IEI Technology ICE-QM770 Manual de usuario

COM Express Basic Type 6 module with socket G2 supports

Intel® 2nd 3rd generation Core™ i7/i5/i3 Celeron®

processor, VGA/LVDS, DDI, GbE, SATA 6Gb/s, USB 3.0, Audio

and RoHS

ICE-QM770

Quick Installation Guide

Version 1.00

Oct, 1, 2012

Package Contents

ICE-QM770 package includes the following items:

 1 x ICE-QM770-R10 single oard computer

 1 x Heat Spreader

 1 x Cooler

 1 x Driver CD

 1 x Utility CD

 1 x QIG (Quick Installation Guide)

WARNING!

Never run the em edded module without the heat sink. The heatspreader

plate shipped with the ICE-QM770 acts as a thermal interface etween the

module and the heat sink. The heat sink must e installed on the

heatspreader plate to maintain proper operating temperatures. Make sure to

maintain the heatspreader plate temperature under 60°C in operation.

Specifications

 Form Factor

PICMG COM Express R2.0 Basic Type 6

 CPU

Socket G2 supports Intel® 2nd & 3rd generation Core™

i7/i5/i3/Celeron® processor

 PCH

Intel® QM77

 Memory

Two 204-pin 1600/1333/1066 MHz dual-channel DDR3 SDRAM

un uffered DIMMs supported (system max. 16GB)

Supports 1.35V DDR3L

 BIOS

UEFI BIOS

 Graphics Engine

Intel® HD Graphics 2000/3000

Supports DX11, OCL 1.1 and OpenGL 3.0

Full MPEG2, VC1, AVC Decode

 Display Output

VGA integrated in the Intel® QM77 (signal to ase oard)

3 x DDI (up to 2560 x 1600 @60Hz)

1 x VGA up to QXGA (up to 2048 x 1536 @75Hz)

1 x 18/24- it dual-channel LVDS (up to 1920 x 1200 @60Hz)

 Ethernet

Intel® 82579LM

 Em edded Controller

iWDD

 I/O Interface

2 x RS-232 (to ase oard) 8 x USB 2.0 (to ase oard)

4 x USB 3.0 (to ase oard) 2 x SATA 3GB/s (signal to ase oard)

2 x SATA 6G /s (signal to ase oard)

 Audio

High definition audio interface

 SMBus

Yes (to ase oard)

 I2C

YYes (to ase oard)

 LPC

Yes (to ase oard)

 Expansions

1 x PCIe x16 signal (to ase oard)

7 x PCIe x1 signal (to ase oard)

 Watchdog Timer

Software programma le supports 1~255 sec. system reset

 GPIO

8- it GPIO (to ase oard)

 TPM

Through the ase oard

 Intel® AMT

Supports Intel® AMT 8.0

 Power Consumption

[email protected], Vcore [email protected]3A

 Operating Temperature

-10°C ~ 60°C

 Operating Humidity

5% ~ 95%, non-condensing

 Dimensions

125 mm x 95 mm

 Weight

GW: 700g/NW: 250g

Ordering Information

ICE-GM4 A-R11: COM Express Basic Type 6 module, Intel® 22nm Core™

i7/i5/i3 processor, VGA/LVDS, G E, SATA 6G /s, USB 3.0, Audio and RoHS

ICE-DB-T6-R10: Base Board for COM Express Type 6 modules

Table of Jumper Setting

LABEL

FUNCTION

SW1

LCD Panel Type Setting switch

1. LVDS Panel type Selection

The Panel type of LVDS can e selected y using SW1. O =0 OFF=1

SW1

4321

EDID

Resolution Color Depth Channel

0000 640X480 18- it Single

0001 800X480 18- it Single

0010 800X600 18- it Single

0011 1024X768 18- it Single

0100 1024X768 24- it Single

0101 1280X1024 24- it Dual

0110 1600X1200 24- it Dual

0111 1280X768 18- it Single

1000 1280X800 18- it Single

1001 1366X768 24- it Single

1010 1440X900 24- it Dual

1011 1600X900 24- it Dual

1100 1680X1050 24- it Dual

1101 1920X1080 24- it Dual

1110 1920X1200 24- it Dual

1111 LVDS disa le

1. Flash SPI ROM (BIOS)

• JSPI1: Flash BIOS SPI ROM

DESCRIPTION

+V3.3M_SPI_CON

SPI_CS

SPI_SO_SW

SPI_CLK_SW

SPI_SI_SW

GND

2. Flash SPI ROM (EC)

• JSPI2: Flash BIOS SPI ROM

PIN NO.

