IFM Electronic Efector 200 Manual de usuario

Operating instructions

Diffuse reflection sensor with

background suppression

OGH7xx

704076 / 03 06 / 2011

1 Preliminary note

1.1 Symbols used

►Instruction

> Reaction, result

[…] Designation of pushbuttons, buttons or indications

→Cross-reference

Important note

Non-compliance can result in malfunctions or interference.

2 Safety instructions

According to the cULus approval

Caution - Use of controls or adjustments or procedures other than those specified

herein may result in hazardous radiation exposure.

Visible laser light; CLASS 1 LASER PRODUCT.

IEC 60825-1 : 2007

Complies with 21 CFR 1040.10 except for deviations pursuant to Laser

Notice No. 50, dated June 2007.

Position of the product label Additional label

3 Functions and features

The diffuse reflection sensor detects objects and materials without contact and

indicates their presence by a switching signal.

Range 20 ... 200 mm (on white paper 200 x 200 mm, 90 % remission)

4 Installation



1: LED

2: programming buttons

►Align the diffuse reflection sensor to the object to be detected.

►Secure it to a bracket.

Note:

The objects to be detected are to move transver-

sally to the lens of the sensor.

►In case of other directions of movement

it should be tested before whether safe

switching is guaranteed.

5 Electrical connection

The unit must be connected by a qualified electrician.

►The national and international regulations for the installation of electri-

cal equipment must be adhered to.

►Voltage supply according to EN 50178.

►Disconnect power.

►Connect the unit as follows:

DC PNP











pin 1 = L+ ( 10...36 V DC )

pin 3 = L-

pin 4 = load (200 mA)

(pin 2 = not connected)

DC NPN











pin 1 = L+ ( 10...36 V DC )

pin 3 = L-

pin 4 = load (200 mA)

(pin 2 = not connected)

6 Settings

6.1 The sensor is to switch when the object is detected

►Position the object





►Press [OUT on] for 2 s.

> The sensitivity is set to the object.

> The LED flashes.

►Remove the object





►Press [OUT off].

> The sensitivity is set without object.

> The LED goes out. The programming is finished.

6.2 The sensor is not to switch when the object is detected

►Position the object (see figure 1) and press [OUT off] for 2 s.

►Remove the object (see figure 2) and press [OUT on].

The setting can also be carried out first without object and then with object.

6.3 Setting of the maximum sensitivity

►Align the sensor so that no light is reflected.

The sensor is to switch when the object is detected

►First press [OUT on], then [OUT off].

The sensor is to switch when the object is not detected

►First press [OUT off], then [OUT on].

6.4 Programming unsuccessful

> The LED flashes quickly, 8 Hz.

• Measured value difference too small

• Max. programming time (15 min.) exceeded.

6.5 Electronic lock

Lock or unlock the buttons

►Press [OUT on] and [OUT off] simultaneously for 10 s.

> Acknowledgement is indicated by a change of the LED status.

7 Operation

►Check whether the unit operates correctly.

> The LED lights when the switching output is switched.

8 Maintenance, repair and disposal

►Keep the front pane of the sensor free from soiling.

►For cleaning do not use any solvents or cleaning agents which could damage

the plastic material.

►Do not try to open the module enclosure. There are no user - serviceable

components inside.

Technical data and further information at

www.ifm.com→Selectyourcountry→Datasheetdirect:
