ICW Elite Manual de usuario

1) Do not attempt to adjust your Elite arm until everything you intend to mount to

the arm is mounted.

2) Arm must be completely horizontal (extended) before adjusting the arms tension.

Failure to do so will damage the arm and void the warranty.

3) Never loosen or remove any of the shoulder bolts. Doing so will cause the

arm to immediately come apart with tremendous force, and could cause seri-

ous injury.

4) If equipment requiringAC power is mounted to this unit, have a certified electri-

cian inspect the installation.

5) Failure to install this unit according to these instructions will void all ICW warran-

ties. If installed incorrectly, ICW is not liable for any damage or injury caused by

the unit.

ICWElitewallmountinstallation

DANGER!

The Elite arm contains high pressure gas springs.

The following cautions MUST be observed to

avoid serious injury.

Shoulder bolt

Locate a stud in the wall you intend to mount your arm on

and remove the wall mount from the box. Mark the top

hole, drill 11/64 pilot hole and insert an ICW provided

#14 screw and tighten slightly. Using a level, mark the two

lower holes and drill pilot holes, insert the last two #14

screws and, with the mount level, tighten all screws se-

curely.

Wallmount

Note:ICWsupplies#14 wood screws,ifinstallingontometal studs

youwillneedto replace withpropermetalstudfasteners. All

hardwareused to securewallmountmust have aproper

countersunkhead.

2

The wall mount is shipped

with the bearings wrapped and

it is recommended that you

leave the wrapping on until

later in the installation process.

Nylock

Steel

race

Find the 3/8 bolt assembly in

your hardware bag.

Remove the 4 covers as shown. Removethecenter coverby

unscrewingthe4 10-24 flathead

screwsusingthe 1/8 hexkey.

Removethelongarm

coversbyunscrewing

the2 6-32flathead

screwsusingaphilps

headscrewdriver.

Removetheend

coverby unscrew-

ingthe 210-24

screwsusingthe

1/8hexkey.

Removewrappingfrombearing and place theendofthe

Elitearmonthewallmount.

3

Extendthearmstraightout and lay allofthecables

foryourmonitor,keyboard,andmouseinthe channel

ontop ofthe arm.

Be sure your cables are to one or

theotherside of thecenteradjustment

hub.YOUMUSTLEAVEABITOF

SLACK IN THE CORDSTOALLOW

FORARM MOVEMENT.

Hub

Cable

4

Passthe 3/8 boltwith

thebearingassembly

throughthewallmount

andthearmfrom

underneath. Placethe

steelrace overthe bolt

insidethearmasshown

andsecurefirmlywith

thenylockusingthe

provided9/16wrench

and5milhex key.

Elite arm mounted on wall.

Keepthe armfolded

whileinstalling.

Wiretie your cablestogetherwiththe hub betweenthem.

Wireties arefoundin your hardwarebag.

Addthe wireclips tosecure thecables.

Wireclips are foundinyour hardware bag.

Wireclips

Addthe wire clipto the

endofarm.

Cable

Feedcordthroughtheplasticbushingin

themount assembly. The plasticbushing

canbe removed,opened andslipped

overcordif nessesary.

5

Replace all of the covers. Being sure not to pinch the cables.

The long covers should be replaced first, then the center cover,

and lastly the two end covers.

6

Usethe provided1/4” wrenchto open

theplasticslidermountand insert the

ballontheVESAPlate.Tightenfirmly. Secure yourmonitorto the

VESAplateusingthe4provided

4mmscrews.

Besureto tighten bothbolts

together - not one side and

then the other.

Attachthe keyboard tothe keyboardmount

usingthe supplied screws.

Attachtheoptionallargehandleto

theendoftheslider by screwing

togetherthetwohalves.

Usetheslider handle toadjust

themonitorup and down.

Usethepush

buttonstopivotthe

monitorforward and

back. Liftgentlyon

themonitortorelease

theweight off the buttons.

7

Extend the Elite straight out as shown before adjusting the arms

resistance. Be sure all equipment is mounted on the arm before

adjusting. Adjust the arm closest to the monitor first.

Use the T-handle provided to adjust the arms resistance.

Thank you for your purchase of an ICW Elite arm, your arm is now

ready to use.

Any questions please contact ICW at: 1-800-558-4435.

Before adjusting the tension on your Elite arm place everything

you are going to mount on it in place, including the monitor, key-

board, mouse, and mouse pad.

8
