Quick Start Guide
31500BCF_02
Product overview
Power button LAN port
LAN/WAN port Landline phone port
Power input Ambient light strip
Hi/WPS button Wi-Fi® indicator
4G signal indicator 5G signal indicator
SIM card slot Reset button
Setup
1. Make sure you use the correct SIM card.
mini-SIM (2FF) micro-SIM (3FF) nano-SIM (4FF)
2. Open the SIM card cover.
3. Insert the SIM card gently into the SIM card slot
in the direction shown in the figure below until it
clicks. Then close the SIM card cover.
• To remove the SIM card, gently press the
SIM card in until it clicks. The card will
automatically pop out.
• Do not insert or remove a SIM card when
the router is running, as this may aect
performance or damage the SIM card.
4. Connect the power adapter to the router.
The indicators will turn on when the router has
successfully connected to a network.
5G signal
indicator
Green: Strong.
Yellow: Moderate.
Red: Weak.
4G signal
indicator
Green: Strong.
Yellow: Moderate.
Red: Weak.
• If both the 5G signal indicator and 4G signal
indicator are o, it indicates there is no
network connection. Please refer to the FAQs
in this guide.
Connecting to your router’s Wi-Fi
network
Once the router has connected to a mobile data
network, you can connect your computer or mobile
phone to the router’s Wi-Fi network to access the
Internet. Please refer to the label on the bottom of
the router for the default Wi-Fi network name (Wi-Fi
Name) and password (Wi-Fi Password).
• When the Wi-Fi indicator is steady on, Wi-Fi
is enabled. To enable or disable Wi-Fi, refer
to the router’s webbased management page.
• Ensure that you promptly change the Wi-
Fi network name and password on the
web-based management page to prevent
unauthorized access to your Wi-Fi network.
Once you have changed the password, you
will need to reconnect to the router’s Wi-Fi
network.
Managing your router
You can manage the router using the web-based
management page. Please refer to the label on the
bottom of the router for the default IP address,
password and so on.
More information can be found in the web-based
management page.
• Ensure that you promptly change the
default login password for the web-based
management page to prevent unauthorized
users from changing the router’s settings.
• You can also manage your router using the
HUAWEI SmartHome App. Scan the QR code
below to download.
Optional configurations
The features described in this section are for
reference purposes only. Your router may not
support all of these
features.
Connecting multiple devices
You can connect a computer, or landline phone to
the router to access the Internet, make telephone
calls, and more.
Accessing the Internet through an Ethernet port You
can connect the router to a wall-mounted Ethernet
port using an Ethernet cable to connect to the
Internet.
Configure the relevant settings on the web-based
management page before connecting to the Internet
through an Ethernet port. For details, please contact
your carrier.
FAQs
How do I restore factory settings?
When the router is turned on, press the Reset
button for approximately 3 seconds using a pointed
object until the Ambient light strip starts to blink.
Restoring factory settings will restore the settings
to the default. You can reconfigure them after the
router is restored.
What should I do if I forgot the Wi-Fi password or
the login password for the web-based management
page?
Restore the router to its factory settings and then
use the default Wi-Fi password and login password
to try again.
What should I do if the 5G signal indicator and 4G
signal indicator are o or an Internet connection
cannot be established?
1. Check if the SIM card is inserted. Refer to the
Setup section for the right size of SIM card and
the right way to insert it into the slot.
2. If the issue persists, restore the router to factory
settings and try again.
3. Contact your carrier to check if your SIM card
is out of service. If it’s a new card, check if it has
been activated.
What should I do if the Internet speed is slow?
1. Check the 5G signal indicator and 4G signal
indicator on the router. If both of them are red,
adjust the router’s direction or move it close to a
window to improve signal reception.
2. If your device is connected to the router over
Wi-Fi, adjust your device’s position to receive
better signal.
3. Switch to Wi-Fi 5 GHz if it is supported by your
device.
4. Restart the router and your device, and try again.
5. Check if you have reached your data trac limit
for the month. If so, your carrier may limit your
Internet speed.
How can I connect to the router using WPS(Wi-Fi
Protected Setup)?
To connect a WPS-enabled device to your router
using the Hi/WPS button:
1. Press and hold the Hi/WPS button on the router
for at least 1 second and then release, the Wi-Fi
indicator starts to blink.
