Features:

1. Plug and Play

2. Support DDC1 & DDC2B

3. On Screen Display (OSD) Contrast, Brightness, Screen Size etc.

4. VESA holes standard 75 x 75mm, Wall or Free Arm mountable

Precautions:

1. Always handle your MT-1xxx with care when moving it, and avoiding the

impact and shock.

2. Don’t apply pressure to the screen.

3. Don’t touch the screen directly with the fingers.

4. The display area is highly prone to scratching.

5. Don’t let water or oil penetrate the monitor and wipe off water drop immediately.

Long contact with water may cause discoloration or spots.

6. Please keep the food particles and fingerprints away from the display area.

7. Be sure to turn off power supply.

8. Avoid exposing the MT-1xxx to direct sunlight or other heat source.

The MT-1xxx should be facing away from direct sunlight to reduce the glare.

9. Choose a well-ventilated area to position your MT-1xxx to allow adequate

dissipation of heat. Don’t place anything on top of the MT-1xxx.

10. Ensure the area around the MT-1xxx is clean and moisture-free.

11. Never remove the rear cover. The display unit contains high-voltage parts.

You may suffer electric shock if you touch these parts.

12. If the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.

Storage:

1. Don’t store the monitor in temperature higher than 60℃or lower than -20℃.

2. Store in dark places away from sunlight and ultra violet (UV) radiation.

Cleaning:

1. Before cleaning the monitor, make sure the monitor is under the “Off” condition.

2. Please un-plug the monitor first, and don’t apply the cleaning liquid to the

monitor directly.

3. Keep a certain distance form the monitor, and apply the cleaners to the cloths and

then use the cloths to clean the monitor gently.

4. Don’t use ketene type material (ex. Acetone), Ethy1 alcohol, toluene, Ethy1 acid

or Methy1 chloride to clear the panel.

5. The desirable cleaners are water, IPA (Iso Prophy1 Alcohol) or Hexane.

3

FRONT CONTROL PANEL

The monitor’s OSD control functions are located on the lower middle of the front

view side.

REAR INPUT/OUTPUT PORT

Select :To select the input source (VGA, AV1, AV2, AV3)

Menu :To select the Basic Setting, Position, Screen Setting,

Auto Adjust, Menu Setting, Recall, All Reset and Exit

Down :To decrease the value of the Select function

Up :To increase the value of the Select function

LED :The LED is showing the power status.

On :Green

Stand by :Red

Off :Red

On/Off :Power switch to turn ON or OFF the monitor.

Select Menu Down Up LED On/Off

4

Installation:

1. Product Package

Please check the contents first after opening the carton. The package should

include the following items;

z

Analog Color TFT LCD Monitor

z

Accessory box:

1. RGB cable

2. AC Adapter & Cord

3. Audio cable (comes with Model MT-1xxxA)

4. Video cable (comes with Model MT-1xxxAV)

5. USB cable (comes with Model MT-1xxxAVU)

z

Operating manual

2. Installation:

2.1 Make sure the monitor and the system unit power switches are OFF.

2.2 Plug one end of the 15pin signal cable to the monitor and the other end to the

video signal connector at the rear of the system. Tighten the two screws on

the cable connector on both ends. Please reference to the followings to

finish the installation:

If the installation is complete, turn the computer (or video machine) ON.

Adjust the OSD control to suit your personal preference.

5

ON SCREEN DISPLAY FOR VGA (OSD)

Fig2

EXIT : Return to last menu.

Fig 3

MODE : 1024 X 768

H : 47.7K v:60

BASIC SETTING

POSITION

SCREEN SETTING

AUTO ADJUST

MENU SETTING

RECALL

ALL RESET

EXIT

1.1 Fig 1:

BASIC SETTING: (See section 1.2)

POSITION: (See section 1.3)

SCREEN SETTING: (See section 1.4)

AUTO ADJUST: (See section 1.5)

MENU SETTING: (See section 1.6)

RECALL: When you run the function, the monitor will be setting to last status

of the saving value.

ALL RESET: To setting default value to the monitor.

EXIT: To close the OSD & saving all value.

MODE : 1024 X 768

H : 47.7K V : 60

BRIGHTNESS 128

CONTRAST 128

COLOR CONTROL

SOUND CONTROL

EXIT

1.2 Fig 2:

BRIGHTNESS : To adjust the black color

level of the image.

CONTRAST : To adjust the white color level

of the image.

COLOR CONTROL : (See section 1.7)

SOUND CONTROL : (See section 1.8)

MODE : 1024 X 768

H : 47.7K V: 60

PHASE 16

H-SIZE 32

H-POSITION 32

V-POSITION 32

EXIT

1.3 Fig 3:

PHASE : To adjust the noise of the image.

H-SIZE : To adjust the horizontal size of the

image.

H-POSIITON : To adjust the horizontal position

of the image.

V-POSITION : To adjust he vertical position of

the image.

