1

Mini-ITX SBC with AMD® Quad core 2.4GHz on-board SoC with

VGA/LVDS, Dual GbE, Dual PCIe Mini, USB 3.0,

SATA 6GB/s and Audio

KINO-SE-i2

Quick Installation Guide

Version 1.0

Dec 11, 2014.

Package List

KINO-SE-i2 package includes the following items:

1 x KINO-SE-i2 single board computer

2 x SATA with power output cable kit (P/N:32801-000100-300-RS)

1 x IO shielding (P/N:45014-0029C0-00-RS)

1 x QIG

1 x Utility CD

1 x One key recovery CD

©2006 Copyright by IEI Integration corp.

All rights reserved.

2

Specifications

SoC:

AMD® Embedded G-Series G-Series SoC

GX-424CC on-board Soc (2.4GHz, quad-core, 2MB cache,

TDP=25W)

GX-412HC on-board Soc (1.2GHz, quad-core, 2MB cache,

TDP=7W) (by request)

GX-212JC on-board Soc (1.2GHz, dual-core, 1MB cache,

TDP=6W) (by request)

GX-209HA on-board Soc (1.0GHz, dual-core, 1MB cache,

TDP=9W) (by request)

GX-411GA on-board Soc (1.0GHz, dual-core, 2MB cache,

TDP=15W) (by request)

Memory:

Two 204-pin 1600/1333 MHz single-channel DDR3/DDR3L

SO-DIMM supported (system max. 8GB)

BIOS: UEFI BIOS

Ethernet:

Dual PCIe GbE by Realtek RTL8111E with ASF 2.0 support

Graphics:

GPU frequency 300MHz (Radeon™ HD 8310E), DirectX ®

11.1, UVD4.2, HDMI™ 1.4a, DisplayPort 1.2

Display Output:

2 x HDMI (3840 x 2160)

1 x VGA (2048 x 1536)

Super IO: Fintek F81866

Digital I/O:8-bit digital I/O (4-bit input / 4-bit output)

Audio:

Realtek ALC892HD Audio codec

1 x SPDIF for digital audio

1x Line-out / Mic-In audio jack on rear IO

I/O Interface:

4 x RS-232 (1 by rear I/O, 3 by pin header)

3

1 x RS-422/485

1 x 6-pin wafer for PS/2 KB/MS

2 x SATA 6Gb/s with 5V/12V SATA power connector

2 x USB 3.0 (2 on rear I/O)

4 x USB 2.0 (2 by rear I/O, 2 by pin header)

1 x SD card

1 x IPMI slot

Watchdog Timer:

Software programmable support 1~255 sec. System reset

FAN:

1 x 4-pin system fan connector

Front Panel:

1 x Front Panel

(Power LED, HDD LED, Speaker, Power Button, Reset Button)

LAN LED:

2 x 2-pin (1x2) header

SMBus:

1 x 4-pin (1x4) wafer

I2C:

1 x 4-pin (1x4) wafer

Expansion:

1 x full-size PCIe Mini card co-lay mSATA support (SATA1 and

mSATA shares SATA signal)

1 x half-size PCIe Mini card slot

1 x PCIe x4 slot

Power supply:

12V DC input only (AT/ ATX support)

1 x 4-pin (2x2) internal power jack

Operation Temperature: -10°C ~ 60°C

Storage Temperature:-20°C ~ 85°C

Operation Humidity: 5% ~ 95%, non-condensing

Dimensions: 170mm x 170mm

4

Weight GW/NW: 600g / 250g

Ordering Information

Mini-ITX SBC supports AMD® 28nm Quad-Core GX-424CC 1.0GHz

(25W) on-board SoC with VGA/Dual GbE, Dual PCIe Mini, USB 3.0,

SATA 6GB/s, iRIS-2400, audio and RoHS

KINO-SE-i2-4241-R10:

Mini-ITX SBC supports AMD® 28nm Quad-Core GX-412HC 1.0GHz

(7W) on-board SoC with VGA/Dual GbE, Dual PCIe Mini, USB 3.0,

SATA 6GB/s, iRIS-2400, audio and RoHS

KINO-SE-i2-4121-R10:

Mini-ITX SBC supports AMD® 28nm Dual-Core GX-411GA 1.0GHz

(15W) on-board SoC with VGA/Dual GbE, Dual PCIe Mini, USB 3.0,

SATA 6GB/s, iRIS-2400, audio and RoHS

KINO-SE-i2-4111-R10:

Mini-ITX SBC supports AMD® 28nm Dual-Core GX-212JC 1.0GHz

(6W) on-board SoC with VGA/Dual GbE, Dual PCIe Mini, USB 3.0,

SATA 6GB/s, iRIS-2400, audio and RoHS

KINO-SE-i2-2121-R10:

Mini-ITX SBC supports AMD® 28nm Dual-Core GX-209HA 1.0GHz

(9W) on-board SoC with VGA/Dual GbE, Dual PCIe Mini, USB 3.0,

SATA 6GB/s, iRIS-2400, audio and RoHS

KINO-SE-i2-2091-R10:

iRIS-2400-R10:

DDR3 SO-DIMM socket interface

IPMI 2.0 adapter card with AST2400 BMC chip for

CB-USB02A-RS:

pitch USB connector;RoHS

Dual ports USB cable with bracket, with 2.0mm

19800-000300-100-RS:

