IEI Technology SPCIE-C2160 Manual de usuario

Full-size PICMG 1.3 CPU Card supports LGA1155 Intel®

Xeon® E3 and Intel® Core™ i3/Pentium®/Celeron® CPU

per Intel® C216, DDR3, VGA/DVI-D, Dual Intel® PCIe GbE,

SATA 6Gb/s, mini PCIe, Audio and RoHS

SPCIE-C2160

Quick Installation Guide

Version 1.03

Jun. 25, 2013

Package Contents

SPCIE-C2160 package includes the following items:

1 x SPCIE-C2160 Single Board Computer

1 x Dual RS-232 Cable (P/N:19800-000051-RS)

4 x SATA Cable (P/N:32000-0628000-RS)

1 x USB Cable (P/N: CB-USB02-RS)

1 x DVI and USB Kit (P/N:IO-KIT-001-R20)( DVI SKU only)

1 x Mini Jumper Pack

1 x Utility CD

1 x QIG (Quick Installation Guide)

Specifications

LGA1155 socket supports Intel® Xeon® E3/ Intel® Core™

i3/Pentium® /Celeron® processor

System Chipset: Intel® C216

BIOS: UEFI BIOS

System Memory: Two 240-pin 1333/1600 MHz Dual-Channel

DDR3 SDRAM ECC and non-ECC Unbuffered DIMM supported

(system max.16GB)

Graphic: VGA Integrated in Intel® C216

Display Output:

1 x VGA

1 x DVI-D (DVI SKU only)

(2 x 13-pin pin header via IO-KIT-001-R20 DVI-D/USB Module)

Ethernet:

Intel® 82574L PCIe controller

Intel® 82579 PHY with Intel® AMT 8.0 supported

Super I/O: Fintek F81866

I/O Interface:

4 x RS-232

1 x RS-422/485

10 x USB 2.0 (2 by Rear IO, 8 by pin header)

4 x SATA 3Gb/s

2 x SATA 6Gb/s

Raid 0/1/5/10 supported

1 x LPT

1 x 6-pin wafer for KB/MS

Digital I/O: 8-bit Digital I/O (4-bit input, 4-bit output)

Infrared Interface: 1 x 5-pin infrared connector

Audio: Supports by IEI AC-KIT-888HD Audio Kit

Front Audio:2 x 5-pin pin header

TPM: 2 x 10-pin pin header

SMBus: 1 x 4-pin wafer

I2C: 1 x 4-pin wafer

Infrared Interface: 1 x 5-pin pin header

Expansion:

PCIe signal and PCI signal via golden finger

1 x mini PCIe slot

Watchdog Timer: software Programmable support 1~255 sec.

System reset

FAN connector: 1 x 4-pin Smart FAN Connector

Power Supply: 5V/12V, AT/ATX support

Power Consumption: 3.3V@1.69A, 5V@3.45A, 12V@0.32A,

[email protected], 5VSb@0.17 (Intel® Core™ i7-2600 3.40GHz

CPU with 1333MHz DDR3 2GB x 2 memory)

Operation Temperature: -10 ~ 60°C( 14°F ~ 140°F)

Operation Humidity: 5% ~ 95%, non-condensing

Dimensions: 338mm X 126mm

Weight: 1.2Kg

Ordering Information

SPCIE-C2160-R10: Full-size PICMG 1.3 CPU Card supports LGA1155

Intel® Xeon® E3 and Intel® Core™ i3/Pentium®/Celeron® CPU per

Intel® C216, DDR3, VGA, Dual Intel® PCIe GbE, SATA 6Gb/s, mini PCIe,

Audio and RoHS

SPCIE-C2160-DVI-R10: Full-size PICMG 1.3 CPU Card supports

LGA1155 Intel® Xeon® E3 and Intel® Core™ i3/Pentium®/Celeron®

CPU per Intel® C216, DDR3, VGA/DVI-D, Dual Intel® PCIe GbE, SATA

6Gb/s, mini PCIe, Audio and RoHS

32200-074800-RS: RS-422/485 cable, 200mm

19800-000075-RS: KB/MS cable with Bracket

SAIDE-KIT01-R10: SATA to IDE/CF Converter board

IO-KIT-001-R20: DVI and four USB 1.1/2.0 translation daughter board

32102-000100-200-RS: SATA Power Cable

32200-015100-RS: LPT Cable

AC-KIT-892HD-R10: 7.1 channel HDAudio kit with RealtekALC892

support dual audio streams

CF-1156A-RS-R11: High-performance LGA1155/LGA1156 cooler kit, 1U

chassis compatible,73W

CF-1156B-RS: High-performance LGA1155/LGA1156 cooler kit, 95W

CF-1156C-RS: LGA1155/LGA1156 cooler kit, 1U chassis compatible,

45W

CF-1156D-RS: LGA1155/LGA1156 cooler kit, 1U chassis compatible,

65W

Jumpers setting and Connectors

Table of Jumpers

LABEL

FUNCTION

J_CMOS1

CMOS state setting

WOL_SEL1

WOL Enable setting

JATX_AT1

Power Mode Setting

Table of Connectors

LABEL

FUNCTION

VGA1

VGA 15-pin Female Connector

USB_C1

USB_C2

USB Port Connector

LAN1、LAN2

RJ45 LAN Connector

KB_MS1

Internal PS/2 KEYBOARD/MOUSE Connector

COM1

COM2

Internal Serial Port DB-9 Connectors

USB1

USB2

USB3

USB4

USB5

USB6

Internal USB Connectors

J_AUDIO1

Extend Audio Module Connector

SATA1

SATA2

SATA3

SATA4

SATA5

SATA6

Serial ATA Connectors

IR1

IrDA Infrared Interface Connector

LPT1

Internal LPT Connector

DVI1

DVI-D connector (DVI SKU only)