DESCRIPTION

+V3.3M_SPI_CON

_EC

SPI_CS

#0_CN_EC

SPI_SO_SW

_EC

SPI_CLK_SW

_EC

SPI_SI_SW

_EC

GND

Table of Connectors

LABEL

FUNCTION

JSPI

FLASH SPI ROM (BIOS)

JSPI2

FLAS

H SPI ROM (EC)

COM Express

Connector

COM Express

Connector

3. COM Express Connector AB

• J3: The standard COM Express connector AB location and pinouts

are shown below

Pin No. Description Pin No. Description

A1 GND B1 GND15

A2 GBE0_MDI3- B2 GBE0_ACT#

A3 GBE0_MDI3+ B3 LPC_FRAME#

A4 GBE0_LINK100# B4 LPC_AD0

A GBE0_LINK1000#

B LPC_AD1

A6 GBE0_MDI2- B6 LPC_AD2

A7 GBE0_MDI2+ B7 LPC_AD3

A8 GBE0_LINK# B8 LPC_DRQ0#

A9 GBE0_MDI1- B9 LPC_DRQ1#

A10 GBE0_MDI1+ B10 LPC_CLK

A11 GND1 B11 GND16

A12 GBE0_MDI0- B12 PWRBTN#

A13 GBE0_MDI0+ B13 SMB_CK

A14 GBE0_CTREF B14 SMB_DAT

A1 SUS_S3# B1 SMB_ALERT#

A16 SATA0_TX+ B16 SATA1_TX+

A17 SATA0_TX- B17 SATA1_TX-

A18 SUS_S4# B18 SUS_STAT#

A19 SATA0_RX+ B19 SATA1_RX+

A20 SATA0_RX- B20 SATA1_RX-

A21 GND2 B21 GND17

A22 SATA2_TX+ B22 SATA3_TX+

A23 SATA2_TX- B23 SATA3_TX-

A24 SUS_S5# B24 PWR_OK

A2 SATA2_RX+ B2 SATA3_RX+

A26 SATA2_RX- B26 SATA3_RX-

A27 BATLOW# B27 WDT

A28 ATA_ACT# B28 AC/HD_SDIN2

A29 AC/HD_SYNC B29 AC/HD_SDIN1

A30 AC/HD_RST# B30 AC/HD_SDIN0

A31 GND3 B31 GND18

A32 AC/HD_BITCLK B32 SPKR

A33 AC/HD_SDOUT B33 I2C_CK

A34 BIOS_DISABLE# B34 I2C_DAT

A3 THRMTRIP# B3 THRM#

Pin No. Description Pin No. Description

A36 USB6- B36 USB7-

A37 USB6+ B37 USB7+

A38 USB_6_7_OC# B38 USB_4_5_OC#

A39 USB4- B39 USB5-

A40 USB4+ B40 USB5+

A41 GND4 B41 GND

A42 USB2- B42 USB3-

A43 USB2+ B43 USB3+

A44 USB_2_3_OC# B44 USB_0_1_OC#

A4 USB0- B4 USB1-

A46 USB0+ B46 USB1+

A47 VCC_RTC B47 EXCD1_PERST#

A48 EXCD0_PERST# B48 EXCD1_CPPE#

A49 EXCD0_CPPE# B49 SYS_RESET#

A 0 LPC_SERIRQ B 0 CB_RESET#

A 1 GND5 B 1 GND20

A 2 PCIE_TX5+ B 2 PCIE_RX5+

A 3 PCIE_TX5- B 3 PCIE_RX5-

A 4 GPI0 B 4 GPO1

A PCIE_TX4+ B PCIE_RX4+

A 6 PCIE_TX4- B 6 PCIE_RX4-

A 7 GND6 B 7 GPO2

A 8 PCIE_TX3+ B 8 PCIE_RX3+

A 9 PCIE_TX3- B 9 PCIE_RX3-

A60 GND7 B60 GND

A61 PCIE_TX2+ B61 PCIE_RX2+

A62 PCIE_TX2- B62 PCIE_RX2-

A63 GPI1 B63 GPO3

A64 PCIE_TX1+ B64 PCIE_RX1+

A6 PCIE_TX1- B6 PCIE_RX1-

A66 GND8 B66 WAKE0#

A67 GPI2 B67 WAKE1#

A68 PCIE_TX0+ B68 PCIE_RX0+

A69 PCIE_TX0- B69 PCIE_RX0-

A70 GND9 B70 GND22

A71 LVDS_A0+ B71 LVDS_B0+

A72 LVDS_A0- B72 LVDS_B0-

A73 LVDS_A1+ B73 LVDS_B1+

A74 LVDS_A1- B74 LVDS_B1-

