I-Tech UltraView iAP26W Manual de usuario

UserManual

InnovativeLCDDisplaySolutions

26W/AP-26WT

26W/DP-26WT

26W/OP-26WT

ltraView

Jan 05

P.1

AP-26WT/ DP-26WT/ OP-26WTSeriesUserManual

1.TableofContent Page.1

2.Introduction

A)OverviewPage.2

B)FeaturesPage.2

C)Dimension DiagramsPage.3-5

D)TechnicalSpecificationsPage.6

3.Installation

A)Package ContentsPage.7

B)Cautiontothe userPage.7

C)Cleaning Page.7

D)PrecautionsPage.8-9

4.Using theSystem

A)Product ViewsPage.10-12

B)I/O OutletPage.13

C)Installation ProceduresPage.14

D)Setup Touchscreen(Optional)Page.15

i) ForWindows Page.15

ii) ForDOS Page.16-18

E)OSDSwitchPage.19

F)OSDControlPage.20-27

G)RemoteControl(Optional)Page.28

1. Tableof Content

Disclaimer

Thisinformation issubjecttochange withoutnotice.Theproducerofthismanual acceptsno

responsibilityfordamage orclaims,resulting frommisuseormisinterpretation.

Jan 05

P.2

Disclaimer

Thisinformation issubjecttochange withoutnotice.Theproducerofthismanual acceptsno

responsibilityfordamage orclaims,resulting frommisuseormisinterpretation

A.Overview

B.Features

2.Introduction

AP-26WT/ DP-26WT/ OP-26WTSeriesUserManual

ThisLCDmonitorincorporates26 coloractivematrixthin-film-

transistor(TFT)liquid

crystaldisplaytoprovide superiordisplayperformance.Amaximumresolution of

1,366 x768 isidealfordisplaying complexgraphics and high definition images.

Otheroutstanding designsthat enhancethisLCD monitor’sperformancearePlug &

PlaycompatibilityandOSD(OnScreen Display)controls.

High contrastcolorTFTLCD display,supportresolution up to1366 x768.

Advanced OSDcontrolforpicturequalityadjustment.

Slimand compact size

Wide Viewing Angle

Jan 05

P.3

AP-26WTseries

C.DimensionDiagrams

2.Introduction

Disclaimer

Thisinformation issubjecttochange withoutnotice.Theproducerofthismanual acceptsno

responsibilityfordamage orclaims,resulting frommisuseormisinterpretation.

AP-26WT/ DP-26WT/ OP-26WTSeriesUserManual

Jan 05

P.4

DP-26WTseries

C.DimensionDiagrams

2.Introduction

Disclaimer

Thisinformation issubjecttochange withoutnotice.Theproducerofthismanual acceptsno

responsibilityfordamage orclaims,resulting frommisuseormisinterpretation.

AP-26WT/ DP-26WT/ OP-26WTSeriesUserManual

Jan 05

P.5

OP-26WTseries

C.DimensionDiagrams

2.Introduction

Disclaimer

Thisinformation issubjecttochange withoutnotice.Theproducerofthismanual acceptsno

responsibilityfordamage orclaims,resulting frommisuseormisinterpretation.

AP-26WT/ DP-26WT/ OP-26WTSeriesUserManual

Jan 05

P.6

2.Introduction

Technical Specifications

Monitor

PanelSamSung26"Widescreen LCD Panel

DisplayType TFT LCD activematrixcolor

Resolutions1,366x768

ResponseTimeTr=10ms, Tf=6ms

Contrast Ratio1000:1typical

Brightness 500cd/m2typical

PixelPitch0.51075x0.51075mm

PanelColor16.7Mdisplaycolor

ViewingAngle85 / 85/85/ 85(L/ R/U/ D)

StorageTemp.-20°to65°C

OperatingTemp.0°to50°C

MTBF50,000hours(Min.)

