I-Tech FCOP0430 Manual de usuario

i-Tech Company LLC

TOLL FREE: (888) 83-2418 • EMAIL: [email protected] • WEB: www.iTechLCD.com Modified: 10-20-21

4.3" Digital TFT-LCD Module

MODEL: FCOP0430

FCOP430-TR-v1 2021 03 18 V1.2

P.1

1. General Description

1.1 Features

■4.3” (480x272) Digital TFT LCD

■Aspect Ratio: 16:9

■Input Signal CVBS / VGA

■Maximum Support Resolution 1920x1080

■4 Wires Resistive Touch Panel

■5 Key Buttons Controls

■9 Language OSD Menu

■LED Backlight

■Single Operation Voltage +12V

1.2 Applications

■Industrial

■Medical Environment

■Instrument Display

■Kiosk

■Security

■Signage

■Office Electronics

■Home Application

■Educate Application

FCOP430-TR-v1 2021 03 18 V1.2

P.2

2. Contents

Contents Page

1. General Description…………………………………………………………………………………….……………. 1

1.1 Features 1

1.2 Applications 1

2. Contents……………….…………………………………………………………...…………………………….…. 2-3

3. Specifications………..………………………………………….………………..…………………………………… 4

4. Black Diagram………………………………………………………………….………………………………….…. 4

5. Order Information…..………………...……………………………………………………………………………… 5-6

5.1 Unit

5.2 Customized

5-6

5.3 Demo Board (Option) 6

6. Accessories (Option)……………………………………………………………………………….…………….…. 7

7. Operation manual / Connection……………………………………………………………………………………. 8

7.1 Driver Board Manual 8

8. Pin Description……………………………………………………………………………………………………….. 9-11

8.1 J105：Pin Assignment of Analog RGB Input ( D-Sub 15Pin) 9

8.2 J103: Pin Assignment of UART (Pitch 1.25mm 4Pin, Top Entry Type) 9

8.3 DC JACK: Pin Assignment of Power Input (Inside Diameter:2.1ψOutside Diameter:5.5ψSide Entry Type) 10

8.4 RCA: Pin Assignment of Video Input (RCA JACK Yellow, Side Entry Type) 10

8.5 J402：Pin Assignment of Touch USB (USBA-Female, Side Entry Type )(Option) 10

8.6 J404：Pin Assignment of Touch RS232 (D-SUB 9 FEMALE)(Option) 10

8.7 J102：Pin Assignment of Analog RGB Input (Pitch 2.0mm 14Pin, Side Entry Type) 11

8.8 J101：Pin Assignment of Signal Input (Pitch 1.25mm 8Pin, Side Entry Type) 11

8.9 J401：Pin Assignment of Touch (Pitch 2.0mm 4Pin, Side Entry Type) 11

9. Absolute Maximum Ratings………………………………………………………………………………...………... 12

9.1 Absolute Maximum Ratings 12

10. Recommended Operating Conditions……………………………………………………………………...………. 12

10.1 Electrical Characteristics 12

10.2 Support Display Mode Characteristics 12

11. 4W Resistance Touch Panel Characteristics………….………………………….………………………………… 13-16

11.1 Electrical Performance 13

11.2 Mechanical Performance 13

11.3 Durability Performance 13

11.4 Touch Panel Operation System Support 14

11.5 Touch Screen Integration Design Guide 15

11.6 Mechanical Design Notice For Touch Panel 16

12. Key Function by OSD………………………………………………………………………………………………. 17-21

FCOP430-TR-v1 2021 03 18 V1.2

P.3

12.1 Menu Operation 17-21

13. Dimension Information……………………………………………………………………………………………. 22

13.1Unit (FCOP430-TR-v1)

14. Appendix………………………………………………………………………………….………………………… 23-29

14.1 TFT-LCD Mechanical Specifications 23

14.2 TFT-LCD Optical Characteristics

14.3 Application Circuit

14.4 Application Circuit

14.5 (Option)

14.6 (Option)