CPU_FAN1

Fan Connector

DIO1

Digital I/O Connector

F_PANEL1

PWR & RST Buttons and Indicators

CPU12V1

ATX-12V CPU Power Source

MINI-PCIE1

PCI-E Mini Card

I2C_1

I2C Connector

SMBUS_1

SMBUS Connector

TPM1

TPM Connector(80 port CONN)

COM 4

RS422/485 Serial Port

J_CMOS1 : Clear CMOS setting Jumper

J_CMOS1

DESCRIPTION

1-2

(Default)

Normal

2-3

Clear CMOS Data

JATX_AT1 : Power Mode Setting by ATX or AT

JATX_AT1

DESCRIPTION

1-2

(ON)

ATX Power Mode

1-2

(OFF)

AT Power Mode

VGA1 : 15-pin Female Connector

DESCRIPTION

RED

GREEN

BLUE

GND

VCC

GND

DDCDAT

HSYNC

VSYNC

DDCCLK

USB_C01,USB_C02

PIN NO.

DESCRIPTION

VCC

DATA-

DATA+

GROUND

LAN1、LAN2: RJ45 LAN Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

MDIA3-

MDIA1+

MDIA3+

MDIA2+-

MDIA2-

MDIA0-

MDIA1-

MDIA0+

MS/KB1: Internal 6-pin Keyboard Connector

DESCRIPTION

VCC(+5V)

Mouse Data

Mouse Clock

Keyboard Data

Keyboard Clock

Ground

USB1-USB6: Internal USB Connector

DESCRIPTION

VCC

GND

DATA-

DATA+

DATA-

GND

VCC

J_AUDIO1 : External Audio Module Connector

DESCRIPTION

ACZ_SYNC

ACZ_BITCLK

ACZ_SDOUT

ACZ_PCBEEP

ACZ_SDIN

ACZ_RST#

ACZ_VCC(+5V)

ACZ_GND

ACZ_12V

ACZ_GND

SATA1-SATA6 : Serial ATA Connector

DESCRIPTION

GND

RX-

TX+

RX+

TX-

GND

COM1,COM2, COM3,COM4

: Internal Serial Port Connector

DESCRIPTION

DCD#

DSR#

RXD

RTS#

TXD

CTS#

DTR#

RI#

GND

SATA1-SATA6 : Serial ATA Connector

DESCRIPTION

GND

RX-

TX+

RX+

TX-

GND

IR1: IrDA connector

PIN NO.

DESCRIPTION

VCC

IR-RX

GND

IR-TX

LPT1 : Parallel Port Connector

DESCRIPTION

STROBE#

AUTO FORM FEED #

DATA0

ERROR#

DATA1

INITIALIZE#

DATA2

PRINTER SELECT

LN#

DATA3

GND

DATA4

GND

DATA5

GND

DATA6

GND

DATA7

GND

ACKNOWLEDGE#

GND

BUSY

GND

PAPER EMPTY

GND

PRINTER SELECT

CPU12V1: ATX-12V CPU Power Input connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

GND

+12V

DVI Connector (DVI SKU only)

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

Data 2-

VCC

Data 2+

GND

Hot Plug Detect.

N/C

Data 0-

N/C

Data 0+

DDC Clock

GND

DDC Data

N/C

Data 1-

GND

Data 1+

Clock +

GND

Clock -

N/C

GND

N/C

F_PANEL1 : External Switches and Indicators panel

DESCRIPTION

Power LED

+5V

Speaker

N/C

GROUND

N/C

PWRBTN

PWRBTN+

Speaker

PWRBTN-

N/C

RESET

HDDLED

+5V

Reset-

HDLED-

GND

DIO1 : Digital Input / Output Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

Ground

VCC

Output 3

Output 2

Output 1

Output 0

Input 3

Input 2

Input 1

Input 0

CPU_FAN1 : CPU Fan Connector

PIN NO.

DESCRIPTION

Ground

+12V

Rotation Signal

Control

MINI-PCIE1 : PCI-E Mini Card Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

PCIE_WAKE#

VCC3

N/C

GND

N/C

1.5V

CLKREQ#

LFRAME#

GND

LAD3

CLK-

LAD2

CLK+

LAD1

GND

LAD0

PCIRST#

GND

LPC

VCC3

GND

PCIRST#

PERN2

3VDual

PERP2

GND

1.5V

GND

SMBCLK

PETN2

SMBDATA

PETP2

GND

USBD-

N/C

USBD+

N/C

GND

N/C

RF_LINK#

N/C

BLUELED#

N/C

1.5V

N/C

GND

N/C

VCC3

I2C_1

PIN NO.

DESCRIPTION

GND

PCH_GP38_PU

PCH_GP39_PU

+V5S

TPM1 Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

CLK

GND

FRAME#

RERST#

+5V

AD3

AD2

+3V

AD1

AD0

GND

SMB_CLK

SMB_DATA

SB3V

SERIRQ

GND

CLKRUN#

PM_SUS_STAT#

DRQ#

COM5 : Internal Serial Port Connector (RS422/485)

PIN NO.

DESCRIPTION

RXD485#

RXD485+

TXD485+

TXD485#

RS485 Pin define

RS422 Pin define

D-SUB 9PIN MALED-SUB 9PIN MALE

TX+(TXD485+)

RS422/485

TX-(TXD485#)

RX-(RXD485#)

RX+(RXD485+)

TX+(TXD485+)

TX-(TXD485#)

SMBUS Connector

PIN NO.

DESCRIPTION

GND

SMB_DATA

SMB_CLK

+V5S