PowerSupply PowerSupply110V-220VACInput

CableLengthof Power

Cord 182cm

Connectors

ScartVideo Scart21-pin(female)x1

RCAVideo CompositeVideo (female)x1

RCAAudioCompositeAudio(female)x2in/out

S-videoS-video(female)x1

ComponentVideo Component (Y/Pb/Pr) x1

VGAHDD D-sub 15 Pin(female)x1

DVI-DDVI-Dx1

RFTVAntenna Availableintelevisionmodelonly

Product

Dimension

AP Series: 670(W)x430(H)x80(D)mm

DPSeries:650(W)x410(H)x80(D)mm

OPSeries: 680(W)x440(H)x85(D)mm

Packing

DimensionAP /DP/ OPSeries: 876(W)x714(H)x338(D)mm

Net/ Gross

Weight

AP Series: 15 Kg/ 20 Kg

DPSeries:14Kg/19Kg

OPSeries: 14Kg/19 Kg

Disclaimer

Thisinformation issubjecttochange withoutnotice.Theproducerofthismanual acceptsno

responsibilityfordamage orclaims,resulting frommisuseormisinterpretation.

AP-26WT/ DP-26WT/ OP-26WTSeriesUserManual

Afterunpacking the carton,check and see ifthefollowingitemsareincluded in

good condition.Contactyoursupplierassoonaspossibleforreplacingthe

missing / damaged items.

26 TFT LCD monitor

VGACable(MaletoMale)

PowerCord

Mounting Bracket (AP Seriesonly)

UserManual

CD Disc

ToassurecontinuedFCC compliance,pleaseusegrounded powersupply

cordand the provided shielded video interfacecablewithbonded ferritecores.

If aBNC cableisgoingtobe used,useonlyashielded BNC (5)cable.Also,

TheFederalCommunicationsCommissionwarnstheuserthatany

unauthorized changesormodificationstothe unitifnot expresslyapprovedby

thepartyresponsibleforcompliancecouldvoidtheuser'sauthorityof

operatingthe equipment.

1.Gentlywipe screen withaclean camelhairlensbrush,orasoft,clean,

lint-free cloth.Thisremovesdustand otherparticlesthatcan scratchthe

screen.

2.Donotapplyexcessivepressuretothescreensurfacewhen wiping itclean

becausethismaydamage the LCD.

3.Donot pourorsprayanyliquiddirectlyontothescreen orcaseof the LCD

monitor.Chemicalcleanershavebeenreported todamage thescreen or

caseof theLCD monitor.

A.PackageContents

Jan 05

P.7

B.Caution totheusers

C.Cleaning

3.Installation

AP-26WT/ DP-26WT/ OP-26WTSeriesUserManual

Jan 05

P.8

Read allof theseinstructionsandsavethemforlateruse. Followallwarnings

and instructionson the product.

Product

Donot coverorblock the vent holesinthe case.

Donotinsertsharpobjectsorspillliquidintothe LCD monitorthrough

cabinet slots.Theymaycauseaccidentfire,electricshock orfailure.

Disconnect thepowerplug fromthe ACoutletif you willnot useit foran

indefiniteperiod oftime.

Donotattempttoservicethisproductyourself,asopening orremoving

coversmayexposeyou todangerousvoltage pointsorotherrisks.

Donottouchthe screendirectlywithyourfingers.You maydamage the

screen, and oilfromyourskinindifficult tomove.

Donot applypressuretoscreen. TheLCD isverydelicate.

D.Precautions

Power

1.Usethe type of powerindicatedon the markinglabel.

Plugs

1.Donotremoveanyof the prongsofthemonitor’sthree-pronged power

plug.

2.DisconnectthepowerplugfromtheACoutletunderfollowing

conditions

If the product willnot be used foran indefiniteperiod time.

Whenthe powercordorplug isdamaged orfrayed.

Iftheproductdoesnotoperatenormallywhentheoperating

instructionsarefollowed.

Adjustonlythosecontrolsthatarecoveredbytheoperating

instructions.Improperadjustment of othercontrolsmayresult in

damageandwilloftenrequireextensiveworkbyaqualified

technician torestoretheproduct tonormaloperation.

If the producthasbeen dropped orthe cabinet hasbeen damaged.

If the productexhibitsadistinctchangeinperformance,indicatinga

need forservice.

3.Installation

AP-26WT/ DP-26WT/ OP-26WTSeriesUserManual
