Operating instructions

AS-i CompactModule M8

AC2490

80272461/00 03/2018

UK

UK

2

1 Preliminary note

Technical data, approvals, accessories and further information at

www.ifm.com.

2 Safety instructions

• Read this document before setting up the product and keep it during the entire

service life.

• The product must be suitable for the corresponding applications and

environmental conditions without any restrictions.

• Only use the product for its intended purpose (→ Functions and features).

• If the operating instructions or the technical data are not adhered to, personal

injury and/or damage to property may occur.

• The manufacturer assumes no liability or warranty for any consequences

caused by tampering with the product or incorrect use by the operator.

• Installation, electrical connection, set-up, operation and maintenance of the

product must be carried out by qualified personnel authorised by the machine

operator.

• The plant operator is responsible for the safety of the plant in which the device

is installed.

• If the device is not used as intended by the manufacturer, the protection

supported by the device may be impaired.

• Protect units and cables against damage.

2.1 Symbols used

► Instructions

→ Cross-reference

Important note

Non-compliance may result in malfunction or interference.

Information

Supplementary note.

3

UK

3 Functions and features

• Maximum number of modules per master: 62

• AS-Interface version 3.0, downward compatible

• 4 inputs / 4 outputs / AS-i profile S-7.A.7 / extended addressing mode: yes

• The unit can only be operated in conjunction with a version 3.0 master (master

profile M4).

4 Installation

► Disconnect the system from power before installation.

► For installation choose a flat mounting surface.

The entire bottom of the module must lie flat on the mounting surface.

► Fix the module onto the mounting surface using M4 screws and washers.

5 Electrical connection

► Disconnect the installation from power and connect the unit.

To ensure the protection rating:

► Connect the plugs of the sensors to the M8 sockets.

► Tighten firmly, recommended tightening torque 0.3...0.5 Nm.

► Cover the sockets that are not in use with the enclosed protective caps.

5.1 Pin connection

Socket M12

1: AS-i +

2: AUX -

3: AS-i -

4: AUX +

4

12

3

Input M8

1: sensor supply +

3: sensor supply -

4: data input

Output M8

3: external voltage E-

4: switching output

4

Parameter bit Designation Description

P1 Periphery fault 1 peripheral fault indication active

0 peripheral fault indication not active

6 Addressing

► Addressing the unit via the M12 connector; the address is set to 0 at the

factory.

Addressing unit AC1154

Wiring of the addressing socket

51

34

2

1: SFC-i + / 2: TTL → / 3: SFC-i -

4: TTL ← / 5: + 5 V

7 Operating and display elements

M12x1

M8x1

LED

PWR ⁄ FAULT

LED

AUX

LEDs -x

LEDs O-x

8 Operation

LED I-x / O-x yellow: input / output switched

LED PWR green: AS-i voltage supply OK

LED AUX green: External voltage supply (AUX) o.k.

LED FAULT red is lit: AS-i communication error, slave does not participate

in the "normal" exchange of data, e.g. slave address

0.

LED FAULT red flashes: Periphery fault, e.g. sensor supply overloaded or

shorted, is signalled to the AS-i master

(version 2.1 or higher).