Pin No. Description Pin No. Description

A7 LVDS_A2+ B7 LVDS_B2+

A76 LVDS_A2- B76 LVDS_B2-

A77 LVDS_VDD_EN B77 LVDS_B3+

A78 LVDS_A3+ B78 LVDS_B3-

A79 LVDS_A3- B79 LVDS_BKLT_EN

A80 GND10 B80 GND23

A81 LVDS_A_CK+ B81 LVDS_B_CK+

A82 LVDS_A_CK- B82 LVDS_B_CK-

A83 LVDS_I2C_CK B83 LVDS_BKLT_CTRL

A84 LVDS_I2C_DAT B84 VCC5SBY1

A8 GPI3 B8 VCC5SBY2

A86 RSVD B86 VCC5SBY3

A87 RSVD B87 VCC5SBY4

A88 PCIE0_CK_REF+ B88 BIOS_DIS1#

A89 PCIE0_CK_REF- B89 VGA_RED

A90 GND11 B90 GND24

A91 SPI_VCC B91 VGA_GRN

A92 SPI_MISO B92 VGA_BLU

A93 GPO0 B93 VGA_HSYNC

A94 SPI_CLK B94 VGA_VSYNC

A9 SPI_MOSI B9 VGA_I2C_CK

A96 PP_TPM B96 VGA_I2C_DAT

A97 RSVD B97 SPI_CS#

A98 RS1_TX B98 RSVD

A99 RS1_RX B99 RSVD

A100 GND13 B100 GND25

A101 RS2_TX B101 FAN_PWMOUT

A102 RS2_RX B102 FAN_TACHIN

A103 LID# B103 SLEEP#

A104 VCC_12V7 B104 VCC_12V16

A10 VCC_12V8 B10 VCC_12V17

A106 VCC_12V9 B106 VCC_12V18

A107 VCC_12V10 B107 VCC_12V19

A108 VCC_12V11 B108 VCC_12V20

A109 VCC_12V12 B109 VCC_12V21

A110 GND14 B110 GND26

4. COM Express Connector CD

• J4: The standard COM Express connector AB location and pinouts

are shown below

Pin No. Description Pin No. Description

C1 GND0 D1 GND15

C2 GND D2 GND

C3 USB_SSRX0- D3 USB_SSTX0-

C4 USB_SSRX0+ D4 USB_SSTX0+

C GND D GND

C6 USB_SSRX1- D6 USB_SSTX1-

C7 USB_SSRX1+ D7 USB_SSTX1+

C8 GND D8 GND

C9 USB_SSRX2- D9 USB_SSTX2-

C10 USB_SSRX2+ D10 USB_SSTX2+

C11 GND1 D11 GND16

C12 USB_SSRX3- D12 USB_SSTX3-

C13 USB_SSRX3+ D13 USB_SSTX3+

C14 GND D14 GND

C1 DDI1_PAIR6+ D1 DDI1_AUX+

C16 DDI1_PAIR6- D16 DDI1_AUX-

C17 RSVD D17 RSVD

C18 RSVD D18 RSVD

C19 PCIE_RX6+ D19 PCIE_TX6+

C20 PCIE_RX6- D20 PCIE_TX6-

C21 GND2 D21 GND17

C22 RSVD D22 RSVD

C23 RSVD D23 RSVD

C24 DDI1_HPD D24 RSVD

C2 DDI1_PAIR4+ D2 RSVD

C26 DDI1_PAIR4- D26 DDI1_PAIR0+

C27 RSVD D27 DDI1_PAIR0-

C28 RSVD D28 RSVD

C29 DDI1_PAIR5+ D29 DDI1_PAIR1+

C30 DDI1_PAIR5- D30 DDI1_PAIR1-

C31 GND3 D31 GND18

C32 DDI2_AUX+ D32 DDI1_PAIR2+

C33 DDI2_AUX- D33 DDI1_PAIR2-

C34 DDI2_CTRLCLK D34 DDI2_CTRLDATA

C3 RSVD D3 RSVD

Pin No. Description Pin No. Description

C36 DDI3_AUX+ D36 DDI1_PAIR3+

C37 DDI3_AUX- D37 DDI1_PAIR3-

C38 DDI3_CTRLCLK D38 DDI3_CTRLDATA

C39 DDI3_PAIR0+ D39 DDI2_PAIR0+

C40 DDI3_PAIR0- D40 DDI2_PAIR0-

C41 GND4 D41 GND19

C42 DDI3_PAIR1+ D42 DDI2_PAIR1+

C43 DDI3_PAIR1- D43 DDI2_PAIR1-

C44 DDI3_HPD D44 DDI2_HPD

C4 RSVD D4 RSVD