14.7 Cable: 8P-8P 1.25mm L:100mm (Option)

14.8 Cable: 14P-14P 2.0mm L:110mm (Option) 29

FCOP430-TR-v1 2021 03 18 V1.2

P.4

3. Specifications

4. Block Diagram

LCD Input Signal

Panel Size 4.3” CVBS RCA JACK

Resolution (Pixels) 480x272 VGA D-Sub15

Color 16.2M Controls

Luminance without TP 500 cd/m2Key 5 Buttons

Luminance (RTP) 400 cd/m2Serial Remote Control UART / RS232 (Option)

Contrast Ratio 500 Environment

Viewing Angle 70(L) / 70(R) / 50(T) / 70(B) Without TP 4W RTP

LED Life Time (Min.) 20K hours Operating Temp. -20~+70℃-20~+70℃

Power Requirement Storage Temp. -20~+70℃-20~+70℃

Power Input (DC Jack 2.1ψ)+12VDC High Temperature &

High Humidity (Non-condensing) +60℃/ 90% +60℃/ 90%

Power Consumption 2.28

Touch Screen

Resistive Type USB / RS232 Interface

Resistive Type Support OS Windows / Linux / DOS / Mac / QNX

FCOP430-TR-v1 2021 03 18 V1.2

P.5

5. Order Information

5.1 Unit

Item FCOP430-TR-v1 Unit Remark

CVBS ◎

Power Connector

(Dc Jack/CON. 1.25mm 8Pin) Dc Jack

VGA

(D-Sub15/CON. 2.0mm 14Pin) D-Sub15

Touch Panel Type 4W Resistive

Touch Screen Interface USB

Serial Remote Control UART

Dimension 118.5 x 69 x 20.4 mm

Weight 135.5

g ±10%

Condition Standard

Note: 1.The assembling of panel and bracket is aimed for delivery, packaging and experiment. If the demand of shockproof and long-term fix, pls

have it into consideration of mechanism design.

FCOP430-TR-v1 2021 03 18 V1.2

P.6

5.2 Customized

Note: Special order condition will apply to non-standard items and pls. contact salespersons in iTech.

5.3 Demo Board (Option)

Demo Board

Part Number Remark

Cable: 8P-8P 1.25mm L:100mm

Function Item

Serial Remote Control RS232 (DB9)

External Key 5 keys

FCOP430-TR-v1 2021 03 18 V1.2

P.7

6. Accessories (Option)

Before you begin installing the KIT, please make sure that the following materials have been shipped:

A. AC to DC Adapter (L:1500mm, 100-240VAC 50-60Hz to +12VDC @ 3.3A)

B. Power Cord (L:1800mm, Plug Type B for USA)

C. Video Cable (L:1800mm)

D. VGA Cable (L:1800mm)

E. USB Cable (L:1800mm)

F. RS232 Cable (L:1800mm)

G. Touch Screen Driver CD Disk / User Manual

2021 03 18 V1.2

P.8

FCOP430-TR-v1

7 Operation manual / Connection

7.1 Driver Board Manual

FCOP430-TR-v1 2021 03 18 V1.2

P.9

8. Pin Description

8.1 J105

：

Pin Assignment of Analog RGB Input ( D-Sub 15Pin)

8.2 J103: Pin Assignment of UART (Pitch 1.25mm 4Pin, Top Entry Type)

※Connector Part No.: MS24014 (STM) [Same as 53398-0471 (MOLEX)] ;

※Matching Connector Part No.: P24014 (STM) [Same as 51021-0400 (MOLEX)].

Pin No. Symbol I/O Description Remark

1TX / RS232 TX (Option) O UART / RS232 (Option) Transmission Data

2RX / RS232 RX (Option) I UART / RS232 (Option) Receive Data

3 GND - Ground

4 +3.3Vdc O +3.3Vdc Output Voltage

Note: All Functions can be controlled by UART , About UART command list please contact iTech sales.

Pin No. Symbol I/O Description Remark

1RI+ I Analog Red Signal

2GI+ I Analog Green Signal

3 BI+ I Analog Blue Signal

4 NC - No Connection

5 GND - Ground

6 AGND - Analog Ground

7 AGND - Analog Ground

8 AGND - Analog Ground

9 NC - No Connection

10 NC - No Connection

11 NC - No Connection

12 NC - No Connection

13 HS_IN I TTL Horizontal sync

14 VS_IN I TTL Vertical sync

15 NC - No Connection
