Huawei WA8021V5 Manual de usuario

WA8021V5

Quick Start

Issue 09

Date 2021-09-16

HUAWEI TECHNOLOGIES CO., LTD.

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and

the customer. All or part of the products, services and features described in this document may not be

within the purchase scope or the usage scope. Unless otherwise specied in the contract, all statements,

information, and recommendations in this document are provided "AS IS" without warranties, guarantees

or representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every eort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: https://www.huawei.com

Email: [email protected]

Contents

1 Product Overview.................................................................................................................... 1

2 Working as a Router...............................................................................................................3

3 Working as a Wi-Fi repeater.................................................................................................7

4 Network Management.........................................................................................................12

5 Parameter................................................................................................................................13

6 FAQs..........................................................................................................................................14

WA8021V5

Quick Start Contents

1 Product Overview

The WA8021V5 is a home edge ONT that provides gigabit dual-band Wi-Fi and

gigabit network ports.

NO TE

● This product is used indoors only.

● The product appearance shown in this document is for your reference only. The actual

product appearance prevails.

WA8021V5

Quick Start 1 Product Overview

Description of ports and buttons

WA8021V5 Description

Network port Adaptive to the LAN port or WAN port:

Connects to the gateway as a WAN port, or connects to

devices such as computers and IP STBs as a LAN port.

Power port Connects to a power adapter.

Pairing button When the edge ONT has detected a device that can be

paired, press the pairing button on the edge ONT and

release it. The indicator blinks quickly. The device that

can be paired connects to the Wi-Fi of the edge ONT.

When connecting to other device in WPS mode, press the

pairing button on the edge ONT for 3 seconds. If the

indicator blinks quickly, the device is performing WPS

pairing.

Reset button Press and hold the Reset button of the device for more

than 2 seconds using a needle, and release the button

after the indicator turns o. After the device restarts and

the red indicator turns on, the factory settings are

restored.

Description of Indicator

Status Description

White: steady on Internet access is available.

Red: steady on Internet access is unavailable.

1. The edge ONT is being powered on.

2. The edge ONT is not connected to the upstream

gateway.

Red: Blinking slowly

(once per second)

The edge ONT has detected a device that can be paired.

Red: Blinking quickly

(twice per second)

The edge ONT is being paired with Huawei gateway in

one-click mode.

The edge ONT is performing WPS pairing.

WA8021V5

Quick Start 1 Product Overview

2 Working as a Router

If there is no router at home, it is recommended that the WA8021V5 be used as a

router.

NO TE

After being connected to a Huawei gateway of a certain model using a network cable, an

edge ONT automatically adapts itself as a Wi-Fi repeater. The Wi-Fi name and password

are automatically synchronized from the Huawei gateway. You can access the Internet

instantly without conguring the Wi-Fi name and password.

1. Connect cables.

2. Connect a phone or PC to the Wi-Fi of the edge ONT (no password). For the

Wi-Fi name, see the SSID on the device nameplate.

WA8021V5

Quick Start 2 Working as a Router

NO TE

You can also use a network cable to connect a PC to the edge ONT, and then set the

Internet access mode on the PC.

3. Open the browser. The conguration page is automatically displayed. Click

Start, the edge ONT will automatically detect your Internet access mode.

NO TE

1. Some mobile phones automatically display the conguration page following the

Wi-Fi connection page.

2. If the conguration page is not automatically displayed, enter the IP address in the

address box of a browser. (For details about the IP address, see the product

nameplate.)

3. If the device detects that the Internet access mode is dial-up, you need to enter the

broadband account and password. If you forget the broadband account and

password, contact your ISP to retrieve the account and password.

4. On the Service Provider Remote Management Platform page, the Server

address eld is automatically populated after you select an Area. You can

also manually enter a Server address. Then select the privacy statement, and

click Apply to enable the function of service provider remote management.

WA8021V5

Quick Start 2 Working as a Router

NO TE

● This step applies only to general products. Skip this step if it is not displayed on the

product page.

● Select an option as instructed by your service provider. If you do not select an

option or select an incorrect option, the remote software upgrade function will be

unavailable. You can also click Skip, and congure this option on the Service

Provider Remote Management Platform page later.

5. Set a new Wi-Fi SSID and management password of the edge ONT. You can

use the Wi-Fi password as the device management password. Click Next.

After the conguration is complete, reconnect to Wi-Fi.

WA8021V5

Quick Start 2 Working as a Router

NO TE

1. If band steering is enabled, 2.4 GHz Wi-Fi and 5 GHz Wi-Fi are both supported,

and the edge ONT automatically selects a faster Wi-Fi frequency band for you.

2. You can connect devices such as PCs to other network ports of the edge ONT using

network cables to access the Internet.

WA8021V5

Quick Start 2 Working as a Router

3 Working as a Wi-Fi repeater

If you need to extend the existing Wi-Fi, you can use the WA8021V5 as a Wi-Fi

repeater to expand Wi-Fi coverage.

NO TICE

Three-level Wi-Fi cascading is not allowed on the WA8021V5 network. A

maximum of two-level Wi-Fi cascading is supported.

Method 1: One-Click Pairing (Used Together with a Huawei Gateway*)

*Applicable to connection with Huawei gateways with the latest software version

(for details, contact the service provider).

1. Place the edge ONT near a Huawei gateway (within 2 m) and connect the

power cable of edge ONT to a socket.

2. After the edge ONT is powered on, the Huawei gateway can discover edge

ONT, and the WPS indicator of the gateway blinks slowly.

3. Press the WPS button of the gateway once. The WPS indicator and edge ONT

indicator change to blink quickly.

4. Wait until the edge ONT indicator turns steady white, which indicates that the

pairing is successful.

WA8021V5

Quick Start 3 Working as a Wi-Fi repeater