C46 DDI3_PAIR2+ D46 DDI2_PAIR2+

C47 DDI3_PAIR2- D47 DDI2_PAIR2-

C48 RSVD D48 RSVD

C49 DDI3_PAIR3+ D49 DDI2_PAIR3+

C 0 DDI3_PAIR3- D 0 DDI2_PAIR3-

C 1 GND5 D 1 GND20

C 2 PEG_RX0+ D 2 PEG_TX0+

C 3 PEG_RX0- D 3 PEG_TX0-

C 4 RSVD D 4 PEG_LANE_RV#

C PEG_RX1+ D PEG_TX1+

C 6 PEG_RX1- D 6 PEG_TX1-

C 7 RSVD D 7 TYPE2#

C 8 PEG_RX2+ D 8 PEG_TX2+

C 9 PEG_RX2- D 9 PEG_TX2-

C60 GND7 D60 GND21

C61 PEG_RX3+ D61 PEG_TX3+

C62 PEG_RX3- D62 PEG_TX3-

C63 RSVD1 D63 RSVD10

C64 RSVD2 D64 RSVD9

C6 PEG_RX4+ D6 PEG_TX4+

C66 PEG_RX4- D66 PEG_TX4-

C67 RSVD3 D67 GND28

C68 PEG_RX5+ D68 PEG_TX5+

C69 PEG_RX5- D69 PEG_TX5-

C70 GND9 D70 GND22

C71 PEG_RX6+ D71 PEG_TX6+

C72 PEG_RX6- D72 PEG_TX6-

C73 DDI1_CTRLDATA D73 DDI1_CTRLCLK

C74 PEG_RX7+ D74 PEG_TX7+

Tabla de contenidos

Otros manuales de Hardware de computadora de IEI Technology

IEI Technology

IEI Technology KINO-PV-D4253-R10 Manual de usuario

IEI Technology

IEI Technology PEMUX-XEW1 Manual de usuario

IEI Technology

IEI Technology PE-6S-R40 Manual de usuario

IEI Technology

IEI Technology PCIE-G41A2 Manual de usuario

IEI Technology

IEI Technology PE-6SD2-R40 Manual de usuario

IEI Technology

IEI Technology IOWOA-LX-600 Manual de usuario

IEI Technology

IEI Technology IOWA-LX-600 Manual de usuario

IEI Technology

IEI Technology Enano-8523T Manual de usuario

IEI Technology

IEI Technology PCISA-BT Manual de usuario

IEI Technology

IEI Technology PCIE-H610 Manual de usuario

IEI Technology

IEI Technology IOWA-GX Manual de usuario

IEI Technology

IEI Technology PPC2-C ADL Series Manual de usuario

IEI Technology

IEI Technology PICOe-HM650 Manual de usuario

IEI Technology

IEI Technology PM-US15W Manual de usuario

IEI Technology

IEI Technology TANGO-7010 Series Manual de usuario

IEI Technology

IEI Technology ECN-680A-H61 Manual de usuario

IEI Technology

IEI Technology PCISA-9652 Manual de usuario

IEI Technology

IEI Technology PXE-9S2-R10 Manual de usuario

IEI Technology

IEI Technology PCIE-9650 Manual de usuario

IEI Technology

IEI Technology WAFER-TGL-U Manual de usuario

IEI Technology

IEI Technology Picoe-PV-N4551 Manual de usuario

IEI Technology

IEI Technology TANK-101B Manual de usuario

IEI Technology

IEI Technology TANK-700 Manual de usuario

IEI Technology

IEI Technology ROCKY-4786EVG Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
