................................................................................................26

Figure 25 Satellite Connector Type ACT............................................................................................................27

Figure 26 Satellite Connectors, USB-OTG.........................................................................................................28

Figure 27 XMC4500 ...........................................................................................................................................29

Figure 28 Power, Debug Connector, Reset, SDRAM ........................................................................................30

Figure 29 On-board Debugger ...........................................................................................................................31

Figure 30 Component Placement and Geometry...............................................................................................32

CPU_45B-V1

CPU Board XMC4500 SDRAM

List of Figures

Board User's Manual 6 Revision 1.0, 2013-02-20

List of Tables

Table 1 Power status LEDs.............................................................................................................................10

Table 2 Power Measurement..........................................................................................................................11

Table 3 Boot Options Settings ........................................................................................................................13

Table 4 Cortex Debug Connector (10 Pin)......................................................................................................16

Table 5 Cortex Debug+ETM Connector (20 Pin)............................................................................................18

Table 6 Quad SPI Signals...............................................................................................................................19

Table 7 USB micro AB connector Pinout........................................................................................................21

Table 8 User LEDs..........................................................................................................................................23

Table 9 User Buttons.......................................................................................................................................23

Table 10 Potentiometer.....................................................................................................................................23

Table 11 BOM of CPU_45B-V1 Board..............................................................................................................33

CPU_45B-V1

CPU Board XMC4500 SDRAM

Overview

Board User's Manual 7 Revision 1.0, 2013-02-20

Introduction

This document describes the features and hardware details of the CPU board “CPU Board XMC4500 SDRAM”

(CPU_45B-V1) designed to work with Infineon’s XMC4500 Microcontroller. This board is part of Infineon’s

Hexagon Application Kits. Please visit www.infineon.com/xmc-dev for more information about the Hexagon

Application Kit family.

1 Overview

The CPU board CPU_45B-V1 houses the XMC4500 Microcontroller and three satellite connectors (HMI, COM,

ACT) for application expansion. The board along with satellite cards (e.g. HMI_OLED-V1, COM_ETH-V1,

AUT_ISO-V1 boards) demonstrates the capabilities of XMC4500.

The main use case of this board is to demonstrate the external bus unit (EBU) of the XMC4500 device including

the tool chain. For this purpose a 64 Mbit SDRAM is connected to the XMC4500 and for external bus extension

an asynchronous 16-bit wide bus interface is available at the COM satellite connector.

Attention: This board (CPU_45B) has not been designed to work with the “General Purpose Motor Drive

Card” (MOT_GPDLV). For this purpose please use the CPU boards CPU_45A, CPU_44A or

CPU_42A.

The focus is safe operation under evaluation conditions. The board is neither cost nor size optimized and does

not serve as a reference design.

1.1 Key Features

The CPU_45B-V1 board is equipped with the following features

XMC4500 (ARM®Cortex™-M4-based) Microcontroller, 1 MByte Flash, 160 kByte SRAM, LFBGA-144

8 MByte On-board SDRAM, 1 Mbit x 16 bits x 4 banks

Connection to satellite cards via satellite connectors COM, HMI and ACT

USB OTG Host/Device support via micro USB connector

Debug options

−On-board Debugger via the Debug USB connector

−Cortex Debug connector 10-pin (0.05”)

−Cortex Debug+ETM connector 20-pin (0.05”)

Reset push button

32 MBit quad SPI flash memory

Boot option switch

PowerScale Connector: Ready for power consumption analysis

Two User Buttons connected to P5.10 and P0.10

7 LED’s

3 Power indicating LED’s

2 User LEDs (P5.2 and P1.1)

1 RESET LED

1 Debug LED

Potentiometer, connected to analog input P14.1

Power supply

−Via Debug USB connector

−Via Micro-USB connector in USB device mode

−Via satellite connector pins (COM/ACT satellites cards can supply power to CPU board)

−RTC backup battery

CPU_45B-V1

CPU Board XMC4500 SDRAM

Overview

Board User's Manual 8 Revision 1.0, 2013-02-20

1.2 Block Diagram

Figure 1 shows the functional block diagram of the CPU_45B-V1 board. For more information about the power

supply please refer to chapter 2.1.

The CPU board has got the following building blocks:

- 3 Satellite Connectors (COM, HMI ACT)

- 2 User LEDs connected to GPIOs P5.2 and P1.1

- 2 User Buttons connected to GPIOs P5.10 and P0.10.

- Quad SPI flash memory (32 Mbit)

- Synchronous Dynamic RAM (SDRAM, 64Mbit)

- 2 Cortex Debug Connectors

- Variable resistor (POTI) connected to GPIO P14.1

- USB On-The-Go Connector (Micro-USB)

- On-board Debugger via USB connector (Micro-USB)

Figure 1 CPU_45B-V1 Board Block Diagram

Block_Diag.emf

XMC4500

LFBGA144

2xISOFACE

QSPI

I2C

CAN CAN1

CAPCOM

ENCODER

DSMOD

SENSOR

OPAMP

TOUCH

U2C1

CPU Board XMC4500

SDRAM

CPU_45B-V1

U1C1

2xCS

ETH ETHRMII

USB

OTG

USB CCU

4/8

POSIF

DSD

DAC

ADC

GPIO reset

QSPI

RS485

CAN

I2C_IOEX

Debug+ETM

20pin

I2C_IOEX

ACT

GPIO

CAN

UART

I2S

SDCARD

GPIO cmd

OLED

I2C_IOEX

JTAG

HEADSET

U0C0

CAN1

BSL

POTI

SPI

I2C

GPIO

2xLED

2xButton

U2C0

2xCS

SPI

GPIO

SPI

HMI

SWD

SWV

Debug

10pin

SWD

SWV

Debug

USB

On-board

Debugger

XMC4200

EBU

EXTBUS

SDRAM

COM

EBU

CPU_45B-V1

CPU Board XMC4500 SDRAM

Hardware Description

Board User's Manual 9 Revision 1.0, 2013-02-20

2 Hardware Description

The following sections give a detailed description of the hardware and how it can be used.