2. Enable WPS on your device within 2 minutes to
connect to the router’s Wi-Fi network.
Why can’t I access the router’s web-based
management page?
1. Ensure that your computer is connected to the
router through an Ethernet cable or Wi-Fi.
2. Ensure that your computer is set to obtain an IP
address and DNS server address automatically.
3. Restart your browser, or try using another browser.
4. If the problem persists, restore the router to its
factory settings.
Why is the content displayed on the web-based
management page not up to date?
Depending on your browser’s cache, the content for
your device on the web-based management page
may not be up to date. Manually clear your browser’s
cache (for example, open your browser and choose
Internet Options > General > Browsing history >
Delete.) and re-launch the web-based management
page.
Does my router support 5 GHz Wi-Fi? How do I
connect to its 5 GHz Wi-Fi?
1. Yes. Your router supports 5 GHz Wi-Fi, which is
faster and less sensitive to interference. However,
it does not penetrate walls as well as 2.4 GHz Wi-
Fi and can only be used on devices that support 5
GHz Wi-Fi.
2. If you have enabled the feature that prioritizes 5
GHz on your router, the 2.4 GHz and 5 GHz networks
will share the same network name and you will be
automatically connected to the faster network. If
this feature is disabled, two Wi-Fi network names
will be displayed. Connect to the Wi-Fi network
ending with “_5G”. You can manage this feature in
your router’s web-based management page.
If you are experiencing any other issues with the
router:
1. Restart the router.
2. Restore the router to its factory settings.
3. Contact your carrier.
Legal Notice
Copyright © Huawei Technologies Co., Ltd. 2019.
All rights reserved.
No part of this manual may be reproduced or
transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
and its aliates (“Huawei”). The product described
in this manual may include copyrighted software
of Huawei and possible licensors. Customers shall
not in any manner reproduce, distribute, modify,
decompile, disassemble, decrypt, extract, reverse
engineer, lease, assign, or sublicense the said
software, unless such restrictions are prohibited
by applicable laws or such actions are approved by
respective copyright holders.
Trademarks and Permissions
, and are trademarks or
registered trademarks of Huawei Technologies Co.,
Ltd. LTE is a trademark of ETSI. Wi-Fi®, the Wi-Fi
CERTIFIED logo, and the Wi-Fi logo are trademarks
of Wi-Fi Alliance.
Other trademarks, product, service and company
names mentioned may be the property of their
respective owners.
Notice
Some features of the product and its accessories
described herein rely on the software installed,
capacities and settings of local network, and
therefore may not be activated or may be limited
by local network operators or network service
providers.
Thus, the descriptions herein may not exactly match
the product or its accessories which you purchase.
Huawei reserves the right to change or modify any
information or specifications contained in this
manual without prior notice and without any liability.
DISCLAIMER
ALL CONTENTS OF THIS MANUAL ARE PROVIDED
“AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS,
NO WARRANTIES OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE MADE
IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL. TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW, IN NO
EVENT SHALL HUAWEI BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, OR LOSS OF PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL SAVINGS OR
ANTICIPATED SAVINGS REGARDLESS OF WHETHER
SUCH LOSSES ARE FORSEEABLE OR NOT. THE
MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT
APPLY TO LIABILITY FOR PERSONAL INJURY TO
THE EXTENT APPLICABLE LAW PROHIBITS SUCH A
LIMITATION) OF HUAWEI ARISING FROM THE USE OF
THE PRODUCT DESCRIBED IN THIS MANUAL SHALL
BE LIMITED TO THE AMOUNT PAID BY CUSTOMERS
FOR THE PURCHASE OF THIS PRODUCT.
Import and Export Regulations
Customers shall comply with all applicable export
or import laws and regulations and be responsible
to obtain all necessary governmental permits and
licenses in order to export, reexport or import the
product mentioned in this manual including the
software and technical data therein.
Privacy Policy
To better understand how we use and protect your
personal information, please read the Privacy Policy
at http:// consumer.huawei.com/privacy-policy.
Software Update
By continuing to use this device, you indicate that
you have read and agree to the following content:
In order to provide better service, this device will
automatically obtain software update information
from Huawei or your carrier after connecting to
the Internet. This process will use mobile data, and
requires access to your device’s unique identifier
(IMEI/SN) and the service provider network ID (PLMN)
to check whether your device needs to be updated.
