1) Do not attempt to adjust your Elite arm until everything you intend to mount to

the arm is mounted.

2) Arm must be completely horizontal (extended) before adjusting the arms tension.

Failure to do so will damage the arm and void the warranty.

3) Never loosen or remove any of the shoulder bolts. Doing so will cause the

arm to immediately come apart with tremendous force, and could cause seri-

ous injury.

4) If equipment requiringAC power is mounted to this unit, have a certified electri-

cian inspect the installation.

5) Failure to install this unit according to these instructions will void all ICW warran-

ties. If installed incorrectly, ICW is not liable for any damage or injury caused by

the unit.

ICW Elite SingleArm Ceiling Mount

DANGER!

The Elite arm contains high pressure gas springs.

The following cautions MUST be observed to

avoid serious injury.

Shoulder bolt

Removetheceiling mount fromthebox, and findthe4 #14 woodscrews

inyourhardwarebag. Firmlysecurethe ceiling mount toasolidstud

intheceilingusingall4oftheprovidedscrewsand being sure the mount is

level.

Loosenset screwand thread arm onto

ceilingmount,tightensetscrew.

Findthe screws inthe end covers

andthelongcover.

2

Removethelong arm coverbyunscrewing the 26-32flathead screws

usinga philipsheadscrewdriver.

Removethe end coversby unscrewingthe 2 10-24

flatheadscrewsusing the 1/8” hexkey.

Runthecordsalong the armalltheway

throughthe cordchannelupintotheceilingmount.

Replacethe three coverson the arm,being

carefulnotto pinch thecords.

Feedthecordsthroughtheplastic bushing

intheendcovers. The plastic bushing can

beremoved, openedand slippedover

cordif necessary.

3

YourT-REXmountcomeswithauniversal

VESAthatwillaccommodatea75mmor

100mmmonitor.

Usethe buttons to

adjustthe tilt

ofyourmonitor.

Liftgentlyonthe

monitortofree

buttonsfrom the

monitorsweight.

Onceyourmonitor is mounted, extendand

adjustthe tensiononthe arm

usingthet-handleadjustmentwrench

provided.

Adjustmentport.

Thankyou for yourpurchase ofan ICWTitan Elitearm. Any questions pleasecall 1-800-558-4435

Attachyourmonitortothe

T-REX mountusing the4mm

screws in yourhardware bag.

Usethesliderhandletomoveyourmonitoralong

thesliderail.