EXIT : Return last menu.

Fi

g

1

6

MODE : 1024 X 768

H : 47.7K V : 60

MODE : 1024 X 768

H : 47.7K V : 60

1.4 Fig 4:

GRAPHIC/TEXT : To exchange the

640x640 (60Hz)/720x350 (60Hz)

Expansion : To expansion the image to full

screen or to abbreviate the image to normal

(1:1)

SMART SCALLING : To adjust the

image to interpolation.

SHARPNESS : To adjust the image from weak to sharp.

EXIT : Return last menu.

1.5 Fig 5:

AUTO TUNE : To auto turn the tracking,

position & gain of the image.

AUTO TRACKING : To auto tune the

H-size & phase of the image.

AUTO POSIITON : To auto tune the

horizontal & vertical position of the image.

EXIT : Return last menu.

Fig5

1.6 Fig 6:

LANGUAGE : To select the English or

Japanese of the OSD.

MENU POSIITON : To adjust the

horizontal & vertical position of the OSD.

FW VERSION : To show the version of

the system BIOS.

EXIT : Return last menu.

Fig6

GRAPHIC/TEXT

EXPANSION

SMART SCALLING

SHARPNESS

EXIT

MODE : 1024 X 768

H : 47.7K V : 60

AUTO TUNE

AUTO TRACKING

AUTO POSITION

EXIT

LANGUAGE

MENU POSIITON

FW VERSION

EXIT

Fi

g

4

7

MODE : 1024 X 768

H : 47.7K V : 60

1.7 Fig 7:

COLOR1 : To setting the color

temperature of the image to 9600K.

COLOR2 : To setting the color temerature

of the image to 6500K.

COLOR3 : To setting the color

temperature of the image to 5400K.

USER : To setting the RGB color of the

Fig7

image by oneself define.

EXIT : Return last menu.

1.8 Fig 8:

VOLUME : To adjust the volume of the

sound.

TREMLE : To adjust the treble of the

sound.

BASS : To adjust the bass of the sound.

BALANCE : To adjust the left & right

channel of the sound.

Fig8

EXIT : Return last menu.

MODE : 1024 X 768

H : 47.7K V : 60

COLOR1

COLOR2

COLOR3

USER

EXIT

VOLUME

TREBLE

BASS

BALANCE

EXIT

8

ON SCREEN DISPLAY FOR VIDEO (OSD)

BRIGHTNESS 128

BRIGHTNESS : To adjust the black color level of the image.

CONTRAST 128

CONTRAST : To adjust the white color level of the image.

SATURATION 64

SATURATION : To adjust the color saturation of the image.

HUE 0

HUE : To adjust the color hue of the image.

VOLUME 16

VOLUME : To adjust the volume of the sound.

TREBLE 8

TREBLE : To adjust the treble of the sound.

BASS 8

BASS : To adjust the bass of the sound.

BALANCE 8

BALANCE : To adjust the left & right channel of the volume.

RESET

RESET : To setting default value to the monitor.

9

REFERENCE

SIGNAL CONNECTOR PONOUTS

POWER CONNECTOR

Pin 1 Ground

Pin 2 + 12V output

RGB SIGNAL CONNECTOR

Pin 1 Analog Red Input

Pin 2 Analog Green Input

Pin 3 Analog Blue Input

Pin 4 Ground

Pin 5 Digital Ground

Pin 6 Analog Red Ground

Pin 7 Analog Green Ground

Pin 8 Analog Blue Ground

Pin 9 NC

Pin 10 Sync Ground

Pin 11 Ground

Pin 12 SDA (DDC Data)

Pin 13 H. Sync

Pin 14 V. Sync

Pin 15 SCL (DDC CLK)

10

VGA SUPPORT MODE

Resolution Horiz. Vert. Freq. (Hz) Polarity

31.46 70 +/-640 x 350

37.86 85 +/+

31.46 70 +/-720 x 350

37.86 85 +/-

31.46 70 -/+

37.93 85 -/+

640 x 400

24.82 56 -/+

31.46 70 -/+720 x 400

37.86 85 -/+

31.46 59.9 -/-

35.00 66.6 +/-

37.86 72.8 -/-

37.50 75.0 -/-

640 x 480

43.27 85.0 -/-

35.15 56.2 +/+

37.87 60.3 +/+

48.07 72.2 +/+

46.87 75.0 +/+

44.4 70.0 +/+

800 x 600

53.67 85.0 +/+

832 x 624 49.72 74.5 -/-

78.36 60.0 -/-

56.47 70.1 -/-

58.08 72.9

60.02 75.0 +/+

1024 x 768

68.68 84.9 +/+

54.90 60.0

64.19 70.2 +/+

67.50 75.0 -/-

76.30 80.0

1152 x 864

77.09 84.9

1280 x 1024 64.60 59.9 +/+

63.98 60.0 -/-

74.40 59.3

78.72 74.0