In addition, this device supports the automatic
downloading and installation of important updates
from Huawei or your carrier in cases of emergency.
This function is enabled by default. To disable this
function, please log in to the product management
website and make the corresponding changes in the
settings menu.
Safety information
This section contains important information about
the operation of your device. It also contains
information about how to use the device safely. Read
this information carefully before using your device.
Electronic device
Do not use your device if using the device is
prohibited. Do not use the device if doing so causes
danger or interference with other electronic devices.
Interference with medical equipment
• Follow rules and regulations set forth by hospitals
and health care facilities. Do not use your device
where prohibited.
• Some wireless devices may aect the performance
of hearing aids or pacemakers. Consult your service
provider for more information.
• Pacemaker manufacturers recommend that a
minimum distance of 15 cm be maintained
between a device and a pacemaker to prevent
potential interference with the pacemaker. If
using a pacemaker, hold the device on the side
opposite the pacemaker and do not carry the
device in your front pocket.
Areas with flammables and explosives
• Do not use the device where flammables or
explosives are stored (in a gas station, oil depot,
or chemical plant, for example). Using your device
in these environments increases the risk of
explosion or fire. In addition, follow
• Do not store or transport the device in containers
with flammable liquids, gases, or explosives.
Operating environment
• Avoid dusty, damp, or dirty environments. Avoid
magnetic fields. Using the device in these
environments may result in circuit malfunctions.
• Before connecting and disconnecting cables, stop
using the device and disconnect it from the power
supply. Ensure that your hands are dry during
operation.
• Place the device on a stable surface.
• Keep the device away from electronic appliances
that generate strong magnetic or electric fields,
such as a microwave oven or refrigerator.
• During thunderstorms, power o your device and
remove all cables connected to it to protect against
lightning strikes.
• Do not use your device during thunderstorms to
protect your device against any danger caused by
lightning.
• Ideal operating temperatures are 0 °C to 40 °C. Ideal
storage temperatures are -20 °C to +70 °C. Extreme
heat or cold may damage your device or accessories.
• Keep the device and accessories in a well-ventilated
and cool area away from direct sunlight. Do not
enclose or cover your device with towels or other
objects. Do not place the device in a container with
poor heat dissipation, such as a box or bag.
• To protect your device or accessories from fire or
electrical shock hazards, avoid rain and moisture.
• Keep the device away from sources of heat and fire,
such as a heater, microwave oven, stove, water heater,
radiator, or candle.
• Do not place any object, such as a candle or a water
container, on the device. If any foreign object or liquid
Otros manuales para H112
1
Tabla de contenidos
Otros manuales de Enrutador de red de Huawei
Huawei
Huawei AR1200 Series Manual de usuario
Huawei
Huawei AR1200 Series Manual de instrucciones
Huawei
Huawei WS7001 Manual de usuario
Huawei
Huawei S6700 Series Manual de usuario
Huawei
Huawei ADSL2+Broadband Router Aolynk DR814 Manual de usuario
Huawei
Huawei NE20E-S Series Guía
Huawei
Huawei V200R001 Manual de usuario
Huawei
Huawei LTE CPE B593 Manual de usuario
Huawei
Huawei Enterprise S2700 Series Manual de usuario
Huawei
Huawei Mobile wifi e5330 Manual de usuario
Huawei
Huawei AR150/200 Series Manual de usuario
Huawei
Huawei AR1200-S Series Manual de usuario
Huawei
Huawei B628-265 Manual de usuario
Huawei
Huawei 31010GEV Manual de usuario
Huawei
Huawei B315 Series Manual de usuario
Huawei
Huawei H112-370 Manual de usuario
Huawei
Huawei B310s Manual de usuario
Huawei
Huawei EchoLife EG8041V5 Manual de usuario
Huawei
Huawei WS5200 Especificaciones técnicas
Huawei
Huawei NetEngine 8000 F Instrucciones de instalación
Manuales populares de Enrutador de red de otras marcas
NETGEAR
NETGEAR FS526T - Switch Manual de usuario
Korenix
Korenix JetNet 5710G Series Manual de usuario
Automated Logic
Automated Logic ZN551 Manual del propietario
Cisco
Cisco ASR 1000 Series Manual del operador
EnGenius
EnGenius ESR-9710 Manual de usuario
Cisco
Cisco 805 Series Instrucciones de funcionamiento y seguridad