Figure 2 CPU Board XMC4500 SDRAM (CPU_45B-V1)

2.1 Power Supply

The CPU_45B-V1 board can be powered via either of the USB plugs (5 V); however, there is a current limit that

can be drawn from the host PC through USB. If the CPU_45B-V1 board is used to drive other satellite cards

(e.g. AUT_ISO-V1 or MOT_GPDLV-V2) and the total current required exceeds 500 mA, then the board needs to

be powered by a satellite card, which supports external power supply like e.g. AUT_ISO-V1, MOT_GPDLV-V2,

COM_ETH-V1.

The typical current drawn by the CPU board without any satellite cards connected is about 220 mA (@5V).

For powering the board through an USB interface, connect the USB cable provided with the kit to either of the

Micro-USB connector on board as shown in Figure 3.

Board_Interfaces.emf

Debug

Connectors

Boot

Option

Switch

COM

Satellite

ConnEctor

qSPI

Flash

USB OTG

Connector Debug USB

Connector

ACT

Satellite

Connector

Power

indicating

LEDs

Reset

Circuit

Battery

Holder

HMI Satellite

Connector

Potentiometer

User LEDs

and User

Buttons On-board

Debugger

SDRAM

Debug

Connectors

CPU_45B-V1

CPU Board XMC4500 SDRAM

Hardware Description

Board User's Manual 10 Revision 1.0, 2013-02-20

Figure 3 Powering option

To indicate the power status of CPU_45B-V1 board three power indicating LED’s are provided on board (see

Figure 3). The LED will be “ON” when the corresponding power rail is powered.

Table 1 Power status LEDs

LED Reference

Power Rail

Voltage

Note

V401

VDD5

5 V

Must always be “ON”

V402

VDD5USB

5 V

“ON” if powered by USB OTG connector X203

“OFF” in all other supply cases

V403

VDD3.3

3.3 V

Must always be “ON”

Figure 4 Block Diagram Of Power Supply

Power.emf

USB OTG Debug USB

Power

indicating

LEDs

IFX1763

3.3V Linear

Voltage

Regulator PowerScale

Probe

CPU Board XMC4500 SDRAM

CPU_45B-V1

ACT Sat.

Connector

COM Sat.

Connector

HMI Sat.

Connector

Debug

USB

VDD5USB Lin. Voltage

Regulator

IFX1763 VDDP

U200 U401 JP300 U300

Power

LED

HIB_IO_1

P0.1

VDD5 VDD5 VBAT

XMC4400

LFBGA144

BATTERY

VDD3.3 On Board Devices

VDD3.3

Power_Block.emf

USB

OTG Power

LED Power

LED

VDD5USB +5V VDD5 +5V VDD3.3 +3.3V

Otros manuales para XMC4000 series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Microcontrolador de Infineon

Infineon

Infineon PSoC 63 Manual de usuario

Infineon

Infineon XC886CLM Manual de usuario

Infineon

Infineon PG-TO252 DPAK Manual de usuario

Infineon

Infineon TriBoard TC1784 Manual de usuario

Infineon

Infineon XMC4000 series Guía de aplicación

Infineon

Infineon XMC1000 Manual de usuario

Infineon

Infineon TLE984 QX Series Manual de usuario

Infineon

Infineon MOTIX TLE985xQX Manual de usuario

Infineon

Infineon XMC7000 Series Guía

Infineon

Infineon XC800 AP08113 Instrucciones de instalación y funcionamiento

Infineon

Infineon XMC1100 Manual de usuario

Infineon

Infineon XC800 Series Manual de usuario

Infineon

Infineon XMC4000 series Manual de usuario

Infineon

Infineon PSoC 6 Manual de usuario

Infineon

Infineon A2B Manual de usuario

Infineon

Infineon High Side Switch Shield Manual de usuario

Infineon

Infineon C513AO Manual de usuario

Infineon

Infineon XMC4700 Manual de usuario

Infineon

Infineon EVAL-M3-302FTOBO1 Manual de usuario

Infineon

Infineon iMOTION2go Manual de usuario

Infineon

Infineon PSoC 4000 Series Manual del producto

Infineon

Infineon Traveo II Manual de usuario

Infineon

Infineon XC2000 Easy Kit Manual de usuario

Infineon

Infineon AIROC CYW20829 Manual de usuario

Manuales populares de Microcontrolador de otras marcas

AMS

AMS AS7261 Demo Kit Manual de usuario

Novatek

Novatek NT6861 Manual de usuario

Espressif Systems

Espressif Systems ESP8266 SDK Guía de configuración

Nuvoton

Nuvoton ISD61S00 ChipCorder Guía

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manual de usuario

Texas Instruments

Texas Instruments Chipcon CC2420DK Manual de usuario

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manual de usuario

NEC

NEC 78GK0S/K 1+ Series Instrucciones de instalación y funcionamiento

Mikroe

Mikroe SEMITECH N-PLC Click Instrucciones de instalación y funcionamiento

Intel

Intel Agilex Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manual de usuario

Texas Instruments

Texas Instruments TMS320F2837 D Series Manual de usuario

CYPRES

CYPRES CY14NVSRAMKIT-001 Manual de usuario

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manual de usuario

Espressif Systems

Espressif Systems ESP8266EX Instrucciones de funcionamiento

Abov

Abov AC33M8128L Manual de usuario

Laird

Laird BL654PA Manual de usuario
