7CONNECT USING ETHERNET
System Requirements
• Available network port on your router,
modem, or switch.
1. Plug the Ethernet cable into the port located
on the bottom of your clock.
2. Connect the other end of the Ethernet cable into
an available port on your router, switch, or wall port.
3. Disconnect the power supply from the time clock and
reconnect it again to power cycle the time clock.
4. Check to see that the green and amber Ethernet link
lights turn on where the Ethernet cable plugs into the clock.
This verifies that your time clock is connected to your network.
If the lights do not turn on, check the cable connections.
Note: A network connection is not required at all times.
A Network connection is required for accessing the time
clock application and running reports.
5. Press on the time clock to enter Supervisor Mode.
6. Enter the default security code: 00 00 00.
7. Press to scroll and find the View IP Address option. Press Enter.
8. Write down the clock’s assigned IP address below for reference.
IP Address:
^
