ICOP Technology VDX-6372RD Manual de usuario

VDX-6372RD/VDX-6372RD-Plus

DM&P Vortex86DX 600MHz

PC/104 CPU Module

with 2S/2USB/VGA/LCD/GPIO/PWMx16

128MB DDR2 Onboard

User’s Manual

(Revision 1.1A)

The information in this manual is subject to change without notice for continuous improvement in

the product. All rights are reserved. The manufacturer assumes no responsibility for any

inaccuracies that may be contained in this document and makes no commitment to update or to

keep current the information contained in this manual.

No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part,

in any form or by any means without the prior written permission of the IC P Technology Inc..

Manual No. IUM6372D000-01 Ver.1.0A May, 2010

Manual No. IUM6372D000-01 Ver.1.1A ctober, 2014

Trademarks Acknowledgment

Vortex86DX is the registered trademark of IC P Technology Inc.

ther brand names or product names appearing in this document are the properties

and registered trademarks of their respective owners. All names mentioned herewith

are served for identification purpose only.

T a b l e o f C o n t e n t s

T a b l e o f C o n t e n t s ............................................................. iii

C h a p t e r 1 Introduction……………………………………………1

1.1 Packing List ............................................................ 1

1.2 Product Description ................................................ 1

1.3 Specifications ......................................................... 3

1.4 Board Dimension .................................................... 5

C h a p t e r 2 Installation……………………………………………..6

2.1 Board utline ......................................................... 6

2.2 Connectors & Jumpers Location .................... ........7

2.3 Connectors & Jumpers Summary ........................... 9

2.4 Pin Assignments & Jumper Settings ..................... 10

2.5 System Mapping ................................................... 19

2.6 Watchdog Timer ................................................... 23

2.7 GPI .................................................................... 24

2.8 SPI flash ............................................................... 25

2.9 PWM .................................................................... 26

3.0 IDE to SD ............................................................. 27

C h a p t e r 3 Driver Installation……………………………………28

Appendix ………………………………………………………………..29

A. TFT Flat Panel Data utput ...................................... 29

B. TFT Flat Panel Support List ....................................... 30

C. LVDS Flat Panel Support List .................................... 32

D. Flat Panel Hardware Setting ..................................... 33

E. Flat Panel Wiring and Lighting .................................. 34

F. TCP/IP library for D S real mode .............................. 35

G. BI S Default Setting ................................................. 36

Warranty ............................................................................................ 37

This page is blank

VDX-6372RD Vortex86DX PC/104 CPU Module

C h a p t e r 1

Introduction

1.1 Packing List

Product Name Package

VDX-637 RD

VDX-637 RD-Plus

Embedded Vortex86DX CPU All-in-One Board

Manual & Drivers CD x 1

RS 3 cable x

PRINT cable x1

IDE cable x 1

USB cable x 1

(USB port x

)

VGA cable x 1

GPIO cable x 1

PS/ Mouse cable x 1

PS/ Keyboard cable x 1

Screw Kit x 1

VDX-6372RD Vortex86DX PC/104 CPU Module

1.2 Product Description

The VDX-6372RD family of low-power x86 embedded controller is designed to meet PC/104

specification, and integrated with the following features.

600 MHz Vortex86DX SoC

VGA, TFT/ LVDS LCD support up to

1280x1024 resolution

128MB DDR2 system memory

Enhanced IDE (UltraDMA-100/66/33)

2 USB 2.0 (host)

Up to 2 serial ports

Parallel port

16-bit GPI s

PC/104-Plus expansion bus

Meet PC/104 stacking spec.

2 watchdog timer

PWM 16~24 channels

JTAG interface

AMI BI S

Single voltage +5V DC

Support extended operating

temperature range of -20°C to +70°C

The VDX-6372D PC/104 family of embedded controller is designed with backward compatibility

in mind, to provide migration path for projects facing end-of-life challenges with their existing x86

based PC/104 controller. The VDX-6372D family of controller is designed as a plug in

replacement, with backward compatibility to support legacy software to help extend existing

product life cycle without heavy re-engineering.

VDX-6372D is suitable for broad range of data-acquisition, Industrial automation, Process

control, Automotive controller, AVL, Intelligent Vehicle management devic,Medical device,

Human machine interface, Robotics, machinery control And more…application that required

small footprint, low-power and low-cost hardware with open industry standard such as PC/104.

VDX-6372RD Vortex86DX PC/104 CPU Module

1.3 Specifications

Features VDX-637 RD

CPU

M&P SoC CPU Vortex86

00MHz

Real Time Clock with Lithium Battery Backup

Cache

L1:16K I

Cache, 16K D

Cache

128KB

BI S

AMI BI S

Bus Interface

PC/104 Standard Compliant ( ptional: PC

104)

System Memory

DDR2

nboard

Watchdog Timer

oftware programmable from 30.5

to 512 seconds x2

sets(Watchdog 1 fully compatible with M6117D)

VGA

XGI Volari Z9s Chipset

VGA and TFT Flat Panel Interface Support

LVDS Flat Panel Interface Support ( ptional)

nboard 32MB VGA Memory

Support resolution up to 1280 x 1024,16MB colors

I / Interface

Enhanced IDE port (UltraDMA-100/66/33) x1

RS-232 port x1

RS-232/422/485 port x1 (RS485: Auto Direction)

Parallel port x1

USB port x2 (USB 2.0 version)

16-bit GPI port x1

Connectors

2.00 mm ∅ 44-pin box header for IDE x1

2.00 mm ∅ 44-pin box header for LCD x 1

2.00 mm ∅ 10-pin box header for VGA x1

2.00 mm ∅ 10-pin box header for USB x1

2.00 mm ∅ 26-pin box header for Print x1

2.00 mm ∅ 20-pin box header for 16-bit GPI x1

2.00 mm ∅ 10-pin box header for RS-232 x2

2.54 mm ∅ 5-pin box header for Keyboard x1

2.54 mm ∅ 5-pin header for Mouse x1

2.54 mm ∅ 4-pin header for DC-in x1

2.54 mm ∅ 3-pin header for RS-485 x1

2.54 mm ∅ 2-pin header for Reset x1

2.54 mm ∅ 7-pin header for Redundancy x1( pt)

2.54 mm ∅ 2-pin header for SYS-Fail-SW- x1( pt)

1.25 mm ∅ 6-pin Wafer for JTAG x1

Flash Disk Support

44-pin IDE Flash Disk( EmbedDisk 16MB or above)

44-pin IDE to Micro SD ( ptional)

VDX-6372RD Vortex86DX PC/104 CPU Module

PWM

16~24 chann

els

Power Requirement

Single Voltage +5V

Dimension

90 X 96mm (3.54 x 3.77 inches)

Weight

perating

Temperature

C ~ +70

-40°C ~ +85°C ( ptional)

VDX-6372RD Vortex86DX PC/104 CPU Module

1.4 Board Dimension

VDX-6372RD Vortex86DX PC/104 CPU Module

C h a p t e r 2

Installation

2.1 Board Outline

(Note1: COM RS 3 /4 /485 is selected by BIOS setting)

(Note : PCI-104 connector is optional)

(Note3: VI/O Default setting of PCI-104 connector is +5V)

(Note4: Redundancy Signal and System-Fail-SW are optional)