CABLE;2;300MM;28AWG;(A)D-SUB 9PIN MALE;(B)DUPONT

Cable Module;;COM PORT

5

2*5PIN P=2.0F;;;;;ONE PCS PKG W/ LABEL;W/ BRACKET;;;;RoHS

32205-003800-300-RS:RS-422/485 cable, 200mm

6

Jumpers setting and connectors

LABEL FUNCTION

J_ATX_AT1 AT/ATX mode select switch

BAT1 Battery connector

CHASSIS1 Chassis intrusion connector

J_CMOS1 Clear CMOS button

FAN1 CPU fan connector

PWR1 CPU power connector

DIMM1, DIMM2 DDR3 SO-DIMM slots

DIO1 Digital I/O connector

LPT_DB1 EC debug connector

F_PANEL1 Front panel connector

IPMI1 IPMI slot

ID_BT_FP1 IPMI LED connector

KB_MS1 Keyboard and mouse connector

LED_LAN2, LED_LAN3 LAN LED connectors

PCIEX4 PCIe x4 slot

M_PCIE1, M_PCIE2 PCIe Mini Card Slots

COM2, COM3, COM5 RS-232 serial port connector

COM6 RS-422/485 serial port connector

SATA1, SATA2 SATA 6Gb/s drive connectors

SATA_PWR1, SATA_PWR2 SATA power connectors

SD1 SD card slot

CN1, CN2 SMBus connectors

SPDIF1 SPDIF connector

SPI1, SPI2 SPI Flash connectors

FAN2 System fan connector

TPM1 TPM connector

USB3 USB connector

AUDIO_CV2 Audio jacks

LAN1_USB2 Ethernet and USB 2.0 ports

LAN2_USB2 Ethernet and USB 3.0 ports

PWR2 Power connector

7

COM1, HDMI1 Serial port and HDMI connectors

VGA1, HDMI2 VGA and HDMI connectors

CHASSIS1: Chassis Intrusion Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1

+V3.3A_EC_PLL

2

CHASSIE_EC

J_CMOS1: Clear CMOS button

PIN NO.

DESCRIPTION

Open

Normal Operation (default)

Push

Clear CMOS Setup

PWR1: CPU power connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1

GND_VIN

2

GND_VIN

3

12VIN_1

4

12VIN_1

BAT1: Battery Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1

+VBAT

2

GND

FAN1: CPU fan connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1

GND

2

+12V

3

FAN1IN

4

FAN1OUT

J_ATX_AT1: AT/ATX mode select switch

PIN NO.

DESCRIPTION

Short 1 - 2

AT Mode

Short 2 - 3

ATX Mode (default)

8

F_PANEL1: Front panel connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1

NC

2

PWRBTN+

3

GND

4

HDD LED+

5

HDD LED-

6

PWR LED+

7

PWR LED+

8

PWR LED-

9

RST BTN+

10

GND

LPT_DB1: EC debug connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1

KSI0

11

KSO9

2

KSO0

12

KSO10

3

KSO1

13

KSO12

4

KSO2

14

KSI1

5

KSO3

15

KSO11

6

KSO4

16

KSI2

7

KSO5

17

KSI3

8

KSO6

18

GND

9

KSO7

19

GND

10

KSO8

20

GND

DIO1: Digital I/O connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1

GND

2

+5V

3

DOUT3

4

DOUT2

5

DOUT1

6

DOUT0

7

DIN3

8

DIN2

9

DIN1

10

DIN0

9

ID_BT_FP1: IPMI LED connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1 +V3.3A_EC_PLL 2 ID_BT_FP#

LED_LAN2, LED_LAN3: LAN LED connectors

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1

PWR

2

L1/2_LINK_ACT-

KB_MS1: Keyboard and mouse connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1

VCC5_KBMS

2

MSDATA

3

MSCLK

4

KBDATA

5

KBCLK

6

KBMS_GND

10

IPMI1: IPMI slot

PIN

DESCRIPTION

PIN

DESCRIPTION

1

VGA_G2

103

NC_SI_RXD1

2

NC

104

NC_SI_TXD1

3

VGA_R2

105

+5V_DUAL

4

NC

106

+5V_DUAL

5

VGA_B2

107

NC

6

NC

108

NC_SI_CRS_DV

7

NC

109

NC_SI_CLK_IN

8

NC

110

NC_SI_TX_EN

9

VSYNC2

111

+5V_DUAL

10

NC

112

+5V_DUAL

11

HSYNC2

113

APU_VDD_RUN

12

NC

114

NC

13

VI_DDCDAT

115

+0.95V_ALW

14

NC

116

APU_VDDIO_SUS

15

VI_DDCCLK

117

+5V

16

NC

118

+5V

17

NC

119

NC

18

NC

120

APU_VTT_SUS

19

GND

121

NC

20

GND

122

SPI_SWITCH

21

SMB_PCIE_3V3_CLK

123

+3.3V

22

SMB_IPMB_3VSB_CLK

124

+3.3V

23

SMB_PCIE_3V3_DATA

125

ID_BT_FP#

24

SMB_IPMB_3VSB_DATA

126

NC

25

GND

127

GND

26

GND

128

IPMI_DET#

27

BMC_SPKR

129

SPI_BMC_BIOS_CS0_N

28

GND

130

SPI_PATBRG_R_CS0_N

29

APU_VDD_PWRGD_IPMI

131

SPI_BMC_BIOS_CLK

30

NC

132

SPI_PATBRG_R_CLK

31

GND

133

GND

32

GND

134

GND

33

SMB_TEMP_3VSB_CLK

135

SMI_ACTIVE#
