IFM Electronic AS interface AC506S Manual de usuario

Original operating instructions

Safe AS-i module

AC506S

80226206/00 04/2015

Contents

1 Preliminary note��3

1�1 Explanation of symbols��3

2 Safety instructions ��4

2�1 Safety-related requirements regarding the application��5

3 Items supplied��5

4 Functions and features ��5

5 Function and electrical connection ��6

6 Installation��7

7 Operating and display elements ��13

8 Electrical connection��13

8�1 Mechanical contacts ��14

8�2 Electronic contacts ��14

9 Addressing��15

10 Operation��16

10�1 Data bits ��17

10�2 Parameters ��18

10�3 Response times��19

11 Scale drawing ��19

12 Technical data��20

12�1 Safety classification ��21

13 Troubleshooting ��21

14 Maintenance, repair and disposal��22

15 Terms and abbreviations��22

16 Standards ��22

16�1 Approvals / certificates��23

1 Preliminary note

The instructions are part of the unit� They are intended for authorised persons

according to the EMC, Low Voltage and Machinery Directives and safety

regulations�

The instructions contain information about the correct handling of the product�

Read the instructions before use to familiarise yourself with operating conditions,

installation and operation�

Adhere to the safety instructions�

1.1 Explanation of symbols

►

Request for action

LED on

LED off

LED flashes

LED flashes quickly



Important note

WARNING Warning of dangers which may lead to death or serious

irreversible injuries�

2 Safety instructions

• Follow the operating instructions�

• In case of non-observance of notes or standards, specially when tampering

with and/or modifying the unit, any liability and warranty is excluded�

• The unit must be installed, connected and put into operation by a qualified

electrician trained in safety technology�

• The applicable technical standards for the corresponding application must be

complied with�

• For installation the requirements according to EN 60204 must be observed�

• In case of malfunction of the unit please contact the manufacturer� Tampering

with the unit is not allowed�

• Disconnect the unit externally before handling it� Also disconnect any

independently supplied relay load circuits�

• After installation of the system perform a complete function check�

• Onlyusetheunitunderthespecifiedoperatingconditions(→chapter12

Technical data)� In case of special operating conditions please contact the

manufacturer�

• In case of any questions please contact the safety authorities in your own

country�

WARNING

In case of improper handling of the product, the safety and physical

integrity of persons and machinery cannot be guaranteed.

Death or serious irreversible injuries may result�

►Note all remarks on installation and handling given in these instructions�

►The device must only be used under the specified operating conditions and in

accordance with use as prescribed�

2.1 Safety-related requirements regarding the application

It must be ensured that the safety requirements of the respective application

correspond to the requirements stated in these instructions�

Observe the following requirements:

►Adhere to EN 1088 for interlocking devices associated with guards�

► Adheretothespecifiedoperatingconditions(→chapter12Technicaldata).

Use of the unit in the vicinity of chemical and biological media as well as

ionising radiation is not permitted�

►In case of faults within the unit which result in the defined safe state: take

measures to maintain the safe state when the complete control system

continues to be operated�

►Replace damaged units�

3 Items supplied

1 safe AS-i module AC506S,

1 operating instructions AC506S�

If one of the above-mentioned components is missing or damaged, please contact

one of the ifm branch offices�

4 Functions and features

The safe AS-i module detects safety-related switching states of 1-channel

mechanical and electronic contacts, e�g� e-stops, position switches, door contacts,

etc� For this purpose, a code table is transferred via the AS-i system with 8 x 4 bits

which is evaluated by the AS-i safety monitor (e�g� AC001S �� AC004S, AC031S,

AC032S, AC041S)�

The safety function of the unit is achieved by the normally closed operation (input

disconnected = safe state)�

The unit can be used in applications up to Performance Level d, category 3 to EN

ISO 13849-1 and SIL 2CL to EN 62061�



Depending on the safety components used the complete safety system can

also be classified for a lower Performance Level PL or Safety Integrity Level

SILCL!

5 Function and electrical connection

Please also refer to all information in the description of the configuration software

(e�g� E7040S) and the operating instructions of the safety monitor� The above

documents provide all required instructions concerning installation, configuration,

operation and maintenance of the AS-i Safety at Work system�

Information on the parameterizable safety functions of the safe AS-i module can

be found in the chapter "Monitoring devices" of the configuration software manual�



The products described here are designed to be components of a safety-

oriented machine or control system� A complete safety-related system

normally includes sensors, evaluation units, signalling components and

concepts for safe switch-off� It is the responsibility of each manufacturer

of a machine or installation to ensure a correct functioning of the whole

system� The manufacturer of the safe AS-i module, his subsidiaries and

affiliates are not in a position to evaluate all of the characteristics of a given

machine or product not designed by him�

The manufacturer accepts no liability for any recommendation that may be implied

or stated herein�

The warranty contained in the contract of sale is the sole warranty� Any statements

contained herein do not create new warranties or modify existing ones�

The complete description of the configuration software, the operating instructions

of the AS-i safety monitor and the operating instructions of the safe AS-i module

must be taken into account!



Maintenance requirement

A minimum of one testing per year is compulsory by a demand on the safety

function� All connected individual switches must be checked�

6 Installation

►Carefully place the yellow flat cable (e�g� AC4000) in the lower part�

To maintain the indicated protection rating IP 67

►Close the unused sockets using a bridging plug (E7005S)*, tightening torque

0�6��0�8 Nm�

►Tighten all connected M12 connectors and protective caps, tightening torque

0�6��0�8 Nm�

►Close the addressing interface using the supplied protective cap, tightening

torque 0�6��0�8 Nm�

►Use the flat cable seal (E70413)* if the module is at the end of the cable line�

*to be ordered separately

WARNING

Non-observance of the installation instructions (e�g� non-observance of the

tightening torque) can lead to a loss of the protection rating and consequently to

the loss of the safety function�

Death or serious irreversible injuries may result�

►Note all remarks on installation and handling given in these instructions�

►The device must only be used under the specified operating conditions and in

accordance with use as prescribed�

1Alignment of the flat cable on

delivery

Carefully place the yellow AS-i flat

cable into the profile slot�

2Mount the upper part�

3Lock the unit�

With the supplied lower part the

flat cable can be aligned in three

directions�

For the requested direction place the

flat cable guide (1) accordingly�

ASettings at the lower part

Select the position 1, 2 or 3 depending

on the required flat cable alignment

(→)

A = factory setting
