iKey BT-870-TP-SLIM Manual de usuario
Backlight Button
Note:TheBT-870-TP-SLIM
ships from iKey with the internal
battery fully charged and
ready to use out of the box.
BT-870-TP-SLIM
Operation Guide
www.iKey.com • 512.837.0283
Pairing Instructions
iKey’s BT-870-TP-SLIM unit is compatible
with any Windows or Android Operating
System device that has built in Bluetooth®
functionality.
-POWER ON: Press and hold the Power
Button for 3 seconds. Caps/Scroll/Num
Lock Indicators will flash twice and the
Power indicator will illuminate.
-POWER OFF: Press and hold the Power
Button for 3 second. All LED indicators will
turn off.
1. Power the keyboard ON.
2. Press and hold the Bluetooth Button until
the BT Link indicator begins to rapidly flash.
The BT-870-TP-SLIM is now is search mode.
3. Follow the Bluetooth pairing instructions
provided by your host computer.
4. The BT Link will become solid once a
connection is made and will turn off after 30
seconds.
NOTE: A slow flashing BT Link indicates the
keyboard is attempting to re-pair to the last
connected Bluetooth host computer.
Charging Instructions
•To charge the keyboard, insert the provided
Micro USB charging cable into the back of the
keyboard and plug the other end of the cable
into a powered USB port on any computer.
The Charging LED indicator will illuminate
orange when charging and will turn off when
fully charged. In a fully discharged state,
the battery takes 5-6 hours to completely
recharge.
•With average usage of the keyboard, the
anticipated battery life is three to four weeks.
Sleep Mode
•The BT-870-TP-SLIM will go into sleep mode af-
ter 30 minutes of inactivity. To wake simply
press any key.
•To wake the unit from sleep mode press
any key. BT-870-TP-SLIM will
automatically re-pair to the last connected
Bluetooth host computer.
©2017 iKey, Ltd. All rights reserved.
Power Button
Bluetooth®
Button
BT-870-TP-SLIM
Additional Features
www.iKey.com • 512.837.0283
©2017 iKey, Ltd. All rights reserved.
Additional Features
•Switching to wired USB: In the event the Bluetooth connection is
disrupted by interference, the BT-870-TP-SLIM can switch to being a
wired USB keyboard by connecting the keyboard to the computer via the
supplied MicroUSB cable. When connected via USB the keyboard will
begin to charge and communicate over USB.
•Switching from USB to Bluetooth: Once the MicroUSB cable is
removed, the keyboard will attempt to re-pair to the last connected
Bluetooth host computer.
NOTE: Plugging the keyboard in via USB will not establish a Bluetooth
connection. The Bluetooth menu on the host computer must be used to
establish a Bluetooth connection.
•10-Key: A 10-key number pad is imposed on the right hand side of
the keyboard, indicated by the yellow secondary legend. To enable or
disable these secondary keys press “Num Lock”.
•Clean Mode: In order to facilitate easy cleaning, a Clean Mode can be
enabled allowing the user to clean the keyboard without powering down
or disconnecting it. To enter and exit Clean Mode press <FN>+<C>, the
Scroll Lock indicator will begin to flash to indicate mode is active.
BT-870-TP-SLIM
Charging Port
BT-870-TP-SLIM
Charging Port
BT-870-TP-SLIM
FCC Information
www.iKey.com • 512.837.0283
Notice
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to
the antenna or the device is permitted. Any change to the antenna or the device could result in the
device exceeding the RF exposure requirements and void user’s authority to operate the device.
©2017 iKey, Ltd. All rights reserved.
FCC Information
FCC INFORMATION The Federal Communication Commission Radio Frequency Interference
Statement includes the following paragraph:
The equipment has been tested and found to comply with the limits for a Class B Digital Device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instruction,
may cause harmful interference to radio communication. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
1. Reorient or relocate the recieving antenna.
2. Increase the seperation between the equipment and reciever.
3. Connect the equipment into an outlet on a circuit different from that to which the reciever is
connected.
4. Consult the dealer or an experienced radio/TV technician for help.
***The User should not modify or change this equipment without written approval from iKey, Ltd.
Modification could void authority to use this equipment.***
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 0.5 centimeters between the radiator and
your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The
antennas used for this transmitter must be installed to provide a separation distance of at least 0.5 cm from all
persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
