HyperX Cloud Core Headset

Find the language and latest documentation for your HyperX Cloud Core Headset here.

HyperX Cloud Core Headset Installation Guide

Simplied Chinese . . . . .

Traditional Chinese . . . .

. . . . . . . . . . . . For instructions in English

. . . . . . . . . . . . . . . . . . Para instrucciones en español

. . . . . . . . . Für Anleitungen in Deutsch

. . . . . . . . . . . . . . . . . . Pour des instructions en français

. . . . . . . . . . . . . . . . . . Per le istruzioni in italiano

. . . . . . . . . . . . Por as instruções em português

. . . . . . . . . . . . . . . . . . Instrukcje w jezyku polskim

. . . . . . . . . . . . . . . . . . Для инструкции на русском

. . . . . . . . . . . . . . . . . . Turkce talimatlar icin

. . . . . . . . . . . . . . . . . . Japanese

. . . . . . . . . . . . . . . . . . Thai

. . . . . . . . . . . . . . . . . . Vietnamese

. . . . . . . . . . . . . . . . . . Українська

Document No. 480KHX-HSCC001.A01

HyperX Cloud Core Headset

Page 1 of 9

HyperX Cloud Core Headset

Part Numbers:

KHX-HSCC-BK

KHX-HSCC-BK-BR

KHX-HSCC-BK-ER

KHX-HSCC-BK-FR

KHX-HSCC-BK-LR

Document No. 480KHX-HSCC001.A01

HyperX Cloud Core Headset

Page 2 of 9

Introduction

Optimised for pro-gaming, HyperX Cloud Core Headset (KHX-HSCC-BK-xx) is a high-quality communication

device that delivers superior sound, style and comfort. It uses an adjustable, soft-padded leatherette headband

and features a closed-cup design for enhanced bass reproduction and minimal sound leakage. The HyperX Cloud

Core headset is Hi-Fi capable, delivers a durable design for the most rugged gaming environments and is

compatible with tablets and smartphones for mobile use.

What’s Included:

•1 HyperX Cloud Core headset

•1 detachable microphone

(attached to headset)

•PC extension cable (female 4

pole 3.5mm jack to 3.5mm audio

and mic jacks)

Package Contents

Features:

•Hi-Fi capable 53mm drivers for supreme audio quality

•15-25 KHz frequency response (earphones)

•Detachable microphone (quick and easy to plug/unplug for music-only purposes)

•Solid aluminium construction for durability and stability

•Super-soft padded leatherette headband and leatherette padding on cups

•Closed-cup design for enhanced bass reproduction and minimal sound leakage

Document No. 480KHX-HSCC001.A01

HyperX Cloud Core Headset

Page 3 of 9

Technical Specifications:

Headset

•Transducer type: Dynamic 53mm

•Operating principle: Closed

•Frequency response: 15Hz-25KHz

•Nominal impedance: 60 ohm per system

•Nominal SPL: 98+/-3dB

•THD: < 2%

•Power handling capacity: 150mW

•Sound coupling to the ear: Circumaural

•Ambient noise attenuation: Approx. 20 dBa

•Headband pressure: 5 N

•Weight with microphone and cable: 350g

•Cable length and type: 1m mini 3.5mm jack plug (4 pole) + 2m stereo and mic extension cable

•Connection: Mini 3.5mm jack plug (4 pole)

Microphone

•Microphone transducer type: Condenser (back electret)

•Operating principle: Pressure gradient

•Polar pattern: Cardioid

•Power supply: AB powering

•Supply voltage: 2V

•Current consumption: Max 0.5 mA

•Nominal impedance: ≤2.2 k ohm

•Open circuit voltage at f = 1 kHz 20 mV / Pa

•Frequency response: 100 - 12,000 Hz (microphone)

•THD: 2% at f = 1 kHz

•Max. SPL: 105dB SPL (THD ≤1.0% at 1KHz)

•Microphone output: -39+/-3dB

•Dimensions: 6*5mm

•Length mic boom: 150MM (including gooseneck)

•Capsule diameter: 6mm

Document No. 480KHX-HSCC001.A01

HyperX Cloud Core Headset

Page 4 of 9

Overview

A. Leatherette headband w/ HyperX

logo

B. Aluminium arm to adjust

headband

C. Attached cable w/ 3.5mm input

jack

D. Detachable microphone with

adjustable arm and condenser

E. Mini 3.5mm jack plug (4 pole)

F. PC extension cable

Document No. 480KHX-HSCC001.A01

HyperX Cloud Core Headset

Page 5 of 9

Usage (PC extension cable)

To connect your headset directly to your computer (or other device) that has both a headset

jack and a microphone jack. Connect the headset’s 3.5mm jack to the female jack on the PC

extension cable. The extension cable audio jack, which has green stripes, plugs into the port

signified by a green input or earphones symbol . The extension cable microphone jack,

which has pink stripes, plugs into the port signified by a pink input or a microphone symbol .

Using with PC extension cable

Document No. 480KHX-HSCC001.A01

HyperX Cloud Core Headset

Page 6 of 9

Usage (PlayStation®4)

To use the HyperX Cloud Core headset with PlayStation 4 (PS4™), connect the 3.5mm jack on

the headset directly to the PS4 game controller and follow these steps:

1. Turn on your PS4 game console.

2. Navigate to the Settings menu and select it.

3. Highlight the ‘Devices’ menu option and select it.

4. Scroll down to ‘Audio Devices’ and select it.

5. Choose ‘Output to Headphones’ and select ‘All Audio.’

Using with PS4

Document No. 480KHX-HSCC001.A01

HyperX Cloud Core Headset

Page 7 of 9

Usage (Xbox®One)

To use the HyperX Cloud Core headset with Xbox One, you will need the Xbox One adapter

(sold separately) that plugs into the Xbox One controller (pictured below). Connect the 3.5mm

jack on the headset directly to the Xbox One adapter.

Using with Xbox One

Document No. 480KHX-HSCC001.A01

HyperX Cloud Core Headset

Page 8 of 9

Usage (Wii U)

To use the HyperX Cloud Core headset with Wii U®, connect the 3.5mm jack on the headset

directly to the Wii U gamepad controller.

Using with Wii U™

Document No. 480KHX-HSCC001.A01

HyperX Cloud Core Headset

Page 9 of 9

Usage with Mobile Device (Phone or Tablet)

To use the HyperX Cloud Core headset with a mobile device, plug the 3.5mm jack directly into

the headset jack on your phone or tablet.

Using with mobile device (phone or tablet)
